Textbook: Mathematics – Class 9 (Balbharati, official free PDF) · pages 57–63
A parallelogram is a quadrilateral whose opposite sides are parallel. From that one fact we can prove several useful properties: opposite sides are equal, opposite angles are equal, neighbouring angles add to 180°, and the diagonals cut each other in half. This set uses these properties to find unknown sides and angles and to write short proofs.
A parallelogram has both pairs of opposite sides parallel.
Its opposite sides are congruent and its opposite angles are congruent (proved using a diagonal and ASA).
Any two adjacent angles are supplementary: they add up to 180°.
Its diagonals bisect each other: they meet at the midpoint of each.
These properties turn many questions into simple equations, e.g. (3x + 12) + (2x − 32) = 180.
Get a ✓ Verified tutor for “Practice Set 5.1 – Properties of a Parallelogram” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
In □KLMN, KL = 6 cm, LM = 4 cm and ∠K = 65°. Find the other sides and angles.
Answer: MN = 6 cm, NK = 4 cm; ∠L = 115°, ∠M = 65°, ∠N = 115°
Diagonals of a parallelogram meet at O. If one diagonal is 14 cm and the other half of the second diagonal is 4.5 cm, find all four pieces.
Answer: 7 cm, 7 cm, 4.5 cm, 4.5 cm
In □WXYZ, ∠W = (5x + 10)° and ∠X = (3x + 10)°. Find all angles.
Answer: x = 20; angles 110°, 70°, 110°, 70°
The perimeter of a parallelogram is 64 cm and one side is 3 times the other. Find the sides.
Answer: 8 cm, 24 cm, 8 cm, 24 cm
| What | Formula | Symbols |
|---|---|---|
| Opposite sides | AB = DC, AD = BC | AB = 5 ⇒ DC = 5 |
| Opposite angles | ∠A = ∠C, ∠B = ∠D | ∠A = 70° ⇒ ∠C = 70° |
| Adjacent angles | ∠A + ∠B = 180° | 70° + 110° |
| Diagonals | AO = OC, BO = OD | AC = 10 ⇒ AO = 5 |
| Perimeter | P = 2(AB + BC) | 2(25 + 50) = 150 |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Diagonals of parallelogram WXYZ meet at O. ∠XYZ = 135°. Find ∠XWZ and ∠YZW. Also, if OY = 5 cm, find WY.
Answer: ∠XWZ = 135°, ∠YZW = 45°, WY = 10 cm
2. 2. In parallelogram ABCD, ∠A = (3x + 12)° and ∠B = (2x − 32)°. Find x, ∠C and ∠D.
Answer: x = 40, ∠C = 132°, ∠D = 48°
3. 3. A parallelogram has perimeter 150 cm and one side is 25 cm longer than the other. Find all sides.
Answer: 25 cm, 50 cm, 25 cm, 50 cm
4. 4. Two adjacent angles of a parallelogram are in the ratio 1 : 2. Find all its angles.
Answer: 60°, 120°, 60°, 120°
5. 5. Diagonals of parallelogram ABCD meet at O. AO = 5, BO = 12 and AB = 13. Show that ABCD is a rhombus.
Answer: □ABCD is a rhombus (each side 13)
6. 6. In figure 5.12, □PQRS and □ABCR are parallelograms and ∠P = 110°. Find all angles of □ABCR.
Answer: ∠A = 70°, ∠B = 110°, ∠C = 70°, ∠R = 110°
7. 7. In figure 5.13, □ABCD is a parallelogram and E is on ray AB with BE = AB. Prove that line ED bisects seg BC at F.
Answer: BF = FC, so ED bisects BC
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. In □ABCD, ∠A = 75°. Then ∠C =
Answer: A. Opposite angles are equal.
2. In □ABCD, ∠A = 75°. Then ∠B =
Answer: B. Adjacent angles add to 180°.
3. Diagonals of a parallelogram…
Answer: C. Proved by ASA.
4. If AO = 6 cm, then AC =
Answer: D. O is the midpoint of AC.
5. Perimeter 40 cm, one side 12 cm. Adjacent side?
Answer: D. 2(12 + b) = 40.
6. Adjacent angles in ratio 4 : 5 are…
Answer: D. 9x = 180.
7. Which is NOT always true for a parallelogram?
Answer: A. That holds for rectangles only.
8. ∠A = (3x + 12)°, ∠B = (2x − 32)°, adjacent. x =
Answer: A. 5x − 20 = 180.
9. In the proof of opposite sides, the diagonal acts as a…
Answer: C. It cuts the parallel sides.
10. AO = 5, BO = 12, AB = 13 in □ABCD. ∠AOB =
Answer: B. 5² + 12² = 13².
11. If one angle of a parallelogram is 90°, all angles are…
Answer: C. Opposite equal, adjacent supplementary.
12. □PQRS is a parallelogram. Side opposite PQ is…
Answer: B. PQ ∥ SR.
13. Sum of two opposite angles 140°. Each is…
Answer: B. They are equal.
14. Why are ∠A and ∠B supplementary?
Answer: B. AD ∥ BC with transversal AB.
15. A parallelogram with diagonals perpendicular to each other is a…
Answer: C. All sides become equal.
