Textbook: Science – Class 8 (Balbharati, official free PDF) · pages 104–109
How does a vibrating tuning fork reach your ear, and why can't astronauts on the Moon talk directly? Learn compressions and rarefactions, the bell-jar experiment, frequency in hertz, musical notes, the human larynx and the loudspeaker — with answers to every exercise.
Sound is produced by vibrating objects. When the prongs of a tuning fork move outwards they squeeze the air (a compression: high pressure and density); when they move inwards the air spreads out (a rarefaction: low pressure and density). These pass on through the air as a sound wave.
In a sound wave the air itself does not travel from the source to us; only the pattern of compressions and rarefactions (the energy) moves forward. When it reaches the ear, the eardrum vibrates and the brain senses sound.
Sound needs a material medium. In the bell-jar experiment, the ringing grows fainter as air is pumped out. On the Moon there is no air, so astronauts talk using radio waves, which need no medium.
One compression plus one rarefaction is one cycle. The number of cycles per second is the frequency, measured in hertz (Hz). A 512 Hz tuning fork vibrates 512 times a second. Different frequencies give different musical notes — string instruments change tension or length of the string; wind instruments change the length of the air column.
Humans speak with the larynx: air from the lungs makes the vocal cords vibrate, and muscles tighten or loosen them to change the voice. A loudspeaker changes electrical energy into sound: a current-carrying coil moves in a magnet's field and moves a cone back and forth. Loud sound (around 100 dB) is harmful, so we must avoid noise pollution.
Get a ✓ Verified tutor for “Sound” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
When sound travels through air from a bell to your ear, does the air near the bell reach your ear?
Answer: No. Only the compressions and rarefactions (the energy of the sound) move forward; the air itself stays roughly where it is.
A source produces 400 compressions and 400 rarefactions in one second. What is the frequency?
Answer: The frequency is 400 Hz.
| Source | What vibrates | How the note/sound is changed |
|---|---|---|
| Tuning fork | Metal prongs (arms) | Size and material of the prongs fix the frequency |
| Sitar, guitar, violin | Strings | Tension and vibrating length of the string |
| Flute, shehnai | Air column in the pipe | Opening/closing holes; way of blowing |
| Jaltarang | Air column above the water | Water level changes the air column's height |
| Human larynx | Vocal cords | Muscles make the cords tighter or looser |
| Loudspeaker | Conical screen attached to the coil | Changing current in the coil |
| Bell in a bell jar | Bell (heard only if air is present) | Less air → fainter sound |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Fill in the blanks: (a) The region of a sound wave with higher pressure and density is a ___ and with lower pressure and density is a ___. (b) A medium is ___ for sound. (c) The total number of compressions and rarefactions produced per second is 1000. The frequency is ___. (d) Different sound notes have different ___. (e) In a loudspeaker ___ energy is converted into ___ energy.
Answer: (a) compression; rarefaction (b) necessary (c) 500 Hz — 1000 compressions and rarefactions together make 500 pairs, i.e. 500 cycles per second (d) frequencies (e) electrical; sound.
2. Give scientific reasons: (a) The tension on the vocal cords must change as we produce different notes. (b) Astronauts on the Moon cannot hear each other directly. (c) As a sound wave travels through air, the air itself need not move from one place to another.
Answer: (a) A note depends on frequency. Tightening or loosening the vocal cords changes how fast they vibrate, so to sing or speak different notes the muscles must change the tension. (b) Sound needs a material medium. The Moon has no air, so the vibrations of one astronaut's voice have nothing to travel through and cannot reach the other astronaut; they use radio waves instead. (c) In a sound wave each layer of air only vibrates back and forth about its place and passes its energy to the next layer. What travels is the pattern of compressions and rarefactions, not the air.
3. How are different notes produced in a guitar (strings) and a flute (blown air)?
Answer: Guitar: the player changes the tension of a string by turning its peg, and changes its vibrating length by pressing it against the frets with fingers. A tighter or shorter string vibrates faster and gives a higher note. Flute: the player opens or closes the holes with fingers, changing the length of the vibrating air column inside; the frequency and so the note change. Changing the way of blowing also changes the note.
4. How is sound produced in (a) the human larynx (b) a loudspeaker?
Answer: (a) The larynx at the top of the wind pipe has two vocal cords stretched across it with a narrow slit between them. Air pushed by the lungs through the slit makes the cords vibrate, producing sound; muscles change the cords' tightness to change the voice. (b) A loudspeaker has a permanent magnet and a coil fixed to a cone-shaped screen. A changing electric current in the coil makes it move back and forth in the magnet's field; the screen moves with it and makes compressions and rarefactions in the air, i.e. sound.
5. Explain with a neat diagram an experiment to prove that sound needs a material medium.
Answer: Diagram: a glass bell jar on a smooth flat plate, an electric bell hanging inside with wires through the lid to a switch and battery, and a tube from the plate to a vacuum pump. Steps: (1) Switch on the bell with air inside — the ringing is heard clearly. (2) Start the vacuum pump to remove the air. (3) The sound becomes fainter and fainter, though the hammer is still seen striking the bell. (4) When very little air is left, hardly any sound is heard. Conclusion: sound needs a material medium such as air to travel; it cannot travel through vacuum.
6. Match: Human larynx, Loudspeaker, Jal-tarang, Tuning fork, Sitar — with vibrations of metal arms, vibrations in air column, vibrations in vocal cords, vibrations in strings, vibrations of screen.
Answer: Human larynx – vibrations in vocal cords; Loudspeaker – vibrations of screen; Jal-tarang – vibrations in air column; Tuning fork – vibrations of metal arms; Sitar – vibrations in strings.
7. Project: (1) Make a toy phone with two plastic glasses joined by a thread, then try a metal wire and different lengths. (2) Stretch a piece of balloon over a can, put grains of ragi on it and shout into the open end. What do you find?
Answer: Sample: (1) The friend's voice is heard through the tight thread because the vibrations travel through the thread (a solid medium). With a metal wire the sound is usually clearer and louder, since sound travels well in metals. A longer or slack thread gives a fainter sound. (2) The grains jump up and down. The shouting sets up compressions and rarefactions in the air inside the can, which make the stretched rubber vibrate, and the vibrating rubber throws the grains up — proof that sound is vibration carried by air.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A region of high pressure in a sound wave is a…
Answer: C. Air is squeezed together.
2. When the prongs of a tuning fork move towards each other, the air near them forms a…
Answer: A. Air gets more room.
3. In a sound wave travelling through air, what moves forward?
Answer: B. Energy travels; air vibrates in place.
4. Sound cannot travel through…
Answer: A. It needs a medium.
5. In the bell-jar experiment, removing air makes the sound…
Answer: D. Less medium to carry it.
6. Astronauts on the Moon talk using…
Answer: B. These need no medium.
7. One cycle of a sound wave is…
Answer: D. Book definition.
8. The unit of frequency is…
Answer: A. Cycles per second.
9. A 256 Hz tuning fork vibrates…
Answer: B. Hz = per second.
10. In a jaltarang, the note depends on…
Answer: B. Water level changes it.
11. A sitar player changes notes by changing…
Answer: A. Strings vibrate.
12. Which note has the highest frequency in the book's table?
Answer: B. ni = 480 Hz.
13. The human voice is produced by the…
Answer: D. Air makes them vibrate.
14. In a loudspeaker the part that pushes the air is the…
Answer: B. It moves with the coil.
15. Sound of about how many decibels can be harmful?
Answer: D. Very loud sound damages hearing.
