Textbook: Science – Class 8 (Balbharati, official free PDF) · pages 23–27
What makes current flow through a wire, and how does a torch cell or a car battery push it? Learn electrostatic potential and potential difference, the ampere, dry cells, lead-acid, Ni-Cd and lithium-ion cells, simple circuits, batteries of cells in series, the magnetic effect of current, electromagnets and the electric bell, with answers to every exercise.
Every object holds equal numbers of protons and electrons, so it shows no charge. When electrons in a conductor are made to move steadily, we get current electricity.
Just as water flows from a higher level, positive charge tends to flow from higher to lower electrostatic potential. The difference in potential between two points (potential difference, unit volt) makes charge flow; electrons move from the cell's negative terminal to its positive terminal, while conventional current is shown the other way.
Current is the charge passing a point each second; its SI unit is the ampere (1 A = 1 C/s). Cells keep a steady potential difference: dry cells (zinc case, graphite rod, about 1.5 V), rechargeable lead-acid cells (about 2 V, large current), Ni-Cd cells (1.2 V) and lithium-ion cells.
A cell, bulb, key and wires joined in a closed loop form an electric circuit. Cells joined positive-to-negative in series make a battery whose voltage is the sum of the cells' voltages.
A current in a wire produces a magnetic field around it (Oersted). A coil around an iron core becomes an electromagnet only while current flows — the idea behind the electric bell.
Get a ✓ Verified tutor for “Current Electricity and Magnetism” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A charge of 6 coulombs passes through a bulb in 3 seconds. Find the current.
Answer: Current = 2 C/s = 2 A.
Six 2 V lead-acid cells are joined in series in a car battery. What is its total potential difference?
Answer: 12 V.
| Cell | Parts / electrolyte | Voltage and use |
|---|---|---|
| Dry cell | Zinc case (−), graphite rod (+), MnO₂; ZnCl₂ + NH₄Cl paste | About 1.5 V; torches, clocks, radios; small current |
| Lead-acid cell | Pb (−), PbO₂ (+) in dilute sulfuric acid | About 2 V; rechargeable; cars, UPS; large current |
| Ni-Cd cell | Nickel and cadmium electrodes | 1.2 V; rechargeable; portable gadgets |
| Lithium-ion cell | Lithium compounds | Rechargeable; phones, laptops; stores more energy |
| Solar cell | Uses sunlight | Calculators, solar panels |
| Series battery | + of one cell to − of next | Total p.d. = sum of the cells |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Fill in the blanks using: magnetism, 4.5 V, 3.0 V, gravitational attraction, potential difference, potential, higher, lower, 0 V. (a) Water in a waterfall flows from a higher to a lower level because of ___. (b) In a circuit, electrons flow from a point of ___ potential to a point of ___ potential. (c) The difference between the electrostatic potentials of the positive and negative ends of a cell is the ___ of the cell. (d) Three 1.5 V cells joined as a battery give ___ V. (e) A current in a wire creates ___ around the wire.
Answer: (a) gravitational attraction. (b) lower; higher. (c) potential difference. (d) 4.5. (e) magnetism (a magnetic field).
2. A battery is to be made by joining 3 dry cells. Show by a diagram how you will connect them.
Answer: Draw three cell symbols in a row (each a long thin line for + and a short thick line for −). Join the + terminal of cell 1 to the − terminal of cell 2, and the + terminal of cell 2 to the − terminal of cell 3. The free − terminal of cell 1 and the free + terminal of cell 3 are the battery's two ends, joined to the circuit. With 1.5 V cells the battery gives 4.5 V.
3. A battery of two equal cells and a bulb are connected, but the bulb does not glow. What tests will you do to find the reason?
Answer: (1) Check that the key is closed and every connection is tight, with no loose or broken wire. (2) Check that the cells are joined correctly in series (+ to −); if one cell is reversed, the two potential differences cancel and the total is 0 V. (3) Test each cell with a working bulb or a voltmeter to see whether it is dead. (4) Check whether the bulb's filament is broken by trying it in another working circuit. (5) Check the wires and holder for rust or dirt on the contacts.
4. Cells of 2 V each are connected as a battery. Find the total potential difference in (i) a row of three cells and (ii) a row of four cells, all joined + to −.
Answer: (i) 6 V. (ii) 8 V.
5. Describe the construction, working and uses of a dry cell with a diagram.
Answer: Diagram: a cylinder whose outer zinc case (labelled negative terminal) is covered by a protective cover; at the centre a graphite rod with a brass cap (positive terminal), surrounded by a paste of manganese dioxide; between the MnO₂ and the zinc a separator and a moist paste of zinc chloride and ammonium chloride (electrolyte). Working: chemical reactions among these substances build positive charge on the graphite rod and negative charge on the zinc, keeping a potential difference of about 1.5 V; when a circuit is connected, current flows. Since the paste is only moist the reaction is slow, so the current is small. Uses: torches, radios, wall clocks, remote controls and other portable devices — it has a long shelf life and works in any position.
6. Describe the construction and working of an electric bell with a diagram.
Answer: Diagram: an electromagnet (copper coil on iron cores) fixed to a base; a springy iron strip near it carrying a striker at its top, placed beside a gong; a contact screw touching the iron strip; a cell and key joined so that current passes through the coil, the iron strip and the contact screw. Working: pressing the key completes the circuit, the coil becomes a magnet and attracts the iron strip, so the striker hits the gong. As the strip moves, it leaves the contact screw, breaking the circuit; the electromagnet loses its magnetism and the strip springs back to touch the screw. The circuit is completed again and the striker hits the gong again. This repeats many times a second and the bell rings continuously while the key is pressed.
7. Why is a car battery called a battery and not a cell?
Answer: Because it is made of several lead-acid cells (commonly six of about 2 V each) joined in series inside one case to give a higher voltage, and a group of cells joined together is a battery.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Current electricity is due to the flow of…
Answer: A. Electrons move in wires.
2. Positive charge flows from…
Answer: C. Like water flowing downhill.
3. The SI unit of potential difference is…
Answer: D. Named after Volta.
4. 1 ampere equals…
Answer: A. Charge per second.
5. Outside the cell, electrons flow from…
Answer: A. Conventional current is opposite.
6. The negative terminal of a dry cell is…
Answer: D. Zinc forms the outer layer.
7. The electrolyte in a dry cell is…
Answer: D. A moist paste.
8. A lead-acid cell gives about…
Answer: A. Six of them make a 12 V car battery.
9. Which cell is best for a large current in a car?
Answer: B. It can give large current.
10. A Ni-Cd cell gives…
Answer: A. And it is rechargeable.
11. Three 1.5 V cells in series give…
Answer: C. Add them.
12. In series, the + terminal of one cell joins the…
Answer: A. This adds voltages.
13. The magnetic effect of current was first seen by…
Answer: B. A compass needle moved.
14. An electromagnet loses its magnetism when…
Answer: B. It is temporary.
15. In an electric bell, the striker returns because…
Answer: C. No current, no magnet.
