Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 27–34
Before a chemist can study a substance, it has to be pure. Learn how solids are purified (filtration, suction filtration, crystallization, fractional crystallization), how liquids are separated (simple, fractional and reduced-pressure distillation), solvent extraction, and chromatography — column, thin layer and paper — with Rf calculations and answers to every exercise question.
Natural and freshly made substances are impure, so they must be purified before analysis. Every purification method exploits a difference in a physical property — solubility, boiling point or adsorption.
Insoluble impurities are removed by filtration; suction filtration with a Buchner funnel is faster. Crystallization (saturated solution → hot filtration → cooling → filtration) removes both soluble and insoluble impurities; fractional crystallization separates solids whose solubilities differ widely.
Distillation separates a volatile liquid from non-volatile impurities or liquids with different boiling points. Simple distillation suits large boiling-point gaps (acetone 56 °C / water 100 °C); fractional distillation with a fractionating column handles close boiling points (crude oil); distillation under reduced pressure purifies high-boiling or heat-sensitive liquids (glycerol from soap waste).
Solvent extraction transfers a solute from water into an immiscible organic solvent in which it is more soluble; continuous (Soxhlet) extraction reuses the same solvent when solubility is low.
Chromatography (Tswett, 1903) separates components by their different distribution between a stationary and a mobile phase. Adsorption chromatography (column, TLC) uses a solid stationary phase; partition chromatography (paper) uses a liquid one — water held in the paper. Rf = distance moved by solute ÷ distance moved by solvent front.
Get a ✓ Verified tutor for “Some Analytical Techniques” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
You have a mixture of common salt and sand. Plan how to recover dry, clean salt.
Answer: Dissolve → filter (sand removed as residue) → crystallize/evaporate the filtrate → dry pure salt.
A hot saturated solution contains A (solubility at 20 °C: 7 g per 100 g water) and B (solubility at 20 °C: 36 g per 100 g water). On cooling to 20 °C, which separates first, and how is the other obtained?
Answer: A crystallizes first; B is recovered from the concentrated mother liquor — this is fractional crystallization.
Choose a method: (a) pure water from salt water, (b) ethanol (78 °C) from propan-1-ol (97 °C), (c) glycerol (b.p. 290 °C, decomposes) from soap waste, (d) acetone (56 °C) from water (100 °C).
Answer: (a) simple distillation (b) fractional distillation (c) distillation under reduced pressure (d) simple distillation.
Iodine is to be removed from its water solution. Which of ethanol and carbon tetrachloride would you use, and why?
Answer: Carbon tetrachloride — immiscible with water and a much better solvent for iodine.
In a TLC run the solvent front moved 8.0 cm from the base line. Spot P moved 3.6 cm and spot Q moved 6.0 cm. Find their Rf values and say which is more strongly adsorbed.
Answer: Rf(P) = 0.45, Rf(Q) = 0.75; P is more strongly adsorbed.
A green ink is run on paper; the solvent front travels 12.0 cm. A blue dye has Rf 0.80 and a yellow dye Rf 0.30. How far from the base line is each spot, and how far apart are they?
Answer: Blue at 9.6 cm, yellow at 3.6 cm; the spots are 6.0 cm apart.
| Technique | Based on | Typical use |
|---|---|---|
| Filtration | insolubility of one component | sand from water; tea leaves |
| Suction filtration | pressure difference (vacuum pump) | fast collection of crystals |
| Crystallization | solubility rises with temperature | CuSO₄, benzoic acid, common salt |
| Fractional crystallization | widely different solubilities | separating two soluble salts |
| Simple distillation | large boiling-point difference | acetone (56 °C) from water (100 °C) |
| Fractional distillation | small boiling-point difference | crude oil; acetone/methanol |
| Reduced-pressure distillation | lower pressure lowers boiling point | glycerol from soap waste |
| Solvent extraction | greater solubility in an immiscible solvent | organic solute from water |
| Column / TLC | differential adsorption on silica or alumina | separating coloured or colourless mixtures |
| Paper chromatography | partition between water in paper and solvent | dyes, inks, amino acids; Rf values |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option. (A) Separating two compounds with different solubilities in one solvent: fractional crystallization / crystallization / distillation / solvent extraction. (B) Glycerol from soap: reduced-pressure distillation / fractional distillation / filtration / crystallization. (C) Widely used in industry to separate and purify: steam distillation / chromatography / solvent extraction / filtration. (D) Acetone and benzene: simple distillation / fractional distillation / reduced-pressure distillation / sublimation. (E) Colourless components can NOT be observed using: UV light / iodine chamber / spraying reagent / infrared light.
Answer: (A) a. fractional crystallization (B) a. distillation under reduced pressure (C) b. chromatography (D) b. fractional distillation (E) d. infrared light
2. 2. (A) Purification of solid organic compounds: crystallization or distillation? (B) Residue and filtrate. (C) Why is a condenser used in distillation? (D) Why is the paper moistened before filtration? (E) Stationary phase in paper chromatography. (F) What happens if the upper outlet of the condenser is connected to the tap instead of the lower one? (G) Two stationary-phase materials.
Answer: (A) Crystallization. (B) Residue: the insoluble solid left on the filter paper; filtrate: the clear liquid that passes through. (C) It cools the hot vapour so it condenses back to liquid that can be collected in the receiver. (D) Wet paper clings to the funnel without air pockets, so filtration is smooth and fast, and the dry paper does not soak up part of the solution. (E) Water held in the fibres of the chromatography paper. (F) Water fed from the top would run straight out of the lower outlet; the jacket would never fill, so cooling would be poor and much vapour would escape uncondensed. (G) Silica gel and alumina.
3. 2. (H) Properties of solvents useful for extraction. (I) Why is the spot placed above the mobile phase? (J) Define stationary phase and saturated solution. (K) Simple vs fractional distillation. (L) Define solvent extraction and distillation. (M) Properties of a solvent suitable for crystallization.
Answer: (H) It must be immiscible with water (two layers), dissolve the solute much better than water, not react with it, and be volatile enough to remove by distillation. (I) If the spot dipped into the solvent, the sample would dissolve away into the solvent pool instead of being carried up the paper or plate, so no separation would be seen. (J) Stationary phase: the solid or liquid that stays fixed in chromatography (silica gel, alumina, water in paper). Saturated solution: one that can dissolve no more solute at that temperature. (K) Simple distillation separates liquids with a large boiling-point gap or a liquid from non-volatile matter, using flask–condenser–receiver; fractional distillation separates liquids with close boiling points and needs a fractionating column in which vapour and liquid exchange many times. (L) Solvent extraction: removing a solute from water by shaking with an immiscible solvent in which it is more soluble. Distillation: boiling a liquid and condensing its vapour to collect the pure liquid. (M) The compound is sparingly soluble cold but very soluble hot; the solvent does not react with it; it is volatile and easily removed (e.g. water, ethanol, acetone).
4. 2. (N) Name the types of chromatography and give their principles. (O) Why do bands appear in column chromatography? (P) How are colourless compounds seen in TLC and paper chromatography? (Q) Compare TLC and paper chromatography.
Answer: (N) Adsorption chromatography — column and thin layer — depends on differential adsorption of components on a solid (silica gel or alumina). Partition chromatography — paper — depends on continuous differential partitioning of components between two liquids (water held in the paper and the moving solvent). (O) Each component is adsorbed to a different extent, so it moves down at its own speed; components therefore spread into separate zones (bands), the weakly held ones furthest down. (P) Under UV light if they fluoresce; in a closed jar with iodine crystals, where they turn brown; or by spraying a reagent such as ninhydrin (amino acids). (Q) TLC: stationary phase is a thin silica or alumina layer on glass; works by adsorption; faster, sharper spots, plate reusable only once. Paper: stationary phase is water in Whatman No. 1 paper; works by partition; cheaper and simpler but slower. Both use a spot about 2 cm above the end, a closed chamber, capillary rise of solvent, the same ways of seeing colourless spots, and Rf values.
5. 3. Label the diagram (a funnel on a conical flask with a side arm and rubber tube) and explain the process.
Answer: This is filtration under suction. A circle of filter paper is laid on the perforated base of the Buchner funnel and wetted. The funnel is fitted to the side-arm flask with a rubber cork; the side arm is joined through a safety bottle to a vacuum pump. When the pump runs, air pressure above forces the liquid quickly through the paper; the crystals (residue) stay on the paper and the filtrate collects in the flask. The safety bottle prevents filtrate from being sucked into the pump. It is much faster than ordinary filtration — useful in hot filtration during crystallization.
6. Activity / Book box: Describe how impure market salt is purified by crystallization, and how an acetone–water mixture is separated.
Answer: Salt: insoluble siliceous matter stays on the paper during hot filtration; soluble impurities stay in the mother liquor; larger crystals of pure NaCl are obtained. Acetone–water: simple distillation works because the boiling points differ by 44 °C.
7. Own numerical (Rf): On a paper chromatogram the solvent front is 10.0 cm from the base line. Spots of three dyes are at 2.4 cm, 5.5 cm and 8.1 cm. Find their Rf values and identify the dye that is least attracted to the stationary phase.
Answer: Rf = 0.24, 0.55 and 0.81; the dye with Rf 0.81 travels furthest, so it is least held by the stationary phase.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Two compounds with different solubilities in the same solvent are separated by…
Answer: D. The less soluble one crystallizes first.
2. Glycerol is separated from soap waste by…
Answer: D. It decomposes near its normal boiling point.
3. A technique widely used in industry both to separate and purify components is…
Answer: A. It separates and purifies even tiny amounts.
4. Acetone and benzene are best separated by…
Answer: D. Their boiling points are fairly close (329 K and 353 K).
5. Colourless spots on a chromatogram can NOT be detected using…
Answer: A. The book lists UV, iodine and spraying agents.
6. Solid organic compounds are usually purified by…
Answer: B. Distillation is for liquids.
7. In crystallization, soluble impurities end up in the…
Answer: B. They never saturate the solution.
8. The Buchner funnel is used in…
Answer: B. It has a flat porous base for the paper.
9. In a distillation set-up the thermometer bulb is placed…
Answer: C. It must read the vapour temperature.
10. The fractionating column works because…
Answer: A. Each exchange enriches the vapour in the volatile part.
11. A solvent for extracting a solute from water must be…
Answer: C. Two layers must form.
12. Amino acid spots are made visible by spraying…
Answer: D. Ninhydrin gives coloured spots.
13. Paper chromatography is an example of…
Answer: A. Both phases are liquids.
14. A solute moves 4.5 cm while the solvent front moves 9.0 cm. Rf is…
Answer: A. 4.5 ÷ 9.0.
15. In column chromatography the component eluted first is the one that is…
Answer: D. It is held back least.
