Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 230–250
Moving charges feel a magnetic force, and moving charges also create magnetic fields. This chapter links the two: the Lorentz force on a charge, circular and helical paths, the cyclotron, force and torque on current-carrying wires and loops, the moving-coil galvanometer, the Biot–Savart law for wires and loops, Ampere’s circuital law, and the fields of a solenoid and a toroid — with every exercise numerical solved and checked.
A charge q moving with velocity v in a magnetic field B feels F = q(v × B), of size qvB sin θ, at right angles to both v and B. Because this force is always perpendicular to the velocity it does no work: it changes the direction of motion, never the speed or kinetic energy. With an electric field too, the total (Lorentz) force is F = q(E + v × B).
A charge moving at right angles to a uniform B goes round a circle of radius r = mv/(qB) with period T = 2πm/(qB). The period and the cyclotron frequency f = qB/(2πm) do not depend on speed — the idea behind the cyclotron. If v has a component along B, the path becomes a helix whose pitch is v∥T.
A straight wire of length L carrying current I in a field B feels F = IL × B; a closed loop in a uniform field feels zero net force but a torque τ = m × B, where m = NIA is its magnetic dipole moment. In a moving-coil galvanometer a radial field keeps this torque NIAB at every position, so the steady deflection is proportional to the current.
The Biot–Savart law gives the field of a small current element, dB = (μ₀/4π) I dl sin θ/r². It leads to B = μ₀I/(2πa) near a long straight wire, μ₀NI/(2R) at the centre of a circular coil and μ₀IR²/[2(R² + z²)^(3/2)] on its axis. Two parallel wires attract if the currents are in the same direction and repel if opposite, with force per length μ₀I₁I₂/(2πd).
Ampere’s circuital law, ∮B·dl = μ₀I_enclosed, gives fields quickly when there is symmetry: B = μ₀nI inside a long solenoid, B = μ₀NI/(2πr) inside a toroid, and B = 0 outside an ideal toroid.
Get a ✓ Verified tutor for “Magnetic Fields due to Electric Current” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A proton moves at 4 × 10⁶ m s⁻¹ at 30° to a 0.5 T field. Find the force on it.
Answer: 1.6 × 10⁻¹³ N
An electron moves at 2 × 10⁶ m s⁻¹ at right angles to a 1 mT field. Find the radius of its path and its frequency of revolution.
Answer: About 1.14 cm; about 28 MHz.
A coil of 200 turns, area 4 cm², carries 5 mA in a 0.2 T radial field. Its spring constant is 2 × 10⁻⁷ N m per degree. Find the deflection.
Answer: 400° (the coil would go off scale).
A coil of 50 turns and radius 5 cm carries 2 A. Find the field at its centre and on its axis 5 cm from the centre.
Answer: 1.26 × 10⁻³ T at the centre; 4.4 × 10⁻⁴ T on the axis.
A long cylindrical conductor of radius 4 mm carries 8 A spread uniformly. Find B at 2 mm and at 8 mm from its axis.
Answer: 2 × 10⁻⁴ T at both points (one inside, one outside).
A solenoid 40 cm long has 800 turns and carries 1.5 A. Find the field inside it.
Answer: 3.77 × 10⁻³ T (3.77 mT)
| Quantity | Formula | Unit / note |
|---|---|---|
| Force on a charge | F = qvB sin θ | N; zero work done |
| Radius of circular path | r = mv/(qB) | m |
| Cyclotron frequency | f = qB/(2πm) | Hz; independent of speed |
| Max KE in a cyclotron | K = q²B²R²/(2m) | J |
| Force on a wire | F = BIL sin θ | N |
| Torque on a coil | τ = NIAB sin θ | N m |
| Galvanometer | I = cφ/(NAB) | linear scale (radial field) |
| Dipole energy | U = −mB cos θ | J |
| Long straight wire | B = μ₀I/(2πa) | T |
| Coil centre | B = μ₀NI/(2R) | T |
| Coil axis | B = μ₀NIR²/[2(R² + z²)^(3/2)] | T |
| Parallel wires | F/L = μ₀I₁I₂/(2πd) | N m⁻¹ |
| Solenoid | B = μ₀nI | n = turns per metre |
| Toroid | B = μ₀NI/(2πr) | zero outside |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) Two straight pieces of length L lie on a line through P and a semicircle of radius R is centred on P; current I. B at P? (ii) ∮B·dl for loop (a), which the wire threads, and loop (b), which it does not. (iii) A proton enters at the origin along +x into a field pointing into the paper — its path? (iv) A 1 m copper rod with 15 A west to east at the equator, B = 1.3 × 10⁻⁴ T south to north — force? (v) Kinetic energy of a charge entering a field at right angles to v?
Answer: (i) C, (ii) B, (iii) circular path bending towards +y (see note), (iv) D, (v) A
2. Q2. A straight wire of mass 20 g and length 1 m carries 1 A. What horizontal field B at right angles to it will make it float?
Answer: 0.196 T
3. Q3. Field 2 cm from a long straight wire carrying 5 A?
Answer: 5 × 10⁻⁵ T
4. Q4. An electron moves at 3.2 × 10⁷ m s⁻¹ across a 6.00 × 10⁻⁴ T field. Find the radius of its path, its frequency and its KE in keV.
Answer: r ≈ 30.3 cm, f ≈ 16.8 MHz, KE ≈ 2.91 keV
5. Q5. An alpha particle (charge +2e) with KE 10.00 MeV moves on a circle of radius 24.60 cm in a 1.851 T field. Find its mass.
Answer: 6.643 × 10⁻²⁷ kg
6. Q6. Wires 1 and 2 are 8 mm apart and carry 10 A in opposite directions (wire 1 upward, wire 2 downward, wire 2 to the right). Find the field of wire 2 along the 22 cm section AB of wire 1, and the force on that section.
Answer: B = 2.5 × 10⁻⁴ T (into the page); F = 5.5 × 10⁻⁴ N, repulsive
7. Q7. B at 3.1 cm from a long wire with 5.2 A?
Answer: 3.355 × 10⁻⁵ T
8. Q8. Two long parallel wires 1.35 cm apart carry equal currents; the force per metre is 4.76 × 10⁻² N. Find I.
Answer: 56.68 A
9. Q9. B = 16 μT at 2.4 cm from a long wire. Find the current.
Answer: 1.92 A
10. Q10. B at the centre of a loop of radius 12.3 cm is 6.4 × 10⁻⁶ T. Find its magnetic moment.
Answer: 5.954 × 10⁻² A m²
11. Q11. A loop of radius 9.7 cm carries 2.3 A. Find B (a) at the centre and (b) on the axis 9.7 cm from the centre.
Answer: 1.49 × 10⁻⁵ T; 5.27 × 10⁻⁶ T
12. Q12. A coil of 100 turns of radius 8.0 cm carries 0.40 A. Field at its centre?
Answer: 3.142 × 10⁻⁴ T
13. Q13. A proton cyclotron uses B = 1.4 Wb m⁻². How often must the field between the dees be reversed?
Answer: 2.342 × 10⁻⁸ s
14. Q14. A galvanometer coil has 50 turns, 5 cm × 3 cm, in a 0.05 Wb m⁻² radial field; the spring constant is 1.5 × 10⁻⁹ N m per degree. Current for 30° deflection?
Answer: 1.2 × 10⁻⁵ A
15. Q15. A solenoid π m long, 5 cm across, has 1000 turns and carries 5 A. Field at its centre?
Answer: 2 × 10⁻³ T
16. Q16. A toroid of radius 10 cm has 1000 turns. What current gives 5 × 10⁻² T inside?
Answer: 25 A
17. Q17. A proton cyclotron has dees of radius 60 cm and an oscillator at 10 MHz. Find the final KE of the protons.
Answer: ≈ 7.42 MeV (book: 7.419 MeV)
18. Q18. A loop is made of a 270° arc of radius R centred on P, closed by the straight chord (segment II) joining the arc’s ends; the chord subtends 90° at P. Find B at P.
Answer: B = (μ₀I/4πR)(3π/2 + 2) ≈ 6.71 μ₀I/(4πR), into the paper
19. Q19. Two long parallel wires a distance R apart carry I each in the same direction (into the paper). P is equidistant from them and the line from each wire to P makes angle θ with the plane of the wires. Show B = (μ₀I/πR) sin 2θ and give its direction.
Answer: B = (μ₀I/πR) sin 2θ, directed parallel to the plane containing the wires (along the line joining them)
20. Q20. A long wire (radius a) has current density J = J₀r/a. Find B inside at distance r from the axis.
Answer: B = μ₀J₀r²/(3a) (the book’s r should be r²)
21. Q21. Same wire with uniform current density J: B inside at distance r?
Answer: B = μ₀Jr/2
22. Theory (page 264, Q1–3): electric versus magnetic force on a moving charge; uniform circular motion and the cyclotron; why a radial field helps a galvanometer.
Answer: Model answers as above; draw the cyclotron (two dees, gap, oscillator, magnet poles, spiral path)
23. Theory (page 264, Q4–5): Biot–Savart law for a long wire and on the axis of a loop; Ampere’s law and where it is useful.
Answer: Model answers as above
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A charged particle enters a uniform magnetic field at right angles. Its kinetic energy…
Answer: A. The force is perpendicular to v and does no work.
2. The radius of a charge’s circular path in a field B is…
Answer: D. From qvB = mv²/r.
3. Doubling the speed of a proton in a uniform field changes its period by a factor of…
Answer: C. T = 2πm/(qB) does not involve v.
4. A 1 m wire carrying 15 A west to east at the equator, B = 1.3 × 10⁻⁴ T south to north, feels about…
Answer: D. BIL = 1.95 × 10⁻³ N; east × north points up.
5. The pitch of a helical path depends on…
Answer: B. Pitch = v∥ × period.
6. In a cyclotron, the maximum kinetic energy of an ion is…
Answer: C. v_max = qBR/m, so K = ½mv².
7. The torque on a current loop is maximum when its plane is…
Answer: A. Then the normal is at 90° to B, sin θ = 1.
8. A radial field in a galvanometer makes…
Answer: D. Deflection becomes proportional to current.
9. Field at the centre of a single loop of radius R carrying I is…
Answer: D. From Biot–Savart, all elements add.
10. Two long wires 10 cm apart each carry 5 A in opposite directions. The force per metre is…
Answer: B. 2 × 10⁻⁷ × 25/0.1; unlike currents repel.
11. A semicircular arc of radius R with current I gives at its centre…
Answer: C. Half the full-loop value.
12. ∮B·dl round a loop that does not enclose any current is…
Answer: B. Ampere’s law: no enclosed current.
13. The field inside a long solenoid does not depend on its…
Answer: B. B = μ₀nI.
14. Inside a long wire with uniform current, B at distance r from the axis is proportional to…
Answer: A. B = μ₀Ir/(2πR²).
15. A toroid has 500 turns, mean radius 10 cm and 2 A current. Field inside is…
Answer: B. μ₀NI/(2πr) = 2 × 10⁻⁷ × 1000/0.1.
