Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 229–241
Your phone, the TV, Wi-Fi, X-ray scans and the warmth of sunlight all ride on electromagnetic waves. This chapter covers Maxwell's four laws and displacement current, how accelerated charges produce EM waves, their characteristics (c = 1/√(μ₀ε₀), E₀ = cB₀), the EM spectrum from radio waves to gamma rays with sources, properties and uses, propagation by ground, space and sky waves (range d = √(2Rh)), and the basics of communication systems and modulation — with worked numericals and answers to every exercise.
Four laws govern electric and magnetic fields: Gauss' law (charges make E), Gauss' law for magnetism (no monopoles), Faraday's law (a changing B makes E) and Ampere's law. Maxwell added the displacement current — a changing E also makes B — and predicted EM waves. Hertz produced and detected them in 1888, J. C. Bose made millimetre waves in 1895 and Marconi pioneered wireless communication.
Accelerated charges radiate EM waves in which E and B oscillate in phase, at right angles to each other and to the direction of travel (E × B), so the waves are transverse. In vacuum they travel at c = 1/√(μ₀ε₀) = 3 × 10⁸ m/s; in a medium v = 1/√(με). E₀ = cB₀, intensity ∝ amplitude², and the energy is shared equally by E and B.
The EM spectrum, in order of decreasing wavelength, is radio waves, microwaves, infrared, visible light (380–750 nm), ultraviolet, X-rays and gamma rays. Each has its own source and uses — radio for broadcasting, microwaves for radar and ovens, IR for remote controls and thermal imaging, UV for sterilising, X-rays for imaging bones, gamma rays for cancer treatment.
Radio waves reach receivers by ground waves (below about 2 MHz, short range), sky waves (3–30 MHz, reflected by the ionosphere, long range) or space waves (above 30 MHz, line of sight or via satellites). The line-of-sight range of an antenna of height h is d = √(2Rh); with a receiving antenna of height h′, d = √(2Rh) + √(2Rh′).
A communication system has a transmitter, a channel and a receiver, working in point-to-point or broadcast mode. Key terms: signal (analog or digital), transducer, noise, attenuation, amplification, range, bandwidth, repeater. Low-frequency audio is sent by modulating a high-frequency carrier — AM (simple, long range, noisy), FM (better quality, less noise) or PM — and recovered by demodulation.
Get a ✓ Verified tutor for “Electromagnetic Waves and Communication System” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Show that 1/√(μ₀ε₀) gives the speed of light, using μ₀ = 4π × 10⁻⁷ T m/A and ε₀ = 8.85 × 10⁻¹² C²/(N m²). What is the speed in a medium with μ = μ₀ and ε = 4ε₀?
Answer: c ≈ 3.0 × 10⁸ m/s; 1.5 × 10⁸ m/s in the medium.
An EM wave in vacuum travels along +x with frequency 100 MHz and electric field amplitude 30 V/m along y. Find the wavelength and the amplitude and direction of B. Write E_y.
Answer: λ = 3 m; B₀ = 10⁻⁷ T along the z-axis; E_y = 30 sin[2π(x/3 − 10⁸t)] V/m.
Find the wavelength of (a) an FM station at 100 MHz and (b) an AM station at 600 kHz, and the minimum antenna length (λ/4) for each.
Answer: FM: 3 m (antenna 0.75 m); AM: 500 m (antenna 125 m).
Light of wavelength 500 nm and X-rays of wavelength 0.1 nm travel in vacuum. Find their frequencies and identify the colour of the light.
Answer: 6 × 10¹⁴ Hz (green light); 3 × 10¹⁸ Hz for the X-rays.
A TV transmitting antenna is 80 m high. Find its range and covered area (R = 6400 km). What is the maximum line-of-sight distance if the receiving antenna is 20 m high?
Answer: Range 32 km (about 3215 km²); 48 km with a 20 m receiving antenna.
A 12 kHz audio signal is to be transmitted directly. What antenna length (λ/4) would it need? What length is needed if it is carried on a 1.5 MHz carrier?
Answer: About 6.25 km without modulation; only 50 m with the 1.5 MHz carrier.
| Quantity | Formula or value | Note |
|---|---|---|
| Speed in vacuum | c = 1/√(μ₀ε₀) ≈ 3 × 10⁸ m/s | μ₀ = 4π × 10⁻⁷ T m/A, ε₀ = 8.85 × 10⁻¹² |
| Speed in a medium | v = 1/√(με) | less than c |
| Wave relation | c = νλ | ν in Hz, λ in m |
| Field amplitudes | E₀ = cB₀ | E in V/m, B in T |
| Wave equations | E_y = E₀ sin(kx − ωt), B_z = B₀ sin(kx − ωt) | k = 2π/λ, ω = 2πν; in phase |
| Intensity | I_E = ½ε₀E₀², I_B = B₀²/2μ₀ | I ∝ amplitude²; I_E = I_B |
| Direction of travel | along E × B | transverse wave |
| Line-of-sight range | d = √(2Rh) | area covered = πd² |
| Two antennas | d = √(2Rh_t) + √(2Rh_r) | R = 6.4 × 10⁶ m |
| Antenna length | l ≥ λ/4 | radiated power ∝ (l/λ)² |
| Broadcast bands | AM 530–1710 kHz; FM 88–108 MHz; TV 54–890 MHz | |
| Visible light | 380 nm (violet) – 750 nm (red) | ≈ 4–8 × 10¹⁴ Hz |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option: (i) EM wave from the Sun heating the atmosphere (greenhouse effect); (ii) Earth's atmosphere is richest in; (iii) change in frequency of UV light going from air into glass; (iv) direction of an EM wave; (v) TV range from a tower of height h is proportional to; (vi) waves used by satellites; (vii) antenna height to cover a radius of 640 km.
Answer: (i) (A) infrared. (ii) (B) IR. (iii) No change — options (A) 'no change' and (D) 'remains same' say the same thing; either is right. (iv) (A) E × B. (v) (A) h^(1/2). (vi) (A) microwave. (vii) (A) 32000 m.
2. 2. Answer briefly: (i) Two characteristics of EM waves. (ii) Why microwaves in radar? (iii) What are EM waves? (iv) How are they produced? (v) Can a pure electric or magnetic wave exist? (vi) Does a lamp emit EM waves? (vii) Why does light travel in vacuum but sound cannot?
Answer: (i) Any two: E and B are perpendicular to each other and to the direction of travel (transverse); they travel at c = 1/√(μ₀ε₀) in vacuum; E₀/B₀ = c; E and B are in phase; they need no medium. (ii) Microwaves have short wavelengths, so they travel in narrow straight beams, reflect well from aircraft and ships, pass through clouds and rain, and give precise direction and distance. (iii) Waves of mutually perpendicular, in-phase oscillating electric and magnetic fields that travel through space, carrying energy, at right angles to both fields. (iv) By accelerated or oscillating charges: the changing E produces a changing B, which produces a changing E, and so on. (v) No. A changing electric field always produces a magnetic field and vice versa, so the two always exist together. (vi) Yes — its hot filament emits visible light and infrared, both EM waves. (vii) Light is an EM wave made of self-sustaining fields that need no medium; sound is a mechanical wave that needs particles of a medium to vibrate.
3. 2. Answer briefly: (viii) Ultraviolet rays and two uses. (ix) Radio waves and two uses. (x) Most harmful radiation from outer space. (xi) Reasons: long-distance broadcasts use short waves; satellites for long-distance TV. (xii) Three basic units of a communication system.
Answer: (viii) EM waves of wavelength about 30 nm to 400 nm, beyond violet; uses: sterilising instruments and purifying water, detecting forgery or fake gems, burglar alarms. (ix) EM waves of longest wavelength (a few cm to hundreds of km) produced by accelerated charges in conductors; uses: radio and TV broadcasting, mobile phones, wireless communication. (x) Gamma rays (also X-rays and UV) — highly energetic and ionising; most are stopped by the atmosphere and ozone layer. (xi) (i) Short waves (3–30 MHz) are reflected by the ionosphere and can bounce between it and the ground repeatedly, covering very long distances. (ii) TV frequencies pass through the ionosphere and travel only in a line of sight, which the Earth's curvature limits; a satellite high above receives and re-transmits them over a huge area. (xii) Transmitter, communication channel and receiver.
4. 2. Answer briefly: (xiii) Carrier wave. (xiv) Why high-frequency carriers? (xv) Modulation. (xvi) Amplitude modulation. (xvii) Noise. (xviii) Bandwidth. (xix) Demodulation. (xx) Modulation for TV broadcast.
Answer: (xiii) A high-frequency wave whose amplitude, frequency or phase is altered to carry a low-frequency message signal. (xiv) Low audio frequencies need impractically long antennas (λ/4 is kilometres), radiate very little power and would mix with other stations; a high-frequency carrier fixes all three problems. (xv) Superimposing the low-frequency signal on a high-frequency carrier by varying its amplitude, frequency or phase in step with the signal. (xvi) The amplitude of the carrier is varied according to the instantaneous amplitude of the signal, keeping its frequency and phase constant. (xvii) Random unwanted electrical signals, arising inside or outside the system, that disturb the message. (xviii) The range of frequencies over which a circuit or system operates efficiently. (xix) Recovering the original signal from the modulated wave at the receiver. (xx) TV uses amplitude modulation for the picture (video) and frequency modulation for the sound.
5. 2. Answer briefly: (xxi) How does the effective power radiated by an antenna vary with wavelength? (xxii) Why do stations use different frequencies? (xxiii) Need of a carrier wave. (xxiv) Why is AM reception noisy? (xxv) Why is modulation needed?
Answer: (xxi) For an antenna of length l, the power radiated is proportional to (l/λ)², so it increases sharply as the wavelength decreases (frequency increases). (xxii) If two stations used the same frequency their signals would overlap and the receiver could not separate them; different carrier frequencies let a receiver tune to one station. (xxiii) Audio signals cannot travel far on their own, would need antennas kilometres long and would interfere with one another; the carrier carries them far with a practical antenna and separate channels. (xxiv) Most noise and interference change the amplitude of a wave, and in AM the information is in the amplitude, so the noise is reproduced along with the signal. (xxv) Modulation allows practical antenna sizes, high radiated power, long range and separate frequency channels for different stations.
6. 3(i)–(v). Find: (i) frequency of a 250 m radio wave; (ii) wavelength of 2.0 × 10¹⁸ Hz X-rays; (iii) frequency of red light of 6.5 × 10⁻⁷ m; (iv) wavelength of 8.0 GHz microwaves; (v) wavelength for 2 × 10¹⁰ Hz.
Answer: (i) 1.2 MHz. (ii) 0.15 nm. (iii) ≈ 4.6 × 10¹⁴ Hz. (iv) 3.75 cm. (v) 1.5 × 10⁻² m (1.5 cm).
7. 3(vi). The magnetic field amplitude of an EM wave in vacuum is 5 × 10⁻⁷ T. Find the electric field amplitude.
Answer: 150 V/m
8. 3(vii). A TV tower is 200 m high. How many people are covered if the population density is 1000 per km²? (R = 6.4 × 10⁶ m)
Answer: ≈ 8 × 10⁶ people
9. 3(viii). A TV tower is 600 m high. Find its range. What height gives double the coverage area?
Answer: ≈ 87.6 km; 1200 m.
10. 3(ix). Transmitting antenna 32 m high, receiving antenna 50 m high. Maximum line-of-sight distance? (R = 6.4 × 10⁶ m)
Answer: ≈ 45.54 km
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The EM radiation from the Sun mainly responsible for the greenhouse heating of the atmosphere is…
Answer: B. Heat radiation is infrared.
2. When UV light passes from air into glass, its frequency…
Answer: A. Frequency is fixed by the source; speed and wavelength change.
3. The direction of propagation of an EM wave is given by…
Answer: D. Energy flows along E × B.
4. The maximum distance of TV reception from a tower of height h is proportional to…
Answer: D. d = √(2Rh).
5. Artificial satellites communicate using…
Answer: C. Microwaves pass through the ionosphere.
6. A TV telecast is to cover a radius of 640 km. The antenna height should be (R = 6400 km)…
Answer: D. h = d²/2R = (6.4 × 10⁵)²/(1.28 × 10⁷).
7. The amplitude of E in an EM wave is 60 V/m. The amplitude of B is…
Answer: B. B₀ = E₀/c = 60/(3 × 10⁸).
8. If the amplitude of an EM wave is tripled, its intensity becomes…
Answer: B. I ∝ amplitude².
9. Which radiation is used to sterilise surgical instruments?
Answer: B. UV kills germs and bacteria.
10. X-rays were discovered by…
Answer: C. In 1895, while studying cathode rays.
11. Which EM waves have the highest frequency?
Answer: B. Gamma rays have the shortest wavelength.
12. Short-wave radio (3–30 MHz) reaches distant countries mainly by…
Answer: C. The ionosphere reflects these frequencies.
13. A microphone is an example of a…
Answer: A. It converts sound energy into electrical energy.
14. The loss of signal strength while it travels through a channel is called…
Answer: B. The channel weakens the signal.
15. The minimum antenna length for a 75 MHz signal (λ/4) is…
Answer: D. λ = 4 m, so λ/4 = 1 m.
