Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 207–220
Electrons in a copper wire crawl along at a fraction of a millimetre per second, yet a bulb lights the moment you flip the switch. This chapter explains electric current and current density, drift speed, Ohm's law and its microscopic origin, ohmic and non-ohmic devices, electrical power, carbon resistor colour codes and rheostats, series and parallel resistors, resistivity and its change with temperature, superconductivity, emf and internal resistance, cells in series and parallel, and types of cells — with worked numericals and answers to every exercise.
Electric current is the net charge crossing a section per unit time, I = q/t (or dq/dt), measured in ampere. In metals the carriers are free electrons; by convention current is drawn in the direction positive charges would move.
With a field applied, free electrons keep their fast random motion (~10⁶ m/s) but gain a slow drift (~10⁻⁴ m/s) opposite to the field. I = nAev_d and current density J = I/A = nev_d. Collisions with ion cores every τ seconds give v_d = eEτ/m, which leads to Ohm's law E = ρJ with ρ = m/(ne²τ).
Ohm's law V = IR holds for ohmic conductors (straight I–V line through the origin); diodes, vacuum tubes, electrolytes and thermistors are non-ohmic. Power P = VI = I²R = V²/R; energy in kWh = power in kW × hours.
R = ρl/A, where resistivity ρ depends on the material and temperature: ρ = ρ₀[1 + α(T − T₀)]. Some materials become superconductors (zero resistance) below a critical temperature, e.g. mercury at 4.2 K. Series: R_s = R₁ + R₂ + …; parallel: 1/R_p = 1/R₁ + 1/R₂ + …. Carbon resistors are marked with a colour code.
An emf device does work on charges, ε = dW/dq. With internal resistance r, terminal voltage V = ε − Ir and I = ε/(R + r), with a maximum of ε/r. Cells in series add emfs and internal resistances; cells in parallel have 1/r_eq = Σ1/r_i and ε_eq/r_eq = Σε_i/r_i. Primary cells are single-use; secondary cells are rechargeable.
Get a ✓ Verified tutor for “Electric Current Through Conductors” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A copper wire of cross-section 2 mm² carries 3 A. Copper has 8.5 × 10²⁸ free electrons per m³. Find the current density and the drift speed.
Answer: J = 1.5 × 10⁶ A/m²; v_d ≈ 0.11 mm/s.
A car headlamp filament draws 4.5 A from a 12 V battery. Find its resistance and conductance. What current flows if the filament is used on 6 V (assume R unchanged)?
Answer: R ≈ 2.67 Ω; G = 0.375 S; I = 2.25 A at 6 V. (A real filament is cooler at 6 V, so its R would be a little less.)
A 1500 W electric kettle runs on 230 V. Find the current, its resistance, and the cost of using it 30 minutes a day for 30 days at ₹8 per unit.
Answer: 6.5 A; 35.3 Ω; 22.5 units costing ₹180.
A 4 Ω and a 12 Ω resistor are in parallel, and this pair is in series with 5 Ω. The combination is connected to a 9 V cell of internal resistance 1 Ω. Find the current from the cell, the terminal voltage and the current in the 4 Ω resistor. Also read the colour code Green-Blue-Red-Gold.
Answer: 1 A from the cell; 8 V terminal voltage; 0.75 A in the 4 Ω resistor; the resistor is 5.6 kΩ ± 5%.
A nichrome wire (ρ = 1.0 × 10⁻⁶ Ω m) is 2 m long and 0.4 mm in diameter. Find its resistance. A copper coil of 10 Ω at 0 °C has α = 4.3 × 10⁻³ °C⁻¹; find its resistance at 50 °C.
Answer: About 15.9 Ω for the nichrome wire; 12.15 Ω for the copper coil at 50 °C.
Cells of emf 2 V (r = 1 Ω) and 1.5 V (r = 0.5 Ω) are connected in parallel (like terminals together). Find the equivalent emf and internal resistance.
Answer: ε_eq ≈ 1.67 V, r_eq ≈ 0.33 Ω — between the two emfs, with a lower internal resistance.
| Quantity | Formula | SI unit and note |
|---|---|---|
| Current | I = q/t = dq/dt | ampere (A) |
| Current and drift speed | I = nAev_d | v_d ~ 10⁻⁴ m/s |
| Current density | J = I/A = nev_d | A/m² |
| Drift speed from collisions | v_d = eEτ/m | τ = mean free time |
| Ohm's law | V = IR; E = ρJ; J = σE | ohm (Ω); G = 1/R in siemens |
| Resistivity | R = ρl/A; ρ = m/(ne²τ) | Ω m; σ = 1/ρ in S/m |
| Temperature dependence | R = R₀[1 + α(T − T₀)] | α in °C⁻¹ |
| Power | P = VI = I²R = V²/R | watt; 1 kWh = 3.6 × 10⁶ J |
| Series resistors | R_s = R₁ + R₂ + … | same current |
| Parallel resistors | 1/R_p = 1/R₁ + 1/R₂ + … | same voltage |
| emf | ε = dW/dq | volt (J/C) |
| Real cell | V = ε − Ir; I = ε/(R + r); I_max = ε/r | r = internal resistance |
| Cells in parallel | 1/r_eq = Σ1/r_i; ε_eq/r_eq = Σε_i/r_i | signs by polarity |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct alternative (i)–(iv): (i) lowest resistance among 25, 40, 60, 100 W bulbs at 230 V; (ii) ohmic conductor; (iii) use of a rheostat; (iv) wire stretched until its radius is halved — new resistance.
Answer: (i) (D) 100 W. (ii) (D) nichrome wire. (iii) (B) to continuously change the resistance and thereby alter the current. (iv) (D) 16R.
2. 1. Choose the correct alternative (v)–(viii): (v) masses 1:3:5, lengths 5:3:1 — ratio of resistances; (vi) 2 V cell, r = 0.1 Ω, with 0.9 Ω — voltage across the cell; (vii) 100 cells (5 V, 1 Ω) for maximum current in 25 Ω — number of rows; (viii) five 1.5 V cells as in the diagram (the third cell is reversed) — total voltage.
Answer: (v) (D) 125 : 15 : 1. (vi) (B) 1.8 V. (vii) (A) 2. (viii) (B) 4.5 V.
3. 2(i). An 8 Ω and a 6 Ω resistor are in series across a 5 V supply. (a) Find the p.d. across 8 Ω. (b) If a third resistor is put in parallel with 6 Ω, will the p.d. across 8 Ω be larger, smaller or the same?
Answer: (a) ≈ 2.86 V. (b) Larger, because the parallel pair has less resistance than 6 Ω, so more current flows and the 8 Ω resistor takes a larger part of the supply voltage.
4. 2(ii). Prove that current density in a metal is directly proportional to drift speed. 3(i). Distinguish ohmic and non-ohmic substances. 3(ii). DC flows in a metal piece of non-uniform cross-section: which of current, current density or drift speed stays constant?
Answer: 2(ii) Since I = nALe ÷ (L/v_d) = nAev_d, J = I/A = (ne)v_d; n and e are constants for the metal, so J ∝ v_d. 3(i) Ohmic substances obey V = IR with constant R; their I–V graph is a straight line through the origin (copper, nichrome wire at constant temperature). Non-ohmic substances have a curved I–V graph and their resistance changes with V or I (junction diode, vacuum tube, electrolyte, thermistor). 3(ii) The current is the same at every section (charge cannot pile up). Current density J = I/A and drift speed v_d = I/(nAe) are larger where the cross-section is smaller.
5. 4(i). A 20 km steel rail has cross-section 25 cm² and resistivity 6 × 10⁻⁸ Ω m at 20 °C. Find its resistance.
Answer: 0.48 Ω
6. 4(ii). A used battery has emf 24 V and internal resistance 380 Ω. Find the maximum current. Can it start a car?
Answer: ≈ 0.063 A. No — a starter motor needs a current of the order of 100 A, far more than this battery can give.
7. 4(iii). A battery of emf 12 V and internal resistance 3 Ω drives 0.5 A through a resistor. Find (a) the resistance, (b) the terminal voltage.
Answer: (a) 21 Ω; (b) 10.5 V.
8. 4(iv). Current density in a copper wire is 500 A/cm² and copper has 8.47 × 10²² free electrons per cm³. Find the drift velocity.
Answer: ≈ 3.69 × 10⁻⁴ m/s
9. 4(v). 10 Ω, 20 Ω and 30 Ω are in series on a 12 V supply. Find the equivalent resistance and the p.d. across each.
Answer: 60 Ω; 2 V, 4 V and 6 V.
10. 4(vi). 1 kΩ and 2 kΩ are in parallel on a 9 V supply. Find the equivalent resistance and the current in each.
Answer: ≈ 0.67 kΩ (667 Ω); 9 mA and 4.5 mA.
11. 4(vii). A silver wire has resistance 4.2 Ω at 27 °C and 5.4 Ω at 100 °C. Find the temperature coefficient of resistance.
Answer: ≈ 3.91 × 10⁻³ °C⁻¹ (with 27 °C as reference, as the book does; if 0 °C is taken as reference, solving 5.4/4.2 = (1 + 100α)/(1 + 27α) gives about 4.38 × 10⁻³ °C⁻¹).
12. 4(viii). A 6 m wire of diameter 0.5 mm has resistance 50 Ω. Find its resistivity and conductivity.
Answer: ρ ≈ 1.636 × 10⁻⁶ Ω m; σ ≈ 6.11 × 10⁵ S/m (Ω⁻¹ m⁻¹). The book's numbers are right but its units are printed as Ω/m and m/Ω; the correct units are Ω m and S/m.
13. 4(ix). Find the values: (1) Blue Green Red Gold (2) Brown Black Red Silver (3) Red Red Orange Gold (4) Orange White Red Gold (5) Yellow Violet Brown Silver.
Answer: (1) 6.5 kΩ ± 5%. (2) 1.0 kΩ ± 10%. (3) 22 kΩ ± 5% — the book prints 2.2 kΩ; the correct answer is 22 kΩ (2.2 kΩ would be Red Red Red). (4) 3.9 kΩ ± 5%. (5) 470 Ω ± 10% — the book prints 4.70 kΩ; the correct answer is 470 Ω (4.7 kΩ would be Yellow Violet Red).
14. 4(x). Give the colour codes (tolerance ±10%) for (a) 330 Ω (b) 100 Ω (c) 47 kΩ (d) 160 Ω (e) 1 kΩ.
Answer: (a) Orange Orange Brown Silver. (b) Brown Black Brown Silver. (c) Yellow Violet Orange Silver. (d) Brown Blue Brown Silver. (e) Brown Black Red Silver.
15. 4(xi). A 4 A current flows through a headlight for 2 hours. How many electrons pass?
Answer: 1.8 × 10²³ electrons
16. 4(xii). A heating element on 230 V draws 5 A. Find the heat produced in 1 hour (J = 4.2 J/cal).
Answer: ≈ 985.7 kcal
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Four bulbs of 25 W, 40 W, 60 W and 100 W are rated for 230 V. Which has the lowest resistance?
Answer: B. R = V²/P is smallest for the largest P.
2. Which of these is an ohmic conductor?
Answer: D. A metal wire at constant temperature obeys Ohm's law.
3. Drift speed of electrons in a copper wire is of the order of…
Answer: B. Random speed is about 10⁶ m/s; drift is tiny.
4. Current density in a conductor is directly proportional to…
Answer: C. J = nev_d.
5. A wire is stretched so its radius is halved. Its resistance becomes…
Answer: D. Area ÷ 4 and length × 4 give R × 16.
6. The SI unit of resistivity is…
Answer: D. ρ = RA/l.
7. Resistance of metals with rising temperature generally…
Answer: D. Ion cores vibrate more, so collisions are more frequent.
8. Mercury becomes a superconductor at about…
Answer: A. Its critical temperature is 4.2 K.
9. A cell of emf 2 V and r = 0.1 Ω is connected to 0.9 Ω. The terminal voltage is…
Answer: C. I = 2/1 = 2 A; V = 2 − 2 × 0.1.
10. Resistances 6 Ω and 3 Ω in parallel give…
Answer: D. 6 × 3/(6 + 3) = 2 Ω.
11. The colour bands Brown-Black-Red-Silver mean…
Answer: C. 10 × 10² Ω, silver ±10%.
12. Five 1.5 V cells are in series, but one is connected the wrong way round. The total emf is…
Answer: A. 4 × 1.5 − 1.5 = 4.5 V.
13. Maximum current that can be drawn from a cell of emf ε and internal resistance r is…
Answer: D. Short circuit: R = 0.
14. A 2 kW heater used for 3 hours consumes…
Answer: C. 2 kW × 3 h = 6 kWh.
15. Which cell is rechargeable?
Answer: C. Its chemical reaction is reversible.
