Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 16–29
Physics speaks the language of vectors and calculus. This chapter gives you the toolkit: scalars and vectors, the kinds of vectors, the triangle and parallelogram laws, resolving a vector into components with unit vectors i, j, k, the dot and cross products, and a first look at derivatives and integrals — with solved numericals and step-by-step answers to every exercise question.
A scalar is fully known from a number and a unit (mass, time, temperature, work, energy). A vector also needs a direction (displacement, velocity, force). Vectors are drawn as arrows: the length to scale shows the size, the arrowhead the direction. Special kinds include the zero vector, negative vector, equal vectors, position vector and unit vector.
Vectors of the same physical kind are added geometrically. The triangle law (head of the first to tail of the second) and the parallelogram law (tails together, resultant along the diagonal) give R = √(P² + Q² + 2PQ cos θ) with direction tan α = Q sin θ ÷ (P + Q cos θ). Vector addition is commutative and associative.
Any vector can be split into perpendicular (rectangular) components: R = Rₓ i + R_y j + R_z k, with Rₓ = R cos θ, R_y = R sin θ and R = √(Rₓ² + R_y² + R_z²). Two vectors are equal only when every matching component is equal.
The dot product P·Q = PQ cos θ is a scalar (work W = F·s, power P = F·v); in components it is PₓQₓ + P_yQ_y + P_zQ_z. The cross product P × Q = PQ sin θ n̂ is a vector perpendicular to both, found by the right-hand screw rule and by a determinant (torque τ = r × F, angular momentum L = r × p, force on a moving charge F = q v × B).
Calculus handles continuous change. The derivative dy/dx is the limit of Δy/Δx as Δx → 0 — the slope of the tangent to the curve. Integration is the reverse process; the definite integral from a to b equals the area under the curve, F(b) − F(a).
Get a ✓ Verified tutor for “Mathematical Methods” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Find the unit vector along A = 6i − 8j.
Answer: Â = 0.6 i − 0.8 j
Two forces of 3 N and 5 N act at a point with an angle of 60° between them. Find the size and direction of their resultant.
Answer: R = 7 N, at about 38.2° to the 3 N force.
A force of 20 N acts at 30° above the +x axis. Write it in i, j form.
Answer: F = 17.32 i + 10 j newton (i.e. 10√3 i + 10 j N)
A force F = 3i + 4j N moves a box through s = 2i + 6j m. Find the work done and the angle between F and s.
Answer: Work = 30 J; angle ≈ 18.4°
Find A × B for A = i + 2j + 3k and B = 2i − j + k, and the area of the parallelogram they form.
Answer: A × B = 5i + 5j − 5k; area ≈ 8.66 square units
The position of a particle is x = 2t³ + 5t (x in m, t in s). Find its velocity at t = 2 s, and evaluate ∫₀³ (2t³ + 5t) dt.
Answer: v = 29 m/s; the integral = 63
| Quantity | Formula | Note |
|---|---|---|
| Unit vector | Â = A ÷ |A| | magnitude 1; i, j, k along x, y, z |
| Resultant (parallelogram law) | R = √(P² + Q² + 2PQ cos θ) | θ = angle between P and Q |
| Direction of resultant | tan α = Q sin θ ÷ (P + Q cos θ) | α measured from P |
| Rectangular components | Rₓ = R cos θ, R_y = R sin θ | R = √(Rₓ² + R_y² + R_z²); tan θ = R_y/Rₓ |
| Dot product | P·Q = PQ cos θ = PₓQₓ + P_yQ_y + P_zQ_z | scalar; zero if P ⊥ Q; W = F·s, P = F·v |
| Angle between vectors | cos θ = A·B ÷ (AB) | from the dot product |
| Cross product | |P × Q| = PQ sin θ; P × Q = (P_yQ_z − P_zQ_y)i + (P_zQₓ − PₓQ_z)j + (PₓQ_y − P_yQₓ)k | vector ⊥ both; zero if parallel; = parallelogram area |
| Cyclic unit products | i × j = k, j × k = i, k × i = j | reverse order → minus sign |
| Derivative | dy/dx = lim(Δx→0) Δy/Δx; d(xⁿ)/dx = n xⁿ⁻¹ | slope of tangent |
| Product and quotient rules | (f₁f₂)′ = f₁f₂′ + f₂f₁′; (f₁/f₂)′ = f₁′/f₂ − f₁f₂′/f₂² | chain: dy/dx = (dy/dv)(dv/dx) |
| Integral of xⁿ | ∫xⁿ dx = xⁿ⁺¹ ÷ (n + 1) | n ≠ −1; ∫(1/x)dx = ln x |
| Definite integral | ∫ₐᵇ f(x) dx = F(b) − F(a) | area under the curve from a to b |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1 (i) The resultant of two forces 10 N and 15 N acting along +x and −x axes respectively is (A) 25 N along +x (B) 25 N along −x (C) 5 N along +x (D) 5 N along −x.
Answer: (D) 5 N along the −x axis.
2. 1 (ii) For two vectors to be equal, they should have the (A) same magnitude (B) same direction (C) same magnitude and direction (D) same magnitude but opposite direction.
Answer: (C) same magnitude and direction.
3. 1 (iii) The magnitude of the scalar product of two unit vectors perpendicular to each other is (A) zero (B) 1 (C) −1 (D) 2.
Answer: (A) zero.
4. 1 (iv) The magnitude of the vector product of two unit vectors making an angle of 60° with each other is (A) 1 (B) 2 (C) 3/2 (D) √3/2.
Answer: (D) √3/2.
5. 1 (v) If A, B and C are three vectors, which is not correct? (A) A·(B + C) = A·B + A·C (B) A·B = B·A (C) A × B = B × A (D) A × (B + C) = A × B + B × C.
Answer: (C) is the intended answer (the cross product is not commutative). Note: option (D) as printed in the book (… + B × C) is also wrong; it should read A × B + A × C.
6. 2 (i) Show that a = (i − j)/√2 is a unit vector.
Answer: Its magnitude is 1, so a is a unit vector (it points in the xy-plane at −45° to the x-axis).
7. 2 (ii) If v₁ = 3i + 4j + k and v₂ = i − j − k, determine the magnitude of v₁ + v₂.
Answer: 5 (matches the book).
8. 2 (iii) For v₁ = 2i − 3j and v₂ = −6i + 5j, determine the magnitude and direction of v₁ + v₂.
Answer: 2√5, at θ = tan⁻¹(−1/2) with the x-axis (matches the book) — i.e. about 153.4° measured from the +x axis.
9. 2 (iv) Find a vector which is parallel to v = i − 2j and has a magnitude 10.
Answer: (10/√5)i − (20/√5)j = 2√5 i − 4√5 j (matches the book; −10 v̂ is also parallel, pointing the other way).
10. 2 (v) Show that vectors a = 2i + 5j − 6k and b = i + (5/2)j − 3k are parallel.
Answer: All component ratios equal 2, so a = 2b and the vectors are parallel (same direction).
11. 3 (i) Determine a × b, given a = 2i + 3j and b = 3i + 5j.
Answer: a × b = k (matches the book).
12. 3 (ii) Show that a = 2i + 3j + 6k, b = 3i − 6j + 2k and c = 6i + 2j − 3k are mutually perpendicular.
Answer: All three dot products are zero, so each pair is perpendicular (each vector also has magnitude 7).
13. 3 (iii) Determine the vector product of v₁ = 2i + 3j − k and v₂ = i + 2j − 3k.
Answer: v₁ × v₂ = −7i + 5j + k (matches the book).
14. 3 (iv) Given v₁ = 5i + 2j and v₂ = ai − 6j are perpendicular to each other, determine the value of a.
Answer: a = 12/5 = 2.4 (matches the book).
15. 3 (v) Obtain derivatives of (i) x sin x (ii) x⁴ + cos x (iii) x/sin x.
Answer: (i) sin x + x cos x; (ii) 4x³ − sin x; (iii) 1/sin x − x cos x/sin² x (all match the book).
16. 3 (vi) Using the rule for differentiating a quotient, prove that d/dx (sin x/cos x) = sec² x.
Answer: d/dx(tan x) = sec² x. Hence proved.
17. 3 (vii) Evaluate (i) ∫₀^(π/2) sin x dx (ii) ∫₁⁵ x dx.
Answer: (i) 1; (ii) 12 (both match the book).
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Which of these is a vector?
Answer: C. Force needs a direction.
2. Forces of 10 N along +x and 15 N along −x act together. The resultant is…
Answer: C. Anti-parallel: 15 − 10 = 5 N, along the larger force.
3. The acceleration of a body moving with uniform velocity is a…
Answer: D. Velocity does not change.
4. Two forces of 6 N and 8 N act at right angles. The resultant is…
Answer: A. √(36 + 64) = 10 N.
5. The magnitude of 2i − 3j + 6k is…
Answer: A. √(4 + 9 + 36) = √49 = 7.
6. i·j equals…
Answer: A. They are perpendicular.
7. j × k equals…
Answer: C. Cyclic order i → j → k.
8. (2i + 3j)·(4i − j) equals…
Answer: C. 8 − 3 = 5.
9. The cross product of two parallel vectors is…
Answer: A. sin 0° = 0.
10. Magnitude of the cross product of two unit vectors at 60° is…
Answer: D. 1 × 1 × sin 60°.
11. Which statement is NOT correct?
Answer: D. A × B = −(B × A).
12. Work done by a force is the…
Answer: D. W = F·s = Fs cos θ.
13. d(x⁵)/dx equals…
Answer: D. n xⁿ⁻¹.
14. d(cos x)/dx equals…
Answer: A. Standard result.
15. ∫₀² 3x² dx equals…
Answer: D. x³ from 0 to 2 = 8.
