Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 344–364
Every phone charger, solar panel, LED bulb and computer chip relies on p-n junctions. This chapter shows how diodes rectify AC into DC (half-wave and full-wave rectifiers, ripple and filters), how special diodes work — the Zener regulator, photodiode, solar cell and LED — how a bipolar junction transistor amplifies in the common-emitter mode, and how logic gates (NOT, OR, AND, NAND, NOR, XOR) process digital signals.
A p-n junction diode conducts when forward biased and almost blocks current when reverse biased, so it acts like a one-way switch. A half-wave rectifier uses one diode and passes only alternate half-cycles (ripple at the supply frequency); a full-wave rectifier (centre-tap or bridge) uses both halves (ripple at twice the supply frequency, higher efficiency: 81.2 % against 40.6 %). A capacitor or LC filter smooths the pulsating output into nearly steady DC.
A Zener diode is heavily doped and designed to work in reverse breakdown; the voltage across it stays almost fixed at V_Z over a wide range of current, so with a series resistor it regulates the voltage across a load.
Optoelectronic junctions: a photodiode is operated in reverse bias and its small reverse current rises in proportion to light intensity; a solar cell has no external bias and turns light into electrical power by the photovoltaic effect (open-circuit voltage and short-circuit current); an LED is forward biased and emits light when electrons and holes recombine, its colour set by the band gap of the compound semiconductor.
A bipolar junction transistor (n-p-n or p-n-p) has a heavily doped emitter, a thin lightly doped base and a larger collector. With the emitter–base junction forward biased and the collector–base junction reverse biased, I_E = I_B + I_C, and the small base current controls a much larger collector current: α = I_C/I_E (just below 1) and β = I_C/I_B (typically 20–200), with β = α/(1 − α). In common-emitter mode it amplifies a signal with voltage gain −β R_L/r_i (output 180° out of phase).
Digital circuits use two levels, 0 and 1. Basic gates: NOT (Y = Ā), OR (Y = A + B), AND (Y = A·B), and the combinations NAND, NOR and XOR (Y = ĀB + AB̄). NAND and NOR are universal gates: any logic circuit can be built from either one alone.
Get a ✓ Verified tutor for “Semiconductor Devices” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A rectifier is fed from a 60 Hz supply. What is the ripple (output) frequency for half-wave and for full-wave rectification? What is the peak output of a full-wave rectifier fed with 12 V rms (ideal diodes)?
Answer: 60 Hz; 120 Hz; about 17 V
A full-wave rectifier with a capacitor filter feeds a load. If R_L = 1 kΩ and C = 470 μF on 50 Hz mains, compare the time constant with the gap between pulses.
Answer: RC = 0.47 s ≫ 0.01 s, so the ripple is small
A 9 V Zener regulator has V_in = 15 V, R_S = 200 Ω and R_L = 1 kΩ. Find the currents in R_S, the load and the Zener.
Answer: 30 mA, 9 mA, 21 mA
(a) An LED emits light of 620 nm. Estimate the band gap of its material. (b) What is the longest wavelength a silicon photodiode (E_g = 1.1 eV) can detect?
Answer: (a) about 2.0 eV; (b) about 1130 nm
A transistor has β = 99. In common emitter the emitter current is 5 mA. Find α, I_B and I_C.
Answer: α = 0.99; I_C = 4.95 mA; I_B = 0.05 mA
A CE amplifier has β_ac = 100, input resistance r_i = 1 kΩ and load R_L = 4 kΩ. Find the voltage gain, power gain and the output for a 10 mV input.
Answer: A_v = −400; A_p = 4 × 10⁴; output 4 V (180° out of phase)
| Item | Rule / formula | Note |
|---|---|---|
| Half-wave rectifier | output frequency = f | efficiency up to 40.6 % |
| Full-wave rectifier | output frequency = 2f | efficiency up to 81.2 % |
| Ripple factor | rms of AC part ÷ DC value | smaller is better |
| Zener regulator | I_S = I_Z + I_L; V_L = V_Z | reverse biased |
| Photon/band gap | E_g ≈ hc/λ = 1240/λ(nm) eV | LED colour, photodiode limit |
| Transistor currents | I_E = I_B + I_C | — |
| Current gains | α = I_C/I_E; β = I_C/I_B | β = α/(1 − α) |
| CE voltage gain | A_v = −β R_L/r_i | 180° phase change |
| Power gain | A_p = β × |A_v| | — |
| NOT / OR / AND | Y = Ā; Y = A + B; Y = A·B | basic gates |
| NAND / NOR | Y = (A·B)‾; Y = (A + B)‾ | universal gates |
| XOR | Y = ĀB + AB̄ | 1 when inputs differ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v and the second iv): (i) Largest current in a BJT flows in the emitter, collector, base or CB junction? (ii) Purpose of the series resistance in a Zener circuit? (iii) An LED emits light when…? (v) A solar cell works on…? (iv) A logic gate is a circuit which…?
Answer: (i) A, (ii) B, (iii) C, (v) C, (iv) A
2. Q2 (i–v): (i) Why is the base thin and lightly doped? (ii) Zener versus ordinary diode. (iii) What decides the wavelength of an LED? (iv) Why is a photodiode reverse biased? (v) Principle and uses of a solar cell.
Answer: Model answers as above
3. Q3–Q5: Half-wave rectifier circuit and its ripple frequency; why filters are needed; full-wave rectifier circuit and working.
Answer: Model answers as above; draw the input and output waveforms
4. Q6–Q10: How a Zener keeps the load voltage constant; forward and reverse characteristic of a Zener; working of an LED; construction and working of a solar cell; principle of a photodiode.
Answer: Model answers as above
5. Q11–Q14: Logic gate, truth table and Boolean expression; AND gate; uses of logic gates and why NOT is an inverter; Boolean expressions for OR, AND and NAND.
Answer: Model answers as above
6. Q15–Q17: Why the emitter, base and collector are doped differently; biasing used for an amplifier; define α and β and relate them.
Answer: β = α/(1 − α)
7. Q18. α = 0.967 and I_E = 10 mA. Find I_B.
Answer: 0.33 mA
8. Q19. In common base, I_E = 10 mA and I_C = 9.8 mA. Find I_B.
Answer: 0.2 mA
9. Q20. In common base, I_E = 6.28 mA and I_C = 6.20 mA. Find the DC current gain.
Answer: α ≈ 0.987
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. In a BJT, the largest current flows in the…
Answer: C. I_E = I_B + I_C.
2. A series resistance in a Zener diode circuit is used to…
Answer: C. It limits the current through the diode.
3. An LED emits visible light when…
Answer: B. Recombination releases photons.
4. A solar cell operates on the principle of…
Answer: A. Light creates a voltage across the junction.
5. A logic gate is an electronic circuit that…
Answer: C. Its output follows a logical rule.
6. The ripple frequency of a full-wave rectifier on 50 Hz mains is…
Answer: B. Two pulses per cycle.
7. Maximum efficiency of a half-wave rectifier is…
Answer: C. Half the input is unused.
8. A photodiode is normally operated in…
Answer: A. Fractional change of current is largest.
9. The base of a transistor is…
Answer: B. So most carriers pass to the collector.
10. For a transistor with α = 0.98, β is…
Answer: A. 0.98/0.02.
11. The output of a CE amplifier is…
Answer: D. A rise in I_C lowers V_CE.
12. The output of a NOR gate is 1 only when…
Answer: B. NOT of OR.
13. Which are universal gates?
Answer: C. Any gate can be built from either.
14. XOR with inputs A = 1, B = 1 gives…
Answer: D. Same inputs give 0.
15. An LED emitting 500 nm light has a band gap of about…
Answer: B. 1240/500.
