Textbook: Biology – Class 12 (Balbharati, official free PDF) · pages 119–133
A 60-metre tree lifts hundreds of litres of water every day without a single pump. This chapter explains how. It covers why water is so special, how root hairs take water from the soil by imbibition, diffusion and osmosis, the language of DPD and water potential, plasmolysis, the apoplast and symplast routes across the root, active and passive absorption, the theories of ascent of sap (root pressure, capillarity, cohesion–tension), mineral and food transport with Münch's pressure-flow idea, and finally transpiration, stomatal structure and the opening and closing of stomata. Every exercise question is answered at the end.
Water makes up 90–95 % of most plant tissue. Hydrogen bonding gives it high specific heat, high heat of vaporisation, strong cohesion and adhesion, and excellent solvent power. Roots absorb only capillary water from the soil; gravitational, hygroscopic and combined water are not available.
Root hairs (1–10 mm, thin pectin–cellulose walls, large vacuole) take in water by imbibition into the wall, diffusion through it and osmosis across the plasma membrane. DPD = OP − TP; in modern terms ψw = ψs + ψp, pure water has ψ = 0, and water always moves toward the more negative water potential.
Water crosses the root by the apoplast (walls and spaces, blocked at the endodermis by the Casparian strip) and the symplast (cytoplasm through plasmodesmata). About 98 % of absorption is passive, driven by transpiration pull; active absorption, driven by root pressure and respiration energy, works mainly at night.
Ascent of sap occurs in xylem. Root pressure (about 1–2 bar) and capillarity can each lift water only a limited height; the cohesion–tension (transpiration pull) theory of Dixon and Joly is widely accepted. Minerals move as ions in the xylem stream; food moves as sucrose in phloem from source to sink, best explained by Münch's pressure-flow hypothesis.
Transpiration is loss of water vapour — stomatal (90–93 %), cuticular (about 8–10 %) and lenticular (under 1 %); guttation is loss of liquid through hydathodes. Stomata open when guard cells become turgid (starch → sugar, or K⁺ and malate build-up) and close when they lose water. Curtis called transpiration 'a necessary evil' because open stomata are needed for gas exchange.
Get a ✓ Verified tutor for “Plant Water Relation” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A cell has an osmotic pressure of 14 atm and a turgor pressure of 9 atm. Its neighbour has OP 11 atm and TP 3 atm. Find the DPD of each and the direction of water flow.
Answer: Water moves from cell 1 (DPD 5 atm) into cell 2 (DPD 8 atm).
Cell P has ψs = −1.2 MPa and ψp = +0.5 MPa; cell Q has ψs = −0.9 MPa and ψp = +0.4 MPa. Which way will water move?
Answer: Water moves from Q to P, although Q has the weaker solute potential.
A plant shows a root pressure of 1.5 bar. Ignoring friction, how high could this push a column of water? Take 1 bar = 1.0 × 10⁵ Pa, density 1000 kg m⁻³ and g = 9.8 m s⁻².
Answer: About 15 m at best — not enough for a 40–100 m tree, so root pressure alone cannot explain ascent of sap.
Under a microscope a leaf peel shows 45 stomata and 255 other epidermal cells in one field. Find the stomatal index.
Answer: Stomatal index = 15 %.
| Quantity or process | Relation or meaning | Note |
|---|---|---|
| DPD | DPD = OP − TP | Old term for the suction power of a cell |
| Water potential | ψw = ψs + ψp | Pure water ψ = 0; water flows to lower ψ |
| Flaccid cell | TP = 0, so DPD = OP | ψw = ψs |
| Fully turgid cell | TP = OP, so DPD = 0 | ψw = 0 |
| Plasmolysis | Exosmosis in hypertonic solution | Protoplast leaves the wall |
| Root pressure | About +1 to +2 bar | Exudation, guttation |
| Water column height | h = P ÷ (ρg) | 1 bar ≈ 10 m of water |
| Stomatal index | S ÷ (S + E) × 100 | S = stomata, E = epidermal cells |
| Transpiration share | Stomatal 90–93 %, cuticular 8–10 %, lenticular < 1 % | Mostly by day |
| Stomatal opening | K⁺ + malate ↑ → ψ ↓ → water in | ABA closes |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q.1 MCQs: (1) Water available to roots. (2) Most accepted theory of ascent of sap. (3) Water movement between cells is due to. (4) Sugar → starch in guard cells: the pore. (5) Surface tension is due to. (6) Solution with a lower level of solutes. (7) Wooden doors warp in rain because of. (8) Water absorption takes place through. (9) Low atmospheric pressure: rate of transpiration. (10) Osmosis is a property of.
Answer: (1) b. capillary water. (2) d. transpiration pull theory. (3) c. D.P.D. (4) a. closes almost completely. (5) d. cohesion. (6) b. hypotonic. (7) b. imbibition. (8) c. root hair. (9) a. increase. (10) c. solution.
2. Q.2 Very short answers: (1) Osmotic pressure. (2) Condition in which the protoplast shrinks. (3) Effect of applying pressure above atmospheric to pure water or a solution. (4) Solution causing deplasmolysis. (5) Plants with negative root pressure. (6) When is transpiration pull affected? (7) Guard-cell shape in Cyperus. (8) Why diurnal changes occur in osmotic potential of guard cells. (9) Symplast pathway.
Answer: (1) The pressure that must be applied to a solution to prevent water from entering it across a semipermeable membrane. (2) Plasmolysis (in a hypertonic solution). (3) Its water potential rises (pressure potential becomes positive); if the solution is separated from water by a semipermeable membrane and the pressure exceeds its osmotic pressure, water is forced out of the solution — reverse osmosis. (4) A hypotonic solution or pure water. (5) Tall, rapidly transpiring trees, especially conifers, whose xylem is under tension during the day. (6) When the water column breaks by air bubbles (embolism), when stomata close (darkness, drought, ABA), in very humid or still air, or when leaves are lost. (7) Both kidney-shaped and dumb-bell-shaped. (8) Light by day causes starch → sugar conversion and K⁺/malate uptake, lowering ψ of guard cells; at night the reverse occurs, so their osmotic potential rises and falls daily. (9) Movement of water from the cytoplasm of one living cell to the next through plasmodesmata.
3. Q.3 (1) Mechanism of water absorption. (2) Theories of water translocation. (3) Transpiration and the mechanism of stomatal opening and closing.
Answer: (1) Root hairs take water by imbibition (wall), diffusion (through the wall) and osmosis (across the membrane). Passive absorption: transpiration creates tension in leaf xylem, transmitted to root xylem, which pulls water in through the root; no ATP; by day; about 98 %. Active absorption: living root cells accumulate ions, creating a DPD gradient from epiblema to xylem (osmotic, Atkins and Priestley) or take water directly using respiratory energy (non-osmotic, Kramer and Thimann); this builds root pressure, mainly at night. (2) Root pressure theory: water entering roots builds hydrostatic pressure (about 1–2 bar) pushing sap up; shown by exudation from cut stumps; fails for tall trees, rootless shoots and conifers. Capillarity theory (Boehm): xylem as capillary tubes; water rises only a few cm; vessels are wide and tracheids closed. Cohesion–tension theory (Dixon and Joly): cohesion and adhesion keep a continuous column; transpiration creates tension that pulls the column up; widely accepted. (3) Transpiration is the loss of water vapour from aerial parts, mostly through stomata. Guard cells have thick inner and thin outer walls. When they absorb water (endosmosis) the thin walls stretch outward and pull the thick walls apart — the stoma opens; when they lose water it closes. Starch–sugar theory: by day phosphorylase converts starch to sugar, lowering ψ; at night sugar becomes starch. K⁺–proton theory: light drives H⁺ out and K⁺ and Cl⁻ in; starch forms malate; potassium malate lowers ψ, water enters, stoma opens; ABA or darkness reverses it.
4. Q.3 (4) Role of transpiration. (5) Root pressure theory and its limitations. (6) Capillarity theory. (7) Why transpiration is 'a necessary evil'.
Answer: (4) Removes excess water; creates the pull for passive absorption and ascent of sap; carries minerals upward; cools leaves; keeps cells turgid; allows gas exchange through open stomata. Excess transpiration causes wilting and injury. (5) Proposed from root activity (Priestley; the term root pressure from Hales): continuous uptake by living root cells builds hydrostatic pressure in the root that forces water into the xylem and up the stem. Evidence: exudation from a cut stump measured by a manometer, guttation. Value +1 to +2 bar. Limitations: inadequate for trees over about 20 m; ascent occurs without roots; near zero in tall gymnosperms; absent during rapid transpiration; xylem sap is normally under tension. (6) Boehm (1863): xylem vessels are narrow tubes; surface tension, cohesion and adhesion raise water as a wick raises oil. Objections: rise is only a few centimetres; tracheids have end walls; cortex separates xylem from soil water; tall trees have wide vessels. (7) Transpiration wastes most of the water absorbed and can cause wilting — an evil. But it cannot be avoided because stomata must be open for CO₂ entry (photosynthesis) and O₂ exchange, and it also gives cooling and the pull for water and mineral transport — necessary. Hence Curtis called it a necessary evil.
5. Q.3 (8) Movement of water in the root. (9) Define: osmosis, diffusion, plasmolysis, imbibition, guttation, transpiration, ascent of sap, active absorption, DPD, turgor pressure, water potential, wall pressure, root pressure. (10) Distinguish (a) OP and TP, (b) diffusion and osmosis.
Answer: (8) Water enters root hairs, lowering their DPD; inner cortical cells have higher DPD and pull it inward, setting up a gradient epiblema → cortex → endodermis → pericycle → xylem. It travels by the apoplast (walls and spaces) up to the endodermis, where the Casparian strip forces it into the symplast (through plasmodesmata); it then enters the pericycle and protoxylem; root pressure helps push it into the xylem. (9) Osmosis: water movement across a semipermeable membrane to lower ψ. Diffusion: net movement from higher to lower concentration. Plasmolysis: shrinkage of protoplast from the wall in hypertonic solution. Imbibition: swelling of hydrophilic colloids by adsorbing water. Guttation: loss of liquid water through hydathodes. Transpiration: loss of water vapour from aerial parts. Ascent of sap: upward transport of water and minerals in xylem. Active absorption: water uptake due to root activity using metabolic energy. DPD: deficit in diffusion pressure of water in a solution compared with pure water. Turgor pressure: pressure of cell contents on the wall. Water potential: free energy of water, zero for pure water. Wall pressure: wall's counter-pressure on the contents. Root pressure: hydrostatic pressure in root xylem from active uptake. (10a) OP: property of a solution, depends on solute concentration, highest in flaccid cell, present even in a beaker; TP: develops only inside a cell with a wall, due to water entry, zero in flaccid cell, maximum (= OP) in fully turgid cell. (10b) Diffusion: any substance (solid, liquid, gas), no membrane needed, in any direction of its gradient; Osmosis: only solvent (water), needs a semipermeable membrane, toward the stronger solution.
6. Q.4 (1) Structure of root hair. (2) Journey of water from soil to xylem. (3) Cohesion theory. (4) Mechanism of opening and closing of stoma. (5) Active absorption of minerals.
Answer: (1) An unbranched, colourless, tube-like outgrowth of an epiblema cell, 1–10 mm long and short-lived. It has a two-layered wall (outer pectin, inner cellulose; freely permeable), a selectively permeable plasma membrane, a thin layer of cytoplasm with nucleus and mitochondria, and a large central vacuole with cell sap. It greatly increases absorbing surface. (2) Capillary water → root-hair wall (imbibition, diffusion) → cytoplasm (osmosis) → cortex by apoplast and symplast down a DPD gradient → endodermis (Casparian strip forces the symplast route; passage cells in monocots) → pericycle → protoxylem → xylem, driven by transpiration pull by day and root pressure at night. (3) Water forms a continuous column in xylem held by cohesion (water–water hydrogen bonds) and adhesion (water–lignified wall). Transpiration from leaves raises mesophyll DPD; they draw water from leaf xylem, creating tension (negative pressure) that is transmitted down to the roots, so the whole column is pulled up passively. Strong cohesion (tensile strength up to about 30 MPa) prevents breaking. Objections: air embolism, ascent in leafless trees. (4) Turgid guard cells (endosmosis) bow apart because their thin outer walls stretch while thick inner walls do not — the stoma opens; flaccid guard cells collapse together — it closes. Changes in guard-cell ψ come from starch ⇌ sugar conversion (Steward) or from K⁺ and Cl⁻ entry with malate formation in light (Levitt), reversed in darkness or by ABA. (5) Most ions are at higher concentration inside root cells than in soil, so they are taken up against the gradient by carrier proteins and pumps in the plasma membrane using ATP from respiration; a proton pump sets up an H⁺ gradient that drives ion symport. Evidence: uptake is selective, falls when O₂ is low, at low temperature or with respiratory inhibitors. Ions then pass to the xylem and travel up in the transpiration stream.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Water available for absorption by roots is…
Answer: D. It is held loosely in soil pores.
2. The most widely accepted theory of ascent of sap is…
Answer: A. Cohesion–tension explains lift in tall trees.
3. Water movement between cells depends on…
Answer: B. Water moves toward higher DPD (lower ψ).
4. When sugar in guard cells is converted to starch, the stomatal pore…
Answer: C. Osmotic concentration falls, water leaves, cells become flaccid.
5. Surface tension of water is due to…
Answer: C. Water molecules attract one another by hydrogen bonds.
6. A solution with fewer solutes than the cell sap is…
Answer: D. Water enters the cell from it.
7. Wooden doors warp in the rainy season because of…
Answer: A. Cellulose in wood adsorbs water and swells.
8. Water absorption takes place mainly through…
Answer: B. Root hairs give a huge surface.
9. At low atmospheric pressure the rate of transpiration…
Answer: D. Lower pressure speeds evaporation (higher diffusivity).
10. A cell with ψs = −0.8 MPa and ψp = +0.3 MPa has ψw equal to…
Answer: A. ψw = ψs + ψp.
11. The Casparian strip is made of…
Answer: D. A suberised band in radial and transverse walls.
12. Root pressure is best seen…
Answer: C. Guttation and exudation are visible then.
13. Food is translocated in phloem as…
Answer: C. Sucrose is soluble and non-reducing.
14. Lenticular transpiration accounts for about…
Answer: A. Lenticels are few and slow.
15. Stomata open when guard cells gain…
Answer: D. K⁺ (with malate and Cl⁻) lowers ψ so water enters.
