Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 324–343
What is inside an atom, and what holds a nucleus together? This chapter goes from Thomson’s plum-pudding model through Rutherford’s gold-foil experiment to Bohr’s model of hydrogen and its spectral series, then into the nucleus: its size and density, the strong nuclear force, mass defect and binding energy, alpha, beta and gamma decay, the law of radioactive decay with half-life and mean life, and nuclear fission and fusion — with every exercise numerical worked and checked.
Thomson pictured the atom as a sphere of positive charge with electrons embedded in it. The Geiger–Marsden alpha-scattering experiment proved this wrong: most alphas went straight through gold foil but a few bounced back. Rutherford concluded that all the positive charge and almost all the mass sit in a tiny nucleus (about 10⁻¹⁵–10⁻¹⁴ m), with electrons orbiting far outside. His model could not explain atomic stability or line spectra.
Bohr’s postulates — stable orbits with angular momentum nh/2π, and radiation only when an electron jumps between orbits (hν = E_i − E_f) — give rₙ = ε₀h²n²/(πmZe²), vₙ = Ze²/(2ε₀hn) and Eₙ = −13.6 Z²/n² eV for hydrogen-like atoms. Transitions give 1/λ = R(1/n₁² − 1/n₂²), the Lyman (UV), Balmer (visible), Paschen, Brackett and Pfund series. De Broglie’s view: an allowed orbit holds a whole number of electron wavelengths.
A nucleus of mass number A has radius R = R₀A^(1/3), with R₀ ≈ 1.2 fm, so all nuclei have the same enormous density, about 2.3 × 10¹⁷ kg m⁻³. Protons and neutrons are held by the strong nuclear force: very strong, short-range (a few fm), charge-independent and attractive except at very short distances.
The mass of a nucleus is less than the total mass of its nucleons; this mass defect Δm corresponds to the binding energy Δm c² (1 u ↔ 931.5 MeV). Binding energy per nucleon peaks near A = 56 (iron, about 8.8 MeV), so energy is released when heavy nuclei split (fission) or light nuclei join (fusion).
Unstable nuclei decay by emitting α (helium nucleus), β⁻ (electron plus antineutrino), β⁺ (positron plus neutrino) or γ (photon). Decay is random but follows N = N₀e^(−λt); half-life T½ = 0.693/λ, mean life τ = 1/λ, and activity A = λN (unit becquerel; 1 Ci = 3.7 × 10¹⁰ Bq).
Get a ✓ Verified tutor for “Structure of Atoms and Nuclei” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A 5 MeV alpha particle approaches a gold nucleus (Z = 79) head-on. Find its distance of closest approach.
Answer: About 4.5 × 10⁻¹⁴ m
For hydrogen, find the radius and energy of the n = 3 orbit and the energy needed to ionise an electron from it.
Answer: 0.477 nm; −1.51 eV; 1.51 eV
Find the wavelength of the first Balmer line (Hα) of hydrogen.
Answer: 656 nm
Find the binding energy of a deuteron. Atomic masses: ²H = 2.014102 u, ¹H = 1.007825 u; neutron 1.008665 u.
Answer: 2.22 MeV (1.11 MeV per nucleon)
A sample of 100 g of a nuclide with half-life 8 days is stored for 24 days. How much is left? Find λ and τ.
Answer: 12.5 g; λ ≈ 0.0866 day⁻¹; τ ≈ 11.5 days
Find the energy released in ²H + ³H → ⁴He + n. Masses: ²H 2.014102 u, ³H 3.016049 u, ⁴He 4.002603 u, n 1.008665 u.
Answer: About 17.6 MeV
| Quantity | Formula | Unit / note |
|---|---|---|
| Bohr radius | rₙ = ε₀h²n²/(πmZe²) | 0.053 n²/Z nm |
| Orbital speed | vₙ = Ze²/(2ε₀hn) | 2.19 × 10⁶ Z/n m s⁻¹ |
| Energy level | Eₙ = −13.6 Z²/n² | eV |
| Photon emitted | hν = E_i − E_f | J |
| Rydberg formula | 1/λ = R(1/n₁² − 1/n₂²) | R = 1.097 × 10⁷ m⁻¹ |
| Nuclear radius | R = R₀A^(1/3) | R₀ ≈ 1.2 fm |
| Mass defect | Δm = Zm_H + Nm_n − M | u |
| Binding energy | E_B = Δm × 931.5 | MeV |
| Decay law | N = N₀e^(−λt) | — |
| Half-life | T½ = 0.693/λ | s |
| Mean life | τ = 1/λ = 1.44 T½ | s |
| Activity | A = λN | Bq; 1 Ci = 3.7 × 10¹⁰ Bq |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) Smallest first-orbit radius: H, He⁺, deuterium or tritium? (ii) r₄ is smaller than r₈ by a factor of? (iii) Longest-wavelength transition: 2→1, 5→4, 7→6 or 8→7? (iv) Nuclear property independent of A? (v) N nuclei after two half-lives?
Answer: (i) B, (ii) B, (iii) D, (iv) D, (v) B
2. Q2 (i–v): (i) Bohr’s postulates. (ii) Difficulties of Rutherford’s model. (iii) α, β, γ decays. (iv) Excitation, binding and ionisation energy. (v) Show that the frequency of the first Lyman line equals the difference between the Lyman and Balmer series limits.
Answer: Model answers as above
3. Q3–Q5: Derive Eₙ for hydrogen; derive the Lyman and Balmer wavelengths and their shortest values; find the maximum angular speed of an electron in hydrogen.
Answer: E = −13.6/n² eV; 91.2 nm and 364.6 nm; ω_max ≈ 4.13 × 10¹⁶ rad s⁻¹
4. Q6. The Lyman series limit is 911.6 Å. Find the Balmer, Paschen and Brackett limits.
Answer: 3646 Å, 8204 Å, 14 586 Å
5. Q7–Q9: α, β, γ decays with energy formulae; fission and fusion with examples; principle of a reactor and reactor versus bomb.
Answer: Model answers as above
6. Q10. Binding energy of an α-particle of mass 4.00151 u (nuclear mass).
Answer: 28.29 MeV
7. Q11. An electron stays in hydrogen’s second orbit for 10⁻⁸ s. How many revolutions does it make?
Answer: 8.22 × 10⁶
8. Q12. Binding energy per nucleon of ²⁴⁴₉₅Am (atomic mass 244.06428 u).
Answer: ≈ 7.5 MeV
9. Q13. Energy released in ⁷₃Li + p → 2α (atomic masses ⁷Li 7.016 u, ⁴He 4.0026 u).
Answer: ≈ 17.35 MeV (book: 16.84 MeV)
10. Q14. Complete: (a) ²²⁶₈₈Ra → α + ? (b) ¹⁹₈O → e⁻ + ? (c) ²²⁸₉₀Th → α + ? (d) ¹²₇N → ¹²₆C + ?
Answer: (a) ²²²₈₆Rn, (b) ¹⁹₉F + ν̄, (c) ²²⁴₈₈Ra, (d) e⁺ + ν
11. Q15. Energy released in (a) ²²³Ra → ²⁰⁹Pb + ¹⁴C, (b) ²³⁶U → ¹⁴⁰Ba + ⁹⁴Kr + 2n, (c) ¹¹C → ¹¹B + e⁺ + ν. Masses (u): Ra 223.0185, Pb 208.9811, ¹⁴C 14.00324, U 236.0456, Ba 139.9106, Kr 93.9341, ¹¹C 11.01143, ¹¹B 11.0093; n 1.00866.
Answer: (a) 31.8 MeV, (b) 171.0 MeV, (c) 0.96 MeV (book: 32.096, 172.485, 1.485 MeV)
12. Q16. Living carbon: 15.3 decays g⁻¹ min⁻¹; old charcoal: 12.3. λ = 3.839 × 10⁻¹² s⁻¹. Age?
Answer: ≈ 1803 years
13. Q17. T½ of ⁹⁰Sr is 28 years. Activity of a 5 mg sample?
Answer: ≈ 2.63 × 10¹⁰ s⁻¹
14. Q18. Mass of ⁶⁰Co (T½ = 5.3 years) needed for a 10.0 mCi source?
Answer: ≈ 8.89 × 10⁻⁶ g
15. Q19. Decay rate 10¹⁰ per hour at 20 h and 6.3 × 10⁹ per hour at 30 h. Find T½ and the initial number of atoms.
Answer: 15 h; 5.45 × 10¹¹ atoms
16. Q20. ⁵⁷Co has T½ = 272 d. (a) Mean life and λ; (b) number of nuclei in a 2.0 μCi source; (c) activity after one year.
Answer: 3.39 × 10⁷ s, 2.95 × 10⁻⁸ s⁻¹; 2.51 × 10¹² nuclei; 0.789 μCi
17. Q21. ³²P (T½ = 14.3 d) and ³³P (T½ = 25.3 d): initially 90 % of decays are from ³²P. When will only 15 % be from ³²P?
Answer: ≈ 186.6 days
18. Q22. Atmospheric carbon had 0.255 Bq per gram of carbon. (a) Fraction of atoms that are ¹⁴C? (b) A 500 mg specimen shows 174 decays per hour. Age? (T½ = 5730 y)
Answer: (a) about 4 in 3 × 10¹² atoms; (b) ≈ 8020 years
19. Q23. Mass of ²³⁵U fissioned per day for 3000 MW of thermal power (202.79 MeV per fission)?
Answer: ≈ 3.1 kg
20. Q24. Mg has average atomic mass 24.312 u; ²⁴Mg (23.98504 u) is 78.99 %. Find the abundances of ²⁵Mg (24.98584 u) and ²⁶Mg (25.98259 u).
Answer: ²⁵Mg ≈ 9.3 %, ²⁶Mg ≈ 11.7 %
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The first-orbit radius is smallest for…
Answer: A. r ∝ 1/Z; He⁺ has Z = 2.
2. The radius of the 4th orbit is smaller than that of the 8th by a factor of…
Answer: A. r ∝ n²: 64/16.
3. Which transition in hydrogen gives the longest wavelength?
Answer: A. Smallest energy gap.
4. Which nuclear property does not depend on mass number?
Answer: A. ρ is the same for all nuclei.
5. After two half-lives, N nuclei become…
Answer: C. (½)².
6. In Rutherford’s experiment, a few alphas bounced back because…
Answer: B. Only a massive, concentrated charge can reverse an alpha.
7. The ionisation energy of hydrogen in its first excited state is…
Answer: C. |E₂| = 13.6/4.
8. The Balmer series lies in the…
Answer: B. n₁ = 2.
9. Nuclear radius of a nucleus with A = 64 is about…
Answer: B. 1.2 × 4.
10. In β⁻ decay, the mass number…
Answer: D. n → p + e⁻ + ν̄.
11. A gamma ray is emitted when…
Answer: D. No change in A or Z.
12. Mean life τ and half-life T½ are related by…
Answer: B. τ = 1/λ = T½/0.693.
13. Binding energy per nucleon is maximum for nuclei near…
Answer: B. Iron is the most stable.
14. The function of control rods in a reactor is to…
Answer: D. Cadmium or boron rods.
15. Fusion needs very high temperature in order to…
Answer: D. Nuclei must come within about 1 fm.
