Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 26–55
Liquids and gases cannot hold a shape of their own — they flow. This chapter explains how fluids push (pressure, Pascal's law, the hydraulic lift and barometers), why liquid surfaces behave like stretched skins (surface tension, angle of contact, excess pressure in drops and bubbles, capillary rise), why some liquids flow sluggishly (viscosity, Stokes' law, terminal velocity, Reynolds number) and how moving fluids trade pressure for speed (equation of continuity and Bernoulli's equation with its everyday applications). Every exercise question is answered step by step at the end.
A fluid is any substance that flows because it cannot resist a shear stress. An ideal fluid is taken to be incompressible, non-viscous, irrotational and steady. Pressure p = F/A is a scalar measured in pascal (N m⁻²); at depth h in a liquid of density ρ the pressure is p = p₀ + hρg, so it depends only on depth, not on the shape of the vessel (the hydrostatic paradox).
Pascal's law: an extra pressure applied to an enclosed liquid reaches every part of it undiminished. A hydraulic lift multiplies force in the ratio of piston areas, F₂ = F₁(A₂/A₁). A mercury barometer measures atmospheric pressure (about 76 cm of Hg = 1.013 × 10⁵ Pa); an open-tube manometer reads gauge pressure, and absolute pressure = atmospheric + gauge.
Surface tension T is force per unit length along a line drawn in the surface, or equally the surface energy per unit area (N m⁻¹ = J m⁻²). It arises because molecules at the surface have unbalanced inward cohesive pulls. The angle of contact decides whether a liquid wets a solid (acute angle, concave meniscus, rise in a capillary) or not (obtuse angle, convex meniscus, fall). Excess pressure is 2T/R inside a drop and 4T/R inside a soap bubble; capillary rise is h = 2T cosθ/(rρg).
Viscosity is internal friction between fluid layers: f = ηA(dv/dx), with η in N s m⁻² (1 poise = 0.1 N s m⁻²). A small sphere falling slowly feels Stokes' drag 6πηrv and soon reaches a terminal velocity v_t = 2r²(ρ − σ)g/(9η). The Reynolds number Rₙ = vρd/η decides the flow type: below 1000 streamline, above 2000 turbulent, in between unsteady.
For steady flow of an incompressible fluid, A₁v₁ = A₂v₂ (equation of continuity — conservation of mass), so liquid speeds up in a narrow pipe. Bernoulli's equation p + ½ρv² + ρgh = constant expresses conservation of energy along a streamline; where the speed is high the pressure is low. It explains Torricelli's speed of efflux √(2gh), the venturimeter, aircraft lift, atomizers and roofs lifted off in storms.
Get a ✓ Verified tutor for “Mechanical Properties of Fluids” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A diver is 15 m below the surface of a freshwater lake (ρ = 1000 kg/m³, p₀ = 1.01 × 10⁵ Pa, g = 9.8 m/s²). Find the gauge and absolute pressure on her.
Answer: Gauge 1.47 × 10⁵ Pa; absolute 2.48 × 10⁵ Pa.
In a car-service lift the small piston has diameter 4 cm and the large one 40 cm. What force on the small piston can hold up a 1500 kg car? (g = 9.8 m/s²)
Answer: About 147 N (roughly the weight of 15 kg).
A mercury drop of radius 3 mm is split into 27 equal droplets. Find the work done (T for mercury = 0.47 N/m).
Answer: About 1.06 × 10⁻⁴ J.
Water (T = 0.073 N/m, θ = 0°) rises in a glass tube of internal diameter 0.6 mm. Find the height. (ρ = 1000 kg/m³, g = 9.8 m/s²)
Answer: About 5.0 cm.
A steel ball of radius 1 mm (density 7800 kg/m³) falls through glycerine (density 1260 kg/m³, η = 1.5 N s/m²). Find its terminal velocity. (g = 9.8 m/s²)
Answer: About 9.5 mm/s.
Water flows through a horizontal pipe whose diameter narrows from 8 cm to 4 cm. The speed in the wide part is 1.5 m/s and the pressure there is 1.8 × 10⁵ Pa. Find the speed and pressure in the narrow part.
Answer: v₂ = 6.0 m/s; p₂ ≈ 1.63 × 10⁵ Pa.
| Quantity | Formula | Unit / note |
|---|---|---|
| Pressure at depth | p = p₀ + hρg | Pa; same at equal depths |
| Hydraulic lift | F₂ = F₁A₂/A₁ | Pascal's law |
| Surface tension | T = F/L = W/ΔA | N m⁻¹ = J m⁻² |
| Excess pressure | drop 2T/R; soap bubble 4T/R | concave side at higher pressure |
| Capillary rise | h = 2T cosθ/(rρg) | h ∝ 1/r |
| Newton's law of viscosity | f = ηA dv/dx | η in N s m⁻² |
| Stokes' law | F = 6πηrv | small sphere, slow motion |
| Terminal velocity | v_t = 2r²(ρ − σ)g/(9η) | v_t ∝ r² |
| Reynolds number | Rₙ = vρd/η | < 1000 streamline, > 2000 turbulent |
| Continuity | A₁v₁ = A₂v₂ | conservation of mass |
| Bernoulli | p + ½ρv² + ρgh = constant | conservation of energy |
| Torricelli efflux | v = √(2gh) | or √(2p/ρ) for gauge pressure p |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Multiple choice: (i) Load of 2000 kg on a piston of area 2.25 × 10⁻² m² — maximum pressure? (ii) Capillaries of radii 0.3 cm and 0.6 cm — ratio of rises? (iii) Energy stored in a soap bubble of diameter 6 cm, T = 0.04 N/m? (iv) Hailstones with radii 1 : 4 — ratio of terminal velocities? (v) What is conserved in Bernoulli's theorem?
Answer: (i) A; (ii) B 2 : 1; (iii) A; (iv) C 1 : 16; (v) D energy.
2. Q2 Answer in brief: (i) Why is the surface tension of paints and lubricating oils kept low? (ii) Work done in forming a soap bubble of radius r? (iii) Basis of Bernoulli's principle? (iv) Why is a low-density liquid used in a laboratory manometer? (v) What is an incompressible fluid?
Answer: See the steps for each brief answer.
3. Q3–Q5 (3) Why do two or more mercury drops form a single drop on touching? (4) Why does water speed up on entering a narrow pipe from a broad one? (5) Why do speed rise and pressure fall at a constriction in a horizontal pipe?
Answer: (3) Lower surface energy; (4) continuity A₁v₁ = A₂v₂; (5) continuity plus Bernoulli.
4. Q6 Derive the excess pressure inside a liquid drop.
Answer: Δp = 2T/R for a drop (4T/R for a soap bubble).
5. Q7 Obtain the conservation of mass starting from the equation of continuity.
Answer: ρAv = constant (mass flux constant); A₁v₁ = A₂v₂ for an incompressible fluid.
6. Q8 and Q9 Explain capillary action and derive the capillary rise for a liquid with a concave meniscus.
Answer: h = 2T cosθ/(rρg).
7. Q10 Find the pressure 200 m below the ocean surface if the surface pressure is 1 atm (ρ = 1060 kg/m³).
Answer: 21.789 × 10⁵ N/m² (matches the book).
8. Q11 Hydraulic lift: input piston 30 cm², output piston 1500 cm², 25 N on the input. Find the load on the output.
Answer: 1250 N.
9. Q12 Viscous force on a raindrop of diameter 1 mm falling steadily at 2 m/s through air (η = 1.8 × 10⁻⁵ N s/m²).
Answer: 3.393 × 10⁻⁷ N.
10. Q13 A 1 N force moves a plate of area 10⁻² m² at 2 × 10⁻² m/s on an oil layer 1.5 × 10⁻³ m thick. Find η.
Answer: 7.5 N s/m².
11. Q14 Terminal velocity of an air bubble 0.4 mm in diameter in a liquid of η = 0.1 N s/m² and specific gravity 0.9 (air 1.29 kg/m³).
Answer: −0.783 × 10⁻³ m/s; the minus sign means the bubble rises at about 0.78 mm/s (book: −0.782 × 10⁻³ m/s).
12. Q15 Water moves at 2 m/s in a pipe of diameter 10 cm. What nozzle diameter gives a speed of 4 m/s?
Answer: 7.07 × 10⁻² m.
13. Q16 Speed of water leaving an orifice of a tank with gauge pressure 4 × 10⁵ N/m² (ρ = 1000 kg/m³).
Answer: ≈ 28.28 m/s.
14. Q17 Pressure in a closed water pipe is 3 × 10⁵ N/m²; on opening the valve it falls to 2 × 10⁵ N/m². Find the flow speed.
Answer: ≈ 14.14 m/s.
15. Q18 Rise of water in a clean glass capillary of radius 0.1 mm (T = 7 × 10⁻² N/m, θ = 0, g = 9.8 m/s²).
Answer: ≈ 0.1429 m.
16. Q19 Gauge pressure in an air bubble of radius 0.2 mm just below the water surface (T = 7.2 × 10⁻² N/m).
Answer: 720 N/m².
17. Q20 Twenty-seven water droplets of radius 0.1 mm coalesce into one drop (T = 0.072 N/m). Find the change in surface energy.
Answer: ≈ 1.63 × 10⁻⁷ J = 1.63 erg released (book: 1.628 × 10⁻⁷ J).
18. Q21 A mercury drop of radius 0.2 cm breaks into 8 identical droplets (T = 435.5 dyne/cm). Find the work done.
Answer: 2.189 × 10⁻⁵ J.
19. Q22 Work needed to form a soap bubble of radius 2 cm (T = 0.07 N/m).
Answer: ≈ 0.704 × 10⁻³ J (book: 0.7038 × 10⁻³ J).
20. Q23 A soap film on a square frame is enlarged from 2 cm × 2 cm to 3 cm × 3 cm (T = 3 × 10⁻² N/m). Find the work done.
Answer: 3 × 10⁻⁵ J.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The pressure at the base of a liquid column depends on…
Answer: A. p = hρg + p₀.
2. A hydraulic lift has piston areas 10 cm² and 500 cm². A 20 N push on the small piston can support…
Answer: A. F₂ = 20 × 500/10 = 1000 N.
3. Absolute pressure equals…
Answer: C. Gauge pressure is measured above atmospheric.
4. The SI unit of surface tension is…
Answer: B. Force per unit length.
5. A liquid that wets glass has an angle of contact…
Answer: B. Acute angle → concave meniscus and wetting.
6. The excess pressure inside a soap bubble of radius R is…
Answer: C. A soap film has two surfaces.
7. If the radius of a capillary tube is halved, the rise of water…
Answer: C. h ∝ 1/r.
8. Adding detergent to water…
Answer: B. Detergents concentrate at the surface and reduce T.
9. The dimensions of the coefficient of viscosity are…
Answer: C. η = f/(A dv/dx) → N s m⁻².
10. Terminal velocity of a small sphere is proportional to…
Answer: B. v_t = 2r²(ρ − σ)g/(9η).
11. Viscosity of a liquid on heating…
Answer: B. Cohesive forces weaken as temperature rises.
12. Flow with Reynolds number 3500 is…
Answer: B. Above about 2000 the flow is turbulent.
13. Water enters a pipe narrowing to half its diameter. Its speed becomes…
Answer: C. A ∝ d², so v ∝ 1/d².
14. Bernoulli's equation is a statement of conservation of…
Answer: C. Each term is energy per unit volume.
15. Water leaves a hole 5 m below the surface of an open tank (g = 10 m/s²) at…
Answer: D. v = √(2gh) = √100 = 10 m/s.
