Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 114–141
Why does a steel rail need a gap, why does steam scald worse than boiling water, and why does tea cool fast at first and then slowly? This chapter adds temperature as the fourth fundamental quantity and covers heat and temperature, thermometers and the Celsius, Fahrenheit and Kelvin scales, absolute zero and the ideal gas equation, linear, areal and volume expansion (β = 2α, γ = 3α), specific heat and calorimetry, change of state, latent heat and phase diagrams, conduction, convection and radiation, thermal conductivity and resistance, and Newton's law of cooling — with solved numericals and answers to every exercise.
Heat is energy that flows because of a temperature difference; temperature tells how hot a body is and is a measure of the average kinetic energy of its particles. Two bodies in contact exchange heat until they reach the same temperature (thermal equilibrium). The zeroth law — if A and B are each in equilibrium with C, they are in equilibrium with each other — is what makes thermometers work.
Thermometers use a thermometric property (length of a liquid column, resistance, gas pressure, thermo-emf) calibrated between the ice point and steam point: T = 100(P_T − P₁)/(P₂ − P₁) °C. The scales are linked by T_C/100 = (T_F − 32)/180 = (T_K − 273.15)/100. Extrapolating gas graphs to zero pressure gives absolute zero, −273.15 °C = 0 K; the Kelvin scale uses the triple point of water, 273.16 K, as its single fixed point. With kelvin temperatures the gas laws combine into PV = nRT.
Most substances expand on heating. Linear, areal and volume expansion follow Δl = αlΔT, ΔA = βAΔT and ΔV = γVΔT, with β = 2α and γ = 3α, so α : β : γ = 1 : 2 : 3. Liquids are kept in containers, so the apparent overflow depends on γ_liquid − γ_container. Water is an exception between 4 °C and 0 °C.
The heat needed to change temperature is Q = msΔT; heat capacity of a body is ms. A gas has two principal specific heats, s_p > s_v, because at constant pressure part of the heat does work in expanding. In a calorimeter, heat lost = heat gained (method of mixtures). During melting or boiling the temperature stays constant and Q = mL, where L is the latent heat.
Heat travels by conduction (solids, no bulk movement), convection (fluids, bulk movement of hot matter) and radiation (electromagnetic waves, no medium needed). Conduction obeys Q/t = kA(T₁ − T₂)/x; thermal resistance R_T = x/(kA). Newton's law of cooling: for small excess temperature, the rate of fall of temperature is proportional to (T − T₀).
Get a ✓ Verified tutor for “Thermal Properties of Matter” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A thermometer's mercury thread is 20 mm long at the ice point and 220 mm at the steam point. Find the temperature when it is 95 mm long, and give it in °F and K.
Answer: 37.5 °C = 99.5 °F = 310.65 K
A gas in a rigid cylinder is at 27 °C and 2.0 atm. It is heated to 177 °C. Find the new pressure.
Answer: About 3.0 atm (the kelvin temperature rises 1.5 times, so the pressure does too).
A steel bridge girder is 50 m long at 10 °C. By how much does it lengthen on a 40 °C afternoon? (α_steel = 1.2 × 10⁻⁵ K⁻¹)
Answer: 18 mm — engineers leave expansion joints for exactly this reason.
A 0.2 kg iron ball at 150 °C is dropped into 0.5 kg of water at 20 °C (ignore the container). Find the final temperature. (s_iron = 448, s_water = 4186 J kg⁻¹ K⁻¹)
Answer: About 25.3 °C — water's large specific heat keeps the rise small.
How much heat turns 0.2 kg of ice at 0 °C into steam at 100 °C? (L_f = 3.33 × 10⁵ J/kg, L_v = 22.6 × 10⁵ J/kg, s_water = 4186 J kg⁻¹ K⁻¹)
Answer: About 6.02 × 10⁵ J — three-quarters of it goes into boiling.
A copper rod 0.5 m long with cross-section 4 cm² has its ends at 100 °C and 20 °C. Find the rate of heat flow and the rod's thermal resistance. (k = 385 W m⁻¹ K⁻¹)
Answer: About 24.6 W; R_T ≈ 3.25 K/W.
A cup of soup cools at 2 °C/min when it is at 80 °C in a 25 °C room. At what rate will it cool when it is at 47 °C?
Answer: 0.8 °C per minute — the excess fell to 2/5 of its value, so the rate did too.
| Quantity / law | Formula | SI unit and note |
|---|---|---|
| Temperature scales | T_C/100 = (T_F − 32)/180 = (T_K − 273.15)/100 | 1 °C step = 1 K step = 1.8 °F step |
| Thermometer calibration | T = 100(P_T − P₁)/(P₂ − P₁) | °C; P = any thermometric property |
| Ideal gas equation | PV = nRT | R = 8.31 J mol⁻¹ K⁻¹; T in kelvin |
| Linear expansion | l₂ = l₁[1 + α(T₂ − T₁)] | α in K⁻¹ |
| Areal expansion | A₂ = A₁[1 + β(T₂ − T₁)] | β = 2α |
| Volume expansion | V₂ = V₁[1 + γ(T₂ − T₁)] | γ = 3α; α : β : γ = 1 : 2 : 3 |
| Heat equation | Q = msΔT | s in J kg⁻¹ K⁻¹; heat capacity = ms (J/K) |
| Molar specific heat | C = M × s | J mol⁻¹ K⁻¹; for gases C_p > C_v |
| Method of mixtures | m₁s₁(T₁ − T) = (m₂s₂ + m₃s₃)(T − T₂) | heat lost = heat gained |
| Latent heat | Q = mL | J/kg; water L_f = 3.33 × 10⁵, L_v = 22.6 × 10⁵ |
| Conduction | Q/t = kA(T₁ − T₂)/x | k in W m⁻¹ K⁻¹, [L¹M¹T⁻³K⁻¹] |
| Thermal resistance | R_T = x/(kA) = ΔT/(Q/t) | K/W, [M⁻¹L⁻²T³K¹] |
| Newton's law of cooling | dT/dt = −C(T − T₀) | valid for small T − T₀ |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Choose the correct option. (i) Range of a clinical thermometer: (A) 70–100 °C (B) 34–42 °C (C) 0–100 °F (D) 34–80 °F. (ii) A glass bottle full of water cracks in the freezer because: (A) bottle contracts (B) bottle expands (C) water expands on freezing (D) water contracts on freezing. (iii) Two temperatures differ by 25 °C; on the Fahrenheit scale they differ by (A) 65° (B) 45° (C) 38° (D) 25°. (iv) α : β : γ = (A) 1:3:2 (B) 1:2:3 (C) 2:3:1 (D) 3:1:2. (v) (I) α has dimension K⁻¹, (II) γ has dimension K⁻¹: (A) both correct (B) I only (C) II only (D) both wrong. (vi) Water falls 200 m; temperature difference between top and bottom (s = 4200 J kg⁻¹ °C⁻¹)? (A) 0.96 °C (B) 1.02 °C (C) 0.46 °C (D) 1.16 °C
Answer: (i) B; (ii) C; (iii) B; (iv) B; (v) A; (vi) C (0.466… °C, nearest option 0.46 °C).
2. Q2 (i) Difference between heat and temperature. (ii) How is a thermometer calibrated? (iii) Scales of temperature and their relation. (iv) What is absolute zero?
Answer: (i) Heat is energy transferred because of a temperature difference; unit joule; it depends on mass, material and temperature change. Temperature is the degree of hotness, a measure of the average kinetic energy per particle; unit kelvin; it decides the direction of heat flow. A bathtub of warm water holds more heat than a cup of boiling water, though its temperature is lower. (ii) Place the thermometer in melting pure ice at 1 atm and mark the reading P₁ (0 °C); then in steam above boiling water at 1 atm and mark P₂ (100 °C). Divide the interval into 100 equal parts; any temperature is then T = 100(P_T − P₁)/(P₂ − P₁). Modern scales use the triple point of water (273.16 K) as a single fixed point. (iii) Celsius (ice 0, steam 100, 100 divisions), Fahrenheit (32 and 212, 180 divisions) and Kelvin (absolute; ice point 273.15 K). Relation: T_C/100 = (T_F − 32)/180 = (T_K − 273.15)/100. (iv) If the straight-line P–T (or V–T) graphs of all gases are extended to zero pressure, they meet the axis at −273.15 °C. This is absolute zero, 0 K — the lowest temperature possible, which cannot actually be reached.
3. Q2 (v) Derive the relation between the three coefficients of thermal expansion.
Answer: β = 2α, γ = 3α, i.e. α/1 = β/2 = γ/3 or α : β : γ = 1 : 2 : 3.
4. Q2 (vi) Applications of thermal expansion. (vii) Why two specific heats for a gas? (viii) Are freezing point and melting point the same? (ix) Define sublimation and triple point. (x) Explain 'steady state'.
Answer: (vi) Gaps between rail sections and expansion joints in bridges; power lines strung slack; a heated iron tyre fitted on a cart wheel shrinks and grips tightly; tight metal lids loosened by warming; bimetallic strips in thermostats and fire alarms; liquid-in-glass thermometers. (vii) Heating a gas changes both its pressure and volume a lot. At constant volume all the heat raises the temperature; at constant pressure the gas also expands and does work on the surroundings, so extra heat is needed. So we define s_v and s_p (and C_v, C_p), with s_p > s_v. (viii) For a pure substance at a given pressure they are the same temperature (0 °C for water at 1 atm); 'melting point' describes the solid → liquid change and 'freezing point' the liquid → solid change. Both phases coexist there. (ix) Sublimation: direct change from solid to vapour without passing through the liquid state (camphor, iodine, dry ice). Triple point: the unique temperature and pressure at which solid, liquid and vapour of a substance coexist in equilibrium — for water 273.16 K and about 611 Pa. (x) When one end of a rod is heated, each section first keeps warming (variable state). After some time the temperature of every section stops changing, though different sections have different temperatures and the temperature falls uniformly from hot end to cold end. This is the steady state.
5. Q2 (xi) Define the coefficient of thermal conductivity and derive its expression. (xii) Four everyday applications of thermal conductivity. (xiii) Explain thermal resistance; its SI unit and dimensions.
Answer: (xi) k is the heat that flows per second between opposite faces of a 1 m cube held 1 K apart (equivalently, rate of heat flow per unit area per unit temperature gradient). From the four proportionalities, Q = kA(T₁ − T₂)t/x, so k = Qx/[A(T₁ − T₂)t]; unit W m⁻¹ K⁻¹, dimensions [L¹M¹T⁻³K⁻¹]. (xii) Metal cooking pots with wooden/ebonite handles; thick hollow-brick walls in cold storage; ice wrapped in a gunny bag; thermocol boxes and woollen clothes trapping air; also, a thick glass cracks when hot water is poured in because glass conducts poorly. (xiii) Thermal resistance is the opposition of a body to heat flow: R_T = (T₁ − T₂)/(Q/t) = x/(kA), like V/I for electric resistance. SI unit K/W (K s J⁻¹; the book also uses °C s/kcal); dimensions [M⁻¹L⁻²T³K¹]. A large R_T means a good insulator.
6. Q2 (xiv) How does heat travel by radiation without a medium? (xv) State Newton's law of cooling and explain its experimental verification. (xvi) What is thermal stress? Give an example of its disadvantage. (xvii) Which materials are used as thermal insulators and why?
Answer: (xiv) Every body above 0 K has fast-moving particles that emit electromagnetic waves (thermal radiation) travelling at 3 × 10⁸ m/s. These waves cross empty space; when they fall on a colder body they are absorbed and increase the motion of its particles, so its temperature rises. Heat → waves → heat; no particles are needed in between, which is how sunlight warms the Earth. (xv) Law: for a small temperature difference, the rate of fall of temperature of a body is directly proportional to the difference between its temperature and the surroundings: dT/dt = −C(T − T₀). Verification: fill a calorimeter two-thirds with boiling water, cover it and insert a thermometer; note the temperature every minute until it falls about 25 °C. Plot T against t (cooling curve); draw tangents at several points to get dT/dt. A graph of dT/dt against (T − T₀) is a straight line through the origin, which proves the law. (xvi) When a body is prevented from expanding or contracting freely as its temperature changes, internal stress develops — thermal stress (≈ YαΔT). Disadvantages: rails laid without gaps buckle in summer; thick glass cracks when hot water is poured in; concrete roads crack without expansion joints. (xvii) Materials with very low thermal conductivity (high thermal resistance) and often trapped air: wood, cork, thermocol, glass wool, wool and cloth, gunny bags, hollow bricks, ebonite, plastics. Still air (k ≈ 0.024 W m⁻¹ K⁻¹) is a very poor conductor, so materials that trap it stop heat flow.
7. Q3 (i) A glass flask of volume 1 × 10⁻⁴ m³ is filled with a liquid at 30 °C and heated to 100 °C. How much liquid overflows? (γ_glass = 1.2 × 10⁻⁵ °C⁻¹, γ_liquid = 75 × 10⁻⁵ °C⁻¹)
Answer: 5.166 × 10⁻⁶ m³ = 516.6 × 10⁻⁸ m³ (matches the book).
8. Q3 (ii) Which needs more energy: heating 2.0 kg of lead by 30 K or 4.0 kg of copper by 5 K? (s_lead = 128, s_copper = 387 J kg⁻¹ K⁻¹)
Answer: Copper needs more (7740 J vs 7680 J).
9. Q3 (iii) Energy needed to turn 5.0 g of water at 100 °C into steam (L_v = 2.26 × 10⁶ J/kg).
Answer: 11.3 × 10³ J
10. Q3 (iv) A sphere cools at 0.05 °C/s at 70 °C and 0.025 °C/s at 50 °C. Find the surroundings' temperature and the cooling rate at 40 °C.
Answer: 30 °C; 0.0125 °C/s
11. Q3 (v) At constant pressure a gas's volume varies linearly with absolute temperature. If it never liquefies, at what temperature would its volume ideally be zero?
Answer: −273.15 °C (absolute zero)
12. Q3 (vi) Rails 10 m long are laid at 27 °C; the maximum temperature is 45 °C. What gap is needed? (α = 1.2 × 10⁻⁵ K⁻¹)
Answer: 2.16 mm
13. Q3 (vii) An iron ring of diameter 1.47 m must fit a wooden rim of diameter 1.5 m (both at 27 °C). To what temperature must the ring be heated? (α_iron = 1.2 × 10⁻⁵ K⁻¹)
Answer: About 1727.7 °C (matches the book).
14. Q3 (viii) On scale X, water boils at 200 °X and freezes at 20 °X. Find the reading for a liquid boiling at 62 °C.
Answer: 131.6 °X
15. Q3 (ix) A gas at 900 °C is cooled until both its pressure and volume are halved. Find its final temperature.
Answer: 293.29 K (about 20.1 °C).
16. Q3 (x) An aluminium rod and an iron rod differ in length by 1.5 m at all temperatures. Find their lengths at 0 °C. (α_Al = 24.5 × 10⁻⁶ °C⁻¹, α_Fe = 11.9 × 10⁻⁶ °C⁻¹)
Answer: Aluminium ≈ 1.417 m, iron ≈ 2.917 m.
17. Q3 (xi) 50 cal of heat raises 6 kg of a metal from 20 °C to 62 °C. Find its specific heat.
Answer: 0.198 cal kg⁻¹ °C⁻¹ (matches the book; the data are unusual — real metals need far more heat — but the arithmetic is right).
18. Q3 (xii) Heat flows through a copper rod at 1500 cal/s with a 30 °C temperature difference. Find its thermal resistance.
Answer: 0.02 °C s/cal (the book prints the unit as '°C s cal'; it should be °C s per cal).
19. Q3 (xiii) A kettle heats water from 0 °C to boiling in 20 min and then needs 90 min to turn it all into steam. Find the latent heat of vaporisation. (s = 1 cal/g °C)
Answer: 450 cal/g
20. Q3 (xiv) Heat passes through a steel plate 4 cm thick at 400 kcal per minute per m². Find the temperature difference across it. (k = 0.026 kcal m⁻¹ s⁻¹ K⁻¹)
Answer: ≈ 10.26 °C (= 10.26 K).
21. Q3 (xv) A metal sphere cools from 80 °C to 60 °C in 6 min. How long will it take to cool from 60 °C to 40 °C in a 30 °C room?
Answer: The book prints 10 min; the correct answer is 12 min.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. The range of a clinical thermometer is about…
Answer: A. Human body temperature stays near 37 °C.
2. A temperature difference of 25 °C equals what difference in °F?
Answer: C. Δ°F = 1.8 × 25 = 45.
3. At which temperature do the Celsius and Fahrenheit scales show the same number?
Answer: C. x/100 = (x − 32)/180 gives x = −40.
4. The single fixed point of the Kelvin scale is…
Answer: B. It is assigned 273.16 K.
5. If α, β, γ are the linear, areal and volume expansion coefficients, then α : β : γ is…
Answer: B. β = 2α and γ = 3α.
6. A 2 m brass rod (α = 2 × 10⁻⁵ K⁻¹) is heated by 50 K. Its length increases by…
Answer: B. Δl = 2 × 2 × 10⁻⁵ × 50 = 2 × 10⁻³ m.
7. Water is densest at…
Answer: D. Between 0 and 4 °C water contracts on heating.
8. Heat needed to warm 2 kg of water by 10 K (s = 4186 J kg⁻¹ K⁻¹)…
Answer: D. Q = 2 × 4186 × 10.
9. Which is the dimension of the coefficient of linear expansion?
Answer: D. α = Δl/(lΔT).
10. During melting, the heat supplied…
Answer: B. It is latent heat.
11. Cooking is quicker in a pressure cooker because…
Answer: B. Water boils above 100 °C inside.
12. Dry ice changing directly into gas is called…
Answer: B. Solid → vapour directly.
13. SI unit of thermal conductivity is…
Answer: C. k = (Q/t)x/(AΔT).
14. Transformers are cooled by oil mainly through…
Answer: A. Hot oil rises, cool oil sinks.
15. A body cools at 3 °C/min at 70 °C in a 20 °C room. At 45 °C it cools at…
Answer: B. Excess halves from 50 to 25, so the rate halves.
