Just as water flows from a higher level to a lower level, positive charge flows from higher electric potential to lower potential. Electrons, being negative, move the other way. The work done to carry a unit positive charge from one point to another is the potential difference: V = W ÷ Q, measured in volt (1 V = 1 J/C).
Metals have free electrons — weakly held outer electrons that wander between atoms. A cell's potential difference makes them drift, producing an electric current I = Q ÷ t, measured in ampere (1 A = 1 C/s). Conventional current is taken from + to −, opposite to electron flow.
Ohm's law: if the physical state of a conductor stays the same, the current through it is directly proportional to the potential difference across it, so V = IR. Resistance R is measured in ohm (Ω) and depends on length, cross-section area and material: R = ρL ÷ A, where ρ is resistivity (Ω m).
In series, the same current flows through every resistor and Rs = R₁ + R₂ + R₃ (bigger than each). In parallel, every resistor has the same potential difference and 1/Rp = 1/R₁ + 1/R₂ + 1/R₃ (smaller than the smallest).
Home appliances are connected in parallel between the live and neutral wires (about 220 V in India), with an earth wire for safety and a fuse in series that melts if the current becomes too large.
Get a ✓ Verified tutor for “Current Electricity” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A current of 0.4 A flows through a conductor for 5 minutes. How much charge passes?
Answer: 120 C
A copper wire is 1 km long with diameter 0.5 mm. Find its resistance (ρ = 1.7 × 10⁻⁸ Ω m).
Answer: About 87 Ω (the book gets 85 Ω because it rounds the area to 0.2 × 10⁻⁶ m²).
Resistors of 5 Ω, 10 Ω and 30 Ω are in parallel across 12 V. Find each current, the total current and Rp.
Answer: 2.4 A, 1.2 A, 0.4 A; total 4 A; Rp = 3 Ω.
| Feature | Series | Parallel |
|---|---|---|
| Current | Same through every resistor | Divides; total = I₁ + I₂ + I₃ |
| Potential difference | Divides; V = V₁ + V₂ + V₃ | Same across every resistor |
| Effective resistance | Rs = R₁ + R₂ + R₃ | 1/Rp = 1/R₁ + 1/R₂ + 1/R₃ |
| Size of effective resistance | More than the largest | Less than the smallest |
| Used to | Increase resistance | Reduce resistance |
| If one bulb fails | All go off | Others stay on |
| Brightness of bulbs | Dimmer than one alone | Same as one alone |
| Example | Decorative bulb strings, fuse with appliance | Home appliances |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Appliances in a house circuit: (A) How are they connected? (B) What is the potential difference across each? (C) Is the current through each the same? (D) Why this way? (E) If the TV stops, do others stop? Also: what is the effective resistance?
Answer: (A) In parallel. (B) The same for all — the mains voltage, about 220 V (230 V). (C) No. Each gets the same voltage, so by I = V ÷ R an appliance with lower resistance (higher power, like an iron) draws more current than one with higher resistance (a lamp). (D) So that every appliance gets full mains voltage and can be switched on or off independently; a fault in one does not stop the others. (E) No — the other branches stay complete, so the rest keep working. Effective resistance: 1/Rp = 1/R₁ + 1/R₂ + … for all appliances switched on, and it is less than the smallest single resistance.
2. Place the given symbols (resistor, cell, ammeter, voltmeter, key, rheostat) to complete the circuit. Which law can you prove with it?
Answer: Connect the cell, plug key, ammeter, rheostat and resistor one after another in series to make one loop; connect the voltmeter in parallel across the resistor (its + side towards the + of the cell). Changing the rheostat changes the current, and V ÷ I stays constant — this circuit verifies Ohm's law.
3. Umesh has bulbs of 15 Ω and 30 Ω. Each one alone gets its filament burnt. (A) Which method should he use? (B) What are its features?
Answer: (A) Connect them in series. (B) Total resistance = 15 + 30 = 45 Ω, larger than each, so the current falls and the filaments are safe; the same current flows through both bulbs; the supply voltage is shared, the 30 Ω bulb getting twice the voltage of the 15 Ω bulb; if one fails, both go off.
4. The table gives V = 4, 5, 6 V and I = 9, 11.25, 13.5 A. (a) Find the average resistance. (b) Nature of the V–I graph? (c) Which law does it prove?
Answer: (a) R ≈ 0.44 Ω (exactly 4/9 Ω). (b) A straight line passing through the origin, because V ÷ I is constant. (c) Ohm's law: if the physical state of a conductor stays the same, the current through it is directly proportional to the potential difference across it, V = IR.
5. Match: (1) free electrons, (2) current, (3) resistivity, (4) resistances in series with (a) V/R, (b) increases the resistance in the circuit, (c) weakly attached, (d) VA/LI.
Answer: 1 – c; 2 – a; 3 – d; 4 – b.
6. A conductor of length x has resistance r and cross-section area a. Find its resistivity and its unit.
Answer: ρ = r a ÷ x; unit ohm metre (Ω m).
7. In the given circuit, R₁ (with the ammeter) is always in the loop; S₁ joins R₂ across R₁; S₂ is a plain wire across R₄; R₃ and the cell are in the main line. Discuss the current when (a) S₁ and S₂ are closed, (b) both are open, (c) S₁ closed, S₂ open.
Answer: (a) R₁ and R₂ are in parallel, and S₂ bypasses R₄, so total resistance = R₁R₂/(R₁ + R₂) + R₃ — the smallest possible, so the current from the cell is the largest. (b) R₂ is cut out and current must go through R₄: total = R₁ + R₃ + R₄ — the largest, so the current is the smallest; the same current flows through R₁, R₃ and R₄. (c) total = R₁R₂/(R₁ + R₂) + R₃ + R₄ — the current is in between; it splits between R₁ and R₂ and then passes through R₄ and R₃. The ammeter always shows only the current in the R₁ branch.
8. Three resistances x₁, x₂, x₃; x is the effective resistance. Name the connection: (a) same current I through all, (b) x larger than each, (c) x smaller than each, (d) same potential difference across each, (e) x = x₁ + x₂ + x₃, (f) x = 1 ÷ (1/x₁ + 1/x₂ + 1/x₃).
Answer: (a) series; (b) series; (c) parallel; (d) parallel; (e) series; (f) parallel.
9. (A) A 1 m nichrome wire has resistance 6 Ω. What is the resistance of 70 cm of it?
Answer: 4.2 Ω
10. (B) Two resistors give 80 Ω in series and 20 Ω in parallel. Find them.
Answer: 40 Ω and 40 Ω
11. (C) 420 C of charge flows through a wire in 5 minutes. Find the current.
Answer: 1.4 A
12. Project: Learn about the wiring in your house from an electrician.
Answer: Sample: Power enters through the service cable to the energy meter, then the main switch and a distribution board with MCBs (modern replacements for fuse wire) for each room circuit. Light and fan circuits use thinner wire and 6–10 A MCBs; power sockets for geysers or ACs use thicker wire and 16–20 A MCBs. Every three-pin socket has its top, thicker pin connected to the earth wire so that a leaking metal body sends current safely to the ground. Many homes also have an RCCB that cuts supply within a fraction of a second if current leaks through a person.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The SI unit of potential difference is…
Answer: D. 1 V = 1 J/C.
2. Electrons in a wire move from…
Answer: D. They are negatively charged.
3. 0.4 A flows for 5 minutes. Charge passed =
Answer: C. Q = 0.4 × 300.
4. Ohm's law holds if the conductor's … stays constant.
Answer: D. Length, area, temperature, material.
5. A 1000 Ω bulb filament on 230 V draws…
Answer: A. I = V/R.
6. Resistance of a wire is directly proportional to its…
Answer: A. R = ρL/A.
7. Unit of resistivity is…
Answer: D. ρ = RA/L.
8. Which has the lowest resistivity?
Answer: C. 1.7 × 10⁻⁸ Ω m.
9. A voltmeter is connected…
Answer: D. Across the component.
10. Resistors 15 Ω, 3 Ω and 4 Ω in series give…
Answer: A. Add them.
11. In parallel, the effective resistance is…
Answer: C. Many paths for current.
12. 16 Ω and 14 Ω in series across 18 V. The current is…
Answer: A. 18 ÷ 30.
13. In series, if one bulb fuses…
Answer: A. The single path is broken.
14. The neutral wire is usually…
Answer: A. Live is red or brown.
15. A fuse protects appliances by…
Answer: A. The circuit then breaks.
