Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 188–206
Why does a sweater crackle in winter and why do petrol tankers drag a chain? This chapter covers electric charge and its properties (additive, quantised, conserved), charging by friction, conduction and induction, Coulomb's law in scalar and vector form, relative permittivity, superposition, electric field and lines of force, electric flux and Gauss' law, the electric dipole (torque and field on its axis and equator) and continuous charge distributions — with worked numericals and answers to every exercise.
Charge is a basic property of protons (+) and electrons (−). Bodies get charged by rubbing (electron transfer), by contact and by induction. Charge is additive (algebraic sum), quantised (q = ±ne, e = 1.6 × 10⁻¹⁹ C) and conserved in every process.
Coulomb's law: F = (1/4πε₀) q₁q₂/r², with 1/4πε₀ = 9 × 10⁹ N m² C⁻² and ε₀ = 8.85 × 10⁻¹² C² N⁻¹ m⁻². In a medium the force drops by the dielectric constant ε_r = ε/ε₀ (80 for water). The force is central, obeys Newton's third law and adds as vectors (superposition).
Electric field E = F/q₀ (N/C or V/m). For a point charge E = q/(4πε₀ε_r r²); between parallel plates the field is uniform, E = V/d. Field lines start on + and end on − charges, never cross, meet conductors at right angles and are crowded where the field is strong.
Electric flux φ = E·S = ES cos θ (unit V m). Gauss' law: the total flux through any closed surface equals the enclosed charge ÷ ε₀, regardless of the surface's shape or size; charges outside give zero net flux.
An electric dipole (charges ±q a distance 2l apart) has moment p = q(2l), from − to +. In a uniform field it feels torque τ = pE sin θ (τ = p × E). For r ≫ l, its field on the axis is 2p/(4πε₀r³) and on the equator p/(4πε₀r³) (opposite to p), so the axial field is twice the equatorial one.
Get a ✓ Verified tutor for “Electrostatics” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A plastic comb rubbed on dry hair acquires a charge of −3.2 µC. How many electrons did it gain? By how much did its mass increase? (mass of electron = 9.1 × 10⁻³¹ kg)
Answer: 2 × 10¹³ electrons; mass increases by about 1.8 × 10⁻¹⁷ kg — far too small to notice.
Two identical metal spheres carry +12 µC and −4 µC. They are touched together and separated. What charge does each carry now?
Answer: +4 µC on each sphere.
Charges +3 µC and −5 µC are 30 cm apart in air. Find the force between them. What would it be in water (ε_r = 80)?
Answer: 1.5 N attraction in air; about 0.019 N in water.
Two parallel plates 2 mm apart are connected to 300 V. Find the field between them, and the force and acceleration of an electron there (m = 9.1 × 10⁻³¹ kg).
Answer: E = 1.5 × 10⁵ V/m; F = 2.4 × 10⁻¹⁴ N; a ≈ 2.6 × 10¹⁶ m/s² towards the + plate.
A charge of 17.7 nC sits inside a closed box. Find the total flux through the box. What is the flux if an extra −8.85 nC is put inside, and if instead a 5 nC charge is placed just outside?
Answer: 2000 V m; 1000 V m; still 2000 V m.
A dipole has charges ±2 nC separated by 2 mm. Find its dipole moment, the field 10 cm away on its axis and on its equator, and the maximum torque in a uniform field of 5 × 10⁴ N/C.
Answer: p = 4 × 10⁻¹² C m; 72 N/C on the axis, 36 N/C on the equator; τ_max = 2 × 10⁻⁷ N m.
| Quantity | Formula | SI unit and note |
|---|---|---|
| Quantisation of charge | q = ±ne | coulomb; e = 1.6 × 10⁻¹⁹ C |
| Coulomb's law | F = q₁q₂/(4πε₀ε_r r²) | newton; 1/4πε₀ = 9 × 10⁹ N m² C⁻² |
| Dielectric constant | ε_r = ε/ε₀ = F_vac/F_med | no unit; water ≈ 80 |
| Electric field | E = F/q₀ | N/C = V/m |
| Field of point charge | E = Q/(4πε₀ε_r r²) | radial; ∝ 1/r² |
| Parallel plates | E = V/d | uniform field |
| Electric flux | φ = E·S = ES cos θ | V m |
| Gauss' law | ∮E·dS = Q/ε₀ | any closed surface |
| Dipole moment | p = q(2l) | C m; from − to + |
| Torque on dipole | τ = pE sin θ (τ = p × E) | N m; max at 90° |
| Dipole field on axis | E = 2pr/(4πε₀(r² − l²)²) ≈ 2p/(4πε₀r³) | along p |
| Dipole field on equator | E = p/(4πε₀(r² + l²)^(3/2)) ≈ p/(4πε₀r³) | opposite to p |
| Charge densities | λ = q/l, σ = q/A, ρ = q/V | C/m, C/m², C/m³ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option: (i) A positive glass rod near an isolated metal rod — charge on the far side? (ii) Electron between plates when the battery is switched on? (iii) +7 µC at the centre of spheres of radius 2 cm and 4 cm — ratio of flux? (iv) Force between two 1 C charges 1 m apart? (vi) Sphere A (+50 µC) touched to isolated sphere B of half the radius — ratio of charges? (vii) Which gives a uniform field?
Answer: (i) (C) same as that on the glass rod but lesser in quantity (the sign is certainly the same; equality would hold only in the ideal case of complete induction). (ii) (A) attracted to the +ve plate. (iii) (C) 1 : 1. (iv) (B) 9 × 10⁹ N. (vi) (B) 2 : 1. (vii) (C) two parallel plates.
2. 1(v). Two +5 µC charges experience 80 × 10⁻³ N. They are moved apart until the force is 2.0 × 10⁻³ N. The distance now is …
Answer: None of the printed options fits the data: the distance becomes about 6.3 times the original. If the second force were 5.0 × 10⁻³ N (16 times smaller), the answer would be (C) four times the previous distance — which is probably what the book intends.
3. 1(viii). A = +5 µC and B = −5 µC are 5 cm apart. A +1 µC charge C is 3 cm from the centre on the perpendicular bisector. Direction of the force on C?
Answer: (C) a direction parallel to line AB (from A towards B).
4. 2. Answer: (i) Charge on an electron. (ii) Law of conservation of charge. (iii) Define unit charge. (iv) 10 V across plates 0.5 mm apart — field strength? (v) Uniform field. (vi) Two lines of force intersecting? (vii) Unit of linear charge density. (viii) Unit of dipole moment. (ix) Relative permittivity.
Answer: (i) 1.6 × 10⁻¹⁹ C (negative). (ii) The total charge of an isolated system stays constant; charge can be transferred but never created or destroyed. (iii) One coulomb is the charge which, kept 1 m from an equal charge in vacuum, experiences a force of 9 × 10⁹ N. (iv) 2 × 10⁴ V/m (N/C) — the question says 'electric charge' but means electric field. (v) A field with the same magnitude and direction at every point, e.g. between charged parallel plates. (vi) It would mean the field has two directions at one point, which is impossible, so lines of force never intersect. (vii) C/m. (viii) C m (or debye). (ix) The ratio of the permittivity of a medium to that of free space, ε_r = ε/ε₀, equal to the ratio of the force between two charges in vacuum to that in the medium at the same distance.
5. 3(i). Two small spheres 18 cm apart carry equal negative charges and repel with 6 × 10⁻³ N. Find the total charge on both spheres.
Answer: Each sphere −1.47 × 10⁻⁷ C; total ≈ −2.94 × 10⁻⁷ C. The book prints 2.94 × 10⁻¹⁰ C; the correct answer is 2.94 × 10⁻⁷ C (0.294 µC).
6. 3(ii). A charge +q exerts a force of magnitude 0.2 N on −2q at 25.0 cm. Find q.
Answer: q ≈ 0.833 µC (matches the book; the force is attractive).
7. 3(iii). Four charges of +6 × 10⁻⁸ C sit at the corners of a 3 cm square. Find the resultant force on each charge.
Answer: ≈ 6.89 × 10⁻² N on each charge, directed outward along the diagonal away from the centre.
8. 3(iv). E = 5.0 kN/C along the z-axis. Find the flux through a 10 cm square (a) in the XY plane, (b) in the XZ plane, (c) with its normal at 45° to the z-axis.
Answer: (a) 50 V m, (b) zero, (c) ≈ 35.4 V m. The book prints 5.0 × 10⁻² V m and 3.5 × 10⁻² V m; with E = 5.0 kN/C the correct values are 50 V m and 35.4 V m (the book's figures correspond to E = 5.0 N/C).
9. 3(v). Three equal charges of 10 × 10⁻⁸ C sit at the corners of a right triangle with sides 15, 20 and 25 cm. Find the force on the charge at the right angle.
Answer: ≈ 4.59 × 10⁻³ N
10. 3(vi). 5000 V is applied across plates 5 cm apart. An oil drop with charge 9.6 × 10⁻¹⁹ C is between them. Find (a) E and (b) the force on the drop.
Answer: (a) 1.0 × 10⁵ N/C; (b) 9.6 × 10⁻¹⁴ N.
11. 3(vii). Find the electric field due to a charge of −8.0 × 10⁻⁸ C at 5.0 cm.
Answer: 2.88 × 10⁵ N/C towards the charge. The book prints 2.88 × 10⁻² N/C; the correct answer is 2.88 × 10⁵ N/C.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A positively charged rod is brought near an insulated metal rod. The far end of the metal rod becomes…
Answer: B. Electrons move to the near end, leaving the far end positive.
2. Which is a possible charge on a body?
Answer: C. It must be a whole multiple of 1.6 × 10⁻¹⁹ C.
3. Two charges of 1 C each are 1 m apart in vacuum. The force is…
Answer: B. F = 9 × 10⁹ × 1 × 1/1².
4. If the distance between two charges is doubled, the force becomes…
Answer: D. F ∝ 1/r².
5. Two charges are moved from air into water (ε_r = 80) at the same separation. The force becomes…
Answer: A. The medium divides the force by ε_r.
6. The SI unit of electric field is…
Answer: A. N/C is the same as V/m.
7. 200 V across plates 4 mm apart gives a field of…
Answer: B. E = V/d = 200/0.004.
8. Which arrangement produces a uniform electric field?
Answer: C. Field lines between plates are parallel and evenly spaced.
9. An electron between two charged parallel plates will…
Answer: C. Negative charge moves opposite to the field.
10. A charge sits at the centre of two concentric spheres of radii 2 cm and 4 cm. The ratio of fluxes through them is…
Answer: A. Flux depends only on enclosed charge.
11. Net flux through a closed surface due to a charge placed outside it is…
Answer: D. Every line that enters also leaves.
12. The direction of the dipole moment is…
Answer: C. By convention, negative to positive charge.
13. Torque on a dipole is maximum when its axis makes an angle with E of…
Answer: D. τ = pE sin θ.
14. For a short dipole, the field at a distance r on the axis compared with the equator at the same r is…
Answer: D. 2p/4πε₀r³ versus p/4πε₀r³.
15. Which molecule has a permanent dipole moment?
Answer: B. Its bent shape keeps the charge centres apart.
