Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 159–187
How does a rear-view mirror shrink a whole bus, why does a pond look shallower than it is, and how does a telescope bring a planet closer? This chapter covers the nature of light, the Cartesian sign convention, plane and spherical mirrors, refraction and refractive index, total internal reflection and optical fibres, refraction at a spherical surface and the lens makers' equation, prisms, dispersion and dispersive power, mirage and rainbows, aberrations, and the simple microscope, compound microscope and telescope — with worked numericals and answers to every exercise.
Light is made of photons that obey the rules of electromagnetic waves; it travels at c ≈ 3 × 10⁸ m/s in vacuum. Ray optics explains reflection and refraction, wave optics explains interference, diffraction and polarisation, and the particle picture explains the photoelectric effect.
With the Cartesian sign convention (distances from the pole, light travelling left to right, left negative, right positive), one formula works for every case: mirrors 1/f = 1/v + 1/u with f = R/2, thin lenses 1/f = 1/v − 1/u, power P = 1/f in dioptre.
Refractive index n = c/v. Snell's law n₁ sin θ₁ = n₂ sin θ₂ explains apparent depth (n = real/apparent depth). Going from a denser to a rarer medium beyond the critical angle (sin i_c = 1/n), light is totally internally reflected — the basis of optical fibres, prism binoculars and periscopes.
Refraction at one curved surface obeys n₂/v − n₁/u = (n₂ − n₁)/R; applying it to both faces of a thin lens gives the lens makers' equation 1/f = (n − 1)(1/R₁ − 1/R₂). A prism obeys A = r₁ + r₂ and δ = i + e − A; at minimum deviation n = sin((A + δ_m)/2)/sin(A/2); a thin prism deviates by δ = A(n − 1).
Different colours have different refractive indices, causing dispersion (dispersive power ω = (n_V − n_R)/(n_Y − 1)), rainbows and chromatic aberration in lenses. Microscopes and telescopes increase the visual angle: simple microscope M = D/f to 1 + D/f, compound microscope M = m_o × M_e, telescope M = f_o/f_e with length f_o + f_e.
Get a ✓ Verified tutor for “Optics” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Light crosses a 3 mm thick glass plate of refractive index 1.6. How long does it take?
Answer: 16 ps
An object is placed 25 cm in front of a concave mirror of focal length 15 cm. Find the image position, magnification and nature.
Answer: Image 37.5 cm in front of the mirror, real, inverted and 1.5 times larger.
A small coin lies at the bottom of a beaker containing 12 cm of water (n = 4/3). How high does it appear to be raised? What is the critical angle for water?
Answer: The coin appears 3 cm higher (9 cm deep); critical angle ≈ 48.6°.
A double convex lens of glass (n = 1.5) has radii 20 cm and 30 cm. Find its focal length and power. Where is the image of an object 40 cm away?
Answer: f = 24 cm (P ≈ +4.2 D); real, inverted image 60 cm behind the lens, 1.5 times larger.
A 60° prism gives a minimum deviation of 40°. Find its refractive index. A thin 6° prism has n_V = 1.54 and n_R = 1.52; find its angular dispersion and dispersive power.
Answer: n ≈ 1.53; angular dispersion 0.12°; ω ≈ 0.038.
A thin convex lens has radii 12 cm and 24 cm. Its refractive index is 1.50 for red and 1.53 for violet. Find the longitudinal chromatic aberration f_R − f_V.
Answer: About 0.91 cm — violet focuses nearer the lens.
An astronomical telescope has an objective of focal length 90 cm and an eyepiece of focal length 3 cm. Find its magnifying power and length in normal adjustment. If a 5 cm lens is used as a simple microscope, what range of magnifying power is possible?
Answer: Telescope: M = 30, length 93 cm. Simple microscope: between 5 and 6.
| Quantity | Formula | Unit and note |
|---|---|---|
| Refractive index | n = c/v; ₁n₂ = n₂/n₁ = v₁/v₂ | no unit |
| Snell's law | n₁ sin θ₁ = n₂ sin θ₂ | angles from the normal |
| Images in two mirrors | n = 360°/θ | N = n − 1 (n even); n − 1 or n (n odd) |
| Mirror formula | 1/f = 1/v + 1/u; f = R/2; m = −v/u | Cartesian signs |
| Apparent depth | n = real depth / apparent depth | near-normal viewing |
| Critical angle | sin i_c = 1/n | denser → rarer only |
| Single spherical surface | n₂/v − n₁/u = (n₂ − n₁)/R | n₁ = medium of real object |
| Lens makers' equation | 1/f = (n − 1)(1/R₁ − 1/R₂) | thin lens formula 1/f = 1/v − 1/u |
| Power | P = 1/f; P = P₁ + P₂ − dP₁P₂ | dioptre (m⁻¹) |
| Prism | A = r₁ + r₂; δ = i + e − A; n = sin((A + δ_m)/2)/sin(A/2) | thin prism δ = A(n − 1) |
| Dispersive power | ω = (n_V − n_R)/(n_Y − 1) = (δ_V − δ_R)/δ_Y | no unit; material only |
| Achromatic doublet | ω₁/f₁ + ω₂/f₂ = 0 | convex crown + concave flint |
| Simple microscope | M_min = D/f; M_max = 1 + D/f | D = 25 cm |
| Compound microscope | M = (v_o/u_o)(D/u_e); L = v_o + u_e | magnitudes |
| Astronomical telescope | M = f_o/f_e; L = f_o + f_e | normal adjustment |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option (i)–(vii): (i) Light consists of … (ii) Which of the denser lenses P, Q (thick-centred crescents) and R, S (thin-centred crescents) have positive focal length? (iii) Mirrors at 40° — number of images? (iv) Concave shaving mirror, curvature 40 cm, image double size — object distance? (v) Aberration NOT possible for spherical mirrors? (vi) Fish sees monkey at 2.5 m, monkey sees fish 1.6 m deep, real height = real depth — refractive index? (vii) TIR in mirage, rainbow, optical fibre, diamond?
Answer: (i) (D) photons obeying the rules of waves. (ii) (B) only P and Q. (iii) (C) 8 or 9. (iv) (A) 10 cm only (30 cm also gives a double-size image, but inverted, which is useless for shaving). (v) (A) chromatic aberration. (vi) (B) 5/4. (vii) (A) only R and S.
2. 1. Choose the correct option (viii)–(xiii): (viii) Spectacles of number −2 commonly use … lenses. (ix) Air bubble at the centre of a glass marble (n = 1.5, radius 1.5 cm) appears … (x) Select the WRONG statement about prisms. (xi) Deviations for extreme colours: (A) 7°, 10° (B) 8°, 11° (C) 12°, 16° (D) 10°, 14° — maximum dispersive power? (xii) Not involved in a rainbow? (xiii) Statements about a simple microscope.
Answer: (viii) (D) convexo-concave. (ix) (B) at the centre. (x) (A). (xi) (A) 7°, 10°. (xii) (D) total internal reflection. (xiii) (D) only P and R are correct.
3. 2. Short answers: (i) Nature of light; which phenomena need wave optics and the particle nature? (ii) Phenomena explained by ray optics and its assumptions. (iii) Focal power and why P = 1/f. (iv) Positions giving diminished and magnified images in spherical mirrors. (v) Restrictions for clear images by spherical mirrors.
Answer: (i) Light is photons guided by EM-wave rules (dual nature). Wave optics explains interference, diffraction, polarisation and the Doppler effect; the particle nature explains the photoelectric effect, spectral line emission and the Compton effect. (ii) Ray optics explains reflection, refraction, double refraction, TIR and image formation by mirrors, lenses and prisms. It assumes straight-line travel in a homogeneous isotropic medium, independent crossing of rays, and the laws of reflection and refraction. (iii) Focal power is the ability of a lens or mirror to converge or diverge light. A shorter focal length bends rays more strongly, so the ability is measured by the reciprocal 1/f (in dioptre, m⁻¹). (iv) Convex mirror: always diminished. Concave mirror: diminished when the object is beyond 2F (and point-sized at infinity); magnified when the object is between F and 2F (real) or between F and the pole (virtual). (v) The mirror must be small (aperture much smaller than u, v, f); objects and images must be close to the axis; incident rays must make small angles with the axis (paraxial).
4. 2. Short answers: (vi) Spherical aberration of mirrors and its cure. (vii) Absolute and relative refractive index. (viii) Mirage. (ix) Conditions for TIR, critical angle and its expression. (x) Optical fibre and its advantages. (xi) Why prism binoculars?
Answer: (vi) Marginal rays focus nearer the pole than paraxial rays, so a point image becomes a blurred circle; the smallest is the circle of least confusion. It is reduced by small apertures and removed completely by a parabolic mirror, where all parallel rays have equal optical paths to one focus. (vii) Absolute index n = c/v (e.g. glass 1.5: light slows to 2 × 10⁸ m/s). Relative index ₁n₂ = n₂/n₁ = v₁/v₂ (e.g. glass w.r.t. water = 1.5 ÷ 1.33 ≈ 1.13). (viii) Hot air near the road has a lower refractive index; light from a tree bends gradually away from the denser upper air, travels nearly along the road and turns upward, so the tree seems reflected from water. (ix) Light must go from denser to rarer and the angle of incidence must exceed the critical angle, e.g. light inside a diamond. With n sin i_c = 1 × sin 90°, sin i_c = 1/n. (x) A thin core inside a lower-index cladding, with buffer and jacket; light travels by repeated TIR. Advantages: very large bandwidth, no EM interference, very low loss, electrical insulation, no theft value, secure data. (xi) Ordinary binoculars are limited because the two tubes cannot be farther apart than the eyes; right-angled prisms fold the light path by TIR, allowing wider objectives, a shorter body and a brighter, erect image.
5. 2. Short answers (xii)–(xiii) and Long answers (i)–(iii): derive the single-surface relation and the lens makers' equation; when is |f| = |R|? Types of dispersion; angular dispersion of a thin prism; dispersive power.
Answer: Single surface (paraxial rays, thin surface, Cartesian signs): n₂/v − n₁/u = (n₂ − n₁)/R. Lens makers' equation: first face n/v₁ − 1/u = (n − 1)/R₁; second face 1/v − n/v₁ = (1 − n)/R₂; adding, 1/v − 1/u = (n − 1)(1/R₁ − 1/R₂) = 1/f. It is called so because lens makers use it to choose radii for a desired f. |f| = |R| for a thin symmetric double convex (or concave) lens with n = 1.5. Dispersion types: angular dispersion (colours travel in different directions, e.g. one surface or a prism) and lateral dispersion (colours emerge parallel but shifted, e.g. a glass slab); both occur because n depends on frequency. For a thin prism: δ_V = A(n_V − 1), δ_R = A(n_R − 1), so angular dispersion = A(n_V − n_R). Dispersive power ω = (δ_V − δ_R)/δ_Y = (n_V − n_R)/(n_Y − 1); it depends only on the material.
6. Long answers (iv)–(vi): Rainbow (conditions, primary, secondary, both together); chromatic aberration and achromatism; spherical aberration of lenses.
Answer: (iv) Conditions: light rain with large drops, sunlight from behind, Sun low (morning/evening). Primary: refraction with dispersion, one internal reflection, refraction out; red at ≈ 43°, violet at ≈ 41° to the line from the Sun, red outside. Secondary: two internal reflections; violet ≈ 53°, red ≈ 51°, violet outside, fainter. Both can be seen together when the Sun is low (below about 41°), the shower is wide and the sky behind is dark. (v) A lens behaves like prisms, so violet is focused nearest and red farthest — chromatic aberration. Achromatism: making f_V = f_R. For two thin lenses in contact, (n₁V − n₁R)K₁ + (n₂V − n₂R)K₂ = 0, which becomes ω₁/f₁ + ω₂/f₂ = 0. As ω is positive, one lens is convex and one concave; for a converging pair the convex lens has smaller ω (crown) and larger power, the concave lens is flint. (vi) Marginal rays of a lens focus at a different point from paraxial rays. Remedies: plano-convex lens with the curved face to the object; R₁ : R₂ = 1 : 6 for n = 1.5; two convex lenses separated by f₁ − f₂; combining a convex and a concave lens whose aberrations cancel; stopping down the aperture.
7. Long answers (vii)–(xii): magnifying power vs lateral magnification; simple microscope; compound microscope; terrestrial vs astronomical telescope; telescope formula; limits on increasing M.
Answer: (vii) Magnifying power M = β/α compares visual angles, while lateral magnification m compares actual sizes; an image may be very large (m = ∞) yet look only a few times bigger. (viii) Simple microscope: M = D/u; image at D gives M_max = 1 + D/f, image at infinity gives M_min = D/f. (ix) Compound microscope: M = (v_o/u_o)(D/u_e), L = v_o + u_e. (x) A terrestrial telescope views objects on Earth and must give an erect image (concave eyepiece or an extra erecting lens); an astronomical telescope views planets and stars with a convex eyepiece and an inverted image. (xi) Normal adjustment: the objective's image lies at the eyepiece focus; tan β = AB/f_e, tan α = AB/f_o, so M = f_o/f_e and L = f_o + f_e. (xii) Simple microscope: very small f needs thick lenses with severe aberrations. Compound microscope: higher m_o needs a longer tube. Telescope: large f_o means a very long tube and large f_o lenses are hard to make; very small f_e brings aberrations.
8. 3(i) A ray strikes water (n = 4/3) at 53°. The water is 36 cm deep. How long does light take to reach the bottom?
Answer: 2 ns
9. 3(ii) Number of images for mirrors inclined at 35°, 36°, 40° and 45°.
Answer: 10, 9, 8 or 9, and 7 respectively.
10. 3(iii) A 30 cm × 3 cm sheet lies along the axis of a concave mirror (f = 30 cm). Describe its image.
Answer: A real, inverted image from 50 cm to 90 cm in front of the mirror; its height grows from 2 cm to 6 cm (3 cm at 60 cm), so the outer edge is a curve, not a straight line. (The question does not state where the sheet is; the book's answer implies it spans 45–75 cm.)
11. 3(iv) A car's convex rear-view mirror has radius of curvature 1.2 m. A minibus 2.4 m × 2.4 m is 6.6 m away. Find the image size.
Answer: A square of side 0.2 m (virtual, erect).
12. 3(v) A 2.5 cm glass slab (n = 5/3) lies on an ink spot, with 8 cm of water (n = 4/3) in a thin-bottomed beaker on top. Apparent depth of the spot from air?
Answer: 7.5 cm
13. 3(vi) A convex lens forms an image of a 6 cm pencil; when the lens is shifted by f, it forms an image of the same size again. Find the image size.
Answer: 12 cm (real inverted in one position, virtual erect in the other).
14. 3(vii) In slab ABCD (AD = 6 cm, height 3 cm), light from corner B is totally reflected at the nearest point P on AD, 4 cm from A, and hits CD at Q. Find n, DQ and the type of reflection at Q.
Answer: n = 5/4, DQ = 1.5 cm; partial reflection at Q (37° < critical angle).
15. 3(viii) An object is 10 cm from one face of a thick double convex lens (n = 1.5, radii 10 cm and 8 cm, thickness 2 cm). Locate the final image.
Answer: 64 cm beyond the other surface (real). (If the 8 cm face faced the object, the same method gives 70 cm.)
16. 3(ix) A ray is incident at 37° on an equilateral prism (n = 3/2). Find e and δ. For what prism angle would the ray just emerge?
Answer: e ≈ 63°, δ ≈ 40°, A ≈ 65°24′.
17. 3(x) n_R = 1.62, n_V = 1.66 and δ_R = 3.1°. Find the angular dispersion and dispersive power.
Answer: 0.2°; ω = 1/16 = 0.0625
18. 3(xi) Flint glass n varies from 1.60 to 1.66. A thin convex lens has radii 10 cm and 15 cm. Find the chromatic aberration.
Answer: 10/11 cm ≈ 0.91 cm
19. 3(xii) Reading spectacles of number 2.00: range of magnifying power? The concavo-convex lens (n = 1.5) has one surface of radius 10 cm; find the other.
Answer: M from 0.5 to 1.5; R₂ = 50/3 ≈ 16.7 cm.
20. 3(xiii) Eyepiece power 6 D, required maximum magnifying power at least 12.5, tube length 25 cm. Find the minimum power of the objective and its radius if biconvex with n = 1.5.
Answer: 40 dioptre; R = 2.5 cm.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. As per recent understanding, light consists of…
Answer: A. Light shows a dual nature.
2. A shaving mirror (concave, R = 40 cm) gives an erect image twice the object's size. The object is at…
Answer: C. Virtual image: v = −2u gives u = −10 cm; 30 cm gives an inverted image.
3. Two plane mirrors at 45° form how many images of an object between them?
Answer: D. n = 8 is even, so N = n − 1 = 7.
4. A convex mirror always forms an image that is…
Answer: C. Rays always diverge after reflection.
5. Which aberration cannot occur in a spherical mirror?
Answer: A. Reflection does not depend on colour.
6. The critical angle for glass of n = 1.5 is about…
Answer: B. sin i_c = 1/1.5 = 0.667.
7. Total internal reflection is involved in…
Answer: D. Mirage and rainbow do not involve TIR.
8. A coin under 9 cm of water (n = 4/3) appears at a depth of…
Answer: D. Apparent depth = 9 ÷ (4/3).
9. A symmetric double convex lens of n = 1.5 and R = 20 cm has focal length…
Answer: D. 1/f = 2(n − 1)/R = 1/R.
10. Lenses of +5 D and −3 D in contact have a combined focal length of…
Answer: A. P = +2 D, so f = 0.5 m.
11. At minimum deviation in a prism…
Answer: A. The ray passes symmetrically, parallel to the base.
12. A thin prism of angle 5° and n = 1.6 deviates light by…
Answer: B. δ = A(n − 1) = 5 × 0.6.
13. Dispersive power depends on…
Answer: D. ω = (n_V − n_R)/(n_Y − 1).
14. In the secondary rainbow, the outermost colour is…
Answer: C. Two internal reflections reverse the order.
15. An astronomical telescope has f_o = 100 cm and f_e = 4 cm. In normal adjustment M and L are…
Answer: B. M = f_o/f_e, L = f_o + f_e.
