Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 214–229
Series and parallel rules cannot untangle every circuit. This chapter gives you Kirchhoff’s two laws for any network, the Wheatstone bridge and its laboratory form the metre bridge, Kelvin’s method for a galvanometer’s resistance, the potentiometer (comparing emfs and finding internal resistance), and how a moving-coil galvanometer is turned into an ammeter or a voltmeter — with every exercise numerical solved step by step.
Kirchhoff’s current (junction) law says the currents entering a junction add up to the currents leaving it, ΣI = 0; it expresses conservation of charge. The voltage (loop) law says that round any closed loop the emfs and the IR drops add to zero, ΣIR + Σε = 0; it expresses conservation of energy. With a sign convention and one equation per independent loop, any steady-current network can be solved.
In a Wheatstone bridge of four resistances P, Q, R, S, no current flows through the galvanometer when P/Q = S/R (in the book’s labelling). The metre bridge is a one-metre uniform wire form of it: X/R = l_X/l_R. With a galvanometer in one gap (Kelvin’s method) the balance condition gives G = R l_g/(100 − l_g).
A potentiometer is a long uniform wire carrying a steady current, so the potential drop along it is proportional to length: V = Kl, where K is the potential gradient. At the null point it draws no current from the cell being tested, so it measures true emf. It compares emfs (ε₁/ε₂ = l₁/l₂, or the sum-and-difference method) and finds internal resistance, r = R(l₁ − l₂)/l₂.
A moving-coil galvanometer detects small currents (around 1 mA full scale, coil about 100 Ω). A small shunt S = I_gG/(I − I_g) in parallel turns it into an ammeter; a large series resistance X = V/I_g − G turns it into a voltmeter. An ideal ammeter has zero resistance and an ideal voltmeter infinite resistance.
Real measurements carry errors: a non-uniform wire, end (contact) resistances, and heating. The metre bridge is used with the null point near the middle third and repeated with the gaps interchanged; the jockey is tapped, never slid.
Get a ✓ Verified tutor for “Current Electricity” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A 6 V cell (internal resistance 1 Ω) and a 3 V cell (internal resistance 1 Ω) are joined in parallel, like terminals together, across a 4 Ω resistor. Find the current in the 4 Ω resistor.
Answer: 1 A through the 4 Ω resistor; the 6 V cell supplies 2 A.
A bridge has P = 20 Ω, Q = 30 Ω, R = 60 Ω and S = 50 Ω (balance needs P/Q = S/R). What resistance must be put in parallel with S to balance it?
Answer: A 200 Ω shunt across S.
In a metre bridge a coil is in the left gap and 12 Ω in the right gap. The null point is at 40 cm from the left end. Find the coil’s resistance and say where the null point would be if the two were swapped.
Answer: 8 Ω; the null point moves to 60 cm.
A 4 m potentiometer wire of resistance 8 Ω is joined to a 2 V cell of negligible internal resistance through a 32 Ω rheostat. Find the potential gradient and the balancing length for a 0.05 V thermocouple.
Answer: K = 0.1 V m⁻¹; balancing length 50 cm.
A cell balances at 90 cm on open circuit. With 6 Ω connected across it the balance falls to 75 cm. Find its internal resistance.
Answer: r = 1.2 Ω
A galvanometer of resistance 50 Ω gives full deflection for 2 mA. Find (a) the shunt for a 0–1 A ammeter and (b) the series resistance for a 0–20 V voltmeter.
Answer: (a) about 0.1 Ω shunt; (b) 9950 Ω in series.
| Quantity | Formula | Unit / note |
|---|---|---|
| Junction law | ΣI = 0 | conservation of charge |
| Loop law | Σε + ΣIR = 0 | conservation of energy |
| Bridge balance | P/Q = S/R | I_g = 0; G drops out |
| Metre bridge | X = R l_X/(100 − l_X) | lengths in cm |
| Resistivity | ρ = Xπr²/L | Ω m |
| Kelvin’s method | G = R l_g/(100 − l_g) | deflection unchanged at balance |
| Potential gradient | K = V/L = εR/[L(R + r)] | V m⁻¹ |
| Emfs (individual) | ε₁/ε₂ = l₁/l₂ | same K for both |
| Emfs (sum–difference) | ε₁/ε₂ = (l₁ + l₂)/(l₁ − l₂) | l₁ = sum, l₂ = difference |
| Internal resistance | r = R(l₁ − l₂)/l₂ | l₁ open, l₂ with R across cell |
| Ammeter shunt | S = I_gG/(I − I_g) = G/(n − 1) | in parallel |
| Voltmeter resistor | X = V/I_g − G = G(n − 1) | in series |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–vi): (i) ΣI = 0 at a junction expresses conservation of (A) charge (B) energy (C) momentum (D) mass. (ii) At balance a potentiometer draws current from (A) both cells and driver (B) cell only (C) driver only (D) neither. (iii) Infinite ladder of 1 Ω series and 2 Ω cross resistors, R_AB = (A) infinite (B) zero (C) 2 Ω (D) 1.5 Ω. (iv) Bridge arms 10, 10, 10, 15 Ω — shunt across 15 Ω: (A) 10 (B) 15 (C) 20 (D) 30 Ω. (v) 40 Ω ring, P and Q a quarter-circle apart, 24 V battery with r = 0.5 Ω — battery current: (A) 0.5 (B) 1 (C) 2 (D) 3 A. (vi) Gold bangle across diametrically opposite points in the left gap, 4 Ω in the right gap, null at 20 cm — bangle resistance: (A) 2 (B) 4 (C) 8 (D) 16 Ω.
Answer: (i) A charge. (ii) C auxiliary battery only. (iii) C 2 Ω. (iv) D 30 Ω. (v) D 3 A. (vi) B 4 Ω (the resistance read between the two points is 1 Ω, which is not among the options; 4 Ω is the resistance of the whole ring of wire).
2. Answer in brief (Q2 i–vii): define a potentiometer and potential gradient; why not slide the jockey; do Kirchhoff’s laws hold for AC and DC; why keep the metre-bridge null point in the middle third; two sources of error and their cures; how potential gradient is measured.
Answer: See the steps — each line is a model answer for one part.
3. Answer in brief (Q2 viii–xiii): factors on which the potential gradient depends; why a potentiometer is preferred to a voltmeter for emf; uses; disadvantages; potentiometer vs voltmeter; effect on the null point of increasing and decreasing the wire current.
Answer: See the steps.
4. Long answers (Q3–Q5): balance condition of a Wheatstone network; finding an unknown resistance with a metre bridge; Kelvin’s method for galvanometer resistance.
Answer: P/Q = S/R; X = R l_X/(100 − l_X); G = R l_g/(100 − l_g).
5. Long answers (Q6–Q9): comparing emfs individually and by the sum-and-difference method; internal resistance of a cell with a potentiometer; factors affecting internal resistance.
Answer: ε₁/ε₂ = l₁/l₂; ε₁/ε₂ = (l₁ + l₂)/(l₁ − l₂); r = R(l₁ − l₂)/l₂.
6. Q10. Cells of 4 V (r = 1 Ω) and 1 V (r = 1 Ω) in parallel, like poles together, drive current through 2 Ω. Find that current.
Answer: 1 A (the 4 V cell gives 2 A; 1 A flows backwards into the 1 V cell).
7. Q11. Cells of 1.5 V (1 Ω) and 2 V (2 Ω) in parallel, aiding, across 5 Ω. Find the current in 5 Ω.
Answer: 5/17 A ≈ 0.294 A
8. Q12. A 30 Ω voltmeter is connected across a 2 V cell of internal resistance 10 Ω. Find its reading.
Answer: 1.5 V
9. Q13. 10, 12 and 15 Ω in parallel, in series with the same three in series, on a 4.1 V battery. Find total resistance and current.
Answer: 41 Ω; 0.1 A
10. Q14. A 1.5 m, 10 Ω potentiometer wire is in series with a 4 V cell of internal resistance 5 Ω. Find the drop per cm.
Answer: 0.0178 V/cm (1.78 V/m)
11. Q15. Two cells balance at 2.7 m when aiding and 0.3 m when opposing. Compare their emfs.
Answer: ε₁ : ε₂ = 1.25 (5 : 4)
12. Q16. A cell balances at 120 cm; shunted by 10 Ω, the balance shortens by 20 cm. Find r.
Answer: 2 Ω
13. Q17. K = 5 × 10⁻³ V/m; a cell balances on 216 cm. Find its emf.
Answer: 0.0108 V (10.8 mV)
14. Q18. An 8 m, 8 Ω potentiometer wire is in series with a resistance box and a 2 V battery. What box resistance gives 1 μV/mm?
Answer: 1992 Ω
15. Q19. In the network of the figure (each resistor 10 Ω), find the resistance between F and B.
Answer: 14 Ω
16. Q20. A 100 Ω voltmeter is connected across a 2 V cell of internal resistance 20 Ω. Find its reading.
Answer: 1.67 V (the book’s 1.66 V is the same value cut off rather than rounded).
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. Kirchhoff’s junction law follows from conservation of…
Answer: D. Charge does not collect at a junction.
2. At the null point, a potentiometer draws current from…
Answer: C. The test cell gives no current; the driver keeps the wire current flowing.
3. An infinite ladder has 1 Ω series and 2 Ω shunt resistors. Its equivalent resistance is…
Answer: D. R = 1 + 2R/(2 + R) gives R² − R − 2 = 0, R = 2 Ω.
4. A bridge has arms 10, 10, 10 and 15 Ω. The shunt across 15 Ω needed for balance is…
Answer: B. 15 ∥ 30 = 10 Ω.
5. In a metre bridge with 5 Ω on the right, the null point is at 60 cm. The left resistance is…
Answer: D. X = 5 × 60/40.
6. Unit of potential gradient is…
Answer: C. Volts per metre of wire.
7. A potentiometer is preferred to a voltmeter for emf because it…
Answer: C. Zero current means no drop across internal resistance.
8. If the current in the potentiometer wire is reduced, the balancing length for a cell…
Answer: C. K falls, so l = ε/K grows.
9. Emfs in sum and difference balance at 300 cm and 100 cm. ε₁/ε₂ is…
Answer: C. (300 + 100)/(300 − 100) = 2.
10. A cell balances at 100 cm open and 80 cm with 8 Ω across it. Its r is…
Answer: B. 8 × 20/80 = 2 Ω.
11. To convert a galvanometer into an ammeter you connect…
Answer: D. Shunt in parallel.
12. A 100 Ω galvanometer (1 mA) needs a range of 0–10 mA. The shunt is…
Answer: B. S = G/(n − 1) = 100/9.
13. A galvanometer of 20 Ω, 5 mA becomes a 10 V voltmeter with series resistance…
Answer: C. 10/0.005 − 20.
14. In Kelvin’s method the balance point is where…
Answer: D. The galvanometer is in the arm, so its deflection stays steady at balance.
15. Which is a source of error in the metre bridge?
Answer: C. End resistances are not included in the measured lengths.
