Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 265–287
A changing magnetic flux drives a current — the discovery behind every power station, transformer, induction cooktop and electric-guitar pickup. This chapter covers magnetic flux, Faraday’s and Lenz’s laws, motional emf, the induced electric field, AC generators and back emf in motors, eddy currents, self- and mutual inductance, the energy stored in a magnetic field, and the transformer — with all exercise numericals worked and checked.
Magnetic flux through an area is Φ = BA cos θ (weber). Faraday’s law: whenever the flux linked with a circuit changes, an emf is induced equal to the rate of change of flux linkage, e = −N dΦ/dt. Lenz’s law gives the sign: the induced current opposes the change that produces it, which is required by conservation of energy.
A conductor of length l moving with velocity v across a field B has a motional emf e = Blv, because the magnetic force on its free charges pushes them along it. A rod of a Faraday disc rotating with angular speed ω gives e = ½BωR². Moving a conductor against the magnetic drag force requires work, which appears as electrical energy and heat.
A coil of N turns and area A rotating at ω in a field B produces e = NABω sin ωt — the AC generator. In a running motor the same generator action produces a back emf that opposes the supply, limiting the current; the generator, in turn, feels a back torque that the engine or turbine must overcome.
Changing flux through a solid conductor sets up circulating eddy currents; they cause heating and damping, are reduced by laminating cores, and are used in induction furnaces, electromagnetic brakes, speedometers and damped galvanometers.
Self-inductance L = NΦ/I (henry) opposes changes of current in a coil, e = −L dI/dt, and stores energy ½LI² (energy density B²/2μ₀). Mutual inductance M links two coils, e₂ = −M dI₁/dt, with M = K√(L₁L₂). A transformer uses mutual induction on a soft-iron core: e_s/e_p = N_s/N_p = I_p/I_s for an ideal transformer.
Get a ✓ Verified tutor for “Electromagnetic Induction” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A 200-turn coil of area 50 cm² is held at right angles to a field that falls steadily from 0.4 T to 0.1 T in 0.05 s. Find the induced emf.
Answer: 6 V
A 0.5 m rod moves at 4 m s⁻¹ on rails in a 0.8 T field; the circuit resistance is 2 Ω. Find the emf, current, force needed and power.
Answer: 1.6 V; 0.8 A; 0.32 N; 1.28 W
A generator coil has 100 turns of area 0.02 m² and turns at 50 rev s⁻¹ in a 0.5 T field. Find the peak emf and the emf when the coil’s plane is at 30° to the field.
Answer: Peak 314 V; 272 V at that position
A 25 cm aluminium wheel rim segment of a brake moves at 20 m s⁻¹ through a 0.4 T field. Estimate the emf across a 5 cm wide path in the rim.
Answer: About 0.4 V
A 500-turn solenoid is 25 cm long with area 4 cm² (air core). Find L and the energy stored at 2 A.
Answer: L ≈ 0.50 mH; U ≈ 1.0 mJ
A transformer steps 230 V down to 12 V. The primary has 1150 turns. Find the secondary turns and, if the ideal transformer delivers 2 A, the primary current.
Answer: 60 turns; about 0.10 A
| Quantity | Formula | Unit / note |
|---|---|---|
| Magnetic flux | Φ = BA cos θ | Wb |
| Faraday–Lenz | e = −N dΦ/dt | V |
| Motional emf | e = Blv | V |
| Rotating rod / disc | e = ½BωR² | V |
| AC generator | e = NABω sin ωt | e₀ = NABω |
| Induced E field | ∮E·dl = −dΦ/dt | closed field lines |
| Self-induced emf | e = −L dI/dt | V |
| Solenoid inductance | L = μ₀N²A/l | H |
| Magnetic energy | U = ½LI² | J |
| Energy density | u = B²/(2μ₀) | J m⁻³ |
| Mutual inductance | M = μ₀N₁N₂A/l; M = K√(L₁L₂) | H |
| Transformer | V_s/V_p = N_s/N_p = I_p/I_s | ideal |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) Flux linkage of a 100-turn coil, area 1 m², normal to 1 T. (ii) Emf of a rod of length l moving at v across B. (iii) 10 mH and 20 mH in series. (iv) Emf in a 10 mH coil when the current rises from 0 to 1 A in 0.1 s. (v) Energy to set up 1 A in a 20 mH inductor.
Answer: (i) B, (ii) A, (iii) B, (iv) A, (v) A
2. Q2 (i–iii). (i) What is electromagnetic induction? State Faraday’s laws. (ii) Lenz’s law and energy conservation. (iii) Eddy currents and their uses.
Answer: Model answers as above
3. Q2 (iv–v). (iv) A copper-disc pendulum swinging between magnet poles stops quickly — why, and where does its energy go? (v) Why is the inductance of two coils in parallel less than either?
Answer: Model answers as above
4. Q3. Faraday disc of radius R rotating at ω in a perpendicular B: emf between rim and axis?
Answer: e = ½BωR²
5. Q4. A 20 m horizontal wire (east–west) falls at 10 m s⁻¹ perpendicular to a 0.5 × 10⁻⁴ T field. Emf?
Answer: 0.01 V = 10 mV
6. Q5. A disc of radius 30 cm spins at 20 rev s⁻¹ in a 0.20 T field along its axis. Find (a) area swept per second by a radius, (b) flux cut per second, (c) emf.
Answer: (a) 5.655 m², (b) 1.131 Wb, (c) 1.131 V (book rounds to 5.656, 1.130, 1.130)
7. Q6. M = 1.5 H. The current in one coil rises from 0 to 10 A in 0.2 s. Change of flux linkage in the other, and emf?
Answer: 15 Wb; 75 V
8. Q7. A long solenoid has 1500 turns m⁻¹ and carries 3.0 A. A 150-turn coil of area 25 cm² is wound round its middle. Find (a) B at the centre, (b) flux linkage of the coil, (c) average emf if the current is reversed in 0.5 s.
Answer: (a) 5.66 × 10⁻³ T, (b) 2.12 × 10⁻³ Wb, (c) 8.48 × 10⁻³ V
9. Q8. A 2000-turn search coil of area 1.5 cm² is pulled out of a 0.60 T field in 0.2 s. Emf?
Answer: 0.9 V
10. Q9. An aircraft with 50 m wingspan flies horizontally at 400 m s⁻¹ where the (vertical) field is 6 × 10⁻⁵ T. Emf between the wing tips?
Answer: 1.2 V
11. Q10. A semicircular wire of radius R rotates at frequency f in field B about the diameter joining its ends. Peak emf?
Answer: e₀ = π²BR²f
12. Q11. A railway axle 1.75 m long moves at 50 km h⁻¹; vertical field 5 × 10⁻⁵ T. Emf across the axle?
Answer: 1.215 × 10⁻³ V (1.215 mV)
13. Q12. M = 10 mH. The current in one coil falls from 5 A to 1 A in 0.2 s. Emf in the other?
Answer: 0.2 V (book: 2 V)
14. Q13. 96.0 mV is induced in a coil when the current in a nearby coil rises at 1.20 A s⁻¹. Find M.
Answer: 0.080 H = 80 mH
15. Q14. A long solenoid (length l, area A, N₁ turns) has a small coil of N₂ turns round its centre. Find M.
Answer: M = μ₀N₁N₂A/l
16. Q15. Primary and secondary each have L = 200 × 10⁻⁶ H; M = 4 × 10⁻⁶ H. What percentage of flux from one reaches the other?
Answer: 2 %
17. Q16. A toroidal winding of 100 turns per cm on a non-magnetic rod 1 m long and 1 cm in diameter carries 1 A. Find B inside and the self-inductance.
Answer: B ≈ 1.257 × 10⁻² T; L ≈ 9.87 mH (book: 9.872 mH, from rounding π)
18. Q17. A uniform upward field B(t) fills a circular region of radius s. Find the induced electric field (at the edge of the region).
Answer: E = −(s/2) dB/dt, circulating round the axis (emf round the edge = −πs² dB/dt)
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A 100-turn coil of area 1 m² is at right angles to a 1 T field. Flux linkage is…
Answer: D. NBA = 100 × 1 × 1.
2. A rod of length l moves at v perpendicular to B. The emf is…
Answer: C. Motional emf.
3. 10 mH and 20 mH inductors in series (no coupling) give…
Answer: A. Series inductances add.
4. Current in a 10 mH coil rises from 0 to 1 A in 0.1 s. Induced emf is…
Answer: C. L ΔI/Δt = 0.01 × 10.
5. Energy to build 1 A in a 20 mH inductor is…
Answer: D. ½LI² = 0.5 × 0.02 × 1.
6. Lenz’s law is a consequence of conservation of…
Answer: D. Otherwise energy would be created.
7. A magnet’s north pole approaches a coil. The near face of the coil becomes…
Answer: A. It repels the approaching north pole.
8. The emf of a rod of length R rotating about one end at ω in B is…
Answer: A. Average speed ωR/2.
9. The peak emf of a generator is…
Answer: C. From d(NBA cos ωt)/dt.
10. Laminating a transformer core reduces…
Answer: D. Insulated sheets cut the current loops.
11. A copper plate swinging between magnet poles stops quickly because of…
Answer: A. Induced currents oppose the motion.
12. Self-inductance of a solenoid is proportional to…
Answer: D. L = μ₀N²A/l.
13. Two coils of 8 mH and 2 mH with K = 0.9 have M =…
Answer: B. 0.9 × √16 mH.
14. A step-up transformer increases…
Answer: D. V_s I_s = V_p I_p (ideal).
15. The back emf in a motor is greatest when the motor…
Answer: B. e_b grows with speed.
