Why does a freely hanging magnet always settle north–south, and why can't you ever get a single magnetic pole? This chapter covers magnetic lines of force and flux, the bar magnet as a magnetic dipole, its field on the axis, on the equator and at any point (using the electrostatic analogy), Gauss' law for magnetism, and the Earth's magnetism — meridians, declination, dip, field components and magnetic maps — with worked numericals and answers to every exercise.
Magnetism has been known for over 2600 years. Gilbert showed the Earth is a weak magnet, Oersted linked electricity with magnetism, and Maxwell showed both are faces of one electromagnetic field. Unlike electric charges, magnetic poles never occur alone — breaking a magnet always gives smaller complete magnets.
Magnetic field lines form closed loops (N to S outside, S to N inside), never cross, and their density shows the field strength. Magnetic flux φ is measured in weber; for a uniform field normal to an area, B = φ/A in tesla (1 T = 10⁴ gauss).
A bar magnet is a magnetic dipole with pole strength q_m (A m), magnetic length 2l ≈ 5/6 of its geometric length and moment m = q_m(2l) from S to N (A m²). By analogy with the electric dipole (1/4πε₀ → μ₀/4π), for r ≫ l: B_axis = (μ₀/4π)2m/r³, B_eq = (μ₀/4π)m/r³ opposite to m, and at any point B = (μ₀/4π)(m/r³)√(3cos²θ + 1).
Gauss' law for magnetism: the net magnetic flux through any closed surface is zero, ∮B·dS = 0, because isolated poles (monopoles) do not exist.
The Earth behaves like a huge magnet whose magnetic N pole lies below Antarctica. Its field at a place is described by declination (angle between magnetic and geographic meridians), dip φ (angle of the field below the horizontal) and the horizontal component: B_H = B cos φ, B_V = B sin φ, tan φ = B_V/B_H. Isodynamic, isogonic and aclinic lines on magnetic maps help navigation.
Get a ✓ Verified tutor for “Magnetism” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A uniform field of 0.2 T passes normally through a coil face of area 50 cm². Find the magnetic flux. What is the field in gauss?
Answer: 1 × 10⁻³ Wb (1 mWb); 2000 gauss.
A bar magnet 12 cm long has a pole strength of 20 A m. Find its magnetic length and magnetic dipole moment.
Answer: Magnetic length 10 cm; m = 2 A m².
A short bar magnet has m = 2 A m². Find the field 10 cm from its centre (a) on the axis, (b) on the equator. For a magnet with m = 1 A m², find B at 10 cm in a direction making 60° with the axis.
Answer: (a) 4 × 10⁻⁴ T; (b) 2 × 10⁻⁴ T; (c) ≈ 1.32 × 10⁻⁴ T at about 41° to the line OP.
A closed spherical surface surrounds the north end of a bar magnet. 3 × 10⁻⁴ Wb of flux leaves through the part of the sphere near the north pole. How much flux enters through the rest of the sphere, and what is the net flux?
Answer: 3 × 10⁻⁴ Wb enters elsewhere; the net flux is zero.
At a place the Earth's field is 5 × 10⁻⁵ T and the angle of dip is 30°. Find the horizontal and vertical components.
Answer: B_H ≈ 4.33 × 10⁻⁵ T, B_V = 2.5 × 10⁻⁵ T.
A dip needle placed in a vertical plane at 60° to the magnetic meridian shows a dip of 60°. Find the true dip.
Answer: True dip ≈ 40.9° (the apparent dip is always larger than the true dip).
| Quantity | Formula | SI unit and note |
|---|---|---|
| Magnetic field from flux | B = φ/A | tesla = Wb/m²; 1 T = 10⁴ G |
| Magnetic dipole moment | m = q_m(2l) | A m²; from S to N |
| Magnetic length | 2l = (5/6) × geometric length | poles lie inside the ends |
| Axial field | B = (μ₀/4π)2m/r³ | along m; r ≫ l |
| Equatorial field | B = (μ₀/4π)m/r³ | opposite to m |
| Field at any point | B = (μ₀/4π)(m/r³)√(3cos²θ + 1) | tan α = ½ tan θ |
| Force on a pole | F = q_mB | newton |
| Energy of a dipole | U = −m·B | joule |
| Gauss' law for magnetism | ∮B·dS = 0 | no monopoles |
| Earth's components | B_H = B cos φ, B_V = B sin φ, tan φ = B_V/B_H | φ = angle of dip |
| Apparent dip | tan φ = tan φ′ cos β | β = angle with magnetic meridian |
| Constant | μ₀/4π = 10⁻⁷ T m/A | μ₀ = 4π × 10⁻⁷ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. 1. Choose the correct option: (i) field on the axis at distance r is always proportional to … (ii) magnetic meridian is the plane … (iii) B_H = B_V — dip? (iv) field lines inside a bar magnet … (v) B_V = 0 — dip? (vi) B_H = 0 lies at … (vii) needle not parallel to a non-uniform field experiences …
Answer: (i) (D) not necessarily 1/r³ at all points. (ii) (C) passing through the magnetic axis of Earth. (iii) (B) 45°. (iv) (D) from S pole to N pole. (v) (A) 0°. (vi) (D) one of the geomagnetic poles. (vii) (C) both a force and a torque.
2. 2. Answer briefly: (i) What happens if a bar magnet is cut transverse to its length / along its length? (ii) Gauss' law if a monopole of strength p were enclosed?
Answer: (i) Cut across (transverse): two magnets, each with N and S poles, each half as long; pole strength stays the same, so each moment is halved. Cut along the length: two thinner magnets of the same length, each with half the pole strength and so half the moment. In both cases no isolated pole is produced. (ii) By analogy with electrostatics, ∮B·dS = μ₀p — the net flux would equal μ₀ times the enclosed pole strength instead of zero.
3. 3. Answer in detail: (i) Explain Gauss' law for magnetic fields. (ii) What is a geographic meridian; how does declination vary with latitude; where is it minimum? (iii) Define angle of dip; how does it change from the magnetic equator to a magnetic pole?
Answer: (i) The net magnetic flux through any closed surface is zero, ∮B·dS = 0. Magnetic lines are closed loops, so every line entering a closed surface also leaves it. Even a surface around one end of a magnet encloses a matching opposite pole within the material, because each slice is a dipole. Unlike electric charges, isolated magnetic poles do not exist; the dipole is the basic unit. (ii) The geographic meridian at a place is the vertical plane containing the Earth's geographic (rotation) axis, i.e. the true north–south vertical plane. Declination differs from place to place because the magnetic and geographic poles do not coincide: it is small near the equator and grows at higher latitudes, being largest near the poles; it is minimum (close to zero) at low latitudes such as in India (Mumbai 0°58′ W, Delhi 0°41′ E). (iii) The angle of dip is the angle between the Earth's resultant magnetic field at a place and the horizontal. Moving from the magnetic equator (φ = 0°, field horizontal) towards a magnetic pole, the dip increases steadily and reaches 90° at the pole, where the field is vertical.
4. 4(i). A magnetic pole of strength 100 A m is on the axis of a bar magnet, 20 cm from its centre. The magnet has pole strength 200 A m and length 5 cm. Find the force on the pole.
Answer: ≈ 2.5 × 10⁻² N (using the exact axial formula with l = 2.5 cm gives about 2.6 × 10⁻² N).
5. 4(ii). A magnet makes 45° with the horizontal in a vertical plane at 30° to the magnetic meridian. Find the true dip.
Answer: φ = tan⁻¹(0.866) ≈ 40.9°
6. 4(iii). Two small identical magnets (m = 1.0 A m² each) lie in a plane with axes perpendicular; the axis of one passes through the centre of the other; centres 2 m apart. Find the field at the midpoint.
Answer: √5 × 10⁻⁷ T ≈ 2.24 × 10⁻⁷ T
7. 4(iv)–(v). Field lines in the gap of a hypothetical circular magnet (N at the centre, S around it); between the south poles of two such magnets; and around two bar magnets on a line with north poles facing each other — mark neutral points.
Answer: (iv) In the gap the lines run radially outward from the central N pole to the surrounding S ring, like the spokes of a wheel. Between the outer south poles of two such magnets placed side by side, lines from each south ring bend away from each other (like poles repel), leaving a region between them with no lines. (v) With N poles facing, the lines from each N pole curve away sideways and return to their own S poles; they never cross. Midway between the facing N poles (on the line joining them) the two fields are equal and opposite, so that point is a neutral point (if the magnets are identical; otherwise it shifts towards the weaker magnet). Considering the Earth's field as well, extra neutral points can appear where a magnet's field cancels B_H.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The axial field of a bar magnet at distance r from its centre is…
Answer: A. B = (μ₀/4π)2mr/(r² − l²)²; it is ∝ 1/r³ only when r ≫ l.
2. Magnetic meridian is the vertical plane…
Answer: C. By definition.
3. If B_H = B_V at a place, the angle of dip is…
Answer: A. tan φ = 1.
4. Inside a bar magnet, field lines run…
Answer: B. Lines form closed loops.
5. Where the vertical component of the Earth's field is zero, the dip is…
Answer: B. The field is horizontal — the magnetic equator.
6. The horizontal component of the Earth's field is zero at…
Answer: B. There the field is vertical.
7. A magnetic needle in a non-uniform field, not parallel to it, experiences…
Answer: C. Unequal forces on the poles give a net force; the couple gives a torque.
8. The SI unit of magnetic dipole moment is…
Answer: A. m = q_m × 2l, (A m)(m).
9. A magnet has geometric length 18 cm. Its magnetic length is about…
Answer: B. 5/6 × 18 = 15 cm.
10. At the same distance from a short magnet, B_axis : B_equator is…
Answer: D. 2m/r³ versus m/r³.
11. The net magnetic flux through a closed surface is…
Answer: A. No isolated poles exist.
12. 1 tesla equals…
Answer: D. 1 G = 10⁻⁴ T.
13. The Earth's magnetic north pole lies…
Answer: D. Field lines leave the southern hemisphere.
14. Lines joining places of equal declination are called…
Answer: D. 'Gon' refers to angle — declination.
15. Doubling the distance from a short magnet changes its field by a factor of…
Answer: D. B ∝ 1/r³.
