Rotational DynamicsClass 12 Physics Chapter 1 Notes – Maharashtra Board

Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 1–25

Fans, wheels, merry-go-rounds, cars on curved roads and planets all move along circles or spin about an axis. This chapter builds the physics of such motion: uniform and non-uniform circular motion, the forces that keep vehicles on level and banked roads, the conical pendulum, motion in a vertical circle, moment of inertia and radius of gyration, the parallel and perpendicular axis theorems, angular momentum and its conservation, and rolling without slipping — with every exercise solved step by step.

🎧 Listen to the summary

Summary: Rotational Dynamics

Circular motion is always accelerated because the direction of velocity keeps changing. Angular displacement θ, angular velocity ω = dθ/dt and angular acceleration α = dω/dt play the roles of s, v and a; the linear speed is v = ωr and ω = 2π/T = 2πn. In uniform circular motion the only acceleration is centripetal, a = ω²r = v²/r, pointing to the centre; in non-uniform motion a tangential part a_t = αr is added.

A centripetal force is not a new kind of force — friction, tension, gravity or a normal reaction supplies it. On a level road friction limits the speed to v_max = √(μrg); on a road banked at θ the safe speed without friction is v = √(rg tanθ), and with friction the speed range is set by (tanθ ± μ)/(1 ∓ μ tanθ). A two-wheeler on a level curve must lean by tanθ = v²/(rg).

In a conical pendulum the bob moves in a horizontal circle and T = 2π√(L cosθ/g). In a vertical circle on a string the speed is least at the top (at least √(rg)) and greatest at the bottom (at least √(5rg)); the tension at the bottom exceeds that at the top by 6mg whatever the speed or radius.

Moment of inertia I = Σmr² measures how hard a body is to spin up; it depends on the mass and on how that mass is spread about the axis. The radius of gyration K is defined by I = MK². The parallel axis theorem I = I_c + Mh² and the perpendicular axis theorem I_z = I_x + I_y let us find I about new axes.

Angular momentum L = Iω and torque τ = Iα are the rotational partners of p = mv and F = ma. When the net external torque is zero, Iω stays constant — divers, skaters and planets use this. A body rolling without slipping has total kinetic energy ½mv²(1 + K²/R²), so on an incline its acceleration is g sinθ/(1 + K²/R²): bodies with smaller K²/R² roll down faster.

Key points to remember

  • v = ωr; ω = 2π/T = 2πn; centripetal acceleration a_r = ω²r = v²/r, towards the centre
  • Tangential acceleration a_t = αr; total acceleration a = √(a_r² + a_t²) in non-uniform circular motion
  • Centrifugal force (mω²r, outward) is a pseudo force seen only from the rotating frame
  • Level road: v_max = √(μ_s rg); well of death: v_min = √(rg/μ_s)
  • Banked road, no friction: tanθ = v²/(rg); with friction v_max² = rg(tanθ + μ)/(1 − μ tanθ), v_min² = rg(tanθ − μ)/(1 + μ tanθ)
  • Two-wheeler on a level curve leans so that tanθ = v²/(rg)
  • Conical pendulum: tanθ = v²/(rg), T = 2π√(L cosθ/g), frequency independent of the mass
  • Vertical circle (string): v_top ≥ √(rg), v_bottom ≥ √(5rg), v at horizontal ≥ √(3rg); T_bottom − T_top = 6mg
  • Vertical circle with a rigid rod: v_top can be zero, v_bottom ≥ √(4rg) = 2√(rg)
  • I = Σmr²; ring (axis) MR², disc (axis) ½MR², solid sphere ⅖MR², rod (centre, transverse) ML²/12
  • I = MK²; parallel axes I_o = I_c + Mh²; perpendicular axes (lamina only) I_z = I_x + I_y
  • L = Iω, τ = Iα = dL/dt; if τ_ext = 0 then I₁ω₁ = I₂ω₂
  • Rolling: KE = ½mv²(1 + K²/R²); a = g sinθ/(1 + K²/R²); v² = 2gh/(1 + K²/R²)
Want a teacher to explain Rotational Dynamics?

Get a ✓ Verified tutor for “Rotational Dynamics” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.

Get a tutor for this chapter →

Rotational Dynamics – question answers

1 question

Questions students asked about this chapter, answered and checked by TalentJR.

Explain Rotational Dynamics in simple words

From your chapter: Rotational dynamics is the study of how objects rotate and the forces that cause this rotation. It involves concepts like torque, angular momentum, and the moment of inertia.

  • Torque is the force that causes an object to rotate. It depends on the force applied and the distance from the pivot point.
  • Angular momentum is a measure of how much motion an object has while rotating. It depends on the object's mass, shape, and speed of rotation.
  • Moment of inertia is how difficult it is to change an object's rotation. It depends on the mass distribution of the object.

These concepts help us understand how things like wheels, planets, and spinning tops move.

Extra help: Think of a merry-go-round. The harder you push (torque), the faster it spins. If you sit closer to the center, it spins faster than if you sit at the edge. This is because of the moment of inertia!
