Textbook: Chemistry – Class 11 (Balbharati, official free PDF) · pages 55–80
Why do atoms stick together, and why does a water molecule bend while carbon dioxide stays straight? Learn the octet rule, ionic bonds and lattice enthalpy, covalent bonds and Lewis structures, formal charge, limits of the octet rule, VSEPR shapes, valence bond theory with sigma and pi overlap, sp³, sp² and sp hybridisation, molecular orbital theory and bond order, bond parameters, dipole moment, Fajans' rules and resonance — with worked examples and every exercise answered.
Atoms bond to reach a stable noble-gas arrangement (octet, or duplet for H and Li) by transferring electrons (ionic bond) or sharing pairs (covalent bond). Kossel and Lewis proposed this electronic theory of valence in 1916. The stability of an ionic solid comes mainly from the energy released when its crystal lattice forms (lattice enthalpy of NaCl: 788 kJ mol⁻¹).
Lewis structures show bonding pairs and lone pairs; formal charge (FC = V − N − B/2) picks the best structure. The octet rule fails for incomplete octets (BeCl₂, BF₃), expanded octets (PCl₅, SF₆) and odd-electron molecules (NO, NO₂), and it cannot explain shapes or bond energies.
VSEPR theory: electron pairs around the central atom spread out to minimise repulsion (lp–lp > lp–bp > bp–bp). This gives linear, trigonal planar, tetrahedral, trigonal bipyramidal and octahedral arrangements, and bent, pyramidal, see-saw, T-shaped, square pyramidal and square planar shapes when lone pairs are present.
Valence bond theory: a covalent bond forms by overlap of half-filled orbitals with opposite spins. Head-on overlap gives a σ bond, sideways overlap a π bond. Hybridisation (sp³ 109°28′, sp² 120°, sp 180°) explains equal bonds in CH₄, BF₃, BeCl₂, C₂H₄ and C₂H₂. Molecular orbital theory combines atomic orbitals into bonding and antibonding MOs; bond order = (Nb − Na)/2, and it explains why O₂ is paramagnetic.
Bond length falls and bond enthalpy rises as bond order increases (C–C > C=C > C≡C in length). Unequal sharing makes bonds polar; the dipole moment μ = Q × r (debye) of a molecule is the vector sum of bond and lone-pair dipoles. Fajans' rules explain covalent character in ionic compounds, and resonance describes molecules like O₃ and CO₃²⁻ by a lower-energy hybrid of canonical forms.
Get a ✓ Verified tutor for “Chemical Bonding” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Arrange MgO, NaCl and KCl in order of lattice enthalpy and justify.
Answer: MgO > NaCl > KCl — higher charge and smaller ions give larger lattice enthalpy.
Work out the formal charges in the nitrate ion, NO₃⁻, drawn with one N=O and two N–O bonds.
Answer: N +1, the double-bonded O 0, each single-bonded O −1 (total −1).
Predict the shapes of SiCl₄, PCl₃, SF₄ and XeF₄ using VSEPR.
Answer: SiCl₄ tetrahedral; PCl₃ trigonal pyramidal; SF₄ see-saw; XeF₄ square planar.
Count the σ and π bonds in HC≡C–CH=CH₂ (but-1-en-3-yne).
Answer: 7 σ bonds and 3 π bonds.
State the hybridisation of each carbon in propene, CH₃–CH=CH₂, and the bond angles around them.
Answer: C1 sp³ (109.5°); C2 and C3 sp² (120°). Rule: count σ bonds + lone pairs on the atom — 4 → sp³, 3 → sp², 2 → sp.
Use MO theory to find the bond orders of O₂⁺, O₂⁻ and O₂²⁻, arrange them with O₂ by bond length, and state their magnetic nature.
Answer: Bond orders: O₂⁺ 2.5 > O₂ 2 > O₂⁻ 1.5 > O₂²⁻ 1; bond length increases in the same order (O₂⁺ shortest). Only O₂²⁻ is diamagnetic.
HCl has bond length 127 pm and dipole moment 1.03 D. Estimate the percentage ionic character of the H–Cl bond.
Answer: About 17 % ionic character — H–Cl is a polar covalent bond.
| Molecule | Pairs / hybridisation | Shape and bond angle |
|---|---|---|
| BeCl₂, CO₂ | 2 bp, 0 lp; sp | linear, 180° |
| BF₃ | 3 bp, 0 lp; sp² | trigonal planar, 120° |
| C₂H₄ | each C: 3 σ; sp² | planar, about 120°; 1 σ + 1 π between C atoms |
| C₂H₂ | each C: 2 σ; sp | linear, 180°; 1 σ + 2 π between C atoms |
| CH₄ | 4 bp, 0 lp; sp³ | tetrahedral, 109°28′ |
| NH₃ | 3 bp, 1 lp; sp³ | trigonal pyramidal, about 107° |
| H₂O | 2 bp, 2 lp; sp³ | bent (angular), 104.5° |
| PCl₅ | 5 bp, 0 lp | trigonal bipyramidal |
| SF₆ | 6 bp, 0 lp | octahedral, 90° |
| SF₄ / ClF₃ / XeF₄ | AB₄E / AB₃E₂ / AB₄E₂ | see-saw / T-shaped / square planar |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose: (A) Linear molecule: SO₃ / CO₂ / H₂S / Cl₂O. (B) Decreasing strength: covalent > hydrogen > van der Waals' / covalent > van der Waals' > hydrogen / hydrogen > covalent > van der Waals' / van der Waals' > hydrogen > covalent. (C) VSEPR predicts: energy levels / shapes of molecules and ions / electronegativities / type of bonding. (D) For CO₂ — C=O bond and molecule: polar, non-polar / non-polar, polar / polar, polar / non-polar, non-polar. (E) Paramagnetism of O₂ is explained by: hybridisation / VBT / MOT / VSEPR. (F) Minimum angle between two covalent bonds: CH₄ / C₂H₂ / NH₃ / H₂O.
Answer: (A) b. CO₂ (B) a. covalent > hydrogen > van der Waals' (C) b. shapes of molecules and ions (D) A. bond polar, molecule non-polar (E) c. MOT (F) d. H₂O
2. 2. Draw (describe): (A) Lewis dot diagrams of H₂, H₂O, CO₂, CH₄, LiF. (C) Lewis structures of HF, C₂H₆, C₂H₄, CF₃Cl, SO₂. (B) bonding in ethene with sp² hybridisation. (D) orbital diagrams of F₂ and HF.
Answer: (A) H₂: H:H. H₂O: O in the centre with two H–O shared pairs and two lone pairs (8 electrons). CO₂: O=C=O, two lone pairs on each O. CH₄: C with four shared pairs to four H. LiF: Li⁺ [:F:]⁻ — Li transfers its electron, F⁻ shows 8 dots in brackets. (C) HF: H–F with three lone pairs on F. C₂H₆: H₃C–CH₃, seven single bonds, no lone pairs. C₂H₄: H₂C=CH₂, one double and four single bonds. CF₃Cl: C at the centre bonded to 3 F and 1 Cl, three lone pairs on each halogen (32 electrons). SO₂: O=S–O ↔ O–S=O with one lone pair on S (18 electrons; resonance). (B) Each C is sp²: two sp² orbitals overlap H 1s (4 C–H σ), one sp² of each C overlaps head-on (C–C σ); the unhybridised 2p orbitals, perpendicular to the plane, overlap sideways above and below to form the π bond; all atoms lie in one plane with angles near 120°. (D) F₂: half-filled 2pz of each F overlaps head-on → p–p σ bond. HF: half-filled H 1s overlaps head-on with half-filled F 2pz → s–p σ bond.
3. 3. (A) σ vs π bond. (B) Electron distribution around O in water, shape and angle. (C) Octet rule and its inadequacy: incomplete and expanded octet. (D) Ionic, covalent and coordinate bond with one example each.
Answer: (A) σ: head-on overlap along the internuclear axis; can form from s–s, s–p, p–p or hybrid orbitals; strong; electron density on the axis; free rotation; exists alone. π: sideways overlap of parallel p orbitals; weaker; density above and below the axis; restricts rotation; forms only with a σ bond. (B) O (2s² 2p⁴) is sp³: two hybrids each hold one electron and bond with H 1s; two hybrids hold lone pairs — 4 electron pairs around O. Shape bent (angular), H–O–H = 104.5° (104°35′). (C) Atoms lose, gain or share electrons to obtain eight valence electrons. Incomplete octet: B in BF₃ has 6, Be in BeCl₂ 4, Li in LiCl 2 — yet stable. Expanded octet: P in PCl₅ has 10, S in SF₆ and H₂SO₄ 12 — period-3 atoms can use d orbitals. (D) Ionic: transfer of electrons — Na⁺Cl⁻. Covalent: sharing of a pair with one electron from each atom — H–H, Cl–Cl. Coordinate: a shared pair donated entirely by one atom — NH₃ gives its lone pair to H⁺ in NH₄⁺ (H₃N→H⁺).
4. 3. (E) Need for hybridisation. (F) Geometry of CH₄ by hybridisation. (G) Why is NH₃ 107° and H₂O 104°35′ although both are sp³? (H) Reasons: σ stronger than π; HF is polar; carbon is tetravalent. (I) Hybridisation, geometry and angle in NH₃.
Answer: (E) Ground-state Be, B and C have 0, 1 and 2 unpaired electrons but form 2, 3 and 4 bonds; and in BeF₂, BF₃ and CH₄ all bonds are equal in length and strength. Promotion alone would give unequal s- and p-type bonds; mixing into identical hybrids explains equal bonds and the observed shapes. (F) C: 2s² 2p² → excited 2s¹ 2px¹ 2py¹ 2pz¹ → four identical sp³ hybrids at 109°28′ pointing to the corners of a tetrahedron; each overlaps a H 1s orbital → four equal sp³–s σ bonds; CH₄ is tetrahedral. (G) NH₃ has one lone pair and H₂O two. Lone pairs repel more strongly than bond pairs; with two lone pairs (lp–lp repulsion) the O–H bonds are pushed closer than the N–H bonds, so 104.5° < 107° < 109.5°. (H) σ: head-on overlap is more extensive than sideways overlap. HF: F (EN 4.0) pulls the shared pair from H (2.1), giving δ+H–Fδ− and μ = 1.91 D. Carbon: on excitation 2s² 2p² → 2s¹ 2p³ it has four half-filled orbitals (hybridised to sp³), so it forms four bonds. (I) sp³; trigonal pyramidal; about 107°.
5. 3. (J) Type of overlap in H₂, F₂ and HF. (K) F–Be–F is linear but H–O–H is angular. (L) BF₃ is planar but NH₃ pyramidal. (M) In acetylene: number of covalent bonds, σ and π bonds, hybridisation. (N) Define bond enthalpy and bond length. (O) Shapes and angles of CF₄, NF₃, HCN, H₂S.
Answer: (J) H₂: s–s σ (two 1s). F₂: p–p σ (two 2pz, head-on). HF: s–p σ (H 1s with F 2pz). (K) Be in BeF₂ is sp-hybridised with two bond pairs and no lone pair → 180°. O in H₂O is sp³ with two bond pairs and two lone pairs → bent at 104.5°. (L) B in BF₃ has three bond pairs, no lone pair, sp² → trigonal planar 120°. N in NH₃ has three bond pairs and one lone pair, sp³ → the lone pair pushes the bonds down into a pyramid (107°). (M) Five covalent bonds counted as lines (2 C–H + 3 in C≡C); 3 σ (2 C–H, 1 C–C) and 2 π; sp hybridisation. (N) Bond enthalpy: energy required to break one mole of a particular bond between atoms in the gaseous state (H–H 435.8 kJ mol⁻¹). Bond length: equilibrium distance between the nuclei of two bonded atoms (H–H 74 pm). (O) CF₄: tetrahedral, 109°28′. NF₃: trigonal pyramidal, about 102° (less than 109.5° because of the lone pair). HCN: linear, 180° (C is sp). H₂S: bent, about 92° (two lone pairs; smaller than water).
6. 4. Table: ethane (C–C, 0.154 nm, 348 kJ mol⁻¹), ethene (C=C, 0.134 nm, 612), ethyne (C≡C, 0.120 nm, 837). (a) Effect of unsaturation on bond length. (b) Which is the most stable? (c) Relation between bond strength and bond enthalpy. (d) Overall relation between bond length, bond enthalpy, bond strength and stability.
Answer: (a) As unsaturation increases (single → double → triple), bond length decreases: 0.154 > 0.134 > 0.120 nm. (b) The C≡C bond of ethyne is the strongest and hardest to break (837 kJ mol⁻¹), so in terms of the carbon–carbon bond ethyne is the most stable. (Chemically, ethyne is still the most reactive of the three because its π bonds are exposed — the table only compares C–C bond strength.) (c) Bond strength is measured by bond enthalpy: the larger the bond enthalpy, the stronger the bond. (d) Shorter bond ↔ higher bond enthalpy ↔ stronger bond ↔ greater stability of that bond; all three follow bond order (C≡C > C=C > C–C).
7. 5. Complete the flow chart (formula → structural formula → shape → angle) for BeCl₂, CO₂ and C₂H₂. 6. Complete the table of hybridisation, bonds, geometry and angle for CH₄, NH₃, H₂O, BF₃, C₂H₄, BeF₂ and C₂H₂.
Answer: 5: BeCl₂ → Cl–Be–Cl → linear → 180°. CO₂ → O=C=O → linear → 180°. C₂H₂ → H–C≡C–H → linear → 180°. 6: CH₄ sp³; 4 C–H σ; tetrahedral; 109°28′. NH₃ sp³; 3 N–H σ + 1 lone pair; trigonal pyramidal; 107°. H₂O sp³; 2 O–H σ + 2 lone pairs; angular; 104.5°. BF₃ sp²; 3 B–F σ; trigonal planar; 120°. C₂H₄ sp²; 4 C–H σ + 1 C–C σ + 1 C–C π (5σ + 1π); trigonal planar about each C; 120°. BeF₂ sp; 2 Be–F σ; linear; 180°. C₂H₂ sp; 3σ + 2π (1 C–C σ, 2 C–H σ, 2 C–C π); linear; 180°.
8. 7. One sentence: (A) Factor measuring stability of an ionic compound. (B) Decreasing lattice energy: BeF₂, AlCl₃, LiCl, CaCl₂, NaCl. (C) Electrons around S in SF₆. (D) Covalent bond is directional — justify. (E) Interacting forces in molecule formation. (F) Overlap forming a π bond. (G) Steps in hybridisation. (H) Bond order formula. (I) Why O₂ is paramagnetic. (J) Formal charge and its significance.
Answer: (A) Lattice enthalpy — the energy released when the ions pack into the crystal lattice. (B) AlCl₃ > BeF₂ > CaCl₂ > LiCl > NaCl. (C) 12 (six S–F bond pairs). (D) Bonds form by overlap of p, d or hybrid orbitals that point in definite directions, so bonds lie along fixed directions and molecules have definite shapes. (E) Attraction between each nucleus and the other atom's electrons, and repulsion between the two nuclei and between the electrons. (F) Lateral (sideways) overlap of two parallel half-filled p orbitals. (G) Excitation (promotion of an electron to a vacant orbital) followed by mixing and recasting of orbitals into equivalent hybrids. (H) Bond order = (Nb − Na)/2. (I) In its MO configuration two electrons occupy π*2px and π*2py singly, so it has two unpaired electrons. (J) Formal charge = V − N − B/2 is the charge an atom would carry if bonding electrons were shared equally; the structure with the smallest formal charges is the most stable, e.g. O=C=O (all zero) is preferred to O–C≡O (+1 and −1 on the oxygens).
9. Can you tell / Use your brain power (book boxes): (i) Why is He₂ not stable? (ii) Which of H–I, H₂O, HBr, Br₂, N₂, I₂, NH₃ are polar? (iii) Which atom in NH₄⁺ has formal charge +1? (iv) Electrons around I in IF₇? (v) Why is H₂ stable though it never has an octet?
Answer: (i) Bond order zero — the antibonding electrons cancel the bonding ones, so no net bond. (ii) Polar: HI, H₂O, HBr, NH₃; non-polar: Br₂, N₂, I₂. (iii) Nitrogen. (iv) 14 electrons (seven I–F bond pairs). (v) Each H reaches the stable duplet 1s² of helium, which is its noble-gas arrangement.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Which molecule is linear?
Answer: D. AB₂ with no lone pairs on C.
2. Correct order of strength (strongest first) is…
Answer: A. Van der Waals forces are the weakest.
3. VSEPR theory is used to predict…
Answer: B. It deals with electron-pair repulsion and geometry.
4. For CO₂, the C=O bond and the molecule are respectively…
Answer: C. Bond dipoles cancel in a linear molecule.
5. Paramagnetism of O₂ is explained by…
Answer: D. MOT places two unpaired electrons in π* orbitals.
6. The bond angle is smallest in…
Answer: C. 104.5° due to two lone pairs.
7. Formal charge on the central O atom in O₃ is…
Answer: A. 6 − 2 − 6/2 = +1.
8. The number of σ and π bonds in C₂H₂ is…
Answer: B. 2 C–H σ + 1 C–C σ + 2 π.
9. The shape of ClF₃ is…
Answer: D. AB₃E₂.
10. Bond order of He₂ is…
Answer: B. (2 − 2)/2 = 0, so He₂ does not exist.
11. Which has zero dipole moment?
Answer: C. Trigonal planar; three equal dipoles cancel.
12. Which is the most covalent?
Answer: A. Small cation, large polarisable anion.
13. Which species has bond order 3?
Answer: B. Isoelectronic with N₂.
14. Hybridisation of N in NH₃ is…
Answer: B. 3 bond pairs + 1 lone pair = 4.
15. As bond order increases, bond length…
Answer: D. More shared electrons pull the nuclei closer.
