Textbook: Science – Class 9 (Balbharati, official free PDF) · pages 18–29
When does a physicist say work is done? Learn work W = Fs cos θ, positive, negative and zero work, joule and erg, kinetic energy ½mv² and potential energy mgh, energy changing form, the law of conservation of energy in free fall, and power with watt, horse power and kilowatt hour — with solved numericals and every exercise answered.
In physics, work is done only when a force moves an object. Work = force × displacement in the direction of the force. If the force acts at an angle θ to the displacement, W = F s cos θ.
Work is positive when force and displacement point the same way (θ = 0°), negative when they are opposite (θ = 180°) and zero when they are at right angles (θ = 90°) or when there is no displacement. The SI unit is the joule (1 J = 1 N × 1 m); the CGS unit is the erg, and 1 J = 10⁷ erg.
Energy is the capacity to do work and has the same units as work. Kinetic energy is energy of motion, K.E. = ½mv². Potential energy is energy stored because of position or state, P.E. = mgh; it depends on the level from which height is measured.
Energy changes from one form to another but is never created or destroyed. In free fall, potential energy turns into kinetic energy while the total, mgh, stays the same at every height.
Power is the rate of doing work, P = W ÷ t, measured in watt (1 W = 1 J/s). 1 horse power = 746 W. Household electricity is billed in kilowatt hours: 1 kWh = 1 unit = 3.6 × 10⁶ J.
Get a ✓ Verified tutor for “Work and Energy” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Pravin applies 100 N at 60° to the horizontal and does 400 J of work moving an object horizontally. Find the displacement.
Answer: 8 m
Find the work done in lifting a 20 kg object to a height of 10 m (g = 9.8 m/s²).
Answer: 1960 J of work done by the lifter; gravity does −1960 J.
A 250 g stone is falling. Find its kinetic energy when its velocity is 2 m/s.
Answer: 0.5 J
Swaralee carries a 20 kg bag up 5 m in 40 s. Find her power (g = 9.8 m/s²).
Answer: 24.5 W
| Quantity | Formula | Unit and note |
|---|---|---|
| Work | W = F s cos θ | joule (J); CGS erg; 1 J = 10⁷ erg |
| Work along the force | W = F s | θ = 0°, positive work |
| Kinetic energy | K.E. = ½mv² | joule; depends on speed squared |
| Potential energy | P.E. = mgh | joule; relative to the reference level |
| Total energy in free fall | T.E. = K.E. + P.E. = mgh | same at every height |
| Power | P = W ÷ t | watt (W) = J/s |
| Horse power | 1 hp = 746 W | used in industry |
| Kilowatt hour | 1 kWh = 3.6 × 10⁶ J | = 1 unit of electricity |
Solve each one in your notebook first. Then open the solution and compare every step.
1. (a) Explain the difference between potential energy and kinetic energy.
Answer: Kinetic energy is the energy an object has because it is moving; K.E. = ½mv², it is zero at rest and depends on mass and speed (e.g. a moving cricket ball, flowing wind). Potential energy is energy stored because of an object's position or state; P.E. = mgh for height, and it depends on mass and height measured from a chosen level (e.g. water in an overhead tank, a stretched bow, a wound spring). K.E. is found only in moving objects; P.E. can be present in an object at rest.
2. (b) Derive the formula for the kinetic energy of an object of mass m moving with velocity v.
Answer: K.E. = ½mv²
3. (c) Prove that the kinetic energy of a freely falling object on reaching the ground equals its initial potential energy.
Answer: K.E. at the ground = mgh = initial P.E.; energy is only transformed, the total is conserved.
4. (d) Find the work done when an object moves at an angle of 30° to the applied force. (e) If an object has zero momentum, does it have kinetic energy? (f) Why is the work done on an object in uniform circular motion zero?
Answer: (d) W = (√3/2) F s ≈ 0.866 F s — about 87% of the work that would be done if force and motion were in line. (e) No. Zero momentum means velocity is zero, and K.E. = ½mv² = 0. (f) The force keeping it in the circle acts along the radius towards the centre, while the displacement at each instant is along the tangent. They are at 90°, cos 90° = 0, so W = 0.
5. Choose the correct alternative(s): (a) For work to be done, energy must be … (b) Joule is the unit of … (c) Dragging a heavy object on a smooth horizontal surface — which forces have equal magnitude? (d) Power is a measure of … (e) While dragging or lifting an object, negative work is done by …
Answer: (a) (i) transferred from one place to another and (iii) transformed from one type to another. (b) (ii) work and (iv) energy. (c) (ii) gravitational force and (iii) the vertical reaction force — they balance each other. (d) (i) the rapidity with which work is done. (e) (ii) gravitational force (when lifting) and (iii) frictional force (when dragging).
6. Rewrite with the proper alternative: (a) Your P.E. is least when you are … (b) Total energy of a freely falling object … (c) If a car on a flat road goes four times faster, its P.E. … (d) Work done on an object does not depend on …
Answer: (a) sleeping on the ground — your body is at the lowest height. (b) remains unchanged — P.E. only turns into K.E. (c) will not change — height has not changed (it is the kinetic energy that becomes 16 times). (d) the initial velocity of the object — W = F s cos θ uses only force, displacement and angle.
7. Activity: two balls of the same size and weight are released from the same height down channels of different lengths. Answer: (1) energy at release, (2) which energy changes into which, (3) why the same distance, (4) the eventual form of energy, (5) which law it shows.
Answer: (1) Only potential energy (mgh). (2) As they roll down, potential energy changes into kinetic energy. (3) They start at the same height with equal mass, so they have the same P.E. and reach the bottom with the same K.E., which carries them the same distance. (4) In the end their energy becomes heat (and a little sound) through friction with the floor, and they stop. (5) The law of conservation of energy — energy changed from P.E. to K.E. to heat, but none was created or destroyed.
8. (a) A 2 kW electric pump lifts water to 10 m. How much water does it lift each minute? (g = 9.8 m/s²)
Answer: About 1224.5 kg of water per minute.
9. (b) A 1200 W iron is used 30 minutes daily. Find the electricity used in April.
Answer: 18 units
10. (c) A ball falls from 10 m and loses 40% of its energy on hitting the ground. How high will it rebound?
Answer: h' = 6 m
11. (d) A 1500 kg car speeds up from 54 km/h to 72 km/h. Find the work done.
Answer: 131250 J
12. (e) Ravi applies 10 N and moves a book 30 cm along the force. Find the work done.
Answer: 3 J
13. Project: Study instances of energy transformation around you.
Answer: Sample: mixer — electrical to mechanical (and sound); gas stove — chemical to heat and light; bicycle dynamo — mechanical to electrical; mobile charging — electrical to chemical; solar panel — light to electrical; a ball thrown up — kinetic to potential; hydroelectric dam — potential energy of water to kinetic to electrical.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Work is done when…
Answer: C. Displacement is needed.
2. If force and displacement are at 90°, the work done is…
Answer: D. cos 90° = 0.
3. 1 joule equals…
Answer: D. 10⁵ dyne × 10² cm.
4. Friction on a sliding box does…
Answer: A. It acts opposite to motion.
5. A force of 10 N moves a book 30 cm along the force. Work done =
Answer: C. 10 × 0.3 m.
6. Kinetic energy is given by…
Answer: A. Energy of motion.
7. If the speed of a ball is doubled, its kinetic energy…
Answer: A. K.E. depends on v².
8. 500 kg of water in a tank 10 m high has P.E. (g = 9.8 m/s²)…
Answer: D. 500 × 9.8 × 10.
9. Potential energy of your body is least when you are…
Answer: C. Your centre is lowest.
10. The total energy of a freely falling object…
Answer: D. P.E. turns into K.E.
11. A loudspeaker changes…
Answer: B. A microphone does the reverse.
12. Power is a measure of…
Answer: D. P = W ÷ t.
13. 1 horse power is…
Answer: C. Term first used by James Watt.
14. 1 kWh equals…
Answer: A. 1000 W × 3600 s.
15. A 25 W bulb runs 10 hours. Energy used =
Answer: D. 0.025 kW × 10 h.
