Textbook: Science – Class 9 (Balbharati, official free PDF) · pages 128–137
Why do you hear a train through the rail before you hear it through the air, and how do ships measure the depth of the sea? Learn about longitudinal sound waves, wavelength, frequency and amplitude, v = νλ, the speed of sound in solids, liquids and gases, audible, infrasonic and ultrasonic sound, echo and reverberation, SONAR, sonography, the human ear, and fully worked answers to every exercise.
Sound is energy carried as waves that give us the sense of hearing. It needs a medium. In air it travels as a longitudinal wave — a series of compressions and rarefactions, with particles vibrating along the direction the wave moves.
A sound wave has wavelength (λ), frequency (ν), time period (T = 1/ν) and amplitude (A). Frequency decides pitch; amplitude decides loudness. Speed v = νλ.
Sound is fastest in solids and slowest in gases, and is faster at higher temperature. In a gas v ∝ √T, v ∝ 1/√ρ and v ∝ 1/√M; at fixed temperature it does not depend on pressure. In air at about 25 °C it is about 346 m/s.
Humans hear 20 Hz to 20 kHz. Below 20 Hz is infrasound; above 20 kHz is ultrasound, used in cleaning, crack-detection, sterilising milk, sonography and SONAR.
Sound reflects by the same laws as light. A distinct echo needs the reflector at least about 17.2 m away (at 22 °C). Repeated reflections in a hall cause reverberation. The ear's outer, middle and inner parts collect sound, vibrate the eardrum and turn the vibrations into nerve signals in the cochlea.
Get a ✓ Verified tutor for “Study of Sound” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Show that sound travels four times faster in hydrogen (M = 2) than in oxygen (M = 32) under the same conditions.
Answer: Sound is 4 times faster in hydrogen than in oxygen.
Nita sees lightning and hears its thunder 4 s later. If sound travels at 340 m/s in air, how far away was the lightning?
Answer: The lightning was 1360 m (1.36 km) away.
A SONAR pulse returns from the seabed after 4 s. Speed of sound in sea water is 1550 m/s. Find the depth.
Answer: The sea is 3100 m deep there.
| Quantity or idea | Value or formula | Remember |
|---|---|---|
| Speed of a wave | v = νλ = λ/T | SI unit m/s |
| Audible range | 20 Hz to 20 kHz | Humans |
| Infrasound | Below 20 Hz | Earthquake tremors, pendulum |
| Ultrasound | Above 20 kHz | Bats, SONAR, sonography |
| Speed in air (25 °C) | About 346 m/s | Rises with temperature |
| Speed in pure water | About 1498 m/s | Sea water about 1531 m/s |
| Speed in steel | About 5960 m/s | Solids are fastest |
| Minimum echo distance | 17.2 m at 22 °C | Brain keeps a sound 0.1 s |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Fill in the blanks and explain: (a) Sound does not travel through …… (b) The velocity of sound in steel is …… than in water. (c) The incidence of …… in daily life shows sound is slower than light. (d) To find a sunken ship or objects deep in the sea, …… technology is used.
Answer: (a) Vacuum — there are no particles to form compressions and rarefactions. (b) Greater — about 5960 m/s in steel against about 1498 m/s in water; sound is fastest in solids. (c) Thunder and lightning — we see the flash first and hear the thunder later, though both happen together. (d) SONAR — ultrasonic pulses sent into the water reflect from the object, and the echo time gives its distance.
2. Give scientific reasons: (a) The roofs of cinema halls and conference halls are curved. (b) Reverberation is stronger in a closed, empty house. (c) We cannot hear an echo in a classroom.
Answer: (a) A curved roof (and often a curved board behind the stage) reflects sound evenly towards every part of the audience, so people at the back and sides also hear clearly. (b) An empty house has bare hard walls, floor and roof and no curtains, furniture or people to absorb sound, so sound reflects many times and lingers. (c) A classroom's walls are much closer than 17.2 m, so the reflected sound returns in less than 0.1 s and merges with the original sound instead of being heard separately.
3. What is an echo? What factors are important to get a distinct echo?
Answer: An echo is the repetition of a sound caused by its reflection from a distant surface. For a distinct echo: (1) the reflecting surface must be at least about 17.2 m away (at 22 °C), so the echo returns after 0.1 s or more; (2) the surface should be large, hard and a good reflector, like a cliff or a building; (3) the original sound should be short and loud; (4) the minimum distance changes with temperature because the speed of sound does.
4. Study the Gol Gumbaz at Vijapur and discuss the reasons for its multiple echoes.
Answer: Sample: The Gol Gumbaz is a huge tomb with one of the world's largest domes, about 44 m across, built of hard stone and plaster with no pillars inside. Its curved, smooth inner surface reflects sound again and again, and the large size means each reflection returns after more than 0.1 s. Also, its 'whispering gallery' round the base of the dome carries a whisper across to the other side. So a single clap is heard repeated many times.
5. What should be the dimensions and shape of classrooms so that no echo is produced? Where and why are sound-absorbing materials used?
Answer: Classrooms should be small enough that walls are less than about 17 m from the speaker, with flat or slightly uneven walls rather than large curved domes that focus sound; a lower ceiling also helps. Sound-absorbing materials — curtains, carpets, fibreboard, acoustic tiles, cushioned seats, thermocol panels — are used in auditoriums, cinema halls, recording studios, conference halls and music rooms to cut reverberation and echo so that speech and music are heard clearly.
6. The speed of sound in air at 0 °C is 332 m/s and increases by 0.6 m/s per degree. At what temperature will it be 344 m/s?
Answer: 20 °C. (The book prints 200 °C, which is a misprint: 12 ÷ 0.6 = 20.)
7. Nita heard thunder 4 s after seeing lightning. Speed of sound in air is 340 m/s. How far away was the lightning?
Answer: 1360 m.
8. Sunil stands between two parallel walls. The nearer wall is 660 m away. He hears the first echo after 4 s and another after 2 s more. Find the speed of sound and the distance between the walls.
Answer: Speed of sound = 330 m/s; distance between the walls = 1650 m.
9. Bottles A and B (identical) hold 12 g and 48 g of hydrogen at the same temperature. In which bottle will sound travel faster, and how many times?
Answer: Book answer: faster in A, twice as fast. Note: the rule v ∝ 1/√ρ holds only when pressure stays the same. In closed bottles at the same temperature, B's pressure is also 4 times higher, and for an ideal gas the speed of sound depends only on temperature and molecular mass — so in reality the speed would be the same in both. Write the book answer in the exam, but know the true physics.
10. Identical bottles A and B hold 10 g and 40 g of helium. If the speed of sound is the same in both, what can you conclude?
Answer: Book answer: the absolute temperature of B is 4 times that of A. Note: for an ideal gas, speed depends only on temperature (and the gas), not on how much gas is in the bottle — so by correct physics, equal speed in the same gas simply means both bottles are at the same temperature.
11. Project: Find out how different notes are produced in a Jaltarang.
Answer: Sample: A Jaltarang is a set of china or metal bowls of different sizes filled with different amounts of water, struck with thin sticks. Each bowl vibrates at its own natural frequency. Adding water makes the bowl vibrate more slowly, giving a lower pitch; less water gives a higher pitch. Tuning the water levels produces the notes sa, re, ga, ma, pa, dha, ni.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. In a longitudinal wave, particles vibrate…
Answer: B. Along the direction of travel.
2. A sound has ν = 500 Hz and λ = 0.68 m. Its speed is…
Answer: A. v = 500 × 0.68.
3. Loudness depends on…
Answer: A. Bigger amplitude, louder sound.
4. Sound travels fastest in…
Answer: D. About 5960 m/s.
5. If the absolute temperature of a gas becomes four times, sound speed…
Answer: D. v ∝ √T.
6. Sound in hydrogen compared to oxygen (same conditions) is…
Answer: D. √(32/2) = 4.
7. Humans cannot hear…
Answer: C. Above 20 kHz is ultrasound.
8. Vibrations of the earth's crust before an earthquake are…
Answer: A. Below 20 Hz.
9. Which is NOT a use of ultrasound?
Answer: D. Speech is audible sound.
10. Sound of wavelength 1 cm and speed 340 m/s has frequency…
Answer: A. ν = 340 ÷ 0.01; it is ultrasound.
11. The minimum time gap for a distinct echo is about…
Answer: D. The brain keeps a sound 0.1 s.
12. Which is a poor reflector of sound?
Answer: D. Soft materials absorb sound.
13. Many quick reflections in an empty hall cause…
Answer: B. Sounds merge into one.
14. A SONAR echo returns after 2 s; speed in water 1500 m/s. Depth is…
Answer: A. 1500 × (2 ÷ 2).
15. The eardrum is in the…
Answer: C. It vibrates with the sound.
