Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 251–264
Why is iron pulled strongly by a magnet, aluminium only slightly, and copper or water pushed away? The answer lies inside atoms: orbiting and spinning electrons are tiny current loops. This chapter covers the torque, energy and oscillations of a magnet in a field, the orbital magnetic moment and Bohr magneton, the quantities M, H, χ and μ, diamagnetism, paramagnetism and ferromagnetism, domains and the Curie temperature, the hysteresis loop, and how we choose materials for permanent magnets, electromagnets and magnetic shields.
A magnet (or current loop) of moment m in a uniform field B feels a torque τ = m × B and has potential energy U = −mB cos θ. It is most stable along the field and least stable opposite to it. Displaced slightly, it oscillates in angular SHM with period T = 2π√(I/(mB)), which is the basis of the vibration (oscillation) magnetometer.
An orbiting electron is a current loop with orbital moment m = evr/2 = (e/2mₑ)L, pointing opposite to its angular momentum. With Bohr’s rule L = nh/2π, the smallest moment is the Bohr magneton μ_B = eh/(4πmₑ) ≈ 9.27 × 10⁻²⁴ A m². Electrons also have spin moments; filled shells cancel, so unpaired electrons decide an atom’s magnetism.
Magnetisation M is magnetic moment per unit volume; magnetic intensity H = nI depends only on the free current. Then B = μ₀(H + M), and for weak fields M = χH, so B = μ₀(1 + χ)H = μ₀μᵣH with μᵣ = 1 + χ.
Diamagnetic materials (χ small and negative, nearly independent of temperature) are weakly repelled; paramagnetic materials (χ small and positive) are weakly attracted, and their χ follows Curie’s law χ = C/T; ferromagnetic materials (χ very large) are strongly attracted because of domains of aligned atoms. Above its Curie temperature a ferromagnet becomes paramagnetic, with χ = C/(T − T_c).
The B–H hysteresis loop of a ferromagnet shows saturation, retentivity (B left at H = 0) and coercivity (reverse H needed to make B zero); its area is the energy lost per cycle. Hard materials (high retentivity and coercivity) make permanent magnets; soft iron (high permeability, low coercivity, narrow loop) makes electromagnets and transformer cores; soft-iron enclosures provide magnetic shielding.
Get a ✓ Verified tutor for “Magnetic Materials” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A magnet with m = 2 A m² and I = 4 × 10⁻⁶ kg m² oscillates in the Earth’s horizontal field B_H = 4 × 10⁻⁵ T. Find its period. How much work is needed to turn it from along the field to 60°?
Answer: T ≈ 1.40 s; W = 4 × 10⁻⁵ J
An electron moves round a nucleus at 1.0 × 10⁶ m s⁻¹ in an orbit of radius 1.0 × 10⁻¹⁰ m. Find its orbital magnetic moment and angular momentum, and check their ratio.
Answer: 8.0 × 10⁻²⁴ A m²; 9.1 × 10⁻³⁵ kg m² s⁻¹
A rod with χ = 499 is placed in a solenoid giving H = 2000 A m⁻¹. Find M, μᵣ and B in the rod.
Answer: M ≈ 1.0 × 10⁶ A m⁻¹; μᵣ = 500; B ≈ 1.26 T
A paramagnetic salt has χ = 2.0 × 10⁻⁴ at 200 K. Find its susceptibility at 400 K and at −73 °C.
Answer: 1.0 × 10⁻⁴ at 400 K; 2.0 × 10⁻⁴ at −73 °C
A cube-shaped iron domain is 2 μm on a side. Iron has density 7.9 g cm⁻³, molar mass 55 g mol⁻¹, and each atom has moment 9.27 × 10⁻²⁴ A m². Estimate the domain’s maximum moment and magnetisation.
Answer: m_max ≈ 6.4 × 10⁻¹² A m²; M ≈ 8.0 × 10⁵ A m⁻¹
A transformer core has a hysteresis loop of area 300 J m⁻³ per cycle. The core volume is 2 × 10⁻³ m³ and the supply is 50 Hz. Find the power lost to hysteresis.
Answer: 30 W
| Quantity / type | Formula / property | Unit / note |
|---|---|---|
| Torque on a magnet | τ = mB sin θ | N m |
| Potential energy | U = −mB cos θ | J; stable at θ = 0 |
| Oscillation period | T = 2π√(I/(mB)) | s |
| Orbital moment | m = evr/2 = (e/2mₑ)L | A m² |
| Bohr magneton | μ_B = eh/(4πmₑ) | 9.27 × 10⁻²⁴ A m² |
| Field in a material | B = μ₀(H + M) = μ₀μᵣH | T |
| Susceptibility | χ = M/H; μᵣ = 1 + χ | no unit |
| Curie law (paramagnet) | χ = C/T | T in kelvin |
| Above Curie point | χ = C/(T − T_c) | ferromagnet turns paramagnetic |
| Diamagnetic | χ small, negative | weakly repelled |
| Paramagnetic | χ small, positive | weakly attracted |
| Ferromagnetic | χ very large | domains; hysteresis |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) Earth’s field inside a hollow iron box compared with outside. (ii) Why soft iron for transformer cores. (iii) Which is true of diamagnets: μᵣ less than 1, χ negative and small, χ independent of temperature, or all of these. (iv) A freely suspended magnet of period T is broken into two equal halves (each half the length); ratio T′/T. (v) H = 360 A m⁻¹ produces B = 0.6 T; permeability?
Answer: (i) A, (ii) A, (iii) D, (iv) B, (v) C
2. Q2 (i–iv). (i) Which property of soft iron suits electromagnets? (ii) Ferromagnet heated above its Curie temperature? (iii) Retentivity and coercivity of a permanent magnet? (iv) Curie’s law for paramagnets.
Answer: Model answers as above
3. Q2 (v–vii). (v) Derive the orbital magnetic moment of an electron. (vi) What does a hysteresis loop show? (vii) One use of an electromagnet.
Answer: Model answers as above
4. Q3. A plate 10 cm × 0.5 cm × 0.2 cm in H = 0.5 × 10⁴ A m⁻¹ acquires a moment of 0.5 A m². Find B in the plate.
Answer: 0.634 T (Wb m⁻²)
5. Q4. A rod of cross-section 0.25 cm² in H = 4000 A m⁻¹ carries a flux of 25 × 10⁻⁶ Wb. Find μᵣ, χ and M.
Answer: μᵣ ≈ 199, χ ≈ 198, M ≈ 7.92 × 10⁵ A m⁻¹
6. Q5. Work to turn a magnet through 90° from the meridian is n times the work to turn it through 60°. Find n.
Answer: n = 2
7. Q6. An electron orbits at radius 5.3 × 10⁻¹¹ m with speed 2 × 10⁶ m s⁻¹. Find its orbital magnetic moment and angular momentum.
Answer: 8.48 × 10⁻²⁴ A m²; 9.645 × 10⁻³⁵ J s
8. Q7. A paramagnetic gas has 2.0 × 10²⁶ atoms per m³, each with moment 1.5 × 10⁻²³ A m², at 27 °C. (a) Maximum magnetisation? (b) Can a 3 T field saturate it?
Answer: (a) 3.0 × 10³ A m⁻¹; (b) No — thermal energy is far larger than mB
9. Q8. A needle with m = 2 × 10⁻² A m² and I = 7.2 × 10⁻⁷ kg m² makes 10 oscillations in 6 s. Find B.
Answer: 3.948 × 10⁻³ T (39.48 × 10⁻⁴ Wb m⁻²)
10. Q9. A short magnet in a 700 gauss field feels 0.014 N m at 30°. Find m and the work to turn it from most stable to most unstable.
Answer: 0.4 A m²; 0.056 J
11. Q10. A needle pivoted at its centre in the magnetic meridian is kept horizontal by a 0.1 g mass on one end. Pole strength is 20 A m. Find the vertical component of the Earth’s field (g = 9.8 m s⁻²).
Answer: B_V = 2.45 × 10⁻⁵ T (book: 9.8 × 10⁻⁵ T)
12. Q11. A paramagnetic material has susceptibility χ at 27 °C. At what temperature is it χ/3?
Answer: 627 °C
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Inside a hollow iron box placed in the Earth’s field, the field is…
Answer: C. Soft iron draws the lines into its walls — magnetic shielding.
2. Soft iron is used for transformer cores because of its…
Answer: C. It magnetises and demagnetises easily, losing little energy.
3. For a diamagnetic material…
Answer: B. All three properties hold.
4. A freely oscillating bar magnet of period T is broken into two equal halves, each half the original length. One half oscillates with period…
Answer: D. m halves, I falls to 1/8, so T′ = T√(1/4).
5. H = 360 A m⁻¹ gives B = 0.6 T. The permeability is…
Answer: D. μ = B/H = 0.6/360.
6. The magnetic potential energy of a dipole is highest when m is…
Answer: A. U = −mB cos 180° = +mB.
7. The orbital magnetic moment of an electron in a circular orbit is…
Answer: D. Current ev/(2πr) times area πr².
8. The Bohr magneton is…
Answer: B. Orbital moment for n = 1.
9. A paramagnetic substance has χ at 300 K. At 900 K its susceptibility becomes…
Answer: D. χ ∝ 1/T.
10. Which is diamagnetic?
Answer: D. Bi has a negative χ.
11. Ferromagnetism disappears above the…
Answer: D. Domains break up at T_c.
12. B left in a material after H is reduced to zero is called…
Answer: B. Also called remanence.
13. A material suitable for a permanent magnet should have…
Answer: A. It must keep its magnetism and resist demagnetising.
14. The area of the B–H loop represents…
Answer: B. Lost as heat in the material.
15. A superconductor in a magnetic field shows…
Answer: B. Meissner effect: χ = −1.
