Structure of AtomClass 11 Chemistry Chapter 4 Notes – Maharashtra Board

Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 35–54

What is inside an atom, and how are its electrons arranged? Learn the discovery of the electron, proton and neutron, atomic and mass numbers, isotopes, isobars and isotones, the failure of Rutherford's model, electromagnetic radiation and Planck's quantum, the hydrogen spectrum and Bohr's model, de Broglie and Heisenberg, the four quantum numbers, shapes of orbitals, and the aufbau, Pauli and Hund rules for writing electronic configurations — with solved numericals and every exercise answered.

🎧 Listen to the summary

Summary: Structure of Atom

Atoms contain electrons (Thomson, 1897), protons (Rutherford, 1911–1919) and neutrons (Chadwick, 1932). Protons and neutrons (nucleons) form the nucleus. Atomic number Z = number of protons; mass number A = Z + N. Isotopes share Z, isobars share A, isotones share N.

Rutherford's planetary model could not explain why a revolving (accelerated) electron does not radiate energy and spiral into the nucleus, nor how electrons are arranged. Light has a dual nature: wave (c = νλ) and particle (photon energy E = hν, Planck 1900).

Hydrogen gives a line spectrum whose wavenumbers fit the Rydberg equation ν̄ = 109677 (1/n₁² − 1/n₂²) cm⁻¹ (Lyman, Balmer, Paschen, Brackett, Pfund series). Bohr (1913) explained it with fixed stationary orbits: Eₙ = −2.18 × 10⁻¹⁸ (Z²/n²) J, rₙ = 52.9 n²/Z pm, mvr = nh/2π.

Bohr's model failed for many-electron atoms, fine spectral details, Zeeman and Stark effects and bonding. De Broglie (λ = h/mv) and Heisenberg (Δx·Δp ≥ h/4π) led to Schrödinger's quantum mechanical model (Ĥψ = Eψ), where ψ² gives the probability of finding the electron and orbitals are described by n, l, mₗ and mₛ.

s orbitals are spherical, p dumb-bell shaped (px, py, pz), and d mostly double dumb-bell (five orbitals). Electrons fill orbitals by the aufbau principle using the (n + l) rule, with at most two opposite-spin electrons per orbital (Pauli) and single occupation before pairing (Hund). Half-filled and full subshells give extra stability, so Cr is [Ar] 4s¹ 3d⁵ and Cu [Ar] 4s¹ 3d¹⁰.

Key points to remember

  • Electron: charge −1.6022 × 10⁻¹⁹ C, mass 9.109 × 10⁻³¹ kg; proton +1.6022 × 10⁻¹⁹ C, 1.6726 × 10⁻²⁷ kg; neutron neutral, 1.6749 × 10⁻²⁷ kg
  • A = Z + N; for a neutral atom, protons = electrons = Z
  • Isotopes: same Z, different A (¹²C, ¹³C, ¹⁴C); isobars: same A, different Z (¹⁴C, ¹⁴N); isotones: same N (¹¹B, ¹²C — both 6 neutrons)
  • c = νλ; ν̄ = 1/λ; E = hν = hc/λ; h = 6.626 × 10⁻³⁴ J s; c = 3.0 × 10⁸ m s⁻¹
  • Rydberg equation: ν̄ = 109677 (1/n₁² − 1/n₂²) cm⁻¹; Lyman n₁ = 1 (UV), Balmer 2 (visible), Paschen 3, Brackett 4, Pfund 5 (infrared)
  • Bohr: Eₙ = −2.18 × 10⁻¹⁸ Z²/n² J; rₙ = 52.9 n²/Z pm; mvr = nh/2π; ν = ΔE/h
  • De Broglie: λ = h/mv; Heisenberg: Δx × Δp ≥ h/4π
  • n = shell (K, L, M, N…), n² orbitals and 2n² electrons per shell; l = 0 to n − 1 (s, p, d, f); mₗ = −l … +l (2l + 1 orbitals); mₛ = +½ or −½
  • (n + l) rule: lower n + l fills first; for equal n + l, the lower n fills first: 1s 2s 2p 3s 3p 4s 3d 4p 5s 4d 5p 6s 4f 5d 6p 7s
  • Pauli: no two electrons in an atom share all four quantum numbers — at most 2 opposite-spin electrons per orbital
  • Hund: in degenerate orbitals, electrons enter singly with parallel spins before pairing
  • Exceptions: Cr = [Ar] 4s¹ 3d⁵ and Cu = [Ar] 4s¹ 3d¹⁰ (extra stability of half-filled and full d subshells)
