Thermodynamics is the bookkeeping of heat, work and internal energy. This chapter starts from thermal equilibrium and the zeroth law, defines internal energy, heat and work, and builds the first law ΔU = Q − W. It then reads processes off p–V diagrams (isothermal, isobaric, isochoric, adiabatic, cyclic, free expansion), explains heat engines, refrigerators, heat pumps and air conditioners, states the second law in its Kelvin–Planck and Clausius forms, and ends with the Carnot engine and the Stirling cycle. All exercise questions — including the three graph problems — are solved at the end.
Two bodies in contact stop exchanging heat when they reach thermal equilibrium — the same temperature. The zeroth law says that if A and B are each in equilibrium with C, they are in equilibrium with each other; this is what makes thermometers possible.
Internal energy U is the total energy of the molecules (random kinetic plus intermolecular potential) and is a state function. Heat Q is energy transferred because of a temperature difference; work W is energy transferred by a force acting through a displacement, such as a piston moving (W = ∫p dV). The first law, ΔU = Q − W, is conservation of energy with Q positive when heat enters and W positive when the system does work.
On a p–V diagram work is the area under the path, and in a cycle the net work is the enclosed area. Isothermal: ΔU = 0, Q = W = nRT ln(V_f/V_i). Isobaric: W = pΔV. Isochoric: W = 0, Q = ΔU. Adiabatic: Q = 0, pV^γ = constant, W = (p_iV_i − p_fV_f)/(γ − 1). Cyclic: ΔU = 0, Q = W. Free expansion: Q = W = ΔU = 0.
A heat engine takes Q_H from a hot reservoir, does work W and rejects Q_C to a cold one: efficiency η = W/Q_H = 1 − Q_C/Q_H. A refrigerator uses work to pump heat from cold to hot: coefficient of performance K = Q_C/W. The second law says no engine can turn all heat into work (Kelvin–Planck) and heat cannot flow by itself from cold to hot (Clausius).
The Carnot cycle (two isothermals and two adiabatics, all reversible) gives the highest possible efficiency between two temperatures, η = 1 − T_C/T_H, independent of the working substance; a Carnot refrigerator has K = T_C/(T_H − T_C). The Stirling cycle uses two isothermals joined by two constant-volume steps and runs both as an engine and, reversed, as a cryogenic refrigerator.
Get a ✓ Verified tutor for “Thermodynamics” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A gas at a constant 2.0 × 10⁵ Pa expands from 3.0 L to 7.5 L. How much work does it do?
Answer: 900 J done by the gas.
A gas absorbs 1200 J of heat and at the same time 300 J of work is done on it by a piston. Find ΔU.
Answer: ΔU = +1500 J.
Two moles of an ideal gas expand isothermally at 400 K from 10 L to 30 L. Find the work done and the heat absorbed (R = 8.31 J mol⁻¹ K⁻¹).
Answer: W = Q ≈ 7.3 kJ.
A car engine burns fuel releasing 50 kJ per cycle and delivers 14 kJ of work. Find its efficiency and the heat dumped per cycle.
Answer: 28%; 36 kJ rejected each cycle.
A refrigerator removes 360 kJ of heat from its interior while its compressor uses 90 kJ of electrical work. Find K and the heat given to the kitchen.
Answer: K = 4; 450 kJ released to the kitchen.
A Carnot engine works between 527 °C and 127 °C and absorbs 2000 J per cycle from the source. Find η, W and Q_C.
Answer: η = 50%, W = 1000 J, Q_C = 1000 J.
| Process / law | Formula | Note |
|---|---|---|
| First law | ΔU = Q − W | W by the system is positive |
| Work by a gas | W = ∫p dV | area under p–V curve |
| Isothermal | W = Q = nRT ln(V_f/V_i) | ΔU = 0 |
| Isobaric | W = pΔV = nRΔT | Q = nC_PΔT |
| Isochoric | W = 0, Q = ΔU = nC_VΔT | vertical line on p–V |
| Adiabatic | pV^γ = const; W = (p_iV_i − p_fV_f)/(γ − 1) | Q = 0 |
| Cyclic | ΔU = 0, Q = W | W = enclosed area |
| Engine efficiency | η = W/Q_H = 1 − Q_C/Q_H | η < 1 |
| Refrigerator | K = Q_C/W | can exceed 1 |
| Carnot engine | η = 1 − T_C/T_H | kelvin temperatures |
| Carnot refrigerator | K = T_C/(T_H − T_C) | highest possible K |
| Second law | Kelvin–Planck; Clausius | direction of processes |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Choose the correct option: (i) 10 J heat in, lid lifted 2 m by 3 N — ΔU? (ii) Which is an example of the first law? (iii) Carnot efficiency is large when…? (iv) The second law deals with transfer of…? (v) Where does the refrigerant reject heat?
Answer: (i) B 4 J; (ii) D; (iii) C (T_H − T_C large); (iv) B energy; (v) A condenser.
2. Q2 Answer in brief: (i) Gas in a thickly insulated cylinder is suddenly compressed — heat transfer? work? (ii) Process with no heat exchange but a temperature change? (iii) Heat added without a temperature change? (iv) What limits a heat engine's efficiency? (v) Why does a Carnot cycle use two isothermal and two adiabatic steps?
Answer: See steps.
3. Q3 (i) H₂ + O₂ in a rigid insulated cylinder is sparked; T and p rise a lot. What does the first law tell us? (ii) A current-carrying resistor in running water (system = resistor): heat into resistor? into water? work done? first law? (iii) Fuel + oxygen burned in a constant-volume chamber in a water bath that warms up: heat transferred? work? sign of ΔU?
Answer: (i) ΔU = 0; (ii) Q = W, both negative; (iii) Q < 0, W = 0, ΔU negative.
4. Q3 (iv) Draw a p–V diagram and explain positive and negative work with examples. (v) Compare a solar cooker and a pressure cooker as thermodynamic systems.
Answer: See steps.
5. Q4 A gas expands against a constant 1 atm from 5 L to 10 L and absorbs 400 J of heat. Find ΔU.
Answer: ΔU = −106.5 J.
6. Q5 A system releases 130 kJ of heat while 109 kJ of work is done on it. Find ΔU.
Answer: ΔU = −21 kJ. The book prints ΔU = 21 kJ; the correct answer is −21 kJ (the system loses more energy as heat than it gains as work).
7. Q6 A Carnot engine has efficiency 75% with the hot reservoir at 727 °C. Find the cold reservoir temperature.
Answer: 250 K, i.e. −23 °C. The book prints 23 °C; the correct answer is −23 °C.
8. Q7 A Carnot refrigerator works between 250 K and 300 K. Find its COP.
Answer: K = 5.
9. Q8 An ideal gas does 2000 J of work in an isothermal process. How much heat is added?
Answer: 2000 J.
10. Q9 An ideal monatomic gas is compressed adiabatically until its temperature doubles. Find p_f/p_i.
Answer: ≈ 5.656 (= 4√2).
11. Q10 The cycle in the figure is a circle on a p–V graph spanning p = 1 to 11 × 10⁵ Pa and V = 2 to 6 × 10⁻³ m³. Find the work done in 25 cycles.
Answer: ≈ 7.85 × 10⁴ J (book: 7.855 × 10⁴ J).
12. Q11 From the V–T diagram of a hypothetical cycle a → b → c → d → a for an ideal gas, draw the p–V and p–T diagrams.
Answer: p–V diagram as in the book's figure (a); p–T diagram as in figure (b).
13. Q12 A system goes round the rectangle A → B → C → D → A on a p–V graph: AB at 6 × 10⁵ Pa and CD at 2 × 10⁵ Pa, V from 2 L to 6 L. Find the work in each step.
Answer: AB = 2.4 × 10³ J, CD = −8 × 10² J, BC = DA = 0. The book prints AB = 2.4 × 10⁶ J and CD = −8 × 10⁵ J, treating litres as m³; the correct values are 2400 J and −800 J.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A gas receives 10 J of heat and lifts a lid 2 m with a 3 N force. ΔU =
Answer: C. ΔU = 10 − 3 × 2 = 4 J.
2. The zeroth law of thermodynamics leads to the concept of…
Answer: C. Equal temperature ⇔ thermal equilibrium.
3. In an isothermal expansion of an ideal gas…
Answer: C. U depends only on T.
4. No work is done by a gas in a(n)… process.
Answer: B. ΔV = 0.
5. In an adiabatic expansion the temperature of a gas…
Answer: A. W > 0 and Q = 0, so ΔU < 0.
6. Which is an extensive variable?
Answer: D. It doubles when the system is doubled.
7. For a complete cycle, the net heat absorbed equals…
Answer: B. ΔU = 0 so Q = W.
8. Free expansion of an ideal gas is…
Answer: D. No heat, no work, no change in U.
9. The second law of thermodynamics deals with transfer of…
Answer: A. It fixes the direction of heat flow and its conversion to work.
10. In a refrigerator, heat is rejected by the refrigerant in the…
Answer: D. The condenser coils give heat to the room.
11. A Carnot engine works between 600 K and 300 K. Its efficiency is…
Answer: B. 1 − 300/600.
12. A Carnot refrigerator between 250 K and 300 K has K =
Answer: D. 250/50.
13. An engine takes 800 J and rejects 600 J per cycle. Its efficiency is…
Answer: D. W = 200 J; 200/800.
14. The adiabatic curve through a point on a p–V diagram is…
Answer: B. Slope −γp/V versus −p/V.
15. The Clausius statement forbids…
Answer: D. That needs external work.
