Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 1–15
Every result in physics is a number plus a unit, and every measurement carries some error. This chapter covers SI base and derived units, plane and solid angle, measuring huge distances by parallax, the modern definitions of the metre, kilogram and second, dimensions and dimensional analysis, accuracy and precision, types of errors and how they combine, and significant figures — with solved numericals and worked answers to every exercise.
A physical quantity is written as a number followed by a unit. The SI system (adopted in 1971) has seven base quantities — length, mass, time, temperature, electric current, luminous intensity and amount of substance — with units m, kg, s, K, A, cd and mol. All other units, such as m s⁻¹ or kg m s⁻², are derived from these. Plane angle (radian) and solid angle (steradian) are the supplementary units.
Distances too large for a scale are found by parallax: two observers a baseline b apart see the object at a small angle θ, so D = b/θ (θ in radian). The angular diameter α of a planet then gives its size, d = αD. Astronomers use the AU, the light year and the parsec; atoms are measured with electron microscopes in fermi or ångström.
Since 20 May 2019 every SI base unit is fixed by an exact constant of nature: the second by the caesium-133 frequency, the metre by the speed of light, the kilogram by the Planck constant, and the mole by the Avogadro number. The atomic mass unit is one-twelfth the mass of a C-12 atom.
Dimensions show how a quantity is built from M, L, T (and I, K, etc.). The principle of homogeneity — every term in a valid equation has the same dimensions — lets us check equations, derive relations such as T = 2π√(l/g) up to a constant, and convert units (1 J = 10⁷ erg). It cannot give numerical constants, or handle sin, log or exponential terms.
Errors are systematic (one-sided; from instruments, technique or the observer) or random (either sign; reduced by repeating and averaging). From repeated readings we find the mean, the mean absolute error, the relative error and the percentage error. In sums and differences absolute errors add; in products, quotients and powers relative errors add, each multiplied by its power. Results are reported with the correct number of significant figures.
Get a ✓ Verified tutor for “Units and Measurements” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A dish antenna of face area 0.50 m² is 10 m from a small transmitter. What solid angle does the dish subtend at the transmitter?
Answer: About 5 × 10⁻³ steradian.
Two observatories 4000 km apart sight a distant object at the same moment. The parallax angle is 0.5°. Estimate the distance of the object.
Answer: About 4.6 × 10⁸ m (roughly the Earth–Moon distance).
How many seconds are there in a mean solar day, and how many caesium oscillations take place in one minute?
Answer: 86 400 s per day; about 5.52 × 10¹¹ oscillations per minute.
Use dimensions to find how many dynes make one newton.
Answer: 1 N = 10⁵ dyne.
A student times a pendulum five times: 2.42 s, 2.45 s, 2.40 s, 2.43 s, 2.45 s. Find the mean period, the mean absolute error and the percentage error.
Answer: T = (2.43 ± 0.02) s; percentage error ≈ 0.66%.
A quantity is found from Z = A²B/C. The percentage errors in A, B and C are 1%, 2% and 3%. Find the maximum percentage error in Z.
Answer: 7%
A plot measures 3.6 m by 2.21 m. State its area to the correct significant figures.
Answer: Area = 8.0 m²
| Quantity | Formula | Unit / note |
|---|---|---|
| Plane angle | dθ = ds/r | radian; π rad = 180° |
| Solid angle | dΩ = dA/r² | steradian; whole sphere = 4π sr |
| Parallax distance | D = b/θ | θ in radian; b = baseline |
| Size of planet | d = αD | α = angular diameter in radian |
| Pendulum (dimensional) | T = k√(l/g), k = 2π | found with a + b = 0, −2b = 1 |
| Unit conversion | n₂ = n₁(M₁/M₂)ᵃ(L₁/L₂)ᵇ(T₁/T₂)ᶜ | 1 J = 10⁷ erg; 1 N = 10⁵ dyne |
| Mean value | a_mean = (a₁ + a₂ + … + aₙ)/n | most probable value |
| Mean absolute error | Δa_mean = (Σ|a_mean − aᵢ|)/n | same unit as a |
| Relative / percentage error | Δa_mean/a_mean; × 100% | relative error has no unit |
| Sum or difference | Z = A ± B → ΔZ = ΔA + ΔB | absolute errors add |
| Product or quotient | ΔZ/Z = ΔA/A + ΔB/B | relative errors add |
| Powers | Z = A^p B^q / C^r → ΔZ/Z = pΔA/A + qΔB/B + rΔC/C | highest power matters most |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct option: (i) [L¹M¹T⁻²] is the dimensional formula for (A) velocity (B) acceleration (C) force (D) work. (ii) The error in measuring the sides of a rectangle is 1%; the error in its area is (A) 1% (B) ½% (C) 2% (D) none. (iii) Light year is a unit of (A) time (B) mass (C) distance (D) luminosity. (iv) Kinetic energy has the same dimensions as (A) force (B) acceleration (C) work (D) pressure. (v) Which is not a fundamental unit? (A) cm (B) kg (C) centigrade (D) volt.
Answer: (i) C – force. (ii) C – 2%. (iii) C – distance. (iv) C – work. (v) D – volt (it is derived; note that the SI base unit of temperature is the kelvin, not the centigrade degree, but volt is the expected answer).
2. Answer briefly: (i) Star A is farther than star B. Which has the larger parallax angle? (ii) Find the dimensions of l√(l/g). (iii) What is the maximum possible error in A ± B? Show that for Z = A/B, ΔZ/Z = ΔA/A + ΔB/B.
Answer: (i) Star B (the nearer one) has the larger parallax angle. (ii) [L¹M⁰T¹]. (iii) ΔZ = ΔA + ΔB for both A + B and A − B; for a quotient the relative errors add.
3. Define absolute error, mean absolute error, relative error and percentage error. What are significant figures and order of magnitude?
Answer: Absolute error of a reading = |a_mean − aᵢ|. Mean absolute error = average of all the absolute errors. Relative error = mean absolute error ÷ mean value (no unit). Percentage error = relative error × 100. Significant figures are the digits known for certain plus the first doubtful digit; more of them means a more accurate measurement. Writing a value as A × 10ⁿ with 0.5 ≤ A < 5, the integer n is its order of magnitude — e.g. 1.6 × 10⁻¹⁹ C has order −19.
4. Derive the formula for the kinetic energy of a particle of mass m and velocity v using dimensional analysis.
Answer: KE = ½ m v² (the ½ comes from experiment, not from dimensions).
5. (i) Two masses are 15.7 ± 0.2 kg and 27.3 ± 0.3 kg. Find the total mass and its error.
Answer: (43.0 ± 0.5) kg
6. (ii) An object travels (5.2 ± 0.1) m in (100 ± 1) s. Find the speed and its relative error.
Answer: v = 0.052 m s⁻¹, relative error ± 0.0292 (about 2.9%). The book prints the relative error with the unit m s⁻¹; a relative error has no unit — the absolute error is about ± 0.0015 m s⁻¹.
7. (iii) An electron of charge e moves with velocity v perpendicular to a magnetic field B; the force is F = Bev. Find the dimensions of B.
Answer: [L⁰M¹T⁻²I⁻¹]
8. (iv) A ball of radius 2 m is made from rope of square cross-section, edge 4 mm. Ignoring gaps, find the rope length to the nearest order of magnitude.
Answer: About 10⁶ m, i.e. 10³ km.
9. (v) Nuclear radius R = 1.3 × 10⁻¹⁶ A^(1/3) m. Find the order of magnitude of R for A = 125.
Answer: Order of magnitude −15.
10. (vi) A Vernier calliper (least count 0.01 cm) gives 3.11, 3.13, 3.14, 3.14 cm for a steel plate. Find the mean length, mean absolute error and percentage error.
Answer: 3.13 cm, 0.01 cm, 0.32%
11. (vii) Find the percentage error in the kinetic energy of a body of mass 60.0 ± 0.3 g moving at 25.0 ± 0.1 cm/s.
Answer: 1.3%
12. (viii) Resistance readings 6.12, 6.09, 6.22, 6.15 Ω. Find the mean absolute error, relative error and percentage error.
Answer: 0.04 Ω; 0.0065; 0.65%. (The book writes the relative error with the unit Ω; it is a pure number.)
13. (ix) A freely falling body has velocity v after falling height h. If v depends on g and h, show by dimensions that v = k√(gh).
Answer: v = k g^½ h^½ = k√(gh) (k = √2 from experiment).
14. (x) v = at + b/(t + c) + v₀ is dimensionally valid. Find the dimensions of a, b and c.
Answer: a = [L¹M⁰T⁻²], b = [L¹M⁰T⁰], c = [L⁰M⁰T¹]
15. (xi) A metal sheet is 4.234 m long, 1.005 m wide and 2.01 cm thick. Give its area and volume to correct significant figures.
Answer: Area = 4.255 m²; volume = 0.0855 m³. The book prints the volume as 8.552 m³; the correct answer is 0.0855 m³ (8.55 × 10⁻² m³), with 3 significant figures because the thickness has only 3.
16. (xii) A cylinder has l = (4.00 ± 0.001) cm, r = (0.0250 ± 0.001) cm and m = (6.25 ± 0.01) g. Find the percentage error in its density.
Answer: 8.185% (about 8.2%)
17. (xiii) Jupiter is 824.7 million km away and its angular diameter is 35.72″. Find its diameter.
Answer: d ≈ 1.428 × 10⁵ km
18. (xiv) X = a⁴b³/(c^(1/3) d^(1/2)); percentage errors in a, b, c, d are 2%, 3%, 3%, 4%. Find the percentage error in X.
Answer: 20%
19. (xv) Number of significant figures in 0.003 m², 0.1250 g cm⁻², 6.4 × 10⁶ m, 1.6 × 10⁻¹⁹ C, 9.1 × 10⁻³¹ kg.
Answer: 1, 4, 2, 2, 2
20. (xvi) The diameter of a sphere is 2.14 cm. Find its volume to correct significant figures.
Answer: 5.13 cm³
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Which is NOT an SI base unit?
Answer: A. Newton is derived (kg m s⁻²).
2. The SI unit of solid angle is…
Answer: A. dΩ = dA/r² is in sr.
3. Which is correctly written?
Answer: D. No plurals, lowercase names, no full stop.
4. Star A is farther than star B. The parallax angle of A is…
Answer: A. θ = b/D falls as D rises.
5. A light year is a unit of…
Answer: C. Distance light covers in one year.
6. The dimensional formula [L²M¹T⁻²] belongs to…
Answer: D. Work = force × distance.
7. Impulse has the same dimensions as…
Answer: C. Impulse = F × t = change in momentum.
8. Dimensional analysis cannot be used to…
Answer: B. Pure numbers come from experiment.
9. 1 newton equals…
Answer: A. 10³ × 10² = 10⁵.
10. A zero error in a balance gives a…
Answer: A. It shifts every reading the same way.
11. If each side of a square has 1% error, the error in its area is…
Answer: D. A = l², so 2 × 1%.
12. If Z = A − B, the maximum absolute error in Z is…
Answer: B. Errors always add.
13. In g = 4π²l/T², T has 1% error and l has 0.5%. Error in g?
Answer: B. 0.5% + 2 × 1%.
14. Number of significant figures in 0.1250?
Answer: B. Leading zero not counted; trailing zero after a decimal counts.
15. The order of magnitude of 6400 km (written in metres) is…
Answer: D. 0.64 × 10⁷ m, using 0.5 ≤ A < 5.
