Textbook: Biology – Class 11 (Balbharati, official free PDF) · pages 85–96
Cut a stem, a root or a leaf thinly and look under the microscope — you see a precise pattern of tissues. This chapter covers meristems (by origin, position and function), simple permanent tissues (parenchyma, collenchyma, sclerenchyma), complex tissues (xylem and phloem), the three tissue systems and types of vascular bundles, secondary growth by vascular and cork cambium, wood and bark, and the internal structure of dicot and monocot roots, stems and leaves — with answers to every exercise.
A tissue is a group of cells with a common origin and function. Meristematic tissues are young, dense, thin-walled dividing cells; permanent tissues have stopped dividing and taken up fixed size, shape and role.
Meristems are classified by origin (promeristem, primary, secondary), position (apical, intercalary, lateral) and function (protoderm, procambium, ground meristem).
Simple permanent tissues: parenchyma (living, thin-walled, storage and photosynthesis), collenchyma (living, corners thickened, flexible support) and sclerenchyma (dead, lignified fibres and sclereids). Complex tissues: xylem (tracheids, vessels, xylem parenchyma, fibres — water conduction) and phloem (sieve tubes, companion cells, phloem parenchyma, fibres — food conduction).
Three tissue systems — epidermal, ground and vascular. Vascular bundles may be radial (roots), conjoint collateral open (dicot stems) or closed (monocots), bicollateral (cucurbits) or concentric. Vascular cambium and cork cambium cause secondary growth, forming annual rings, heartwood, sapwood, periderm, bark and lenticels.
Dicot roots have 2–6 radial bundles with exarch xylem; monocot roots are polyarch with a large pith. Dicot stems have a ring of open bundles; monocot stems have scattered closed bundles. Dorsiventral dicot leaves have palisade and spongy mesophyll; isobilateral monocot leaves have uniform mesophyll and stomata on both surfaces.
Get a ✓ Verified tutor for “Plant Tissues and Anatomy” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Based on position, how many types of meristem are there?
Answer: Three — apical, intercalary and lateral.
What is peculiar about the sclerenchyma cell wall?
Answer: A thick, uniformly lignified, pitted wall around a dead cell.
Differentiate between xylem and phloem functioning.
Answer: Xylem conducts water upward through dead tubes; phloem conducts food in either direction through living cells.
A slide shows scattered vascular bundles. The student says 'monocot stem'; the teacher says 'fern rachis'. What did the student see on looking again?
Answer: The bundles were concentric (hadrocentric), not collateral, so it was a fern rachis.
A wooden stopper has lain in the lab for many years without rotting. Why?
Answer: Its tissue is durable heartwood (or suberised cork) that resists water and decay organisms.
Why are vascular bundles of the dicot stem described as conjoint, collateral and open?
Answer: Because of how xylem and phloem are combined, placed and separated by cambium.
A student sees many stomata on the upper surface of a leaf section and thinks the slide is upside down. The teacher says it is correct. Explain.
Answer: The leaf was isobilateral (amphistomatic) or a floating leaf, so stomata on the upper side are normal.
| Organ / feature | Dicot | Monocot |
|---|---|---|
| Root – xylem groups | 2–6 (diarch to hexarch), exarch | More than 6 (polyarch), exarch |
| Root – pith | Small or absent | Large, well developed |
| Stem – hypodermis | Collenchyma | Sclerenchyma |
| Stem – vascular bundles | In a ring; conjoint, collateral, open | Scattered; conjoint, collateral, closed, with bundle sheath |
| Stem – pith and secondary growth | Pith present; secondary growth present | No distinct pith; no secondary growth |
| Leaf – type and stomata | Dorsiventral; stomata mostly on lower surface | Isobilateral; stomata on both surfaces |
| Leaf – mesophyll | Palisade and spongy | Undifferentiated |
| Leaf – venation | Reticulate | Parallel |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option: (A) based on position, meristems are of … types; (B) cambium is also called …; (C) collenchyma is a … tissue; (D) … is a complex permanent tissue; (E) mesophyll is present in …
Answer: (A) c. Three. (B) c. Lateral meristem. (C) a. Living. (D) d. Xylem. (E) c. Leaf.
2. (A) A fresh section showed few green and mostly colourless cells; dipping it in a pink solution made it clearer. What is the magic? (B) A stem with many scattered bundles cannot grow in girth. Why? (C) In a stem, one vascular tissue was wrapped around the other. Describe technically.
Answer: (A) The pink solution is a stain such as safranin. It colours lignified and suberised walls (xylem, sclerenchyma, endodermis) pink-red, giving contrast with unstained parenchyma, so the tissue pattern becomes visible. (B) Scattered bundles mean a monocot stem; its bundles are closed — no cambium between xylem and phloem — and there is no interfascicular cambium, so no cambial ring forms and secondary growth is impossible. (C) A concentric vascular bundle — hadrocentric (amphicribral) if xylem is in the centre surrounded by phloem, leptocentric (amphivasal) if phloem is in the centre surrounded by xylem; such bundles are closed.
3. (D) One cut log had growth rings and another did not — how does seasonal growth explain this? (E) Why do cut trees in Kashmir show distinct rings not seen in Maharashtra? (F) Why did the student agree that the slide with scattered bundles was a fern rachis?
Answer: (D) Rings form when cambium activity changes with the seasons: wide, light spring wood alternates with narrow, dark autumn wood, marking each year. A log without rings is from a plant where cambium works evenly all year (tropical, uniform climate) or a monocot such as a palm with no regular secondary growth. (E) Kashmir is temperate with a warm growing season and a cold winter, so the contrast between early and late wood is sharp; much of Maharashtra is tropical with a smaller seasonal difference, so rings are faint or indistinct. (F) On closer view the bundles were concentric (hadrocentric — xylem surrounded by phloem), typical of ferns, and not the collateral closed bundles with sclerenchyma sheaths found in monocot stems.
4. (G) A wooden stopper has not rotted for years — why? (H) Many stomata were seen on the upper surface of a leaf, and the teacher said the slide was placed correctly — explain.
Answer: (G) It is made of heartwood (or cork). Heartwood is dead, non-conducting, with tyloses blocking vessels and impregnated with resins, gums, oils and tannins that are toxic to fungi, bacteria and insects; cork cells are suberised and waterproof. So decay organisms cannot attack it. (H) The leaf was isobilateral (monocot, e.g. grass or maize), which has stomata on both surfaces, or a floating leaf (water lily) with stomata only on the upper side; so stomata on the upper surface are normal.
5. Write short notes: (A) structure of stomata; (B) secondary growth; (C) peculiarity of the sclerenchyma cell wall.
Answer: (A) A stoma is a minute pore in the epidermis bounded by two guard cells — kidney-shaped in dicots, dumb-bell-shaped in grasses — with chloroplasts and thick inner walls and thin outer walls; around them lie subsidiary cells; together they form the stomatal apparatus; a sub-stomatal chamber lies beneath. Changes in guard-cell turgor open or close the pore, regulating gas exchange and transpiration. (B) In dicots and gymnosperms, intrafascicular cambium joins interfascicular cambium (from medullary rays) to form a cambial ring that produces secondary xylem inward and secondary phloem outward; seasonal activity forms annual rings, heartwood and sapwood. Phellogen arising in the outer cortex produces cork outside and phelloderm inside (periderm); lenticels allow aeration. Roots show similar growth from conjunctive tissue and pericycle. (C) The wall is very thick and uniformly lignified, leaving a narrow lumen; it is hard, rigid and impermeable; it bears simple pits (narrow and oblique in fibres, deep and branched in sclereids); the cell is dead at maturity.
6. Differentiate: (A) vascular bundle of monocot and dicot; (B) internal differences between dicot and monocot leaves (stomata, intercellular spaces, venation, vascular bundles, mesophyll).
Answer: (A) Dicot stem bundle: few, in a ring, open (with cambium), no bundle sheath of sclerenchyma (a cap of hard bast), no lysigenous cavity, phloem parenchyma present, secondary growth possible. Monocot stem bundle: many, scattered, closed, surrounded by a sclerenchymatous bundle sheath, lysigenous protoxylem cavity, phloem parenchyma absent, no secondary growth. (B) Stomata — dicot: mostly on the lower surface (hypostomatic); monocot: on both surfaces (amphistomatic). Intercellular spaces — dicot: large in spongy tissue, small in palisade; monocot: small and uniform. Venation — dicot: reticulate; monocot: parallel. Vascular bundles — dicot: different sizes, with parenchymatous bundle sheath, closed; monocot: similar-sized parallel bundles, sheath often of thick cells, closed. Mesophyll — dicot: palisade and spongy; monocot: undifferentiated; monocot also has bulliform cells.
7. Draw neat labelled diagrams (describe in words): T.S. of dicot leaf, T.S. of monocot root, T.S. of dicot stem.
Answer: Dicot leaf T.S.: cuticle → upper epidermis → palisade (1–2 rows of columnar cells) → spongy parenchyma with air spaces → lower epidermis with stomata and sub-stomatal chambers → cuticle; midrib/vein with bundle sheath, xylem towards upper side and phloem towards lower. Monocot root T.S.: epiblema with root hairs → wide parenchymatous cortex → endodermis with Casparian strips and passage cells → pericycle → many (more than six) alternating radial xylem (exarch, protoxylem outside, metaxylem inside) and phloem groups → large central pith. Dicot stem T.S.: cuticle and epidermis with multicellular hairs → collenchymatous hypodermis → parenchymatous general cortex → endodermis (starch sheath) → pericycle with hard bast patches → ring of conjoint, collateral, open bundles (phloem, cambium, endarch xylem) separated by medullary rays → large parenchymatous pith.
8. Identify and label the diagrams: shoot and root tip (meristems); stoma in surface view; (a) T.S. with root hairs and radial bundles; (b) green cells with chloroplasts; (c) stoma with subsidiary cells; (d) leaf section.
Answer: Shoot tip: shoot apical meristem at the tip, intercalary meristems at the nodes, lateral meristems along the sides; root tip: root apical meristem just behind the root cap. Stoma: guard cells (kidney-shaped, with chloroplasts and nucleus), stomatal pore, thick inner wall, surrounding epidermal/subsidiary cells. (a) T.S. of a (dicot) root — root hairs, epiblema, cortex, endodermis, pericycle, radial exarch xylem and phloem. (b) Chlorenchyma (parenchyma with chloroplasts and intercellular spaces) — photosynthesis and storage. (c) Stomatal apparatus in surface view — guard cells, pore, subsidiary cells. (d) T.S. of a dorsiventral dicot leaf — cuticle, upper epidermis, palisade, spongy mesophyll, vascular bundle with bundle sheath, lower epidermis, stoma.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Based on position, meristems are of … types.
Answer: D. Apical, intercalary, lateral.
2. Cambium is also called…
Answer: A. It lies along the sides.
3. Collenchyma is a … tissue.
Answer: A. It keeps its protoplasm.
4. A complex permanent tissue is…
Answer: A. Many cell types.
5. Mesophyll is present in…
Answer: A. Palisade and spongy tissue.
6. Protoxylem towards the centre is called…
Answer: B. Seen in stems.
7. Sieve tubes at maturity lack…
Answer: C. Companion cells control them.
8. Tracheids form about 95% of the wood of…
Answer: D. Vessels are absent in most.
9. Bicollateral bundles occur in…
Answer: A. Cucurbitaceae.
10. Casparian strips are made of…
Answer: C. On endodermal radial walls.
11. A monocot root is…
Answer: D. More than six xylem groups.
12. Heartwood is durable because it…
Answer: D. Extractives resist decay.
13. Phellem is formed by…
Answer: A. Cork cambium.
14. Distinct annual rings are expected in trees of…
Answer: C. Sharp seasonal change.
15. Stomata on both surfaces and no palisade layer indicate a…
Answer: C. Isobilateral leaf.
