Textbook: Mathematics – Class 9 (Balbharati, official free PDF) · pages 73–75
This problem set brings the whole chapter together: properties of parallelograms, rectangles, rhombuses and squares, tests for a parallelogram, trapeziums and the midpoint theorem. Most questions are a short calculation with Pythagoras' theorem or angle facts, and the last three are proofs that combine several ideas.
Parallelogram: opposite sides and angles equal, adjacent angles add to 180°, diagonals bisect each other.
Rectangle: equal diagonals; rhombus: perpendicular diagonals; square: both.
Square diagonal d and side s: d = s√2. Rectangle diagonal: d² = l² + b².
Rhombus side² = (half of one diagonal)² + (half of the other)².
Midpoint theorem and its converse help prove facts about trapeziums, such as median = ½(sum of parallel sides).
Get a ✓ Verified tutor for “Problem Set 5 – Quadrilaterals Revision” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A rectangle is 9 cm by 12 cm and a square has diagonal 10 cm. Find the rectangle's diagonal and the square's side.
Answer: 15 cm and 5√2 cm
Diagonals of rectangle ABCD meet at O and ∠AOB = 70°. Find ∠OAB.
Answer: ∠OAB = 55°
Segments KL and MN are parallel and both 6 cm, with K opposite M and L opposite N (no crossing). What can you say about KM and LN?
Answer: KM ∥ LN and KM = LN
A trapezium has parallel sides 5 cm and 13 cm. Find its median.
Answer: 9 cm
| What | Formula | Symbols |
|---|---|---|
| Rectangle diagonal | d² = l² + b² | 7, 24 → 25 |
| Square | d = s√2, perimeter = 4s | 12√2 → s = 12, P = 48 |
| Rhombus side | s² = (d₁/2)² + (d₂/2)² | 10, 24 → 26 |
| Parallelogram perimeter | P = 2(a + b) | 2(24 + 32) = 112 |
| Trapezium median | PQ = ½(AB + DC) | ½(5 + 13) = 9 |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option: (i) a quadrilateral with all pairs of adjacent sides congruent is a … (A) rectangle (B) parallelogram (C) trapezium (D) rhombus. (ii) Diagonal of a square is 12√2 cm; its perimeter is … (A) 24 cm (B) 24√2 cm (C) 48 cm (D) 48√2 cm. (iii) Opposite angles of a rhombus are (2x)° and (3x − 40)°; x = … (A) 100° (B) 80° (C) 160° (D) 40°.
Answer: (i) D, (ii) C, (iii) D
2. 2. Adjacent sides of a rectangle are 7 cm and 24 cm. Find its diagonal.
Answer: 25 cm
3. 3. The diagonal of a square is 13 cm. Find its side.
Answer: 6.5√2 cm
4. 4. Adjacent sides of a parallelogram are in the ratio 3 : 4 and its perimeter is 112 cm. Find each side.
Answer: 24 cm, 32 cm, 24 cm, 32 cm
5. 5. Diagonals PR and QS of rhombus PQRS are 20 cm and 48 cm. Find PQ.
Answer: PQ = 26 cm
6. 6. Diagonals of rectangle PQRS meet at M. If ∠QMR = 50°, find ∠MPS.
Answer: ∠MPS = 65°
7. 7. In figure 5.42, seg AB ∥ seg PQ, AB ≅ PQ, seg AC ∥ seg PR and AC ≅ PR. Prove that BC ∥ QR and BC ≅ QR.
Answer: BC ∥ QR and BC ≅ QR
8. 8. In figure 5.43, □ABCD is a trapezium with AB ∥ DC (AB the shorter top side). P and Q are the midpoints of AD and BC. Prove that PQ ∥ AB and PQ = ½(AB + DC).
Answer: PQ ∥ AB and PQ = ½(AB + DC)
9. 9. In figure 5.44, □ABCD is a trapezium with AB ∥ DC (DC the shorter top side). M and N are the midpoints of diagonals AC and DB. Prove that MN ∥ AB.
Answer: MN ∥ AB
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A quadrilateral with all pairs of adjacent sides congruent is a…
Answer: A. All four sides equal.
2. Diagonal of a square is 12√2 cm. Perimeter =
Answer: A. Side 12.
3. Opposite angles of a rhombus are (2x)° and (3x − 40)°. x =
Answer: A. They are equal.
4. Rectangle 7 cm by 24 cm. Diagonal =
Answer: D. 49 + 576 = 625.
5. Square diagonal 13 cm. Side =
Answer: B. 13/√2.
6. Parallelogram sides in ratio 3 : 4, perimeter 112 cm. Longer side =
Answer: D. k = 8.
7. Rhombus diagonals 20 cm and 48 cm. Side =
Answer: D. 10² + 24² = 676.
8. Rectangle PQRS, diagonals meet at M, ∠QMR = 50°. ∠MPS =
Answer: C. (180 − 50)/2.
9. Trapezium with parallel sides 8 cm and 14 cm. Median =
Answer: D. ½(22).
10. If AB ∥ PQ and AB = PQ, then AP and BQ are…
Answer: D. □ABQP is a parallelogram.
11. In the trapezium median proof, AQ is extended to meet…
Answer: B. To build a big triangle.
12. Which is a Pythagorean triple?
Answer: A. 49 + 576 = 625.
13. A rhombus is a square when…
Answer: A. Then all angles are 90°.
14. MN joins midpoints of the diagonals of trapezium ABCD (AB ∥ DC). MN is parallel to…
Answer: B. Proved with the midpoint theorem.
15. ∠QMR = 50° in rectangle PQRS. ∠PMS =
Answer: A. Vertically opposite.
