Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 288–305
Homes and industries run on alternating current because AC is easy to generate and to step up or down. This chapter explains peak, average and rms values, phasors, how resistors, inductors and capacitors behave on AC, impedance of a series LCR circuit, average power and power factor, wattless current, LC oscillations, series and parallel resonance, the Q factor and the choke coil — with every exercise numerical worked step by step.
An alternating voltage e = e₀ sin ωt reverses direction periodically. Its average over a full cycle is zero, so we use the half-cycle average (0.637 e₀) and, above all, the root-mean-square value e_rms = e₀/√2 ≈ 0.707 e₀ — the steady DC value with the same heating effect. Mains ‘220 V’ is an rms value with a peak of about 311 V.
In a pure resistor current and voltage are in phase. In a pure inductor the current lags the voltage by π/2 and the opposition is the inductive reactance X_L = ωL. In a pure capacitor the current leads by π/2 and the reactance is X_C = 1/(ωC). Phasors — rotating arrows — add these out-of-phase voltages.
In a series LCR circuit the impedance is Z = √[R² + (X_L − X_C)²] and the phase angle is given by tan φ = (X_L − X_C)/R. The average power is P = e_rms i_rms cos φ, where cos φ = R/Z is the power factor. Pure L or C circuits use no average power: their current is called wattless current.
A charged capacitor connected to an inductor exchanges energy between electric and magnetic forms at f = 1/(2π√(LC)) — LC oscillations. A series LCR circuit driven at this frequency has X_L = X_C, minimum impedance (R) and maximum current: series resonance, used in radio tuning. Its sharpness is measured by Q = ω_r L/R = ω_r/(bandwidth). A parallel LC circuit at resonance has maximum impedance and rejects that frequency.
A choke coil — a large inductance with tiny resistance on a laminated iron core — limits AC with almost no power loss, because its power factor is nearly zero. A resistor would waste the same energy as heat.
Get a ✓ Verified tutor for “AC Circuits” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A supply is e = 311 sin(100πt) volt. Find the rms voltage, the frequency and the value 1/600 s after it is zero.
Answer: 220 V; 50 Hz; 155.5 V
A 0.2 H inductor and, separately, a 10 μF capacitor are connected to 220 V, 50 Hz. Find each reactance and rms current.
Answer: Inductor: 62.8 Ω, 3.50 A; capacitor: 318 Ω, 0.69 A
R = 30 Ω, X_L = 80 Ω and X_C = 40 Ω are in series across 200 V rms. Find Z, the current, the power factor and the power.
Answer: Z = 50 Ω, I = 4 A, cos φ = 0.6, P = 480 W
A tube light needs 1 A at 100 V. It is run from 220 V, 50 Hz with a choke of negligible resistance. Find the inductance needed.
Answer: About 0.62 H
A 5 μF capacitor charged to 20 V is connected across a 50 mH coil. Find the frequency and the maximum current.
Answer: About 318 Hz; 0.2 A
A series circuit has L = 0.5 H, C = 20 μF and R = 10 Ω. Find the resonant frequency and Q factor.
Answer: f_r ≈ 50.3 Hz; Q ≈ 15.8
| Quantity | Formula | Unit / note |
|---|---|---|
| rms value | i_rms = i₀/√2 | A; 0.707 i₀ |
| Half-cycle average | i_av = 2i₀/π | A; 0.637 i₀ |
| Inductive reactance | X_L = ωL = 2πfL | Ω; current lags 90° |
| Capacitive reactance | X_C = 1/(ωC) | Ω; current leads 90° |
| Impedance | Z = √[R² + (X_L − X_C)²] | Ω |
| Phase angle | tan φ = (X_L − X_C)/R | rad |
| Average power | P = e_rms i_rms cos φ | W |
| Power factor | cos φ = R/Z | 0 to 1 |
| LC / resonant frequency | f = 1/(2π√(LC)) | Hz |
| Q factor | Q = ω_rL/R = (1/R)√(L/C) | no unit |
| Bandwidth | Δω = R/L | rad s⁻¹ |
| LC energy | ½CV₀² = ½LI₀² | J |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) 5 A rms at 50 Hz — current 1/300 s after zero. (ii) Power factor of 500 Ω + 0.5 H on 100√2 sin(1000t). (iii) Current leads by 45° in series LCR — C? (iv) e = 150 sin 150t, i = 150 sin(150t + π/3) — power? (v) Phase difference 45° — power factor?
Answer: (i) B, (ii) A, (iii) D, (iv) C, (v) B
2. Q2 (i–v): (i) Lamp in series with a capacitor — effect of increasing C. (ii) Why can adding a capacitor lower the impedance of an LR circuit? (iii) Why is a capacitor like a conductor at very high frequency? (iv) Wattless current. (v) Natural frequency of an LC circuit and the reactance at this frequency.
Answer: Model answers as above
3. Q3. Series LR with X_L = R has power factor P₁. Adding C with X_C = X_L gives P₂. Find P₁/P₂.
Answer: P₁/P₂ = 1/√2 ≈ 0.707
4. Q4 & Q5. Show that the average power supplied to an ideal inductor, and to an ideal capacitor, over a complete cycle is zero.
Answer: P_av = 0 for both (cos 90° = 0)
5. Q6. (a) Deduce the average power in a series LCR circuit with e = e₀ sin ωt and i = i₀ sin(ωt + φ). (b) Why does a low power factor mean more loss in transmission?
Answer: P = e_rms i_rms cos φ
6. Q7. A device Y with e = e₀ sin ωt carries i = i₀ sin(ωt + π/2). (a) Identify Y and its reactance; (b) e and i graphs; (c) reactance versus frequency; (d) phasor diagram.
Answer: Y is a capacitor; X_C = 1/(ωC)
7. Q8–Q11 (derivations). Impedance of an LCR circuit; resistance versus reactance; voltage leads current by π/2 in a pure inductor; current through a capacitor on e₀ sin ωt.
Answer: Model derivations as above
8. Q12. A 50 Hz AC has rms value 5 A. Peak value? Current 1/600 s after it was zero?
Answer: 7.07 A; 3.535 A
9. Q13. A bulb is rated 100 W, 220 V, 50 Hz. Find its resistance and rms current.
Answer: 484 Ω; 0.4545 A
10. Q14. A 15.0 μF capacitor on 220 V, 50 Hz. Find X_C, rms and peak current. What if f is doubled?
Answer: 212.1 Ω, 1.037 A, 1.466 A; reactance halves, current doubles
11. Q15. A 2 H inductor carries a sinusoidal current of amplitude 0.25 A at 60 Hz. Find the rms voltage across it (π = 3.142).
Answer: ≈ 133.3 V (book: 133.4 V)
12. Q16. e = 220 sin 100πt across an inductance of 1/π H. Write i(t) and the rms reading.
Answer: i = 2.2 sin(100πt − π/2) A; 1.556 A
13. Q17. 25 μF, 0.10 H and 25 Ω in series on e = 310 sin 314t. Find the frequency, reactance, impedance, current and phase angle.
Answer: 50 Hz, 95.99 Ω, 99.19 Ω, 2.21 A (rms), 1.316 rad
14. Q18. 100 μF, a coil of 50 Ω and 0.5 H, in series on 110 V, 50 Hz. rms current?
Answer: ≈ 0.816 A (book: 0.8153 A)
15. Q19. Find the capacitance which, in series with 10 Ω, gives a power factor of 0.5 on 80 V, 100 Hz.
Answer: 9.19 × 10⁻⁵ F (about 92 μF)
16. Q20. Time for a 50 Hz AC to go from zero to its rms value?
Answer: 2.5 × 10⁻³ s
17. Q21. Capacitance that resonates with 101.4 μH at 1 MHz?
Answer: ≈ 249.8 pF (book: 249.7 pF)
18. Q22. A 10 μF capacitor charged to 25 V is connected across a 100 mH coil. Maximum current?
Answer: 0.25 A
19. Q23. A 100 μF capacitor charged to 50 V drives a maximum current of 5 A through an inductor. Find L.
Answer: 0.01 H
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. rms current 5 A at 50 Hz. Value 1/300 s after it is zero:
Answer: C. 5√2 sin(π/3).
2. 500 Ω and 0.5 H in series on V = 100√2 sin(1000t). Power factor:
Answer: B. X_L = 500 Ω = R.
3. In a series LCR circuit the current leads the voltage by 45°. C equals…
Answer: B. X_C − X_L = R.
4. e = 150 sin(150t), i = 150 sin(150t + π/3). Average power:
Answer: D. ½ × 150 × 150 × cos 60°.
5. Phase difference 45° in a series LCR circuit gives a power factor of…
Answer: A. cos 45°.
6. The reactance of an inductor is…
Answer: B. X_L = 2πfL.
7. At series resonance, the impedance equals…
Answer: D. Reactances cancel.
8. The power consumed by an ideal capacitor in an AC circuit is…
Answer: C. cos 90° = 0.
9. A lamp in series with a capacitor glows brighter when C is…
Answer: D. Larger C lowers X_C, so more current.
10. Frequency of oscillation of an LC circuit is…
Answer: B. From the SHM equation.
11. Increasing R in a series LCR circuit makes the resonance…
Answer: A. Q = (1/R)√(L/C).
12. A 50 Hz current goes from zero to its rms value in…
Answer: C. sin ωt = 1/√2 → t = T/8.
13. The peak of a ‘230 V’ mains supply is about…
Answer: A. 230 × 1.414.
14. A parallel LC circuit at resonance draws…
Answer: A. Impedance is maximum.
15. A choke coil has…
Answer: B. So cos φ ≈ 0.
