Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 109–130
A child on a swing, a guitar string, the needle of a sewing machine and the atoms in a crystal all move to and fro about a mean position. This chapter makes that motion precise: linear simple harmonic motion (S.H.M.) and its differential equation, displacement, velocity and acceleration, amplitude, period, frequency and phase, the reference-circle picture, graphs, the combination of two S.H.M.s, energy, the simple pendulum, angular S.H.M. (torsion and a magnet in a field), damped oscillations and resonance. Every exercise question is answered step by step.
A periodic motion repeats after equal intervals; an oscillation is a periodic to-and-fro motion about a mean position. Linear S.H.M. is the special case in which the restoring force is directly proportional to the displacement and always directed towards the mean position: F = −kx. Its differential equation is d²x/dt² + ω²x = 0 with ω = √(k/m).
The solution x = A sin(ωt + α) gives v = ω√(A² − x²) and a = −ω²x. Speed is greatest (Aω) at the mean position and zero at the extremes; acceleration is greatest (Aω²) at the extremes and zero at the mean position. Period T = 2π/ω = 2π√(m/k) is independent of the amplitude. α is the initial phase or epoch.
S.H.M. is the projection of uniform circular motion on a diameter (reference circle). Two parallel S.H.M.s of the same period combine into one S.H.M. with amplitude R = √(A₁² + A₂² + 2A₁A₂ cos(α₁ − α₂)) and epoch tan δ = (A₁ sinα₁ + A₂ sinα₂)/(A₁ cosα₁ + A₂ cosα₂).
KE = ½mω²(A² − x²), PE = ½mω²x², and the total E = ½mω²A² = 2π²mn²A² stays constant. A simple pendulum for small angles performs S.H.M. with T = 2π√(L/g); a second's pendulum (T = 2 s) is about 1 m long on Earth. Angular S.H.M. obeys τ = −cθ with T = 2π√(I/c); a bar magnet in a uniform field B has T = 2π√(I/(μB)).
Real oscillations are damped: a drag force −bv makes the amplitude die away as Ae^(−bt/2m) and slightly lengthens the period. Free oscillations occur at the natural frequency; forced oscillations follow the driving frequency; when the two frequencies match, the amplitude becomes very large — resonance.
Get a ✓ Verified tutor for “Oscillations” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A 0.5 kg block hangs from a spring of force constant 200 N/m. Find ω, the period and the frequency of its vertical oscillations.
Answer: ω = 20 rad/s, T ≈ 0.314 s, n ≈ 3.18 Hz.
A particle performs S.H.M. with amplitude 6 cm and period 0.4 s. Find its maximum speed and maximum acceleration, and its speed at x = 3 cm.
Answer: 0.942 m/s; 14.8 m/s²; 0.816 m/s at 3 cm.
Combine x₁ = 4 sin(ωt) cm and x₂ = 3 sin(ωt + π/2) cm.
Answer: Amplitude 5 cm, epoch ≈ 36.9° (0.644 rad).
A 0.2 kg mass on a spring (k = 80 N/m) oscillates with amplitude 5 cm. Find the total energy and the KE at x = 3 cm.
Answer: E = 0.1 J; KE = 0.064 J.
A pendulum clock is correct on the ground with a 1.0 m pendulum. What is its period at a hill station where g = 9.76 m/s² (ground g = 9.81 m/s²)?
Answer: About 2.011 s.
A torsion pendulum has a disc with I = 2.0 × 10⁻³ kg m² and oscillates with period 0.8 s. Find the torsion constant c and the restoring torque at a twist of 0.5 rad.
Answer: c ≈ 0.123 N m rad⁻¹; τ ≈ 0.062 N m.
| Quantity | Formula | Unit / note |
|---|---|---|
| Differential equation | d²x/dt² + ω²x = 0 | ω² = k/m |
| Displacement | x = A sin(ωt + α) | α = epoch |
| Velocity | v = ω√(A² − x²) | max Aω at x = 0 |
| Acceleration | a = −ω²x | max Aω² at x = ±A |
| Period | T = 2π√(m/k) | independent of A |
| Spring combinations | 1/k_s = 1/k₁ + 1/k₂; k_p = k₁ + k₂ | N m⁻¹ |
| Composition | R² = A₁² + A₂² + 2A₁A₂ cos(α₁ − α₂) | same period, same line |
| Energy | E = ½mω²A² = 2π²mn²A² | KE + PE constant |
| Simple pendulum | T = 2π√(L/g) | small angles |
| Angular S.H.M. | T = 2π√(I/c) | τ = −cθ |
| Magnet in field | T = 2π√(I/(μB)) | small angles |
| Damped amplitude | A e^(−bt/2m) | decays exponentially |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Choose the correct option: (i) displacement when speed is half maximum; (ii) maximum KE for x = 6 sin(100t + π/4) cm, m = 1 kg; (iii) second's pendulum length on the Moon; (iv) frequency ratio of equal springs in series and in parallel; (v) correct statement from the graph of x = A sin(2πt/T).
Answer: (i) A; (ii) D 18 J; (iii) A 1/6 m; (iv) B 1 : 2; (v) B.
2. Q2 (i) Define linear S.H.M. (ii) From the differential equation obtain v and a. (iii) & Q7 Obtain the period of a simple pendulum and state the factors on which it depends. (iv) State the laws of the simple pendulum.
Answer: v = ω√(A² − x²); a = −ω²x; T = 2π√(L/g).
3. Q2 (v) & Q3 Prove that a magnet in a uniform magnetic field performs angular S.H.M. for small angles and find its period.
Answer: Angular S.H.M. for small θ; T = 2π√(I/(μB)).
4. Q4 & Q5 Show that linear S.H.M. is the projection of U.C.M. on a diameter, and describe the x, v, a graphs against phase for start at (a) mean position (b) positive extreme.
Answer: See steps.
5. Q6 Derive KE and PE in S.H.M., show the total is conserved and state the factors it depends on.
Answer: E = ½mω²A², constant.
6. Q8 Path length 10 cm. At what distance from the mean position is the speed half the maximum?
Answer: 4.33 cm.
7. Q9 d²x/dt² = −36x (SI). Find the frequency and period.
Answer: 0.9548 Hz, 1.047 s.
8. Q10 Sewing-machine needle: amplitude 4 cm, 5 Hz. Acceleration 1/30 s after crossing the mean position?
Answer: ≈ 34.2 m/s².
9. Q11 PE = 0.1π²x² J for a 20 g particle in S.H.M. Find the frequency.
Answer: 1.581 Hz.
10. Q12 A 2 kg body in S.H.M. has total energy 40 J. Find its speed at the centre of the path.
Answer: 6.324 m/s. The book prints 6.324 cm/s; the correct unit is m/s.
11. Q13 Pendulum of period 4 s. Time after crossing the mean position for x = A/3?
Answer: 0.2163 s.
12. Q14 Pendulum 100 cm long, bob 50 g. Restoring force at 3 cm displacement?
Answer: ≈ 1.47 × 10⁻² N with g = 9.8 m/s² (the book's 1.48 × 10⁻² N corresponds to g ≈ π² ≈ 9.87 m/s²).
13. Q15 Change in length of a second's pendulum when g changes from 9.75 to 9.80 m/s².
Answer: It increases by 5.07 mm. The book prints 'decreases by 5.07 mm'; since L ∝ g, the length must increase.
14. Q16 Amplitude 8 cm. Where is KE three times PE?
Answer: 4 cm.
15. Q17 Period 2π s; speed b√3 m/s at distance b from O, moving away. Time to travel a further distance b?
Answer: π/3 s.
16. Q18 Mass m₁ on a spring has period T; with m₂ added the period is 2T. Compare m₁ and m₂.
Answer: m₁ : m₂ = 1 : 3.
17. Q19 Show x = a sin ωt + b cos ωt is S.H.M. with amplitude √(a² + b²).
Answer: S.H.M. with amplitude √(a² + b²), epoch tan⁻¹(b/a).
18. Q20 Combine x₁ = 5 sin(4πt + π/3) cm and x₂ = 3 sin(4πt + π/4) cm.
Answer: R ≈ 7.936 cm; epoch ≈ 54° 23′.
19. Q21 A 20 cm wide, 200 g disc on a wire is twisted 60° and released; period 1 s. Maximum restoring torque? (π³ ≈ 31)
Answer: ≈ 0.04133 N m.
20. Q22 Magnet with I = 3 × 10⁻⁶ kg m², μ = 3 A m² in B = 1.6 × 10⁻⁵ T. Oscillations per minute?
Answer: 38.19 oscillations per minute.
21. Q23 A block rests on a vertically vibrating piston of amplitude 25 cm. Maximum frequency without losing contact, and energy per unit mass? (g ≈ π² ≈ 10)
Answer: n_max = 1 Hz; E/m = 1.25 J/kg.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. In S.H.M. starting at the mean position, when speed is half the maximum, x =
Answer: A. v = ω√(A² − x²) = Aω/2 → x² = 3A²/4.
2. 1 kg body: x = 6 sin(100t + π/4) cm. Maximum KE is
Answer: D. ½ × 1 × (100 × 0.06)² = 18 J.
3. Second's pendulum length on the Moon (g/6) is about
Answer: C. L ∝ g.
4. Equal springs in series then in parallel; ratio of frequencies is
Answer: A. n ∝ √k; √(k/2) : √(2k) = 1 : 2.
5. For x = A sin ωt, the force is maximum at
Answer: B. |x| is maximum at T/4 and 3T/4.
6. The period of S.H.M. is independent of
Answer: A. Isochronism.
7. The phase difference between velocity and displacement in S.H.M. is
Answer: B. v = Aω cos(ωt + α).
8. If the amplitude is doubled, the total energy becomes
Answer: D. E ∝ A².
9. At the extreme position the KE of the particle is
Answer: C. v = 0.
10. A pendulum's length is made four times. Its period becomes
Answer: D. T ∝ √L.
11. Two in-phase S.H.M.s of amplitudes 3 cm and 4 cm combine to amplitude
Answer: B. In phase: R = A₁ + A₂.
12. A magnet oscillating in a field B has period T. If B is made 4B, the period becomes
Answer: D. T ∝ 1/√B.
13. In damped oscillations the amplitude
Answer: C. A e^(−bt/2m).
14. Resonance occurs when
Answer: D. Energy is fed in step with the motion.
15. Which shows S.H.M. for small displacements?
Answer: C. Restoring force ≈ −(mg/L)x.
