Textbook: Science – Class 9 (Balbharati, official free PDF) · pages 115–127
Why are car side mirrors bulging outward while a dentist's mirror curves inward? Learn how plane mirrors form images, lateral inversion, images in inclined mirrors, the parts of concave and convex mirrors, the three ray-diagram rules, the six image cases for a concave mirror, the Cartesian sign convention, the mirror formula 1/v + 1/u = 1/f, magnification, and step-by-step answers to every exercise.
Light is electromagnetic radiation that lets us see. A mirror is a polished surface that reflects most of the light falling on it and forms clear images. Mirrors are plane or spherical.
A plane mirror forms a virtual, erect image of the same size, as far behind the mirror as the object is in front, and laterally inverted. Two mirrors at angle A give n = 360°/A − 1 images, and a mirror half a person's height is enough to show the full body.
Spherical mirrors are parts of a hollow sphere: concave if the inner surface reflects, convex if the outer surface reflects. Key terms are pole, centre of curvature, radius of curvature, principal axis, principal focus and focal length (f = R/2).
Ray diagrams use three rules (parallel ray → through F; ray through F → parallel; ray through C → back on itself). A concave mirror gives real inverted images, except when the object is between P and F (virtual, erect, magnified). A convex mirror always gives a virtual, erect, smaller image behind it.
With the Cartesian sign convention (pole = origin, object on the left, distances to the left negative), the mirror formula is 1/v + 1/u = 1/f and magnification M = h₂/h₁ = −v/u.
Get a ✓ Verified tutor for “Reflection of Light” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
How many images are formed when two plane mirrors are kept at 40° to each other? What height of mirror does a 170 cm tall boy need to see his full image?
Answer: 8 images; a mirror at least 85 cm tall.
An object is 30 cm from a concave mirror of focal length 10 cm. Its inverted image is 5 cm tall. Find the image position and object height.
Answer: Screen 15 cm in front of the mirror; object is 10 cm tall; image is real, inverted and diminished.
| Object position | Image position | Nature and size |
|---|---|---|
| Between P and F | Behind the mirror | Virtual, erect, magnified |
| At F | At infinity | Real, inverted, very large |
| Between F and C | Beyond C | Real, inverted, magnified |
| At C | At C | Real, inverted, same size |
| Beyond C | Between C and F | Real, inverted, diminished |
| At infinity | At F | Real, inverted, point-sized |
| Convex mirror (anywhere) | Behind the mirror, between P and F | Virtual, erect, diminished |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Explain the difference between a plane, a concave and a convex mirror with respect to the type and size of images.
Answer: Plane mirror: always virtual, erect, same size as the object and laterally inverted. Concave mirror: real and inverted for objects beyond F (larger, same size or smaller depending on distance); virtual, erect and magnified when the object is between P and F. Convex mirror: always virtual, erect and smaller than the object, formed behind the mirror.
2. Describe the position of the source of light with respect to a concave mirror in (1) a torch (2) a projector lamp (3) a floodlight.
Answer: (1) Torch: the bulb is at the principal focus, so reflected rays come out as a parallel beam. (2) Projector lamp: the lamp is placed so that light falling backwards is sent forward to the lenses — usually at or near the centre of curvature, so reflected rays return through the lamp's position toward the condenser lens (many answer keys simply write 'between F and C', where the mirror gives a magnified real image). (3) Floodlight: according to the book, a little beyond the centre of curvature, giving a strong, bright beam.
3. Why are concave mirrors used in solar devices? Why does the sun's image on paper burn it?
Answer: Sun rays reach us almost parallel. A concave mirror collects them over a large area and brings them together at its focus. This concentrates the heat energy on a small spot, raising the temperature greatly — enough to cook food in a solar cooker or heat water. When the sun's bright point image falls on paper, all that energy is concentrated on one tiny spot, the paper's temperature rises above its ignition point and it catches fire.
4. Why are the mirrors fitted on the outside of cars convex? If a spherical mirror breaks, what type are the pieces?
Answer: Convex mirrors always give an erect, smaller image, so the driver sees a much wider area of the road behind in a small mirror, and the image is never upside down. Each broken piece is still a part of the same sphere, so pieces of a concave mirror are concave and pieces of a convex mirror are convex (with the same radius of curvature).
5. What sign conventions are used for reflection from a spherical mirror?
Answer: (1) The pole is the origin and the principal axis is the x-axis; the object is always on the left. (2) Distances are measured from the pole; those to the right are positive and those to the left negative. (3) Heights above the axis are positive, below negative. (4) So u is always negative, f of a concave mirror is negative and f of a convex mirror is positive; real images (in front) have negative v and negative height.
6. Draw ray diagrams for the six cases of images in a concave mirror.
Answer: For each case draw the mirror, axis, P, F and C, an arrow object, and two rays (one parallel to the axis reflecting through F, and one through F or C). (1) Object between P and F: rays diverge; extend them behind — image behind mirror, erect, virtual, magnified. (2) At F: reflected rays parallel — image at infinity, real, inverted, very large. (3) Between F and C: rays meet beyond C — real, inverted, magnified. (4) At C: rays meet at C — real, inverted, same size. (5) Beyond C: rays meet between F and C — real, inverted, diminished. (6) At infinity: parallel rays meet at F — real, inverted, point-sized.
7. Which type of mirror is used in: periscope, floodlights, shaving mirror, kaleidoscope, street lights, head lamps of a car?
Answer: Periscope – plane mirrors; floodlights – concave; shaving mirror – concave; kaleidoscope – plane mirrors; street lights – convex reflectors (to spread light over a wide area); car head lamps – concave.
8. An object 7 cm high is 25 cm in front of a concave mirror of focal length 15 cm. Where should the screen be kept? Find the size and nature of the image.
Answer: Keep the screen 37.5 cm in front of the mirror. The image is 10.5 cm tall, real, inverted and magnified.
9. A convex mirror has focal length 18 cm. The image is half the height of the object. Find the object distance.
Answer: The object is 18 cm in front of the mirror (image 9 cm behind it, virtual and erect).
10. A 10 cm long stick is kept in front of a concave mirror of focal length 10 cm so that the end nearer the pole is 20 cm away. Find the length of the image.
Answer: For a stick lying along the principal axis, the image is 5 cm long (real, from 15 cm to 20 cm in front of the mirror). The book prints 10 cm — that is the answer only if the 10 cm stick stands upright at C (20 cm), where M = −1 and the image is the same size.
11. Three mirrors are made from a single sphere. Which of pole, centre of curvature, radius of curvature and principal axis are common to them?
Answer: Common: centre of curvature and radius of curvature (both belong to the sphere). Not common: pole (the centre of each piece is different) and principal axis (each goes through a different pole), unless pieces happen to lie along the same line.
12. Project: Make a kaleidoscope and explain how it works.
Answer: Sample: Tape three equal plane mirror strips into a triangular tube, mirrors facing in. Close one end with clear plastic holding small coloured bangle pieces, covered with tracing paper; close the other end with card having a peephole. Light from the pieces reflects many times between the mirrors at 60°, so 360/60 − 1 = 5 images form around the original, making a symmetrical pattern that changes when you turn the tube.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A plane mirror image is…
Answer: D. Rays only appear to meet behind it.
2. Two mirrors at 90° give how many images?
Answer: A. 360/90 − 1 = 3.
3. Two mirrors at 45° give how many images?
Answer: D. 360/45 − 1 = 7.
4. A girl 150 cm tall needs a mirror at least…
Answer: D. Half her height.
5. The focal length of a mirror of radius 40 cm is…
Answer: D. f = R/2.
6. The line through the pole and centre of curvature is the…
Answer: C. It is the mirror's axis.
7. A ray through F of a concave mirror reflects…
Answer: D. Rule 2.
8. Object between F and C of a concave mirror gives an image that is…
Answer: B. Inverted too.
9. A shaving mirror is used with the face…
Answer: C. This gives a big erect image.
10. A torch bulb is kept at the… of its concave reflector.
Answer: D. Gives a parallel beam.
11. Convex mirror images are always…
Answer: A. Whatever the object distance.
12. In the sign convention, the object distance u is…
Answer: B. The object is on the left.
13. f = −15 cm, u = −30 cm. Then v =
Answer: A. 1/v = −1/15 + 1/30 = −1/30.
14. Magnification −2 means the image is…
Answer: D. Negative = real and inverted.
15. Pieces of a broken concave mirror are…
Answer: B. Each piece keeps the same curve.
