Textbook: Physics – Class 11 (Balbharati, official free PDF) · pages 142–158
Why does a train whistle drop in pitch as it passes you, and why did Newton get the speed of sound wrong? This chapter covers wave types and their properties, the wave equation y = a sin(kx − ωt + φ), the speed of waves on strings and in gases, Newton's formula and Laplace's correction, the effects of pressure, temperature and humidity, echo, reverberation and acoustics, pitch, timbre and loudness in decibels, and the Doppler effect — with solved numericals and answers to every exercise.
A wave carries energy and momentum from place to place without carrying the medium along. Mechanical waves need a medium, electromagnetic waves do not, and every moving object has a matter wave. Progressive waves keep travelling outward until something stops them.
Every wave has an amplitude, wavelength λ, period T and frequency n = 1/T, and its speed is v = nλ. Waves repeat both in time and in space (double periodicity). When a wave enters a new medium its frequency stays fixed, while speed and wavelength change.
In transverse waves particles vibrate at right angles to the direction of travel (crests and troughs; can be polarised). In longitudinal waves they vibrate along it (compressions and rarefactions; cannot be polarised). Sound in air is a longitudinal progressive wave.
Newton took sound in air as isothermal, giving v = √(P/ρ) ≈ 280 m/s — about 16% too low. Laplace showed the process is adiabatic, so v = √(γP/ρ) ≈ 332 m/s. Speed of sound does not depend on pressure (at fixed temperature), rises as √T, and is greater in moist air.
Echo needs a reflector at least about 17 m away; reverberation is sound lingering through repeated reflections, controlled by good acoustics. Loudness in decibels is L = 10 log₁₀(I/I₀) with I₀ = 10⁻¹² W/m². The Doppler effect, n = n₀(v ± v_L)/(v ∓ v_s), raises the heard frequency on approach and lowers it on recession.
Get a ✓ Verified tutor for “Sound” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A speaker produces a 500 Hz note. Sound travels at 340 m/s in air and 1480 m/s in water. Find the wavelength in each medium and their ratio.
Answer: 0.68 m in air, 2.96 m in water; the wavelength in air is about 0.23 times that in water.
A wave is given by y = 0.02 sin(4πx − 680πt) in SI units. Find its amplitude, wavelength, frequency, speed and direction.
Answer: a = 2 cm, λ = 0.5 m, n = 340 Hz, v = 170 m/s along the positive x-direction.
A string 2 m long has a mass of 10 g and is stretched with a tension of 125 N. Find the speed of a transverse wave on it.
Answer: About 158 m/s.
Sound travels at 332 m/s at 0 °C. Find its speed at 27 °C (a) exactly using v ∝ √T and (b) with the 0.61 m/s per °C rule.
Answer: About 348 m/s — the shortcut agrees closely with the exact result.
A ship sends an ultrasonic pulse straight down and receives the echo from the sea bed 1.2 s later. Sound travels at 1500 m/s in sea water. How deep is the sea?
Answer: 900 m deep.
A loudspeaker gives an intensity of 10⁻⁵ W/m² at a point. Find the loudness in dB. What is the loudness if the intensity becomes 100 times larger?
Answer: 70 dB, then 90 dB.
A train blowing a 600 Hz whistle passes a person standing on a platform at 25 m/s. Speed of sound = 340 m/s. Find the frequency heard as the train approaches and as it moves away.
Answer: About 648 Hz while approaching and about 559 Hz after it passes.
| Quantity | Formula | SI unit and note |
|---|---|---|
| Wave speed | v = nλ = λ/T | m/s; n in Hz, λ in m |
| Progressive wave | y = a sin(kx − ωt + φ) | k = 2π/λ, ω = 2πn; minus sign → moves along +x |
| Wave on a string | v = √(T/m) | T tension (N), m mass per length (kg/m) |
| Newton's formula | v = √(P/ρ) | isothermal; ≈ 280 m/s at NTP (too low) |
| Laplace's correction | v = √(γP/ρ) | adiabatic; γ = C_p/C_v = 1.41 for air; ≈ 332 m/s |
| Temperature effect | v/v₀ = √(T/T₀); v ≈ v₀ + 0.61 t | T in kelvin; t in °C, small ranges |
| Humidity effect | v_m/v_d = √(ρ_d/ρ_m) | moist air is lighter, so sound is faster |
| Echo distance | d = vt/2 | minimum ≈ 17 m for a distinct echo |
| Loudness | L = 10 log₁₀(I/I₀) dB | I₀ = 10⁻¹² W/m²; I ∝ A², I ∝ 1/r² |
| Doppler effect | n = n₀(v ± v_L)/(v ∓ v_s) | upper signs: approach; lower signs: moving apart |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Choose the correct alternatives: (i) Sound carried by air from a sitar to a listener is a … wave. (ii) When sound goes from air to water, which remains constant? (iii) Laplace's correction is needed because sound waves … (iv) Speed of sound is maximum in … (v) Walls of a hall built for music concerts should …
Answer: (i) (D) Longitudinal progressive. (ii) (B) Frequency. (iii) (C) propagate adiabatically. (iv) (D) solid. (v) (D) absorb sound.
2. Answer briefly: (i) Wave motion is doubly periodic — explain. (ii) What is Doppler effect? (iii) Describe a transverse wave. (iv) Define a longitudinal wave. (x) Define amplitude and wavelength. (xii) Relation between velocity, wavelength and frequency. (xvii) What is the phase of a wave?
Answer: (i) At a fixed point the disturbance repeats every period T (periodic in time); at a fixed instant the wave shape repeats every wavelength λ (periodic in space). (ii) The apparent change in the frequency of a wave because of relative motion between the source and the listener, e.g. the falling pitch of a passing train's horn. (iii) A wave in which the particles vibrate perpendicular to the direction of travel, forming crests and troughs; e.g. ripples on water, a wave on a guitar string; it can be polarised. (iv) A wave in which the particles vibrate parallel to the direction of travel, forming compressions and rarefactions; e.g. sound in air. (x) Amplitude is the maximum displacement of a particle from its rest position; wavelength is the distance between two nearest particles in the same phase (e.g. crest to crest). (xii) In one period T the wave advances one wavelength λ, so v = λ/T = nλ. (xvii) Phase is the state of vibration of a particle — its displacement, its direction of motion and which oscillation it is in — usually written as the angle (kx − ωt + φ); particles one wavelength apart differ in phase by 2π.
3. Answer briefly: (v) State Newton's formula for velocity of sound. (vi) Effect of pressure on velocity of sound. (vii) Effect of humidity. (xx) Explain Newton's formula and its limitation.
Answer: (v) v = √(P/ρ), where P is the pressure and ρ the density of air (Newton took E = P, the isothermal bulk modulus). (vi) v = √(γPV/M); at constant temperature PV is constant (Boyle's law), so pressure has no effect on the speed of sound. (vii) Moist air is less dense than dry air (e.g. 0.81 vs 1.29 kg/m³ at 0 °C as quoted by the book), and v_m/v_d = √(ρ_d/ρ_m) > 1, so sound is faster in humid air. (xx) Newton assumed the temperature of air stays constant as sound passes, so he used the isothermal elasticity P: v = √(P/ρ) = √(0.76 × 13600 × 9.8 ÷ 1.293) ≈ 280 m/s at NTP. The measured value is about 332 m/s, about 16% higher. The limitation is the wrong assumption: the changes are rapid and adiabatic, which Laplace corrected to v = √(γP/ρ).
4. Answer briefly: (viii) What is an echo? (ix) Two applications of acoustics. (xiii) Principle of superposition. (xviii) Define progressive wave and give four properties. (xix) Distinguish transverse and longitudinal waves.
Answer: (viii) An echo is a sound heard again after reflection from a distant hard surface; for a distinct echo the surface must be at least about 17 m away because the brain retains a sound for about 0.1 s. (ix) Any two: SONAR to find depth or submarines; ultrasound imaging of unborn babies, tumours and heart valves; shock waves to break kidney stones; designing auditoriums and quiet vehicles; locating oil deposits by seismic reflection. (xiii) When two or more waves reach a point together, each produces its own displacement independently, and the resultant displacement is the vector sum of the individual ones. (xviii) A progressive wave is a disturbance that travels outward from its source carrying energy until stopped. Properties: every particle vibrates with the same amplitude, period and frequency; the phase changes from particle to particle; energy (not matter) is transferred; the wave pattern moves with a constant speed v = nλ in a given medium. (xix) Transverse: vibration perpendicular to travel; crests and troughs; needs elasticity of shape, so only solids and liquid surfaces; no change of pressure or density; can be polarised. Longitudinal: vibration along the direction of travel; compressions and rarefactions; needs volume elasticity, so travels in solids, liquids and gases; pressure and density vary; cannot be polarised.
5. Answer briefly: (xiv)–(xvi) State the expressions for apparent frequency when (a) source and listener move towards each other, (b) move away from each other, (c) only the listener moves towards / away from a stationary source, (d) only the source moves towards / away from a stationary listener.
Answer: (a) n = n₀(v + v_L)/(v − v_s). (b) n = n₀(v − v_L)/(v + v_s). (c) Towards: n = n₀(v + v_L)/v; away: n = n₀(v − v_L)/v. (d) Towards: n = n₀ v/(v − v_s); away: n = n₀ v/(v + v_s). Here v is the speed of sound, v_L of the listener, v_s of the source and n₀ the emitted frequency.
6. 3(i) A sound wave in air has speed 340 m/s and wavelength 1.7 m. Find (a) the frequency, (b) the period.
Answer: 200 Hz; 0.005 s (matches the book).
7. 3(ii) A tuning fork of 170 Hz produces sound of wavelength 2 m. Find the speed of sound.
Answer: 340 m/s
8. 3(iii) An echo-sounder on a fishing boat receives an echo from a shoal of fish 0.45 s after sending it. Speed of sound in water is 1500 m/s. How deep is the shoal?
Answer: 337.5 m
9. 3(iv) A girl 170 m from a high wall claps so that each clap coincides with the echo of the previous one. (a) With 60 claps per minute, what is the speed of sound? (b) At a new place she needs 45 claps per minute. How far is she from the wall now?
Answer: (a) 340 m/s. (b) About 226.7 m. The book prints 255 m; the correct answer is 226.7 m (255 m would need 40 claps per minute, i.e. 1.5 s between claps).
10. 3(v) Sound wave A has period 0.015 s and wave B has period 0.025 s. Which has the greater frequency?
Answer: Wave A (smaller period means higher frequency).
11. 3(vii) At what temperature will the speed of sound in air be 1.75 times its speed at NTP?
Answer: 836.06 K = 563.06 °C
12. 3(viii) A man between two parallel cliffs fires a gun and hears echoes after 3 s and 5 s. The cliffs are 1360 m apart. Find the speed of sound.
Answer: 340 m/s
13. 3(ix) The speeds of sound at a place on two days are in the ratio 1 : 1.1, at the same temperature. What can you conclude?
Answer: The air was moist on the second day; the density of the drier air was 1.21 times that of the moist air (ρ_dry = 1.1² ρ_moist = 1.21 ρ_moist).
14. 3(x) A police car approaches a stationary observer at 15 m/s with a 250 Hz siren. Speed of sound = 340 m/s. Find the recorded frequency.
Answer: ≈ 261.54 Hz
15. 3(xi) An ambulance siren of 1500 Hz moves at 30 m/s, first towards and then away from a stationary observer. Speed of sound = 340 m/s. Find the difference in the frequencies heard.
Answer: ≈ 266.78 Hz (the book prints 266.79 Hz — a rounding difference only).
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Sound from a sitar reaching a listener through air is a…
Answer: A. Air particles vibrate along the direction of travel and the wave moves outward.
2. When sound passes from air into water, which quantity is unchanged?
Answer: B. Frequency is fixed by the source.
3. A sound of 680 Hz travels at 340 m/s. Its wavelength is…
Answer: D. λ = v/n = 340/680.
4. Which property can only transverse waves show?
Answer: D. Longitudinal vibrations lie along the direction of travel.
5. Laplace's correction was needed because sound in air travels…
Answer: A. Compressions are too quick for heat to escape.
6. The value of γ for air used in the Newton–Laplace formula is about…
Answer: A. γ = C_p/C_v ≈ 1.41.
7. If air pressure doubles at constant temperature, the speed of sound…
Answer: C. Density doubles too, so P/ρ is unchanged.
8. Speed of sound in air is 330 m/s at 0 °C. At 273 °C it is about…
Answer: B. T doubles, so v = 330 × √2 ≈ 467 m/s.
9. Speed of sound is greatest in…
Answer: C. Solids are far stiffer; no sound in vacuum.
10. For a distinct echo at about 344 m/s, the reflector should be at least…
Answer: B. Round trip of 0.1 s → 34.4 m, so half of it.
11. Walls of a music hall should mainly…
Answer: A. Absorbing walls reduce echo and reverberation.
12. A sound of intensity 10⁻⁸ W/m² has a loudness of…
Answer: D. 10 log₁₀(10⁻⁸/10⁻¹²) = 10 × 4.
13. Increasing the loudness by 30 dB multiplies the intensity by…
Answer: D. Every 10 dB is a factor of 10.
14. A source moves towards a stationary listener. The heard frequency is…
Answer: A. Approaching source: crests bunch up, so frequency rises.
15. Listener and source move in the same direction at equal speeds. The heard frequency…
Answer: D. No relative motion, so no Doppler shift.
