Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 123–134
Meet the first three p-block families — boron (group 13), carbon (group 14) and nitrogen (group 15). Learn their electron configurations, how size, ionisation enthalpy and metallic character change down each group, the inert pair effect, oxides, halides, catenation, allotropes of carbon and phosphorus, the shapes of BCl₃, Al₂Cl₆, B₂H₆, H₃BO₃, SiO₂, HNO₃ and H₃PO₄, and the chemistry of borax, silicones and ammonia — with answers to every exercise.
Groups 13, 14 and 15 are p-block families whose outer shells are ns² np¹, ns² np² and ns² np³. Group 13: B, Al, Ga, In, Tl. Group 14: C, Si, Ge, Sn, Pb. Group 15: N, P, As, Sb, Bi. None of them occurs as free single atoms; they appear in compounds, as molecules such as N₂ and P₄, or as giant covalent solids such as diamond.
Going down each group, atomic and ionic radii grow, ionisation enthalpy generally falls and metallic character rises: each family runs from a non-metal or metalloid at the top to a metal at the bottom. Ga is slightly smaller than Al because its ten 3d electrons shield the nucleus poorly.
The highest (group) oxidation state equals the number of valence electrons: +3, +4 and +5. A state two units lower (+1, +2, +3) becomes more stable for heavy members because of the inert pair effect — the ns² pair is reluctant to take part in bonding. So Tl⁺ beats Tl³⁺ and PbCl₂ beats PbCl₄.
Oxides change from acidic at the top through amphoteric to basic at the bottom. Group 13 forms EX₃, group 14 forms EX₄ (and EX₂ for heavy members), group 15 forms EX₃ and EX₅ — except nitrogen, which has no d orbitals and cannot make NX₅. Carbon shows the strongest catenation because the C–C bond is the strongest.
Carbon exists as diamond, graphite, fullerenes, nanotubes and graphene; phosphorus as reactive white P₄ and polymeric red phosphorus. Borax, silicones and ammonia are key compounds: borax gives the bead test and the green-flame borate test, silicones are water-repellent heat-stable polymers, and ammonia (Haber process) is a base and a strong complexing agent.
Get a ✓ Verified tutor for “Elements of Group 13, 14 and 15” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Write the outer configuration and the group number of an element whose atomic number is 51, and say which family it belongs to.
Answer: Antimony (Sb): [Kr]4d¹⁰5s²5p³, group 15, nitrogen family.
Arrange the group 15 elements in increasing order of first ionisation enthalpy using N 1402, P 1012, As 947, Sb 834, Bi 703 kJ mol⁻¹, and explain the trend.
Answer: Bi < Sb < As < P < N; ionisation enthalpy decreases down group 15 as atomic size increases.
Find the oxidation state of the central atom in SnCl₂, PbO₂, NF₃ and Tl₂O₃, and say which one is favoured by the inert pair effect.
Answer: Sn +2, Pb +4, N +3, Tl +3. SnCl₂ shows the lower state that the inert pair effect stabilises; PbO₂ and Tl₂O₃ hold the less stable group state.
How many grams of Al₂O₃ form when 5.4 g of aluminium burns completely in oxygen? (Al = 27, O = 16)
Answer: 10.2 g of Al₂O₃.
Using bond enthalpies, estimate the energy needed to break all the C–C bonds in one mole of n-hexane (CH₃(CH₂)₄CH₃) and compare it with a six-atom Si chain.
Answer: About 1740 kJ for the C₆ chain versus 1485 kJ for Si₆ — carbon chains are much more stable, which is why carbon catenates best.
Count the electrons around boron in BCl₃ and decide whether it can accept a lone pair from NH₃.
Answer: Boron has 6 electrons (incomplete octet), so BCl₃ is a Lewis acid and forms the adduct Cl₃B–NH₃.
How many litres of NH₃ (at the same temperature and pressure) can be made from 15 L of H₂ with excess N₂, and what volume of N₂ is used?
Answer: 10 L of NH₃ using 5 L of N₂.
| Feature | Trend or fact | Example / note |
|---|---|---|
| Outer configuration | ns² np¹ / ns² np² / ns² np³ | groups 13 / 14 / 15 |
| Group oxidation state | +3 / +4 / +5 | lower states +1 / +2 / +3 rise in stability down the group |
| Atomic radius | increases down the group | exception: Ga (135 pm) < Al (143 pm) |
| Ionisation enthalpy | generally decreases down | Al 577 < Si 786 < P 1012 kJ mol⁻¹ across period 3 |
| Metallic character | increases down | B, C, N non-metal/metalloid → Tl, Pb, Bi metals |
| Oxides | acidic → amphoteric → basic | B₂O₃ acidic, Al₂O₃ amphoteric, Tl₂O₃ basic |
| Halides | EX₃ / EX₄ (+EX₂) / EX₃ and EX₅ | no NX₅ (N lacks d orbitals); Tl gives TlX |
| Catenation | C >> Si > Ge ≈ Sn | follows bond enthalpy 348 > 297 > 260 > 240 kJ mol⁻¹ |
| Carbon allotropes | diamond, graphite, fullerene, nanotube, graphene | graphite is the most stable |
| Haber process | N₂ + 3H₂ ⇌ 2NH₃ | 200 atm, ~700 K, Fe oxide + K₂O, Al₂O₃ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option: (A) Not an allotrope of carbon — bucky ball / diamond / graphite / emerald. (B) … is inorganic graphite — borax / diborane / boron nitride / colemanite. (C) Haber's process is used to prepare — HNO₃ / NH₃ / NH₂CONH₂ / NH₄OH. (D) Thallium shows different oxidation states because — inert pair effect / inner transition element / it is a metal / high electronegativity. (E) Most prominent inert pair effect — C / Si / Ge / Pb.
Answer: (A) d. emerald — it is a beryllium aluminium silicate, not carbon. (B) c. boron nitride — its layers resemble graphite. (C) b. NH₃ — direct combination of N₂ and H₂ over an iron catalyst. (D) a. inert pair effect — the 6s² pair stays out of bonding, so +1 is stable besides +3. (E) d. Pb — the heaviest member feels the effect most.
2. Identify the group 14 element that best fits: (A) non-metallic element; (B) forms the most acidic oxide; (C) prefers the +2 oxidation state; (D) forms strong π bonds.
Answer: (A) Carbon. (B) Carbon — CO₂ is the most acidic oxide of the group. (C) Lead (tin also forms stable Sn²⁺ compounds, but Pb most strongly prefers +2). (D) Carbon — its small 2p orbitals overlap well sideways (C=C, C≡C, C=O).
3. Give reasons: (A) Ga³⁺ salts are better reducing agents while Tl³⁺ salts are better oxidising agents. (B) PbCl₄ is less stable than PbCl₂.
Answer: (A) For gallium the +3 state is the stable one, and Ga in its lower (+1) state readily gives up two more electrons to reach +3, so the lower-state gallium salts act as reducing agents. For thallium the inert pair effect makes +1 the stable state, so Tl³⁺ readily gains two electrons (Tl³⁺ + 2e⁻ → Tl⁺) and acts as an oxidising agent. Note: strictly it is gallium(I) salts, not Ga³⁺ salts, that are the reducing agents — Ga³⁺ is already in its stable state. (B) Pb is a heavy element whose 6s² pair is poorly shielded and resists bonding (inert pair effect), so Pb²⁺ is more stable than Pb⁴⁺; PbCl₄ easily decomposes to PbCl₂ + Cl₂.
4. Give the formula of a compound in which carbon shows an oxidation state of (A) +4, (B) +2, (C) −4.
Answer: (A) CO₂ or CCl₄ (+4). (B) CO (+2). (C) CH₄ (−4).
5. Explain the trend in group 13 of (A) atomic radii, (B) ionisation enthalpy, (C) electron affinity.
Answer: (A) Radius increases down the group as new shells are added (B 88 → In 167 → Tl 170 pm), but Ga (135 pm) is smaller than Al (143 pm) because the ten 3d electrons shield the extra nuclear charge poorly. (B) Ionisation enthalpy falls sharply from B (801) to Al (577 kJ mol⁻¹); after that it does not fall smoothly — Ga 579, In 558, Tl 589 — because poorly shielding d and f electrons let the nucleus hold the outer electrons more firmly. (C) Electron affinity is low for all group 13 elements and broadly decreases down the group as size increases, with irregularities for the same shielding reasons; the members easily lose electrons rather than gain them.
6. (A) What is the hybridisation of Al in AlCl₃? (B) Name a molecule having a banana bond.
Answer: (A) sp² — three bond pairs and one vacant orbital (which accepts a Cl lone pair to form the dimer Al₂Cl₆). (B) Diborane, B₂H₆.
7. Describe the structure of (A) orthophosphoric acid, (B) the resonance structures of nitric acid.
Answer: (A) H₃PO₄: phosphorus at the centre of a tetrahedron, joined to one oxygen by a P=O double bond and to three –OH groups; the three H atoms are acidic. (B) HNO₃: an H–O group is attached to an sp² nitrogen that also carries two other oxygens. In one form N=O is drawn to the first oxygen and N⁺–O⁻ to the second; in the other the double and single bonds swap places. N carries a + formal charge in both. The real molecule is a hybrid in which the two terminal N–O bonds are equal and each oxygen carries a partial negative charge; the O–N–O angle is about 130°.
8. Differentiate between (A) diamond and graphite, (B) white and red phosphorus.
Answer: (A) Diamond: sp³ carbons in a 3-D tetrahedral network, C–C 154 pm; hardest natural substance; insulator; used for cutting and jewellery. Graphite: sp² carbons in flat hexagonal layers, C–C 141.5 pm, layers 335 pm apart held by weak forces; soft and slippery; conducts electricity (delocalised π electrons); used as lubricant and electrodes; the most stable allotrope. (B) White P: discrete P₄ tetrahedra with 60° strain; waxy and translucent; glows in the dark; very reactive (stored under water); poisonous; dissolves in hot NaOH. Red P: P₄ units linked into polymeric chains; iron-grey, odourless; does not glow; stable and less reactive; non-poisonous; insoluble in water.
9. What are silicones? Where are they used?
Answer: Silicones are organosilicon polymers with the repeat unit –(R₂SiO)–, the units joined by Si–O–Si links (R = CH₃ or C₆H₅). They are made by hydrolysing alkyl chlorosilanes such as (CH₃)₂SiCl₂ to (CH₃)₂Si(OH)₂, which then condense into chains; (CH₃)₃SiCl caps the chain ends. They are water-repellent, thermally stable, chemically inert and good insulators. Uses: electrical insulation, waterproofing fabrics, sealants, high-temperature lubricants, and additives that make paints resist heat, sunlight and chemicals.
10. Explain the trend in oxidation state of elements from nitrogen to bismuth.
Answer: All have ns² np³, so the group oxidation state is +5 and the lower state is +3; nitrogen and phosphorus also show −3 (NH₃, PH₃). Going down from N to Bi, the stability of +5 decreases and that of +3 increases because of the inert pair effect. So N₂O₅ and PCl₅ are stable, but bismuth is found mainly as Bi³⁺ (BiCl₃, Bi₂O₃) and Bi(V) compounds are strong oxidising agents. The −3 state also becomes less stable down the group (NH₃ is stable, BiH₃ hardly exists).
11. (11) Give the test used to detect the borate radical in qualitative analysis. (13) A compound made by boiling colemanite with sodium carbonate solution is a white crystalline solid used in qualitative analysis — name it and write the reaction.
Answer: (11) Warm the salt with conc. H₂SO₄ and ethanol: Na₂B₄O₇ + H₂SO₄ + 5H₂O → Na₂SO₄ + 4H₃BO₃; then H₃BO₃ + 3C₂H₅OH → B(OC₂H₅)₃ + 3H₂O. The vapour of triethyl borate burns with a green-edged flame, confirming borate. (13) a. Borax, Na₂B₄O₇·10H₂O. b. Ca₂B₆O₁₁ + 2Na₂CO₃ → Na₂B₄O₇ + 2NaBO₂ + 2CaCO₃ (CaCO₃ precipitates and is filtered off; borax crystallises from the filtrate).
12. Explain the structure and bonding of diborane.
Answer: In B₂H₆ each boron is sp³ hybridised: three sp³ orbitals carry one electron each and the fourth is empty. Two half-filled orbitals on each B overlap with the 1s orbitals of two H atoms, giving four terminal B–H bonds (normal two-centre two-electron bonds); both B atoms and these four H atoms lie in one plane. Each of the other two H atoms overlaps at the same time with a half-filled orbital of one B and the empty orbital of the other, so one electron pair holds three atoms (B–H–B). These two three-centre two-electron (3c–2e) or banana bonds lie one above and one below the plane.
13. (14) Ammonia is a good complexing agent — explain. (17) Give reactions supporting the basic nature of ammonia.
Answer: (14) The N atom of NH₃ has a lone pair that it can donate to vacant orbitals of metal ions, forming coordinate bonds: Cu²⁺ + 4NH₃ → [Cu(NH₃)₄]²⁺ (deep blue); AgCl + 2NH₃ → [Ag(NH₃)₂]Cl (colourless, soluble). (17) In water: NH₃ + H₂O ⇌ NH₄⁺ + OH⁻. With acids: NH₃ + HCl → NH₄Cl; 2NH₃ + H₂SO₄ → (NH₄)₂SO₄. It precipitates metal hydroxides: ZnSO₄ + 2NH₄OH → Zn(OH)₂↓ (white) + (NH₄)₂SO₄; FeCl₃ + 3NH₄OH → Fe(OH)₃↓ (brown, hydrated Fe₂O₃) + 3NH₄Cl. (The book writes 2NH₄OH in the iron equation; 3 is needed to balance it.)
14. State true or false and correct the false statement: (A) The acidic nature of oxides of group 13 increases down the group. (B) The tendency for catenation is much higher for C than for Si.
Answer: (A) False — the acidic nature decreases down the group: B₂O₃ is acidic, Al₂O₃ and Ga₂O₃ amphoteric, In₂O₃ and Tl₂O₃ basic. (B) True — the C–C bond (348 kJ mol⁻¹) is much stronger than Si–Si (297 kJ mol⁻¹).
15. Match: BCl₃, SiO₂, CO₂ with angular molecule / linear covalent molecule / tetrahedral molecule / planar trigonal molecule.
Answer: BCl₃ – planar trigonal molecule; SiO₂ – tetrahedral (each Si bonded to four O); CO₂ – linear covalent molecule. 'Angular molecule' is left over.
16. Shravani adds AgNO₃ to a salt solution and gets a white precipitate that dissolves on adding NH₄OH to give a clear solution. Comment and write the reactions.
Answer: The salt contains chloride ions. Ag⁺ forms white, insoluble silver chloride: NaCl + AgNO₃ → AgCl↓ + NaNO₃ (written for a chloride such as NaCl). Ammonia dissolves it by forming the soluble, colourless diamminesilver(I) complex: AgCl + 2NH₃ (from NH₄OH) → [Ag(NH₃)₂]Cl. This complex formation confirms Cl⁻.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Which is not an allotrope of carbon?
Answer: D. Emerald is a beryllium aluminium silicate gem.
2. Which compound is called inorganic graphite?
Answer: C. BN has graphite-like layers.
3. Haber's process is used to make…
Answer: C. N₂ + 3H₂ ⇌ 2NH₃.
4. Thallium shows a stable +1 state because of…
Answer: B. 6s² electrons stay out of bonding.
5. Which shows the most prominent inert pair effect?
Answer: D. Heaviest member of group 14.
6. General outer configuration of group 15 is…
Answer: A. Five valence electrons.
7. Which atom has the smaller radius?
Answer: B. Poor 3d shielding shrinks Ga.
8. Which oxide is basic?
Answer: D. Metallic Bi gives a basic oxide.
9. Phosphorus forms PCl₅ but nitrogen cannot form NCl₅ because nitrogen…
Answer: D. It cannot expand its octet.
10. Hybridisation of boron in diborane is…
Answer: D. Each B uses four sp³ orbitals, one empty.
11. The C–C distance in diamond is…
Answer: D. Single bonds in a tetrahedral network.
12. Red phosphorus is obtained by heating white phosphorus at…
Answer: B. Heating converts P₄ units into chains.
13. Borax solution in water is…
Answer: D. Hydrolysis gives NaOH and weak H₃BO₃.
14. Triethyl borate burns with a … flame.
Answer: D. This is the borate test.
15. Ammonia gives a deep blue solution with…
Answer: A. [Cu(NH₃)₄]²⁺ is deep blue.
