Textbook: Chemistry – Class 12 (Balbharati, official free PDF) · pages 1–27
Why is diamond hard while graphite is soft, and why does silicon conduct better when it is warm? This chapter answers these questions with crystalline and amorphous solids, the four classes of crystals, lattices and unit cells, cubic cells (sc, bcc, fcc), close packing and voids, packing efficiency, density–edge length calculations, crystal defects, band theory with semiconductors, and magnetic properties — plus fully solved exercise problems.
Solids keep their shape and volume because their particles (atoms, ions or molecules) are held by strong attractions. Crystalline solids have long-range order, sharp melting points and are anisotropic; amorphous solids have only short-range order, soften over a range of temperature and are isotropic.
Crystalline solids are grouped by the particles and forces in them: ionic (ions, electrostatic forces), covalent network (atoms, covalent bonds), molecular (molecules, van der Waals or hydrogen bonds) and metallic (cations in a sea of electrons).
A crystal is a lattice plus a basis. The smallest repeating block is the unit cell; there are 7 crystal systems and 14 Bravais lattices. Cubic cells hold 1 (sc), 2 (bcc) or 4 (fcc) particles, and density = zM ÷ (a³Nᴀ).
Equal spheres pack most tightly in hcp (ABAB) or ccp/fcc (ABCABC) arrangements: coordination number 12, 74 % of space filled. N packed spheres create N octahedral and 2N tetrahedral voids. bcc fills 68 % and simple cubic 52.4 %.
Real crystals have defects — Schottky, Frenkel, interstitial, impurity and non-stoichiometric (metal excess with F-centres, metal deficiency). Band theory separates conductors, semiconductors and insulators; doping gives n-type and p-type semiconductors. Unpaired electrons make solids paramagnetic or ferromagnetic.
Get a ✓ Verified tutor for “Solid State” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Sort these into crystalline and amorphous: quartz, window glass, table salt, polythene, iron, candle wax.
Answer: Crystalline: quartz, NaCl, iron. Amorphous: glass, polythene (wax usually treated as amorphous).
A solid melts at −78 °C (sublimes), is soft and does not conduct in any state. Another melts at 1710 °C, is very hard and does not conduct even when molten. Classify both.
Answer: First: molecular crystal; second: covalent network crystal.
Copper is fcc with a = 361 pm and M = 63.5 g mol⁻¹. Find its density.
Answer: About 8.97 g cm⁻³
Oxide ions form a ccp lattice; cation A fills one-eighth of the tetrahedral voids and cation B half of the octahedral voids. Find the formula.
Answer: AB₂O₄
Sodium is bcc with a = 429 pm. Find the radius of a Na atom and the density of sodium (M = 23 g mol⁻¹).
Answer: r ≈ 186 pm; ρ ≈ 0.97 g cm⁻³ (sodium floats on water).
NaCl is doped with 10⁻³ mol % SrCl₂. How many cation vacancies form per mole of NaCl?
Answer: 6.02 × 10¹⁸ cation vacancies per mole of NaCl
Predict the type of semiconductor: (a) Ge doped with Sb (b) Si doped with B (c) Si doped with P.
Answer: (a) n-type (b) p-type (c) n-type
| Quantity | Formula / value | Note |
|---|---|---|
| Particles per cell, z | sc 1, bcc 2, fcc 4 | corner 1/8, face 1/2, edge 1/4, body 1 |
| Radius, simple cubic | r = a/2 | spheres touch along the edge |
| Radius, bcc | r = √3a/4 | touch along body diagonal |
| Radius, fcc/ccp | r = √2a/4 = a/(2√2) | touch along face diagonal |
| Density | ρ = zM ÷ (a³Nᴀ) | a in cm → ρ in g cm⁻³ |
| Packing efficiency | sc 52.4 %, bcc 68 %, fcc/hcp 74 % | void 47.6 %, 32 %, 26 % |
| Coordination number | sc 6, bcc 8, fcc/hcp 12 | nearest neighbours |
| Voids for N spheres | N octahedral, 2N tetrahedral | octahedral void is bigger |
| Unit cells in a sample | atoms ÷ z or volume ÷ a³ | atoms = (mass ÷ M) × Nᴀ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the most correct answer. (i) Molecular solids are: crystalline / amorphous / ionic / metallic solids. (ii) Which is an n-type semiconductor: pure Si / Si doped with As / Si doped with Ga / Ge doped with In? (iii) In a Frenkel defect: electrical neutrality changes / density changes / both cation and anion are missing / overall electrical neutrality is preserved. (iv) Void volume in a bcc lattice: 68 / 74 / 32 / 26 %. (v) Coordination number in bcc: 2 / 4 / 6 / 8.
Answer: (i) a. crystalline solids (ii) b. Si doped with As (iii) d. overall electrical neutrality is preserved (iv) c. 32 % (v) d. 8
2. 1. (vi) Which statement is NOT correct? a. Four spheres make a tetrahedral void. b. The centres of spheres around an octahedral void are at the apices of a regular tetrahedron. c. For N atoms there are 2N octahedral voids. d. For N/2 atoms there are N tetrahedral voids. (vii) A compound forms hcp. Octahedral and tetrahedral voids in 0.5 mol are… (viii) Pb is fcc with edge 495 pm; radius of Pb is 205 / 185 / 260 / 175 pm.
Answer: (vi) b (statement c is also wrong — the book's question has two incorrect statements; b is the intended answer) (vii) a. 3.011 × 10²³, 6.022 × 10²³ (viii) d. 175 pm
3. 2. Answer in one or two sentences: (i) particles in the four classes of crystalline solids; (ii) most and least efficient packing used by metals; (iii) classify materials from band pictures; (iv) unit cell; (v) effect of temperature on semiconductor conductivity; (vi) label bands for Si; (vii) hard, brittle non-conductor whose melt conducts; (viii) two properties common to hcp and ccp; (ix) tetrahedral void; (x) ferromagnetic substances.
Answer: (i) Ionic: cations and anions; covalent network: atoms; molecular: molecules (or noble-gas atoms); metallic: metal cations in a sea of electrons. (ii) hcp/ccp (74 %) is the most efficient, simple cubic (52.4 %) the least. (iii) Partly filled or overlapping bands → metal; full valence band with a small gap → semiconductor; full valence band with a large gap → insulator. (iv) The smallest repeating unit which, repeated in three directions, builds the entire crystal lattice. (v) It increases, because heat promotes more electrons across the small band gap into the conduction band. (vi) Lower filled band = valence band, upper empty band = conduction band, the energy gap between them = band gap (about 1.1 eV for Si). (vii) An ionic solid. (viii) Coordination number 12 and packing efficiency 74 % (also N octahedral and 2N tetrahedral voids). (ix) Three spheres in a triangle with a fourth resting in the hollow above them; the hole enclosed is the tetrahedral void. (x) Substances whose unpaired electron spins line up in domains, so they are strongly attracted by a magnet and can be permanently magnetised — Fe, Co, Ni, CrO₂.
4. 3. Answer in brief: (i) valence and conduction band; (ii) ionic vs molecular solids; (iii) atoms in fcc unit cell; (iv) arrangement of layers in simple cubic packing; (v) packing efficiency of simple cubic; (vi) paramagnetic substances; (vii) consequences of the Schottky defect.
Answer: (i) The band formed from filled valence orbitals is the valence band; the next higher band of empty orbitals, in which electrons can move freely, is the conduction band. (ii) Ionic solids: ions held by strong electrostatic forces, hard and brittle, high melting, conduct when molten (NaCl). Molecular solids: molecules held by weak intermolecular forces, soft, low melting, non-conducting in all states (ice, I₂). (iii) 4 atoms. (iv) In the first layer spheres are in square rows, each touching 4; every later layer is placed exactly above the one below (AAA…), so each sphere has 6 neighbours. (v) 52.4 %. (vi) Substances with unpaired electrons, weakly attracted by a magnetic field and losing magnetism when the field is removed — O₂, Cu²⁺, Fe³⁺, Cr³⁺ salts. (vii) Density decreases; the crystal stays electrically neutral; the vacancies let ions move, so conductivity of the solid increases slightly; lattice energy and stability fall.
5. 3. (viii) CsCl: Cl⁻ at the corners and Cs⁺ at the body centre. How many CsCl units per unit cell? (ix) Cu crystallizes in an fcc cell with edge 495 pm. Radius of Cu? (x) Relate density and edge length.
Answer: (viii) 1 formula unit. (ix) 175 pm with the book's data — but the real edge of copper is about 361 pm (r ≈ 128 pm); 495 pm is the edge for lead, so the book's value for Cu is wrong. (x) ρ = zM/(a³Nᴀ).
6. 4. Iridium: density 22.4 g cm⁻³, fcc, M = 192.2 g mol⁻¹. Find the atomic radius. 5. Al is ccp with a = 353.6 pm. Find r and the number of unit cells in 1.00 cm³.
Answer: 4. 136 pm. 5. 125 pm; 2.26 × 10²² unit cells (both match the book).
7. 6. Atoms of Y form hcp; X occupies one third of the tetrahedral voids. Formula? 7. How are tetrahedral and octahedral voids formed? 8. Difference in placing the third layer for hcp and ccp.
Answer: 6. X₂Y₃. 7. When a sphere of the second layer rests on a triangular hollow of three spheres of the first layer, the space enclosed by these four is a tetrahedral void. Where a triangular hollow of the second layer lies over an opposite-pointing hollow of the first layer, six spheres (three from each layer) surround a larger octahedral void. 8. In hcp the third layer covers the tetrahedral voids of the second layer and sits exactly over the first layer (ABAB…). In ccp it covers the octahedral voids of the second layer, so it matches neither earlier layer and only the fourth layer repeats the first (ABCABC…).
8. 9. An element (M = 27 g mol⁻¹) forms a cubic cell of edge 405 pm and density 2.7 g cm⁻³. What is the cell type? 10. An element is bcc with a = 288 pm. How many unit cells and atoms are in 200 g? (book answer 1.16 × 10²⁴, 2.32 × 10²⁴)
Answer: 9. z = 4 → face-centred cubic (ccp) — aluminium. 10. 1.16 × 10²⁴ unit cells and 2.33 × 10²⁴ atoms (book 2.32 × 10²⁴). The book leaves out the density (7.2 g cm⁻³) needed to solve it.
9. 11. Distinguish conductors, insulators and semiconductors with band diagrams. 12. n-type semiconductors and why they conduct better. 13. Frenkel defect. 14. Impurity defect and aliovalent impurity.
Answer: 11. Conductors (metals): valence band partly filled or overlapping the conduction band, no gap, conductivity falls a little on heating. Semiconductors: filled valence band, small gap (Si ≈ 1.1 eV), conductivity small but rising with temperature. Insulators: filled valence band, wide gap (diamond ≈ 5.5 eV), practically no conduction. 12. Si or Ge doped with a group 15 element (P, As, Sb); four of its five valence electrons bond with Si, the fifth is loosely held and enters the conduction band (donor level just below it), so many extra electrons carry current — far more than the few thermally excited electrons in pure Si. 13. A cation leaves its lattice site and occupies an interstitial void, creating a vacancy–interstitial pair (draw Ag⁺ displaced in AgCl). Conditions: large difference in ion sizes (small cation) and low coordination number. Density and electrical neutrality do not change. Examples: AgCl, AgBr, AgI, ZnS. 14. An impurity defect is a foreign atom or ion in a lattice site or interstitial site. Types: substitutional and interstitial. Aliovalent impurity: an ion with a different charge, e.g. SrCl₂ in NaCl — each Sr²⁺ replaces two Na⁺, occupying one site and leaving the other vacant, so cation vacancies equal the Sr²⁺ ions added (CdCl₂ in AgCl behaves the same).
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Which property is shown only by crystalline solids?
Answer: C. Ordered arrangement makes properties direction dependent.
2. Diamond and graphite are an example of…
Answer: D. Same element, two crystal forms.
3. Which is a covalent network solid?
Answer: D. Silicon carbide is a 3-D web of covalent bonds.
4. The number of atoms in a bcc unit cell is…
Answer: A. 8 × 1/8 + 1 = 2.
5. In an fcc cell of edge a, the atomic radius is…
Answer: C. Atoms touch along the face diagonal: 4r = √2a.
6. Coordination number in hcp is…
Answer: A. Each sphere touches 6 in its own layer and 3 above, 3 below.
7. Packing efficiency of a simple cubic lattice is…
Answer: B. π/6 = 0.524.
8. A metal X (fcc) has density ρ, molar mass M, edge a. Which gives Nᴀ?
Answer: D. From ρ = zM/(a³Nᴀ) with z = 4.
9. Anions form ccp; cations fill all octahedral voids. Formula?
Answer: C. N anions, N octahedral voids → 1 : 1 (NaCl type).
10. Which crystal is most likely to show a Frenkel defect?
Answer: D. Ag⁺ is small enough to sit in interstitial sites.
11. The Schottky defect…
Answer: C. Ion pairs are missing from the lattice.
12. An F-centre is…
Answer: D. Trapped electrons absorb light and give colour.
13. Germanium doped with gallium is…
Answer: B. Ga has 3 valence electrons → holes.
14. Which is ferromagnetic?
Answer: D. CrO₂ is ferromagnetic; O₂ is only paramagnetic.
15. FeO is actually Fe₀.₉₅O. This is a…
Answer: B. Some Fe²⁺ become Fe³⁺ and cation sites stay empty.
