Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 174–189
Why does a cobalt chloride solution turn blue when hot and pink when cold, and why does a Haber plant run at about 500 °C and 200–250 atm? This chapter covers reversible and irreversible reactions, physical and chemical equilibria, the law of mass action, Kc and Kp and the link Kp = Kc(RT)^Δn, units of Kc, heterogeneous equilibria, the reaction quotient Q, calculating equilibrium concentrations, Le Chatelier's principle and the Haber process — with fully worked numericals and answers to every exercise.
An irreversible reaction runs one way until a reactant is used up (CaCO₃ heated in an open vessel, KClO₃ decomposing). A reversible reaction runs both ways at once; in a closed vessel it reaches equilibrium, where the forward and backward rates are equal and concentrations stop changing. The reactions do not stop, so the equilibrium is dynamic.
Physical processes also reach equilibrium: liquid ⇌ vapour (constant saturated vapour pressure), ice ⇌ water at 273 K, solid ⇌ vapour (iodine, camphor, NH₄Cl) and solid ⇌ dissolved solute in a saturated solution. The same equilibrium can be reached starting from either side, as with H₂ + I₂ ⇌ 2HI.
Law of mass action: rate ∝ product of reactant concentrations, each raised to its coefficient. For aA + bB ⇌ cC + dD, Kc = kf/kr = [C]^c[D]^d ÷ [A]^a[B]^b. For gases Kp uses partial pressures and Kp = Kc(RT)^Δn. Pure solids and liquids are left out of K. The unit of Kc is (mol dm⁻³)^Δn.
Kc depends only on temperature and the way the equation is written; reversing the equation gives 1/Kc. Large K (> 10³) means the reaction almost goes to completion; small K (< 10⁻³) means hardly any product. Comparing the reaction quotient Qc with Kc tells the direction: Q < K forward, Q = K at equilibrium, Q > K backward.
Le Chatelier's principle: a system at equilibrium shifts to reduce any imposed change. Adding a reactant or removing a product shifts it forward; higher pressure favours the side with fewer gas molecules; heating favours the endothermic direction and changes K; a catalyst only helps equilibrium come sooner. In the Haber process N₂ + 3H₂ ⇌ 2NH₃ (exothermic, Δn = −2) an optimum of about 773 K, about 250 atm and an iron catalyst gives a good yield at a good rate.
Get a ✓ Verified tutor for “Chemical Equilibrium” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
For N₂O₄(g) ⇌ 2NO₂(g), Kc = 4.6 × 10⁻³ mol L⁻¹ at 298 K. Find Kp (R = 0.08314 L bar K⁻¹ mol⁻¹).
Answer: Kp ≈ 0.11 bar.
Write Kc and its unit for (i) CO(g) + 2H₂(g) ⇌ CH₃OH(g) and (ii) CaCO₃(s) ⇌ CaO(s) + CO₂(g).
Answer: (i) Kc = [CH₃OH]/([CO][H₂]²), mol⁻² dm⁶; (ii) Kc = [CO₂], mol dm⁻³.
1.0 mol H₂ and 1.0 mol I₂ are heated in a 1.0 L sealed flask. Kc for H₂ + I₂ ⇌ 2HI is 49 at this temperature. Find the equilibrium concentrations.
Answer: [HI] ≈ 1.56 mol L⁻¹; [H₂] = [I₂] ≈ 0.22 mol L⁻¹.
| Change | Shift in position | Value of K |
|---|---|---|
| Add a reactant / remove a product | forward (to the right) | no change |
| Add a product / remove a reactant | backward (to the left) | no change |
| Increase pressure (decrease volume) | towards fewer gas molecules | no change |
| Decrease pressure (increase volume) | towards more gas molecules | no change |
| Pressure change when Δn(gas) = 0 | no shift (e.g. H₂ + I₂ ⇌ 2HI) | no change |
| Raise temperature | endothermic direction | K changes (falls for exothermic forward reaction) |
| Lower temperature | exothermic direction | K changes (rises for exothermic forward reaction) |
| Add a catalyst | no shift; equilibrium reached sooner | no change |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option: (A) H₂O(l) ⇌ H⁺(aq) + OH⁻(aq) is (a) dynamic (b) static (c) physical (d) mechanical. (B) For A ⇌ 2B + heat, the number of A molecules increases if (a) volume is increased (b) temperature is increased (c) catalyst is added (d) [B] is decreased. (C) For Cl₂(g) + 2NO(g) ⇌ 2NOCl(g), [NOCl] increases on (a) adding Cl₂ (b) removing NO (c) adding NOCl (d) removing Cl₂.
Answer: (A) a — dynamic; (B) b — temperature is increased; (C) a — adding Cl₂.
2. (D) The relation between Kc and Kp for A(g) + B(g) ⇌ 2C(g) + D(g) is: (a) Kc = Y Kp (b) Kp = Kc² (c) Kc = 1/√Kp (d) Kp/Kc = 1. (E) When the volume of C + H₂O(g) ⇌ CO(g) + H₂(g) is increased at constant temperature the equilibrium will (a) shift left to right (b) shift right to left (c) be unaltered (d) cannot be predicted.
Answer: (D) The correct relation is Kp = Kc·RT (Kp/Kc = RT). None of the printed options states this exactly; the book's options appear garbled — option (d) would be right only if Δn were 0. (E) With carbon as a solid (the real reaction): (a) shifts from left to right. The book prints C(g); taken literally, Δn = 0 and the answer would be (c) unaltered.
3. (A) State the law of mass action. (B) Write the expression for Kc. (D) Write Kc for (i) 2SO₂(g) + O₂(g) ⇌ 2SO₃(g) and (ii) N₂O₄(g) ⇌ 2NO₂(g).
Answer: (A) The rate of a reaction at any instant is proportional to the product of the molar concentrations of the reactants, each raised to a power equal to its coefficient in the balanced equation. (B) For aA + bB ⇌ cC + dD, Kc = [C]^c[D]^d ÷ ([A]^a[B]^b), with equilibrium concentrations in mol dm⁻³. (D)(i) Kc = [SO₃]² ÷ ([SO₂]²[O₂]); Δn = −1, unit mol⁻¹ dm³. (ii) Kc = [NO₂]² ÷ [N₂O₄]; Δn = +1, unit mol dm⁻³.
4. (C/3B) Derive the relation between Kp and Kc, and apply it to A(g) + B(g) ⇌ C(g) + D(g).
Answer: Kp = Kc(RT)^Δn in general; for A(g) + B(g) ⇌ C(g) + D(g), Kp = Kc.
5. (E) Mention applications of the equilibrium constant. (F) How does a change of pressure affect the value of K?
Answer: (E) (1) Predicting the extent of reaction — large K (> 10³) means nearly complete, small K (< 10⁻³) means very little product. (2) Predicting the direction — compare Qc with Kc: Q < K forward, Q > K backward, Q = K equilibrium. (3) Calculating equilibrium concentrations from initial amounts. (4) Linking to kinetics through Kc = kf/kr. (F) Pressure does not change K at all; K depends only on temperature. A pressure change may shift the position of equilibrium (when Δn ≠ 0) until the ratio again equals the same K.
6. (J/3D) Differentiate irreversible and reversible reactions; explain rate of reaction. (L) Relate reversible reactions and dynamic equilibrium.
Answer: Irreversible: proceeds in one direction only, goes to completion until a reactant is used up, single arrow, often in open vessels — C + O₂ → CO₂, 2KClO₃ → 2KCl + 3O₂, CaCO₃ heated in an open vessel. Reversible: proceeds both ways simultaneously, never goes to completion, double arrow, reaches equilibrium in a closed vessel — H₂ + I₂ ⇌ 2HI, N₂O₄ ⇌ 2NO₂. Rate of reaction is the change in concentration of a reactant or product per unit time, −d[R]/dt = +d[P]/dt (mol dm⁻³ s⁻¹). Relation: only a reversible reaction in a closed system can reach equilibrium; there the forward and reverse rates become equal while both reactions continue, so the equilibrium reached is dynamic, not static.
7. (K) Write suitable conditions of concentration, temperature and pressure for the manufacture of ammonia by the Haber process.
Answer: Concentration: N₂ and H₂ in a 1 : 3 volume ratio, with excess reactants and continuous removal of NH₃ by liquefaction and recycling of unreacted gases — this keeps shifting the equilibrium forward. Temperature: the reaction is exothermic, so low temperature favours NH₃, but the rate would be too slow; an optimum of about 773 K (500 °C) is used (the diagram in the book shows 450 °C). Pressure: fewer gas molecules on the right, so high pressure favours NH₃; an optimum of about 200–250 atm is used because very high pressure is costly and lowers catalyst efficiency. Catalyst: finely divided iron with molybdenum (K₂O, Al₂O₃ as promoters).
8. (M) For BaSO₄(s) ⇌ Ba²⁺(aq) + SO₄²⁻(aq), state the effect of (a) adding Ba²⁺ (b) removing SO₄²⁻ (c) adding BaSO₄(s). (3E) What is the effect of adding chloride on AgCl(s) ⇌ Ag⁺(aq) + Cl⁻(aq)?
Answer: (a) Adding Ba²⁺ raises Q above K, so the equilibrium shifts left and more BaSO₄ precipitates. (b) Removing SO₄²⁻ lowers Q, so the equilibrium shifts right and more BaSO₄ dissolves. (c) Adding solid BaSO₄ has no effect, since a pure solid does not appear in K. For AgCl, added Cl⁻ (common ion) shifts the equilibrium to the left, so more AgCl precipitates and [Ag⁺] falls; K is unchanged.
9. (3A) Explain the dynamic nature of chemical equilibrium with an example. (3C) State and explain Le Chatelier's principle with reference to change in temperature and concentration.
Answer: (3A) Heat H₂ and I₂ in a sealed flask: the violet colour fades, then stays constant — the mixture contains H₂, I₂ and HI in fixed amounts. Starting from pure HI gives the same final mixture. If some radioactive iodine were added, it would soon be found in both I₂ and HI, showing that HI keeps forming and decomposing; only the rates are equal. Hence equilibrium is dynamic. (3C) Le Chatelier's principle: when a system at equilibrium is subjected to a change in concentration, pressure or temperature, it adjusts to minimise that change. Temperature: in N₂ + 3H₂ ⇌ 2NH₃ + heat, raising temperature favours the endothermic backward reaction, reducing NH₃ and lowering K; cooling does the reverse (as CO + 2H₂ ⇌ CH₃OH shows, Kc falls from 1.7 × 10¹⁷ at 298 K to 2.1 × 10⁶ at 1000 K). Concentration: adding N₂ or H₂ makes Qc < Kc, so more NH₃ forms until Qc = Kc again; removing NH₃ has the same effect. K stays the same.
10. Numerical (book Problems 12.5 and 12.6): equal amounts of H₂ and I₂ reach equilibrium at 700 K with [HI] = 0.85 mol dm⁻³ and Kc = 54. Find [H₂] and [I₂]. Then, if kr = 1.16 × 10⁻³, find kf.
Answer: [H₂] = [I₂] ≈ 0.12 mol dm⁻³; kf ≈ 6.26 × 10⁻² (same units as kr), i.e. kf is 54 times kr.
11. Numerical: 1.0 mol CH₃COOH and 2.0 mol C₂H₅OH are mixed; Kc for CH₃COOH + C₂H₅OH ⇌ CH₃COOC₂H₅ + H₂O is 4.0. How much ester is present at equilibrium? (Extends the book's 2.0 + 2.0 mol example, where x = 1.33 mol.)
Answer: About 0.85 mol ester (and water); 0.15 mol acid and 1.15 mol alcohol remain — excess alcohol raises the conversion of acid from 67% to about 85%.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The equilibrium H₂O(l) ⇌ H⁺(aq) + OH⁻(aq) is…
Answer: D. Ionisation and recombination continue at equal rates.
2. For A ⇌ 2B + heat, the number of A molecules increases if…
Answer: B. Heating favours the endothermic backward reaction.
3. For Cl₂(g) + 2NO(g) ⇌ 2NOCl(g), [NOCl] increases on…
Answer: C. Adding a reactant shifts the equilibrium forward.
4. For N₂ + 3H₂ ⇌ 2NH₃, Kp = …
Answer: A. Δn = 2 − 4 = −2.
5. For 2A(g) + B(g) ⇌ C(g) + D(g), the unit of Kc is…
Answer: B. Δn = 2 − 3 = −1.
6. Which is a heterogeneous equilibrium?
Answer: B. Solids and a gas — more than one phase.
7. If Kc for a reaction is 4 × 10⁻², Kc for the reverse reaction is…
Answer: C. 1 ÷ 0.04 = 25.
8. For a reaction at equilibrium, Qc is found to be greater than Kc after a change. The reaction will…
Answer: C. Too much product, so it is used up.
9. Which change alters the value of Kc?
Answer: A. K depends only on temperature.
10. Increasing pressure has no effect on the position of…
Answer: D. Equal gas molecules on both sides.
11. H₂(g) ⇌ 2H(g) has Kc = 1.2 × 10⁻⁴² at 500 K. The mixture is mainly…
Answer: D. Very small K: reactant dominates.
12. For CO + 2H₂ ⇌ CH₃OH (ΔH = −90 kJ mol⁻¹), raising the temperature…
Answer: A. Exothermic forward: K falls with heating.
13. For BaSO₄(s) ⇌ Ba²⁺(aq) + SO₄²⁻(aq), adding more solid BaSO₄…
Answer: C. A pure solid is not in the K expression.
14. Kc for H₂ + I₂ ⇌ 2HI is 54.0 at 700 K and kr = 1.16 × 10⁻³. kf is…
Answer: B. kf = Kc × kr.
15. The optimum temperature used in the Haber process is about…
Answer: A. A compromise between yield and rate.
