Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 160–173
Why does a cold bottle get wet on the outside, how does charcoal take the colour out of sugar syrup, and why does a beam of torchlight show up in fog? This chapter covers adsorption and how it differs from absorption, physisorption versus chemisorption, factors that control the adsorption of gases, the Freundlich isotherm, catalysis (homogeneous, heterogeneous, inhibitors, zeolites), and colloids — their classes, preparation, purification, Tyndall effect, Brownian motion, electrophoresis, coagulation, emulsions and uses — with worked examples and answers to every exercise.
Particles at the surface of a solid or liquid have unbalanced attractive forces, so the surface pulls in and holds gas molecules or dissolved particles. This piling up of a substance only on a surface is adsorption; the solid that holds it is the adsorbent and the substance held is the adsorbate. Removing it again is desorption.
Absorption spreads a substance evenly through the whole bulk (water in cotton), while adsorption stays at the surface (dye on charcoal). When both happen together, as when chalk is dipped in ink, it is called sorption.
Physisorption uses weak van der Waals forces, is non-specific, reversible, multilayered and favoured by low temperature (about 20–40 kJ mol⁻¹). Chemisorption forms real chemical bonds, is specific, irreversible, a single layer, needs activation energy and has a heat of about 40–200 kJ mol⁻¹. Easily liquefied gases, large surface area, low temperature and high pressure all increase gas adsorption.
The Freundlich isotherm x/m = kP¹ᐟⁿ (n > 1) links the mass adsorbed per gram of adsorbent to pressure; a plot of log(x/m) against log P is a straight line of slope 1/n and intercept log k. Catalysts speed up reactions without being used up: homogeneous catalysts share the reactants' phase, heterogeneous ones work on a solid surface through diffusion, adsorption, reaction, product formation and desorption.
Colloids have dispersed particles roughly 2–500 nm across, between true solutions and suspensions. They are grouped by physical state, by affinity (lyophilic or lyophobic) and by particle type (multimolecular, macromolecular, micelles). They are made by chemical reactions, Bredig's arc or peptization, cleaned by dialysis, and show the Tyndall effect, Brownian motion, electric charge, electrophoresis and coagulation (Hardy–Schulze rule). Emulsions are liquid-in-liquid colloids of o/w or w/o type.
Get a ✓ Verified tutor for “Adsorption and Colloids” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Why is a powder far better than a lump of the same mass as an adsorbent? Compare the surface-area-to-volume ratio of a sphere of radius 1 cm with that of particles of radius 10 nm.
Answer: 3 cm⁻¹ for the big sphere versus 3 × 10⁶ cm⁻¹ for 10 nm particles — a 10⁶-fold gain in surface, so the powder adsorbs far more.
For a gas on charcoal at 250 K, x/m = 0.20 g g⁻¹ at 1 bar and 0.40 g g⁻¹ at 16 bar. Find k and 1/n in the Freundlich equation, and predict x/m at 81 bar.
Answer: k = 0.20, 1/n = 0.25 (n = 4); x/m at 81 bar ≈ 0.60 g of gas per g of charcoal.
A negatively charged As₂S₃ sol is to be coagulated. Rank NaCl, BaCl₂ and AlCl₃ by coagulating power, and say which ion of a positive Fe(OH)₃ sol coagulant — Cl⁻, SO₄²⁻ or PO₄³⁻ — is most effective.
Answer: AlCl₃ > BaCl₂ > NaCl for the As₂S₃ sol; phosphate (PO₄³⁻) is the best coagulant for the Fe(OH)₃ sol.
| Feature | Physisorption | Chemisorption |
|---|---|---|
| Forces | weak van der Waals | covalent or ionic bonds |
| Heat of adsorption | low, about 20–40 kJ mol⁻¹ | high, about 40–200 kJ mol⁻¹ |
| Specificity | not specific — all gases on all solids | highly specific (O₂ on W, H₂ on Ni) |
| Temperature | favoured by low T; falls as T rises | rises with T at first, falls at very high T |
| Activation energy | negligible | large — 'activated adsorption' |
| Reversibility | reversible | irreversible |
| Layers | can be multimolecular at high pressure | monomolecular |
| Example | N₂ on iron at low temperature | N₂ on iron at high temperature (iron nitride) |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option: (A) The size of colloidal particles lies between (a) 10⁻¹⁰ and 10⁻⁹ m (b) 10⁻⁹ and 10⁻⁶ m (c) 10⁻⁶ and 10⁻⁴ m (d) 10⁻⁵ and 10⁻² m. (B) Gum in water is (a) true solution (b) suspension (c) lyophilic sol (d) lyophobic sol. (C) In the Haber process K₂O is used as (a) catalyst (b) inhibitor (c) promoter (d) adsorbate. (D) Fruit jam is (a) sol (b) gel (c) emulsion (d) true solution.
Answer: (A) b; (B) c — lyophilic sol; (C) c — promoter; (D) b — gel.
2. Answer in one sentence: (A) Type of adsorption with van der Waals forces. (B) Type of adsorption in which a compound is formed. (C) Equation for the Freundlich isotherm.
Answer: (A) Physical adsorption (physisorption). (B) Chemical adsorption (chemisorption), e.g. N₂ on iron at high temperature forming iron nitride. (C) x/m = kP¹ᐟⁿ (n > 1), or in log form log(x/m) = log k + (1/n) log P.
3. Define: (a) inhibition (b) electrophoresis (c) catalysis. Also define adsorption and explain why students can read what is written on a blackboard with chalk.
Answer: (a) Inhibition is the slowing down of a reaction by an added substance (an inhibitor), e.g. ethanol checks the oxidation of chloroform to COCl₂. (b) Electrophoresis is the movement of colloid particles towards one electrode when an electric potential is applied across a sol. (c) Catalysis is the speeding up of a reaction by a substance that remains chemically unchanged at the end, e.g. Fe in the Haber process. Adsorption is the concentration of a substance at the surface of a solid or liquid. The rough, porous surface of the blackboard adsorbs and holds the fine chalk particles, so a thin white layer stays on the surface and the writing is visible.
4. Write the characteristics of adsorption, and explain why 'adsorption is a surface phenomenon'.
Answer: Characteristics: (1) it occurs only at the surface — the adsorbate does not enter the bulk; (2) it is exothermic, so it decreases with rise in temperature; (3) it increases with the surface area of the adsorbent; (4) for gases it increases with pressure until the surface is covered; (5) it is quick and, for physisorption, reversible; (6) easily liquefiable gases are adsorbed more; (7) it may be physical (non-specific) or chemical (specific). It is a surface phenomenon because the driving force — the unbalanced attraction of the particles in the outermost layer — exists only at the surface, so the adsorbate gathers there and its concentration is high only at the surface, not throughout the solid.
5. Distinguish between (A) lyophobic and lyophilic sols; (B) adsorption and absorption, with an example; (C) physisorption and chemisorption, with an example.
Answer: (A) Lyophilic: formed by direct mixing; reversible; self-stabilised; coagulated only by large amounts of electrolyte; viscosity much higher and surface tension lower than the medium; particles hard to see even in an ultramicroscope (e.g. starch, gum). Lyophobic: need special methods; irreversible; unstable without a trace of stabiliser; coagulated by small amounts of electrolyte; viscosity and surface tension about the same as the medium; particles detectable in an ultramicroscope (e.g. gold, Fe(OH)₃, As₂S₃ sols). (B) Adsorption: surface phenomenon, concentration high only at the surface, depends on surface area, T and P, releases heat — acetic acid or a dye on activated charcoal. Absorption: bulk phenomenon, uniform concentration, (as the book states) independent of surface area, no heat of adsorption — water in cotton, ink in blotting paper. (C) See the comparison table: physisorption — van der Waals forces, 20–40 kJ mol⁻¹, non-specific, reversible, multilayer, low T (N₂ on Fe at low T); chemisorption — chemical bonds, 40–200 kJ mol⁻¹, specific, irreversible, monolayer, favoured by higher T (N₂ on Fe at high T giving iron nitride).
6. Identify the dispersed phase and dispersion medium in (a) milk (b) blood (c) printing ink (d) fog.
Answer: (a) Milk: liquid fat in water (emulsion, o/w). (b) Blood: plasma proteins and antibodies (solid) in water (sol); cells and platelets make it partly a suspension. (c) Printing ink: fine solid pigment/carbon particles in a liquid (sol). (d) Fog: liquid water droplets in air (aerosol).
7. Write notes on (a) Tyndall effect (b) Brownian motion (c) types of emulsion (d) Hardy–Schulze rule.
Answer: (a) When light passes through a colloid, the particles scatter it and the beam's path is seen from the side as a bright Tyndall cone; a true solution shows nothing. Needed: particle diameter not much smaller than the wavelength, and a large refractive-index difference between the phases. Used to tell colloids from solutions and to estimate particle size and number. (b) Continuous random zig-zag movement of colloid particles, caused by uneven collisions with fast-moving molecules of the medium, which give the particles kinetic energy; first seen in pollen by Robert Brown and explained by Einstein (1905). It helps keep sols from settling. (c) Oil-in-water (oil dispersed, water continuous — milk, vanishing cream; dilutable by water; conducts with a little electrolyte; water-soluble soaps as emulsifiers) and water-in-oil (water dispersed, oil continuous — butter, cod-liver oil; dilutable by oil; non-conducting; insoluble Zn, Al, Fe or alkaline-earth soaps as emulsifiers). (d) The coagulating power of an added ion increases with its charge; the effective ion has charge opposite to the sol. Negative sols: Al³⁺ > Ba²⁺ > Na⁺. Positive sols: [Fe(CN)₆]⁴⁻ > PO₄³⁻ > SO₄²⁻ > Cl⁻.
8. Explain electrophoresis with a diagram description and give its applications.
Answer: Apparatus: a U-tube holds the sol, with a layer of water above it in each limb and a platinum electrode dipping into each limb. When a potential is applied, the sol boundary moves down in one limb and up in the other because the charged particles drift towards the electrode of opposite sign and get discharged and deposited there — positive sols (Fe(OH)₃) go to the cathode, negative sols (As₂S₃, gold) to the anode. Applications: (1) finding the sign of charge on sol particles; (2) measuring how fast sol particles migrate; (3) separating a mixture of colloids that move at different rates; (4) coagulating a sol (particles lose their charge at the electrode).
9. Explain: (H/4A) why a finely divided substance is a better adsorbent; (J) raw sugar solution passed over animal charcoal becomes colourless; (K) what happens when light is passed through a sol.
Answer: (H) Adsorption occurs only at the surface; dividing a solid finely enormously increases the surface area per gram (for spheres, area/volume = 3/r), and also creates more edges and active sites, so more adsorbate is held. (J) Animal charcoal is a porous adsorbent with a huge surface; the coloured impurities in raw sugar syrup are adsorbed on it while the sugar passes through, so the solution comes out colourless. (K) The particles scatter the light, so the beam's path is seen as a bright cone from the side — the Tyndall effect.
10. (I/4B) What is an adsorption isotherm? Explain the Freundlich isotherm with its graph.
Answer: An adsorption isotherm is a graph showing how x/m (mass adsorbed per unit mass of adsorbent) varies with equilibrium pressure (or concentration) at constant temperature. Freundlich: x/m = kP¹ᐟⁿ (n > 1). The x/m vs P curve rises quickly at low pressure and levels off (saturation) at high pressure. Taking logs, log(x/m) = log k + (1/n) log P, so log(x/m) against log P is a straight line with slope 1/n (0 to 1) and intercept log k. If 1/n = 1, x/m ∝ P; if 1/n → 0, x/m is independent of P. It is valid only over a limited range of pressure.
11. (L/7) Mention the factors affecting adsorption of gases on solids, explaining the role of the nature of adsorbate and adsorbent and of surface area.
Answer: (1) Nature of the gas: easily liquefiable gases with high critical temperature (SO₂, Cl₂, NH₃) are adsorbed much more than N₂, O₂, H₂ — e.g. SO₂ (430 K) 380 cm³ vs N₂ (126 K) 8 cm³ on charcoal. (2) Nature of the adsorbent: porous solids like activated charcoal and silica gel are effective; chemisorption also needs the right chemistry (H₂ on Ni). (3) Surface area: more area per gram (fine powder, rough or porous surface, colloidal particles) means more adsorption. (4) Temperature: adsorption is exothermic, so it decreases as temperature rises. (5) Pressure: x/m increases with pressure, then becomes constant when the surface is fully covered.
12. (M/8) Give four uses of adsorption; (N) explain Bredig's arc method; (O/9) explain emulsions and micelle formation in soap solution.
Answer: Uses: gas masks with activated charcoal remove poisonous gases; silica gel controls humidity; solid catalysts such as Ni in hydrogenating oils and Fe in the Haber process; fluorescein as an adsorption indicator in AgNO₃–NaCl titration; froth flotation of sulfide ores; chromatography; high vacuum with cooled charcoal. Bredig's arc: two rods of the metal (Au, Ag, Pt) dip in water containing a trace of alkali, kept cold in an ice bath; an electric arc between the tips vaporises the metal and the vapour condenses in the cold water as colloid-sized particles — dispersion plus condensation. Emulsions: colloids of one liquid dispersed in another immiscible liquid — o/w (milk) or w/o (butter). Micelles: a soap ion (e.g. C₁₇H₃₅COO⁻) has a long hydrophobic tail and a hydrophilic COO⁻ head; above a certain concentration the ions cluster into spheres with tails pointing to the centre (away from water) and heads on the surface in contact with water, giving a stable colloidal dispersion that can trap grease in its core.
13. (10) Describe the labelled diagrams of (a) Tyndall effect (b) dialysis (c) Bredig's arc (d) soap micelle.
Answer: (a) A light source and lens sending a beam through two beakers: a true solution (no visible path) and a colloid (bright Tyndall cone), with the observer viewing at right angles. (b) A membrane bag (parchment/cellophane) holding the sol, hung in a vessel with fresh water flowing in and out; labels: colloidal particles inside, ions/electrolyte diffusing out. (c) Two metal electrodes connected to a DC supply, their tips under water in a beaker placed in an ice bath, with the arc between the tips; labels: metal electrodes, arc, dispersion medium, ice. (d) A sphere with hydrocarbon tails pointing inward and COO⁻ heads on the surface, surrounded by water molecules; labels: hydrophobic tail, hydrophilic head, water.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Adsorption of a gas on a solid is generally…
Answer: A. Heat is released, so it falls with rising temperature.
2. Which is an example of absorption rather than adsorption?
Answer: A. Water spreads through the whole cotton.
3. Chemisorption usually forms…
Answer: B. Bonds form only with surface sites.
4. Which gas will be adsorbed most on charcoal?
Answer: D. SO₂ has the highest critical temperature (430 K).
5. In the Freundlich plot of log(x/m) against log P, the slope equals…
Answer: A. log(x/m) = log k + (1/n) log P.
6. In the Haber process, K₂O acts as a…
Answer: A. It boosts the iron catalyst.
7. Hydrolysis of sucrose catalysed by H⁺ is an example of…
Answer: A. Reactants and catalyst are all in solution.
8. Pd/Al₂O₃ gives acetaldehyde but Ag/Al₂O₃ gives ethylene oxide from C₂H₄ + O₂. This shows…
Answer: D. Same reactants, different products.
9. Gum in water is a…
Answer: C. Gum has strong affinity for water.
10. Fruit jelly or jam is an example of a…
Answer: C. Liquid dispersed in a solid.
11. The size of colloid particles lies between…
Answer: D. About 1 nm to 1 µm.
12. Soap forms colloids in water as…
Answer: C. They are associated colloids.
13. Which ion is the best coagulant for a negatively charged As₂S₃ sol?
Answer: D. Opposite and highest charge — Hardy–Schulze.
14. A precipitate is turned into a sol by shaking with a little electrolyte. This is…
Answer: D. The electrolyte is the peptizing agent.
15. The path of a light beam becomes visible in a colloid due to…
Answer: D. Particles scatter the light.
