Textbook: Chemistry – Class 12 (Balbharati, official free PDF) · pages 138–164
Oxygen keeps us alive, the ozone layer shields us from UV light, sulfuric acid is the most-produced industrial chemical, chlorine disinfects our water, and neon glows in shop signs. This chapter studies the p-block elements of group 16 (O, S, Se, Te, Po), group 17 (F, Cl, Br, I, At) and group 18 (He to Rn): their configurations, trends in size, ionisation enthalpy, electron gain enthalpy and electronegativity, anomalous oxygen and fluorine, allotropy of sulfur, oxoacids of sulfur and chlorine, O₂, O₃, SO₂, H₂SO₄ (contact process), Cl₂ and HCl, interhalogen compounds and xenon compounds. Every exercise question is answered below.
Group 16 (ns²np⁴) shows −2, +2, +4 and +6 states; oxygen is limited mainly to −2 because it is very electronegative and has no d orbitals. Group 17 (ns²np⁵) shows −1; Cl, Br and I also show +1, +3, +5, +7, but F shows only −1. Group 18 (ns²np⁶, He 1s²) are noble gases with very high ionisation enthalpies.
Down each group atomic radius increases while ionisation enthalpy and electronegativity decrease. Chlorine (not fluorine) has the most negative electron gain enthalpy because the small F atom suffers strong electron–electron repulsion. Hydride acidity rises H₂O < H₂S < H₂Se < H₂Te, while thermal stability falls.
Sulfur exists as rhombic (α) and monoclinic (β) S₈, interconverting at 369 K. Important compounds: O₂ (paramagnetic), O₃ (bent, 117°, strong oxidant), SO₂ (bent, reducing agent and bleach), H₂SO₄ (made by the contact process with V₂O₅; strong acid, dehydrating and oxidising agent).
Chlorine is made from MnO₂ + HCl or by electrolysis of brine; it bleaches by oxidation, reacts with metals, NH₃ and alkalis. HCl is prepared from NaCl and conc. H₂SO₄. Chlorine oxoacids HOCl, HClO₂, HClO₃, HClO₄ grow stronger as the oxidation state of Cl rises.
Interhalogens XX′ₙ (n = 1, 3, 5, 7) form between halogens of different size; the larger halogen is central and F is never central. Xenon forms XeF₂ (linear), XeF₄ (square planar), XeF₆ (distorted octahedral), XeO₃ (pyramidal) and XeOF₄ (square pyramidal).
Get a ✓ Verified tutor for “Elements of Groups 16, 17 and 18” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Arrange H₂O, H₂S, H₂Se, H₂Te by (a) acid strength (b) thermal stability and explain.
Answer: Acidity rises and stability falls from H₂O to H₂Te
How many kilograms of H₂SO₄ can be made, in principle, from 64 kg of sulfur by the contact process?
Answer: 196 kg (theoretical yield)
Use VSEPR to predict the shape of XeF₄.
Answer: Square planar; Xe in +4 state
| Substance / process | Reaction or fact | Note |
|---|---|---|
| Lab O₂ | 2KClO₃ → 2KCl + 3O₂ | heat, MnO₂ catalyst |
| Ozone oxidises PbS | PbS + 4O₃ → PbSO₄ + 4O₂ | black to white |
| Ozone depletion by NO | NO + O₃ → NO₂ + O₂ | also CFCs |
| Lab SO₂ | Na₂SO₃ + H₂SO₄ → Na₂SO₄ + H₂O + SO₂ | dilute acid |
| Contact process key step | 2SO₂ + O₂ ⇌ 2SO₃ | V₂O₅, ≈ 720 K, 2 bar |
| Oleum route | SO₃ + H₂SO₄ → H₂S₂O₇; H₂S₂O₇ + H₂O → 2H₂SO₄ | avoids acid mist |
| Oxidising conc. H₂SO₄ | Cu + 2H₂SO₄ → CuSO₄ + SO₂ + 2H₂O | hot, concentrated |
| Cl₂ with excess NH₃ | 8NH₃ + 3Cl₂ → 6NH₄Cl + N₂ | excess Cl₂ gives NCl₃ |
| Lab HCl | NaCl + H₂SO₄ → NaHSO₄ + HCl | ≈ 420 K |
| XeO₃ formation | XeF₆ + 3H₂O → XeO₃ + 6HF | XeO₃ pyramidal |
| Xenon shapes | XeF₂ linear, XeF₄ square planar, XeF₆ distorted octahedral, XeOF₄ square pyramidal | lone pairs 3, 2, 1, 1 |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Select the appropriate answer. (i) Highest electron gain enthalpy: F/Cl/Br/I. (ii) Acidity of group 16 hydrides. (iii) Does not show +4: O/S/Se/Te. (iv) HI heated with conc. H₂SO₄ gives: HIO₃/KIO₃/I₂/KI. (v) Ozone layer is depleted by: NO/NO₂/NO₃/N₂O₅. (vi) Liquid at room temperature: HIO₃/HBr/HCl/HF. (vii) Oxidation state of S in pyrosulfurous acid.
Answer: (i) B (ii) C (iii) A (iv) C (v) A (vi) D (vii) B
2. 1. (viii) Stability order of XX′ interhalogens. (ix) BrCl + water gives. (x) Cl₂ + excess F₂ gives. (xi) Never the central atom. (xii) One lone pair: IF₃/ICl/IF₅/ClF₃. (xiii) Correct shape: [I₃]⁻ bent / BrF₅ trigonal bipyramid / ClF₃ trigonal planar / [BrF₄]⁻ square planar. (xiv) Maximum atoms in an interhalogen.
Answer: (viii) C (ix) D (x) B. ClF₃ (xi) D. F (xii) C. IF₅ (xiii) D (xiv) D. 8
3. 2. (i) Thermal stability order of group 16 hydrides. (ii) O.S. of Te in TeO₃. (iii) Two ozone-depleting gases. (iv) Two uses of ClO₂. (v) Bromine on magnesium. (vi) Allotropes of selenium. (vii) O.S. of S in H₂SO₄. (viii) pK_a HCl −7.0, HI −10.0: stronger acid? (ix) Reducing property of ozone. (x) Conc. H₂SO₄ with sugar. (xi) Two uses of chlorine.
Answer: Te +6; S +6; HI is the stronger acid
4. 2. (xii) Complete: 1. ICl₃ + H₂O; 2. I₂ + KClO₃; 3. BrCl + H₂O; 4. Cl₂ + ClF₃; 5. H₂C=CH₂ + ICl; 6. XeF₄ + SiO₂; 7. XeF₆ + H₂O; 8. XeOF₄ + H₂O.
Answer: See the eight balanced equations
5. 2. (xiii) Match: XeOF₂, XeO₂F₂, XeO₃F₂, XeO₂F₄ with names. (xiv) Oxidation state of Xe in XeOF₄, XeO₃, XeF₆, XeF₄, XeF₂.
Answer: +6, +6, +6, +4, +2
6. 3. (i) First IE of S, Cl, Ar = 1000, 1256, 1520 kJ mol⁻¹ — explain. (ii) Acidic character H₂O → H₂Te. (iii) Lab O₂ from KClO₃. (iv) Ozone with (a) PbS (b) NO. (v)/4(ii) Oxidising property of conc. H₂SO₄. (vi) Structure of SO₂. (vii) Why F shows only −1.
Answer: See explanations
7. 3. (viii) Chlorine with (a) Fe (b) excess NH₃. (ix) HCl from NaCl. (x) Structures of XeF₆, XeO₃, XeOF₄, XeF₂. (xi) Interhalogens with examples. (xii) HCl with (a) NH₃ (b) Na₂CO₃. (xiii) Two uses of HCl. (xiv) Oxoacids of chlorine.
Answer: See reactions and structures
8. 3. (xv) What happens when (a) Cl₂ reacts with F₂ in equal volume at 437 K (b) Br₂ reacts with excess F₂? (xvi) Preparation of XeF₂, XeF₄, XeF₆. (xvii) Preparation of XeO₃ and XeOF₄. (xviii) Uses of neon and argon. (xix) Structure and uses of ozone. (xx) Trends in atomic radius, ionisation enthalpy, electronegativity in group 16.
Answer: See answers
9. 4. (i) Rhombic vs monoclinic sulfur. (iii) Lab preparation of SO₂ from sodium sulfite; two physical properties. (iv) Manufacture of H₂SO₄ by the contact process.
Answer: Contact process: SO₂ → SO₃ (V₂O₅) → oleum → H₂SO₄
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Highest electron gain enthalpy (most negative) is shown by…
Answer: D. Small F suffers electron repulsion.
2. Strongest acid among the group 16 hydrides is…
Answer: D. Weakest E–H bond.
3. Element that does not show +4 state:
Answer: D. Oxygen has no d orbitals.
4. Which allotrope of sulfur is stable at room temperature?
Answer: D. Stable below 369 K.
5. Ozone is prepared by…
Answer: C. In an ozoniser.
6. Bond angle in SO₂ is about…
Answer: B. Bent, sp².
7. In the contact process SO₃ is absorbed in…
Answer: B. Forms oleum.
8. Conc. H₂SO₄ turns sugar black because it is…
Answer: B. Removes H₂O, leaving carbon.
9. HI heated with conc. H₂SO₄ gives…
Answer: D. H₂SO₄ oxidises I⁻ to I₂.
10. Which oxoacid of chlorine is strongest?
Answer: B. Highest oxidation state of Cl.
11. Shape of ClF₃ is…
Answer: C. 3 bond pairs + 2 lone pairs.
12. Which has exactly one lone pair on the central atom?
Answer: D. IF₅ is square pyramidal.
13. XeF₆ on complete hydrolysis gives…
Answer: D. XeF₆ + 3H₂O → XeO₃ + 6HF.
14. Shape of XeF₂ is…
Answer: D. Three lone pairs equatorial.
15. Gas mixed with O₂ for deep-sea divers is…
Answer: B. Low solubility in blood.
