Textbook: Biology – Class 11 (Balbharati, official free PDF) · pages 138–150
Every bite of food and every breath of oxygen traces back to photosynthesis. Learn the chloroplast and its pigments, absorption and action spectra, the experiments of Van Niel, Hill and Ruben, the light reaction (PS-II, PS-I, photolysis, cyclic and non-cyclic photophosphorylation, chemiosmosis), the Calvin cycle with its ATP and NADPH count, photorespiration, the C4 and CAM pathways, factors affecting the rate and Blackman's law, with answers to all the exercise questions.
Photosynthesis makes glucose from CO₂ and water using light trapped by chlorophyll: 6CO₂ + 12H₂O → C₆H₁₂O₆ + 6O₂ + 6H₂O. It happens in chloroplasts — pigments and the light reaction are on the thylakoids (grana), and the carbon-fixing enzymes are in the stroma.
Chlorophyll a and b (porphyrin head + phytol tail) absorb mainly blue-violet and red light; carotenoids absorb blue-violet, pass energy to chlorophyll a and protect chlorophyll from photo-oxidation. The action spectrum closely follows the absorption spectrum.
Van Niel, Hill and Ruben–Kamen showed that the O₂ released comes from water. In the light reaction PS-II (P680) splits water, electrons pass through an electron transport chain to PS-I (P700) and then to NADP⁺; the proton gradient drives ATP synthase. Non-cyclic flow gives ATP, NADPH and O₂; cyclic flow (PS-I only) gives only ATP.
In the Calvin (C3) cycle in the stroma, Rubisco joins CO₂ to RuBP, giving 3-PGA, which is reduced to 3-PGAL, and RuBP is regenerated. One glucose needs 6 turns, 18 ATP and 12 NADPH. In hot, bright, low-CO₂ conditions Rubisco takes up O₂ instead, causing wasteful photorespiration.
C4 plants (maize, sugarcane) first fix CO₂ into 4-carbon OAA with PEP carboxylase in mesophyll cells and release it in Kranz bundle-sheath cells, avoiding photorespiration at a cost of 30 ATP per glucose. CAM plants (Opuntia, Kalanchoe) open stomata at night and fix CO₂ into malate, then run the Calvin cycle by day. Light, CO₂, temperature and water affect the rate, and Blackman's law says the scarcest factor sets it.
Get a ✓ Verified tutor for “Photosynthesis” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Distinguish between absorption spectrum and action spectrum.
Answer: The absorption spectrum shows which colours a pigment takes in; the action spectrum shows which colours actually drive photosynthesis — and they overlap.
Why do we see many gas bubbles in a pond during the day but few at night?
Answer: The bubbles are oxygen from the light-driven splitting of water by aquatic plants.
What is the advantage of having many pigment molecules in a photocentre?
Answer: More light of more wavelengths is captured and fed to P680/P700, so the light reaction runs faster and more efficiently; carotenoids also protect the centre.
Differentiate cyclic and non-cyclic photophosphorylation.
Answer: Cyclic = PS-I, closed electron loop, ATP only. Non-cyclic = both photosystems, one-way flow from water to NADP⁺, giving ATP, NADPH and O₂.
How many ATP and NADPH are needed to fix 6 CO₂ into one glucose in the Calvin cycle?
Answer: 18 ATP and 12 NADPH (3 ATP + 2 NADPH per CO₂).
How can you tell whether a plant is C3 or C4?
Answer: Kranz anatomy and OAA as the first product mean C4; ordinary mesophyll and PGA as the first product mean C3.
A plant has enough light to use only 10 mg CO₂ per hour. What happens as CO₂ supply is raised from 5 to 15 mg per hour?
Answer: The rate rises until 10 mg CO₂/h and then levels off, because light becomes the limiting factor.
| Feature | C3 / C4 | CAM |
|---|---|---|
| Examples | C3: wheat, rice, most plants / C4: maize, sugarcane, sorghum | Opuntia, Kalanchoe, Aloe |
| First CO₂ acceptor | C3: RuBP / C4: PEP | PEP (at night) |
| First stable product | C3: 3-PGA (3C) / C4: OAA (4C) | OAA, stored as malate |
| Carboxylating enzyme | C3: Rubisco / C4: PEPCase + Rubisco | PEPCase at night, Rubisco by day |
| Leaf anatomy | C3: no Kranz / C4: Kranz anatomy | No Kranz; succulent cells with large vacuoles |
| Separation of steps | C4: in space (mesophyll vs bundle sheath) | In time (night vs day) |
| Photorespiration | C3: high / C4: negligible | Very low |
| ATP per glucose | C3: 18 / C4: 30 | More than C3 |
| Stomata | C3 and C4: open by day | Open at night (scotoactive) |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option (Q1 A–F): (A) A cell lacking chloroplasts does not … (B) Energy goes from light to dark reaction by … (C) Which is wrong about photorespiration? (D) Non-cyclic differs from cyclic photophosphorylation in that it … (E) Fixing 6 CO₂ into one glucose needs … (F) In maize and wheat the first stable products are …
Answer: (A) b — liberate oxygen; O₂ comes only from photolysis in chloroplasts, while CO₂ release, water use and sugar use happen in every cell. (B) c — ATP (with NADPH) carries light energy into the stroma. (C) c — 'it is characteristic of C4 plants' is wrong; photorespiration is a C3 feature (the book prints two options labelled 'c'). (D) d — both: it evolves O₂ and forms assimilatory power (NADPH). (E) b — 18 ATP and 12 NADPH₂. (F) c — OAA in maize (C4) and 3-PGA in wheat (C3). Note: the book says 'in bundle sheath cells', but OAA is actually formed in the mesophyll cells of maize.
2. Choose the correct option (Q1 G–K): (G) Head and tail of chlorophyll … (H) Photo-oxidation of water releases … (I) Fixing one CO₂ needs … (J) In high O₂, RuBP carboxylase converts RuBP to … (K) Order of electron transport from PS-II to PS-I …
Answer: (G) c — porphyrin head and phytol tail (the book misprints them as 'prophyrin and phyrol'). (H) c — protons, electrons and oxygen. (I) b — 3 ATP + 2 NADPH₂. (J) d — PGA and phosphoglycolate (here the enzyme acts as an oxygenase). (K) c — PQ, cytochrome, PC and then FeS; strictly, Fe-S proteins lie after PS-I on the way to ferredoxin, so the transport from PS-II to PS-I is PQ → cytochrome b₆f → PC.
3. Describe the light-dependent steps of photosynthesis. How are they linked to the dark reactions? (2A)
Answer: Antenna pigments absorb light and pass the energy to reaction centres. P680 of PS-II is excited and loses electrons; it refills them by splitting water (2H₂O → 4H⁺ + O₂ + 4e⁻), releasing O₂. The electrons pass along plastoquinone, the cytochrome b₆f complex and plastocyanin to PS-I, and H⁺ is pumped into the thylakoid. P700 of PS-I, excited again, sends electrons via Fe-S and ferredoxin to NADP⁺ reductase, forming NADPH. H⁺ flowing out through ATP synthase makes ATP (non-cyclic photophosphorylation); PS-I alone can also cycle electrons to make extra ATP. Link: the ATP and NADPH diffuse into the stroma and power the reduction of PGA and the regeneration of RuBP in the Calvin cycle; the cycle returns ADP, Pi and NADP⁺ to the thylakoids.
4. Distinguish between: (a) respiration and photorespiration (b) absorption spectrum and action spectrum (c) cyclic and non-cyclic photophosphorylation. (2B)
Answer: (a) Respiration happens in all living cells day and night, in cytoplasm and mitochondria; it breaks glucose to CO₂ and H₂O and yields ATP. Photorespiration happens only in green cells in light, in chloroplast, peroxisome and mitochondrion; its substrate is RuBP/glycolate, it uses ATP instead of making it, and it wastes fixed carbon. (b) Absorption spectrum = light absorbed by a pigment versus wavelength (on a pigment solution); action spectrum = rate of photosynthesis versus wavelength (on a living plant); the two curves overlap with peaks in blue and red. (c) Cyclic: PS-I only, electrons return to P700, no photolysis, no O₂, no NADPH, only ATP. Non-cyclic: PS-II + PS-I, electrons go from water to NADP⁺ and do not return, water is split, O₂, NADPH and ATP are formed.
5. (C) Steps common to C3 and C4 photosynthesis? (D) Are the dark-reaction enzymes inside or outside the thylakoids? (E) Name the three phases of the Calvin cycle and their significance.
Answer: (C) Both have the same light reaction (photolysis, both photophosphorylations) and both run the Calvin cycle with Rubisco — carboxylation of RuBP, reduction of PGA to PGAL and regeneration of RuBP. C4 plants simply add a preliminary CO₂-concentrating step with PEP carboxylase. (D) Outside — in the stroma, which surrounds the thylakoids. (E) Carboxylation: Rubisco fixes CO₂ onto RuBP giving 3-PGA, bringing inorganic carbon into organic form. Reduction: ATP and NADPH convert PGA into PGAL, the energy-rich sugar phosphate that builds glucose. Regeneration: 10 of 12 PGAL rebuild 6 RuBP using 6 ATP, so the acceptor is never used up and the cycle continues.
6. (F) Why are plants that use more than 18 ATP per glucose favoured in tropical regions? (K) Why does the C3 pathway run only in bundle-sheath cells of C4 plants? (L) What if C4 plants had no Kranz anatomy? (M) Why does Rubisco prefer carboxylation in C4 plants? (P) Few bundle-sheath cells, yet C4 plants are highly productive — why? (Q) Functional significance of Kranz anatomy?
Answer: (F) In hot, bright tropics stomata close often, leaf CO₂ falls and O₂ rises, so C3 plants lose much carbon in photorespiration. C4 plants spend 12 extra ATP (30 in all) to pump CO₂, but light energy is plentiful there and they avoid photorespiration, so their net yield is higher. (K) Rubisco and the Calvin enzymes are present in bundle-sheath chloroplasts, and it is only there that malate releases CO₂ at high concentration; mesophyll cells carry PEPCase instead. (L) There would be no separate gas-tight compartment to concentrate CO₂ around Rubisco; Rubisco would meet high O₂, photorespiration would rise, and the plant would behave like a C3 plant. (M) Malate decarboxylation keeps the CO₂ level in bundle-sheath cells very high, so CO₂ wins the competition with O₂ at Rubisco's active site. (P) Every bundle-sheath cell works at full speed because CO₂ is pumped to it continuously, photorespiration loss is negligible, and CO₂ fixation goes on even when stomata are partly closed. (Q) It spatially separates initial CO₂ fixation (mesophyll, PEPCase) from the Calvin cycle (bundle sheath, Rubisco), creating a CO₂-rich zone that suppresses photorespiration and lets sugars reach the phloem quickly.
7. (G) Advantage of more than one pigment in a photocentre? (H) Why does chlorophyll appear green in transmitted and red in reflected light? (N) What if plants had no accessory pigments?
Answer: (G) Many antenna pigments absorb a wider range of wavelengths over a larger area and funnel energy to one reaction centre, so light capture is much more efficient. (H) The book's question has the two words swapped: a chlorophyll extract looks green in transmitted light (green is not absorbed and passes through) and red in reflected light (absorbed energy is re-emitted as red fluorescence). In a leaf the excited electrons are caught by acceptors instead of being lost as fluorescence, which is how light energy is used for photosynthesis. (N) Light of wavelengths that chlorophyll a absorbs poorly (green-blue, 450–500 nm) would be wasted, the rate would fall, and chlorophyll would be damaged by photo-oxidation in strong light since carotenoids protect it.
8. (I) Why is photosynthesis the most important process in the biosphere? (J) Why is photolysis of water linked with non-cyclic photophosphorylation? (O) How can you identify a C3 or C4 plant?
Answer: (I) It is the only major route by which solar energy enters living systems: it makes the food on which all food chains depend, releases the O₂ used in aerobic respiration and in forming the ozone layer, removes CO₂ from the air, and produced the fossil fuels we burn. (J) In non-cyclic flow, electrons leaving P680 go to PS-I and NADP⁺ and never come back. PS-II can work again only if the lost electrons are replaced, and water is the electron donor; splitting it releases O₂. In cyclic flow electrons return to P700, so no water splitting is needed. (O) Look at a leaf section: Kranz anatomy (large chloroplast-rich bundle-sheath cells) means C4. Feed ¹⁴CO₂: the first labelled product is OAA in C4 and 3-PGA in C3. C4 plants also show negligible photorespiration and keep fixing CO₂ at very low CO₂ levels.
9. Q3. Correct the given pathway and name it. (The book's diagram shows OAA placed in the bundle-sheath cell receiving CO₂, malic acid and PEP in the mesophyll, and CO₂ going to the C3 pathway.)
Answer: Corrected: atmospheric CO₂ is fixed by PEP into OAA inside the mesophyll cell (not in the bundle sheath); OAA becomes malic acid, which travels into the bundle-sheath cell, releases CO₂ to the C3 pathway and leaves pyruvic acid; pyruvic acid returns to the mesophyll to regenerate PEP. This is the C4 or Hatch–Slack pathway.
10. Q4. Is something wrong in the given Z-scheme? (In the book's diagram, water feeds PS-I, and electrons go from PS-I through the cytochrome complex to PS-II and then to NADP reductase.) Correct it so that photosynthesis can work.
Answer: Yes — the two photosystems are swapped. Correct order: H₂O → 2H⁺ + ½O₂ + 2e⁻ → PS-II (P680) → primary acceptor → plastoquinone → cytochrome complex (ADP + Pi → ATP) → plastocyanin → PS-I (P700) → primary acceptor → ferredoxin → NADP reductase → NADP⁺ + H⁺ → NADPH. Only with water feeding PS-II and PS-I feeding NADP⁺ will the scheme produce O₂, ATP and NADPH.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A cell without chloroplasts cannot…
Answer: A. O₂ comes from photolysis inside chloroplasts.
2. Energy passes from the light reaction to the dark reaction through…
Answer: A. ATP (and NADPH) carry it to the stroma.
3. Photolysis of water releases…
Answer: B. 4H₂O → 2H₂O + O₂ + 4H⁺ + 4e⁻.
4. Non-cyclic differs from cyclic photophosphorylation because it…
Answer: B. Both photosystems work and water is split.
5. To fix one CO₂ in the Calvin cycle the plant uses…
Answer: C. 18 ATP and 12 NADPH ÷ 6.
6. Correct sequence of carriers from PS-II to PS-I is…
Answer: C. Fe-S and ferredoxin come after PS-I.
7. When O₂ is high, Rubisco converts RuBP into…
Answer: D. This starts photorespiration.
8. Which statement about photorespiration is WRONG?
Answer: D. C4 plants show almost none.
9. In maize and wheat the first stable products of CO₂ fixation are…
Answer: C. Maize is C4, wheat is C3.
10. The enzyme that fixes CO₂ in C4 mesophyll cells is…
Answer: D. PEPCase does not bind O₂.
11. Kranz anatomy is seen in…
Answer: C. Sugarcane is a C4 plant.
12. CAM plants fix CO₂ into malic acid…
Answer: D. Separation is in time.
13. Reaction centre of photosystem I is…
Answer: C. Maximum absorption at 700 nm.
14. Optimum temperature for photosynthesis in most plants is about…
Answer: C. Above it enzymes slow down.
15. The law of limiting factors was given by…
Answer: B. F. F. Blackman, 1905.
