Textbook: Science – Class 7 (Balbharati, official free PDF) · pages 51–57
Why does a comb rubbed on dry hair pick up bits of paper, and what is lightning? Learn about positive and negative charge, attraction and repulsion, charging by friction, contact and induction, the gold leaf electroscope, Franklin's kite, lightning, lightning conductors and staying safe, with answers to every exercise.
Everything is made of atoms, and every atom holds equal amounts of positive and negative charge, so ordinary objects are neutral. When this balance is upset, the object becomes charged.
Rubbing two suitable objects makes negative charges move from one to the other: the one that gains them becomes negative, the one that loses them becomes positive. Charge made this way stays only where it was rubbed and only for a short time, so it is called static (frictional) electricity.
Like charges repel and unlike charges attract; a charged object also attracts uncharged light things. Since only two charged objects can repel, repulsion is the sure test of charge. Objects can be charged by friction, by contact and, temporarily, by induction.
A gold leaf electroscope detects charge: its leaves spread apart when a charged body is brought near the disc and fall back when the disc is touched (the charge escapes to earth).
Lightning is a huge, very fast flow of charge from a charged cloud to the ground (or to another cloud), giving heat, light and sound. Benjamin Franklin showed in 1752 that lightning is electric. A lightning conductor carries this charge safely into the ground and protects a building.
Get a ✓ Verified tutor for “Static Electricity” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A glass rod is rubbed with silk and becomes positively charged. What charge does the silk get, and why?
Answer: The silk becomes negatively charged, with exactly as much charge as the glass lost.
| Idea | What happens | Example |
|---|---|---|
| Like charges | Repel | Two glass rods rubbed with silk |
| Unlike charges | Attract | Glass rod (silk) and plastic rod (wool) |
| Charging by friction | Negative charges move from one body to another | Comb rubbed on dry hair |
| Charging by contact | Same kind of charge passes on | Charged comb touching another comb |
| Charging by induction | Opposite charge appears nearby, only while close | Water stream bends towards a comb |
| Electroscope | Leaves spread when charged | Detects charge on an object |
| Lightning conductor | Carries cloud charge into the ground | Copper strip on a tall building |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Fill in the blanks: (a) There is … between like charges. (b) … is responsible for generation of electric charge in an object. (c) A lightning conductor is made of a … strip. (d) … does not get electrically charged easily by rubbing. (e) There is … when opposite charges come near each other. (f) A … can be detected with an electroscope.
Answer: (a) always repulsion (b) displacement of negative charge (c) copper (d) steel (a metal held in the hand) (e) always attraction (f) charged object.
2. 2. Explain why it is not safe to go out with an umbrella in heavy rain, lightning or thunder.
Answer: An umbrella has a metal rod and pointed metal tips held above the head. It makes you the tallest point around and gives charge an easy path, so lightning is more likely to strike you. The current could pass through your body and kill you. It is safer to stay indoors.
3. 3(a). How will you protect yourself from lightning?
Answer: Stay indoors and away from windows, metal pipes and water taps; unplug TVs and computers; avoid using wired phones. Outdoors, do not stand under a lone tall tree, near electric poles or on open high ground; get out of water and off bicycles or tractors; if there is no shelter, crouch low on the balls of your feet with head tucked, not lying flat; keep away from metal fences and do not hold an umbrella.
4. 3(b). How are charges generated?
Answer: Every object is made of neutral atoms with equal positive and negative charge. When two suitable objects are rubbed, negative particles move from one to the other. The one that gains them becomes negatively charged and the one that loses them becomes positively charged. Charges can also be produced by contact (sharing charge) and by induction (rearranging charge when a charged body is brought near).
5. 3(c). In the lightning conductor, what provision is made for spreading the electricity into the ground?
Answer: The copper strip is joined to a cast-iron plate placed upright in a pit filled with coal and salt, and there is an arrangement to pour water into it. Wet coal and salt conduct well, so the charge spreads quickly into the earth.
6. 3(d). Why do farmers stick an iron staff into the ground while working in the field in rainy weather?
Answer: The tall iron staff works like a small lightning conductor. If lightning strikes nearby, it tends to go through the metal staff into the ground instead of through the farmer. (Even so, the safest choice is to leave the open field and take shelter when a storm comes.)
7. 3(e). Why is lightning not seen every day during the rainy season?
Answer: Lightning happens only when clouds become very strongly charged, which needs tall storm clouds with strong rising air and rubbing. Ordinary rain clouds do not build up that much charge every day, so there is rain but no lightning.
8. 4. What are the characteristics of a static electric charge?
Answer: It is produced by rubbing; it stays only at the place where it was produced and does not flow; it lasts a short time; it is lost quickly in moist air; like charges repel and unlike charges attract; a charged object also attracts light uncharged objects.
9. 5. What damage is caused by lightning? How will you create awareness to prevent it?
Answer: Damage: deaths and burns of people and cattle, trees split or set on fire, houses and buildings cracked, fires, and TVs, computers and wiring destroyed. Awareness: make posters and a short skit on 'Do's and Don'ts in a thunderstorm', explain safe behaviour at a school assembly, ask the school and housing society to fit lightning conductors, and tell farmers not to stand under trees in storms.
10. Project: Make an electroscope with thin aluminium foil and check which substances become charged.
Answer: Sample: Push a thick copper wire through a cork, bend its lower end into a hook and hang two thin strips of aluminium foil from it; fit it in a dry glass jar and fix a foil ball or disc on top. Rub a comb, balloon, refill, eraser, wooden ruler and steel spoon one by one and bring each near the top. Plastic comb, balloon and refill — leaves spread (charged). Wooden ruler and steel spoon — leaves hardly move (not charged easily). Touch the top to close the leaves before each test.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Between like charges there is always…
Answer: A. Like charges push apart.
2. Charge is produced in an object by rubbing because of…
Answer: B. Negative particles move.
3. A lightning conductor strip is made of…
Answer: D. Copper conducts well.
4. Which does NOT get charged easily by rubbing when held in hand?
Answer: D. Charge flows away through the hand.
5. An electroscope is used to detect…
Answer: B. Its leaves spread.
6. A glass rod rubbed with silk becomes positive. The silk becomes…
Answer: B. It gains negative charges.
7. Static charge experiments work best…
Answer: C. Moisture removes charge.
8. Charge produced by induction lasts…
Answer: D. Charges return when it is removed.
9. The word 'electricity' comes from the Greek word for…
Answer: C. Elektron = amber.
10. Who showed lightning is electric charge using a kite?
Answer: D. In 1752.
11. When you touch a charged electroscope's disc, the leaves…
Answer: A. Charge goes to earth.
12. A balloon rubbed on hair sticks to a wall because of…
Answer: C. Opposite charge is induced on the wall.
13. Which proves that an object is charged?
Answer: C. Uncharged objects are also attracted.
14. Coal and salt are put in the lightning conductor pit to…
Answer: C. They improve conduction.
15. When opposite charges come near each other there is…
Answer: A. Unlike charges attract.
