Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 242–256
Every phone, LED bulb, solar panel and satellite runs on semiconductors. This chapter explains how solids conduct (σ = nqμ), the band theory of solids and why metals, semiconductors and insulators differ, intrinsic semiconductors with electrons and holes, n-type and p-type doping (n_e n_h = n_i²), the p-n junction with its depletion region and potential barrier, forward and reverse bias, the junction diode's I–V characteristics, static and dynamic resistance, semiconductor devices and thermistors — with worked numericals and answers to every exercise.
Conductivity σ = nqμ depends on the number of charge carriers, their charge and their mobility. Metals (~10²⁸ free electrons per m³) conduct very well, insulators very poorly, and semiconductors (Si, Ge, GaAs, CdS) lie in between; their conductivity rises with temperature while a metal's falls.
In a solid, the closely packed atoms' outer energy levels split (Pauli's principle) into nearly continuous bands. The valence band is the highest filled band; above it is the conduction band. Metals have overlapping bands, semiconductors a small gap (Si 1.12 eV, Ge 0.66 eV) and insulators a wide gap (diamond about 5.5 eV).
A pure (intrinsic) semiconductor has equal numbers of free electrons and holes made by thermally broken bonds; both carry current, moving in opposite directions. Doping with a pentavalent donor (P, As, Sb) gives n-type (electrons majority); a trivalent acceptor (B, Al, In) gives p-type (holes majority). Both remain electrically neutral, and n_e n_h = n_i².
When p- and n-type regions are joined, carriers diffuse across, leaving a depletion region of fixed ions and a potential barrier (≈ 0.6–0.7 V for Si, 0.3–0.35 V for Ge). Forward bias (p to +) narrows the barrier and a large current (mA) flows above the knee voltage; reverse bias widens it and only a tiny leakage current (µA) flows until breakdown.
A p-n junction with terminals is a diode — a one-way switch with static resistance V/I and dynamic resistance ΔV/ΔI. Semiconductor devices (solar cells, LEDs, photodiodes, transistors, lasers, ICs) are small, light, fast and power-efficient but sensitive to heat, radiation and static charge. Thermistors (NTC and PTC) change resistance sharply with temperature.
Get a ✓ Verified tutor for “Semiconductors” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Pure silicon at 300 K has n_e = n_h = 1.5 × 10¹⁶ m⁻³. Electron mobility is 0.135 m²/V s and hole mobility 0.048 m²/V s. Find its conductivity.
Answer: About 4.4 × 10⁻⁴ S/m — tiny compared with copper's 6 × 10⁷ S/m.
Compare the band gap of silicon (1.12 eV) with the typical thermal energy kT at 300 K (k = 1.38 × 10⁻²³ J/K). Express both in joules and electron-volts.
Answer: The gap (1.12 eV) is about 43 times kT (0.026 eV), so only a very few electrons are thermally excited — pure silicon conducts poorly at room temperature.
A pure semiconductor sample contains 5 × 10²⁸ atoms/m³ and has n_i = 2 × 10¹⁶ m⁻³. What fraction of atoms has contributed a free electron? How many holes per m³ are there?
Answer: Only 4 in 10¹³ atoms (four in ten million million) give a free electron; holes = 2 × 10¹⁶ m⁻³.
Germanium has 4.4 × 10²⁸ atoms/m³ and n_i = 2.4 × 10¹⁹ m⁻³. It is doped with 2 ppm of arsenic. Find n_e and n_h. What type is it?
Answer: n_e ≈ 8.8 × 10²² m⁻³, n_h ≈ 6.5 × 10¹⁵ m⁻³; n-type (arsenic is a pentavalent donor).
A silicon diode (knee voltage 0.7 V) is connected in forward bias with a 215 Ω resistor across a 5 V battery. Find the current. What is the current if the diode is reversed (assume ideal reverse behaviour)?
Answer: About 20 mA forward; practically zero in reverse.
A silicon diode carries 20 mA at 0.70 V and 30 mA at 0.72 V. Find its static resistance at 0.70 V and its dynamic resistance in this range.
Answer: R_g = 35 Ω; r_g = 2 Ω — the dynamic resistance is much smaller above the knee.
An NTC thermistor has 10 kΩ at 25 °C and 4 kΩ at 50 °C. It is in series with a 6 kΩ resistor across 10 V. Find the current at each temperature.
Answer: 0.625 mA at 25 °C; 1.0 mA at 50 °C.
| Quantity | Formula or value | Note |
|---|---|---|
| Conductivity | σ = nqμ | S/m; μ in m²/(V s) |
| Intrinsic conductivity | σ = n_i e(μ_e + μ_h) | both carriers add |
| Intrinsic carriers | n_e = n_h = n_i | pure semiconductor |
| Mass-action law | n_e n_h = n_i² | any doped semiconductor in equilibrium |
| Doping in ppm | dopant density = host density × ppm/10⁶ | one carrier per dopant atom |
| Electron-volt | 1 eV = 1.6 × 10⁻¹⁹ J | kT ≈ 0.026 eV at 300 K |
| Band gaps (300 K) | Si 1.12 eV; Ge 0.66 eV; diamond 5.47 eV | metals: bands overlap |
| Donor/acceptor binding | ≈ 0.01 eV (Ge), 0.05 eV (Si) | freed at room temperature |
| Potential barrier | Si 0.6–0.7 V; Ge 0.3–0.35 V | n-side higher potential |
| Static resistance | R_g = V/I | at an operating point |
| Dynamic resistance | r_g = ΔV/ΔI | 1/slope of I–V curve |
| Diode currents | forward ~ mA; reverse ~ µA | breakdown at large reverse V |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option: (i) Electric conduction in a semiconductor is due to … (ii) The energy levels of holes are … (iii) Current through a reverse-biased p-n junction increases abruptly at … (iv) A reverse-biased diode is equivalent to … (v) The potential barrier in a p-n diode is due to …
Answer: (i) (D) both electrons and holes. (ii) (A) in the valence band. (iii) (A) breakdown voltage. (iv) (A) an off switch. (v) (D) accumulation of positive and negative charges near the junction.
2. 2. Answer: (i) Importance of the energy gap in a semiconductor. (ii) Impurity to make germanium n-type. (iii) What causes the larger current in forward bias?
Answer: (i) The band gap decides how many electrons can be thermally excited into the conduction band: a small gap (about 1 eV or less) lets some electrons cross at room temperature, so the material conducts moderately and its conductivity rises with temperature; the gap also fixes properties such as the colour of light an LED emits or a solar cell absorbs. No gap means a metal, a wide gap an insulator. (ii) A pentavalent element — phosphorus, arsenic or antimony. (iii) Forward bias opposes the built-in barrier, so the barrier height and the depletion width fall; electrons in the n-region and holes in the p-region are pushed towards the junction and easily cross it. Large numbers of majority carriers then flow, giving a current of milliamperes.
3. 2. Answer: (iv) Factors on which the conductivity of a pure semiconductor depends at a given temperature. (v) Why is n-type more conducting than p-type at the same doping?
Answer: (iv) σ = n_i e(μ_e + μ_h), so it depends on the intrinsic carrier density n_i (which depends on the band gap of the material), on the charge, and on the mobilities of electrons and holes (which depend on carrier mass, crystal perfection, defects and impurities). (v) In n-type the majority carriers are free electrons in the conduction band, which move directly and have high mobility. In p-type the majority carriers are holes, which move only by successive jumps of bound valence electrons, so their mobility is lower. With equal carrier numbers, σ = nqμ is therefore larger for n-type.
4. 3(i). Explain how solids are classified on the basis of band theory.
Answer: In a solid, the outer levels of the closely packed atoms split into bands. The highest filled band is the valence band; the next empty band is the conduction band; between them is the band gap. Conductors (metals): the valence and conduction bands overlap (or the valence band is only partly filled, as in sodium), so there is no gap; electrons gain energy from even a small field and conduct easily. Semiconductors: a small gap of about 1 eV or less (Si 1.12 eV, Ge 0.66 eV); at room temperature a few electrons jump into the conduction band leaving holes, so conduction is moderate and increases with temperature. Insulators: a wide gap (diamond about 5.5 eV); electrons almost never gain enough energy to cross, so they hardly conduct.
5. 3(ii). Distinguish between intrinsic and extrinsic semiconductors.
Answer: Intrinsic: pure Si or Ge; carriers only from thermally broken bonds; n_e = n_h = n_i; conductivity very low and depends mainly on temperature; no impurity energy levels in the gap. Extrinsic: doped with a tiny amount of pentavalent or trivalent impurity; carriers mainly from the dopant (electrons in n-type, holes in p-type); n_e ≠ n_h (but n_e n_h = n_i²); conductivity much higher and controllable by the amount of doping; donor or acceptor levels lie in the gap near the band edges.
6. 3(iii). Importance of the depletion region in a p-n junction diode.
Answer: The depletion region, formed by diffusion of carriers across the junction, contains fixed positive ions on the n-side and negative ions on the p-side and no free carriers. These ions create the potential barrier (≈ 0.7 V in Si, ≈ 0.3 V in Ge) with the n-side at higher potential, which stops further diffusion and gives equilibrium. Because external voltage can shrink (forward bias) or widen (reverse bias) this region, the junction lets current pass easily one way and blocks it the other way — the basis of the diode's rectifying, switching and sensing uses.
7. 3(iv)–(v). Explain the I–V characteristic of a forward-biased diode, and the effect of external voltage on the width of the depletion region.
Answer: (iv) As the forward voltage is raised from zero, the current stays very small while the barrier is still being overcome. Near the knee voltage (about 0.7 V for Si, 0.3 V for Ge) the barrier is almost cancelled and the current rises steeply (mA range); beyond it the diode behaves almost like a short circuit, so a series resistor is needed to limit the current and prevent overheating. The static resistance V/I and the dynamic resistance ΔV/ΔI both fall above the knee. (v) In forward bias (p to +, n to −) the applied voltage opposes the built-in barrier, carriers are pushed towards the junction and the depletion region becomes narrower, giving a large current. In reverse bias (p to −, n to +) the applied voltage adds to the barrier, carriers are pulled away and the depletion region becomes wider; only a µA leakage current flows, until breakdown at a large reverse voltage.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Electric conduction in a semiconductor is due to…
Answer: A. Two types of carriers move in opposite directions.
2. The energy levels of holes lie…
Answer: D. A hole is a vacancy in the valence band.
3. Current through a reverse-biased p-n junction rises abruptly at…
Answer: D. Bonds break and avalanche breakdown occurs.
4. A reverse-biased ideal diode is equivalent to…
Answer: A. It blocks current.
5. The potential barrier in a p-n junction is due to…
Answer: C. Fixed donor and acceptor ions create the field.
6. The band gap of germanium at 300 K is about…
Answer: A. Silicon is 1.12 eV, diamond 5.47 eV.
7. To make germanium n-type, it should be doped with…
Answer: B. Arsenic is pentavalent.
8. In a p-type semiconductor, the majority carriers are…
Answer: C. Acceptors create holes.
9. For a semiconductor, n_e × n_h equals…
Answer: A. Mass-action law.
10. If n_i = 10¹⁶ m⁻³ and n_e = 10²² m⁻³, then n_h is…
Answer: C. n_h = 10³²/10²².
11. The knee voltage of a silicon diode is about…
Answer: C. Germanium is about 0.3 V.
12. In forward bias, the width of the depletion region…
Answer: D. The applied voltage opposes the barrier.
13. Heating a metal wire makes its conductivity…
Answer: D. More collisions with vibrating ions.
14. A PTC thermistor is commonly used as a…
Answer: A. Its resistance rises when it heats up, limiting current.
15. Which device converts light into electrical energy?
Answer: D. An LED does the reverse.
