Textbook: Biology – Class 12 (Balbharati, official free PDF) · pages 272–292
How do we make human insulin inside a bacterium, copy a single gene a billion times in an afternoon, or give cotton its own insecticide? This chapter explains the tools of recombinant DNA technology — electrophoresis, PCR, restriction enzymes, ligase, vectors and competent hosts — and the step-by-step method of gene cloning. It then surveys applications in medicine (recombinant proteins, insulin, vaccines, gene therapy), agriculture (Bt crops, Golden Rice, Flavr Savr tomato, plants as factories) and animals (transgenic mice, cattle, sheep, pigs, fish), and ends with bioethics, biosafety, biopatents and biopiracy. Several out-of-date legal and historical claims in the book are corrected.
Biotechnology uses living organisms, cells or their parts to make goods and services. Traditional biotechnology relied on fermentation (curd, vinegar, wine); modern biotechnology began when Stanley Cohen and Herbert Boyer made the first recombinant DNA in 1972–73, letting genes be cut, joined and moved between species.
Key tools: gel electrophoresis separates DNA fragments by size (DNA moves to the anode, small pieces fastest); PCR (Kary Mullis, 1985) copies a chosen DNA stretch by repeated cycles of denaturation, primer annealing and extension with heat-stable Taq polymerase — n cycles give up to 2ⁿ copies; restriction enzymes cut at palindromic recognition sites to give sticky or blunt ends; DNA ligase seals fragments; vectors (plasmids such as pBR322, Ti plasmid, phages, BAC, YAC) carry DNA into competent hosts such as E. coli.
Gene cloning: isolate DNA → cut donor and vector with the same restriction enzyme → join with ligase to make recombinant DNA → transform a competent host (CaCl₂ and heat shock, electroporation, microinjection, gene gun, Agrobacterium) → select transformants using marker genes → multiply → express the gene and purify the product (downstream processing).
Applications: recombinant proteins (insulin, tPA, factor VIII, erythropoietin, hepatitis B vaccine), edible and oral vaccines, gene therapy (somatic, not germ-line), transgenic plants (Bt cotton, Golden Rice, Flavr Savr tomato, iron-rich rice) and transgenic animals (oncomice, sheep and cows that secrete human proteins in milk, fast-growing fish, pigs for organs).
Concerns: herbicide-resistant weeds, effects on non-target species, possible allergens, ethical issues of crossing species and animal welfare. India's GEAC regulates GM organisms. Patents protect real inventions for a limited time; biopiracy is patenting traditional knowledge or bio-resources without consent or benefit-sharing (neem, basmati, turmeric cases).
Get a ✓ Verified tutor for “Biotechnology” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A forensic sample has 10 copies of a target DNA. How many copies will there be after 20 PCR cycles, assuming perfect doubling? If each cycle takes 3.5 minutes, how long do 30 cycles take?
Answer: About 1.05 × 10⁷ copies after 20 cycles; 30 cycles take about 1 hour 45 minutes — enough to analyse a single hair root.
Assuming the four bases occur at random and equally often, how often should EcoRI (6-bp site) and AluI (4-bp site) cut? How many EcoRI sites would you expect in the 48 502 bp genome of phage λ?
Answer: EcoRI should cut about once every 4096 bp (≈12 times in λ), AluI once every 256 bp. Real λ DNA has only 5 EcoRI sites because base sequences are not random — a good reminder that this is only an estimate.
pBR322 is 4361 bp. It has one EcoRI site at position 4359 and one PstI site at 3609. What fragment sizes appear on a gel after cutting with EcoRI alone, and with EcoRI + PstI together?
Answer: EcoRI alone gives one band of 4361 bp; EcoRI + PstI give two bands of 750 bp and 3611 bp (the smaller band runs farther towards the anode).
A bollworm attack cuts a farmer's cotton yield from 20 to 12 quintals per hectare. With Bt cotton the loss falls to 2 quintals per hectare. Calculate the percentage loss in each case and the extra yield per hectare from Bt cotton.
Answer: Loss falls from 40 % to 10 %, giving 6 more quintals per hectare — mainly from lower pest damage and fewer sprays, not from a higher potential yield.
| Tool or product | What it is | Use or example |
|---|---|---|
| Restriction endonuclease | Cuts DNA at a specific palindrome | EcoRI G↓AATTC (sticky), AluI AG↓CT (blunt) |
| DNA ligase | Seals phosphodiester bonds | Joins insert into vector |
| Taq polymerase | Heat-stable DNA polymerase of Thermus aquaticus | Extension step of PCR at ~72 °C |
| Reverse transcriptase | Makes DNA from RNA | cDNA libraries, RT-PCR |
| Alkaline phosphatase | Removes 5′ phosphate | Stops a cut vector closing on itself |
| pBR322 | E. coli plasmid with ori, ampʳ, tetʳ | Selection by insertional inactivation |
| Ti plasmid | Tumour-inducing plasmid of Agrobacterium tumefaciens | Disarmed vector for transgenic plants |
| Gel electrophoresis | Separates DNA by size in an electric field | Check and purify fragments |
| PCR | Repeated denature–anneal–extend cycles | 2ⁿ copies; diagnosis, forensics |
| Human insulin | A and B chains made in E. coli | Diabetes (Humulin, 1982) |
| Bt cotton | cry1Ac gene from Bacillus thuringiensis | Resists bollworms |
| Golden Rice | β-carotene synthesis genes | Fights vitamin A deficiency |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 MCQs: (1) bacterium causing crown gall; (2) nuclease hydrolyses which bonds; (3) in vitro amplification of DNA/RNA; (4) correct recognition sequence of HindIII; (5) recombinant protein that dissolves clots; (6) length of recognition sequences.
Answer: 1 c. Agrobacterium tumefaciens; 2 b. Phosphodiester bonds; 3 c. Polymerase chain reaction; 4 a. 5′-AAGCTT-3′ / 3′-TTCGAA-5′; 5 b. Tissue plasminogen activator; 6 b. 4 to 8.
2. Q2 Very short answers: (1) vector used for human insulin; (2) islet cells making insulin; (3) role of Ca²⁺ in transformation; (4) expand YAC, RE, dNTP, PCR, GMO, MAC; (5) complete the chart: Bt cotton – ?; ? – delays softening of tomato; Golden rice – ?; Holstein cow – ?
Answer: (1) Plasmid pBR322 (in E. coli). (2) β-cells of the islets of Langerhans. (3) Ca²⁺ (as cold CaCl₂) neutralises the negative charges on DNA and on the bacterial surface and makes the membrane permeable, so with a brief heat shock at 42 °C the cells take up the plasmid. (4) YAC — yeast artificial chromosome; RE — restriction endonuclease; dNTP — deoxyribonucleoside triphosphate; PCR — polymerase chain reaction; GMO — genetically modified organism; MAC — mammalian artificial chromosome. (5) Bt cotton — resistance to bollworms (insect pests); Flavr Savr tomato — delays softening; Golden rice — β-carotene (provitamin A) against vitamin A deficiency; Holstein cow — very high milk yield (note: Holstein is a breed improved by conventional selection, not a genetically modified animal).
3. Q3 (1) Properties of a good cloning vector; (2) a PCR machine heats to 100 °C but cannot cool below 70 °C — which step fails first and why; (3) problem if two different restriction enzymes cut vector and donor DNA.
Answer: (1) Origin of replication to copy itself and the insert many times; selectable marker genes (e.g. ampʳ, tetʳ) to pick out transformed cells; a single recognition site for each chosen restriction enzyme, preferably inside a marker or in a polylinker; suitable promoter, operator and ribosome-binding site for expression; small size, easy to isolate and to introduce into the host; able to carry a reasonably large insert. (2) Annealing fails first. Denaturation (90–98 °C) still works, and extension (about 72 °C) could run, but primers can bind only at 40–60 °C; since the machine cannot cool below 70 °C, the primers never attach, so Taq has no starting point and no new DNA is made. (3) The two enzymes leave different, non-complementary sticky ends, so the insert and the vector cannot base-pair and ligase cannot join them efficiently — no recombinant DNA forms (unless both cuts are blunt, which ligate poorly). Using the same enzyme gives matching ends. (Scientists sometimes deliberately cut both molecules with the same pair of enzymes to fix the insert's direction — then the ends do match.)
4. Q3 (4) Match: i. platelet-derived growth factor; ii. α₁-antitrypsin; iii. relaxin; iv. erythropoietin; v. factor VIII; vi. DNase — with a. anaemia; b. cystic fibrosis; c. haemophilia A; d. diabetes; e. emphysema; f. parturition; g. atherosclerosis.
Answer: i – g (atherosclerosis); ii – e (emphysema); iii – f (parturition); iv – a (anaemia); v – c (haemophilia A); vi – b (cystic fibrosis). Option d (diabetes) matches insulin, which is not in the list.
5. Q4 (1) Biopiracy, biopatent, bioethics; (2) steps of rDNA technology; (3) gene therapy and two methods; (4) transgenic mice in cancer research.
Answer: (1) Biopiracy: patenting or commercial use of a country's bio-resources or traditional knowledge without permission or benefit-sharing, e.g. US patent on turmeric's wound-healing use (cancelled 1997), neem fungicide patent (revoked), basmati (Texmati) patent (narrowed). Biopatent: a government-granted exclusive right over a biological invention — new microbial strain, cell line, GM organism, DNA sequence or process — for a limited time (20 years in India), e.g. Chakrabarty's oil-eating Pseudomonas. Bioethics: study of the moral questions raised by biology and medicine — cloning, GM organisms, gene therapy, animal use, embryo selection, euthanasia. (2) Isolate donor DNA → cut with a restriction enzyme and select the gene (or get it from a library or by PCR) → cut the vector with the same enzyme → join with DNA ligase to make rDNA → transform a competent host (CaCl₂ and heat shock, electroporation, gene gun, Agrobacterium) → select recombinants with markers → multiply the clone → express the gene and purify the product (downstream processing); diagram as Fig. 12.5. (3) Gene therapy treats a genetic disorder by supplying a normal gene, replacing or editing a faulty one. Ex vivo: patient's cells are removed, given the gene with a viral or non-viral vector, and returned (e.g. ADA-SCID, 1990). In vivo: the gene is delivered straight into the body or tumour (viral vectors, liposomes, virosomes). Forms: somatic (only the patient affected — allowed) and germ-line (inherited — not allowed). Used for SCID, haemophilia, cystic fibrosis, sickle-cell disease, some cancers. (4) Mice given cancer genes (e.g. myc and ras, by Philip Leder's team at Harvard) develop specific tumours such as breast cancer; they show how oncogenes trigger cancer, how tumours progress and spread, which carcinogens act, and allow new drugs, vaccines and preventive methods to be tested before human trials.
6. Q4 (5) Steps of PCR; (6) vaccine and advantages of oral/edible vaccines; (7) types of restriction enzymes and their role; (8) biological tools of rDNA technology.
Answer: (5) Mix template DNA, two primers, four dNTPs, Taq polymerase and Mg²⁺ buffer in a tube in a thermal cycler. Denaturation (90–98 °C): strands separate. Annealing (40–60 °C): primers pair with the ends of the target. Extension (~72 °C): Taq adds nucleotides from each primer, giving two copies. Repeating 20–30 cycles doubles the target each time (2ⁿ copies); the product is checked by gel electrophoresis; diagram as Fig. 12.1. (6) A vaccine is a preparation of a killed or weakened microbe, its toxoid, a surface antigen or a gene for it, that gives artificial active immunity. Oral/edible vaccines (antigen genes expressed in banana, potato, tomato, or melt-in-mouth tablets): no needles or trained staff, cheap to grow, no cold chain, easy storage and transport, safe from contamination by animal viruses, stimulate mucosal (IgA) immunity at the gut where many pathogens enter. (7) Type I — one protein both cuts and methylates, cuts far from the site, needs ATP (EcoK); Type II — cut within the palindromic site, separate methylase, no ATP, give predictable sticky or blunt ends — the enzymes of genetic engineering (EcoRI, BamHI, HindIII, AluI, HpaI); Type III — cut a short distance from a non-palindromic site, need ATP (EcoP15I). Role: molecular scissors to open vectors, cut out genes and map DNA. (8) Enzymes — lysozyme and other wall-dissolving enzymes to release DNA; restriction enzymes to cut; DNA ligase to join; DNA polymerase/Taq to copy; alkaline phosphatase to stop vector self-closing; reverse transcriptase for cDNA. Vectors — plasmids (pBR322, pUC, Ti), phages (λ, M13), cosmids, BAC, YAC, MAC; need ori, markers and unique sites. Competent hosts — E. coli (most common), Bacillus subtilis, yeast, Agrobacterium for plants, animal cell lines; made competent by CaCl₂ and heat shock or electroporation.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The term 'biotechnology' was first used by…
Answer: B. Ereky used it in 1919 for producing pigs on sugar-beet feed.
2. In agarose gel electrophoresis the smallest DNA fragments…
Answer: A. The gel sieves molecules, so small pieces travel fastest towards the positive pole.
3. The annealing step of PCR is carried out at about…
Answer: C. Primers bind at 40–60 °C; 72 °C is for extension.
4. Starting with 1 molecule, how many copies are made after 10 PCR cycles?
Answer: A. 2¹⁰ = 1024.
5. Restriction enzymes cut…
Answer: C. They break the sugar–phosphate backbone of each strand.
6. Which enzyme gives blunt ends?
Answer: C. AluI cuts AG↓CT at the centre; the other three leave overhangs.
7. Bacteria protect their own DNA from their restriction enzymes by…
Answer: C. A methylase modifies bases at the recognition sites.
8. When foreign DNA is inserted at the PstI site of pBR322, recombinant cells become…
Answer: C. PstI lies inside ampʳ, so that gene is inactivated.
9. Which is NOT a feature needed in a cloning vector?
Answer: D. A vector needs a single (unique) site for each enzyme used, or it would be cut into pieces.
10. cDNA is made from…
Answer: D. It is the DNA copy of mRNA and so lacks introns.
11. Factor VIII made by rDNA technology treats…
Answer: B. Factor IX is for haemophilia B; α₁-antitrypsin for emphysema; erythropoietin for anaemia.
12. Only somatic gene therapy is allowed in humans because germ-line changes…
Answer: A. Heritable changes raise serious safety and ethical problems.
13. Bt toxin becomes active in the insect because the gut is…
Answer: B. The alkaline midgut and its proteases turn the protoxin into the active toxin.
14. Transgenic mice carrying myc and ras genes were developed to study…
Answer: D. Philip Leder's oncomouse developed mammary tumours.
15. Patenting the healing use of turmeric in the USA without consent is an example of…
Answer: B. Traditional Indian knowledge was claimed as a new invention.
