Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 306–323
Light spreads and interferes like a wave, yet it knocks electrons out of metals one packet at a time like a stream of particles. Electrons, which we think of as particles, diffract like waves. This chapter explains the photoelectric effect and why wave theory fails to explain it, Einstein’s photon picture and equation, the photocell, de Broglie’s matter waves and the Davisson–Germer experiment that proved them — with every exercise numerical worked and checked.
In the photoelectric effect, light of high enough frequency ejects electrons from a metal surface. Experiments show a threshold frequency ν₀ for each metal, no time delay, a photocurrent proportional to intensity, and a maximum kinetic energy (measured by the stopping potential V₀) that rises with frequency but does not depend on intensity.
Wave theory cannot explain these facts: it predicts that any frequency should work if the light is intense enough, that a time lag should occur for dim light, and that brighter light should give faster electrons.
Einstein proposed that light comes in photons of energy E = hν. One photon gives all its energy to one electron: hν = φ₀ + KE_max, where the work function φ₀ = hν₀. So eV₀ = hν − φ₀; a graph of V₀ against ν is a straight line of slope h/e, whose intercept gives ν₀. Brighter light means more photons, hence more electrons, but not faster ones.
Radiation therefore shows wave–particle duality: interference and diffraction need waves; photoelectric and Compton effects need particles. A photon has momentum p = h/λ = E/c and no rest mass.
De Broglie proposed that every moving particle has a wave of wavelength λ = h/p = h/(mv). For an electron accelerated through V volts, λ = 1.227/√V nm. Davisson and Germer found an electron diffraction peak from a nickel crystal at 54 V and 50°, giving λ ≈ 0.165 nm in agreement with de Broglie’s 0.167 nm. Everyday objects have wavelengths far too small to notice.
Get a ✓ Verified tutor for “Dual Nature of Radiation and Matter” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
Light of 300 nm falls on sodium (work function 2.4 eV). Find the photon energy, the maximum kinetic energy, the stopping potential and the fastest electrons’ speed.
Answer: 4.14 eV; 1.74 eV; 1.74 V; 7.8 × 10⁵ m s⁻¹
A 2 mW laser emits light of 500 nm. How many photons does it emit per second?
Answer: About 5.0 × 10¹⁵ photons s⁻¹
Tungsten has a work function of 4.5 eV. Find its threshold wavelength. Will green light (530 nm) eject electrons?
Answer: λ₀ ≈ 276 nm; green light cannot eject electrons from tungsten
A photon has wavelength 400 nm. Find its momentum and compare it with an electron moving at 1000 m s⁻¹.
Answer: 1.66 × 10⁻²⁷ kg m s⁻¹; about 1.8 times larger
Find the de Broglie wavelength of (a) an electron accelerated through 100 V and (b) a 0.15 kg ball moving at 30 m s⁻¹.
Answer: (a) 0.123 nm; (b) 1.5 × 10⁻³⁴ m
Electrons are accelerated through 150 V. Find their de Broglie wavelength. Would they be suitable for diffraction by a crystal with atomic spacing 0.2 nm?
Answer: 0.100 nm; yes, suitable
| Quantity | Formula | Unit / note |
|---|---|---|
| Photon energy | E = hν = hc/λ | J; 1 eV = 1.6 × 10⁻¹⁹ J |
| Photon momentum | p = h/λ = E/c | kg m s⁻¹ |
| Einstein’s equation | hν = φ₀ + KE_max | J or eV |
| Stopping potential | eV₀ = KE_max | V |
| Threshold | φ₀ = hν₀ = hc/λ₀ | eV |
| V₀–ν graph | slope h/e | same for all metals |
| Number of photons | n = P/(hν) | per second |
| De Broglie wavelength | λ = h/(mv) = h/√(2mK) | m |
| Electron through V | λ = 1.227/√V | nm |
| Handy conversion | E (eV) = 1240/λ (nm) | photons |
Solve each one in your notebook first. Then open the solution and compare every step.
1. MCQs (Q1 i–v): (i) Cathode material for a street-light photocell using visible light — zinc, aluminium, nickel or potassium? (ii) With polychromatic light the stopping potential depends on the average, longest or shortest wavelength, or none? (iii) Electron, proton, α-particle and H atom with equal KE — longest λ? (iv) N_red versus N_blue for equal-power sources. (v) E = pc is valid for…
Answer: (i) D, (ii) C, (iii) A, (iv) C, (v) C
2. Q2 (i–v): (i) What is the photoelectric effect? (ii) Can microwaves be used? (iii) Is it always possible to see the effect with red light? (iv) Which metal in Table 14.1 needs the highest frequency? (v) Wave–particle duality and where it applies.
Answer: Model answers as above
3. Q3–Q6 (theory): (3) Why is V₀ linearly related to 1/λ? (4) More intensity does not raise KE_max — where does the extra energy go? (5) De Broglie wavelength of an electron; does an electron at rest have one? (6) Importance of the Davisson–Germer experiment.
Answer: Model answers as above
4. Q7. Energy of each photon of light of frequency 5 × 10¹⁴ Hz?
Answer: 3.315 × 10⁻¹⁹ J = 2.07 eV
5. Q8. The slope of the V₀–ν graph is 4.1 × 10⁻¹⁵ V s. Find h.
Answer: 6.56 × 10⁻³⁴ J s
6. Q9. Tungsten’s threshold wavelength is 2.76 × 10⁻⁵ cm. (a) Why no emission at longer λ? (b) KE_max for (i) λ = 1.80 × 10⁻⁵ cm, (ii) ν = 4 × 10¹⁵ Hz.
Answer: (i) 2.40 eV, (ii) 12.07 eV
7. Q10. The current stops at a retarding potential of 0.8 V for 4950 Å. With a new source V₀ = 1.2 V. Find φ₀ and the new wavelength.
Answer: 1.71 eV; 4270 Å
8. Q11. 4500 Å light falls on a metal with φ₀ = 2.0 eV. The fastest electrons move in a circle of radius 20 cm in a perpendicular field B. Find B.
Answer: 1.47 × 10⁻⁵ T
9. Q12. λ = 2536 Å gives V₀ = 1.95 V; λ = 3650 Å gives V₀ = 0.5 V. Find h, φ₀, the threshold frequency and wavelength, and the likely metal.
Answer: h = 6.427 × 10⁻³⁴ J s, φ₀ = 2.80 eV, ν₀ ≈ 6.97 × 10¹⁴ Hz, λ₀ ≈ 4300 Å; calcium
10. Q13. Find the wavelength, momentum and speed of an electron (a) accelerated through 54 V, (b) of kinetic energy 150 eV.
Answer: (a) 0.1672 nm, 39.65 × 10⁻²⁵ kg m s⁻¹, 4.358 × 10⁶ m s⁻¹; (b) 0.1003 nm, 66.09 × 10⁻²⁵ kg m s⁻¹, 7.263 × 10⁶ m s⁻¹ (the book’s 39.70 and 66.17 × 10⁻²⁵ come from using mₑ = 9.11 × 10⁻³¹ kg and e = 1.602 × 10⁻¹⁹ C)
11. Q14. An electron and a proton have equal de Broglie wavelengths. Ratio of (i) momenta, (ii) kinetic energies?
Answer: 1; 1836 (electron : proton)
12. Q15. Two particles have the same λ; one moves four times as fast. The slower is an α-particle. What can the other be?
Answer: A proton or a neutron
13. Q16. Speed of a proton with de Broglie wavelength 0.08 Å?
Answer: ≈ 4.96 × 10⁴ m s⁻¹ (49.6 × 10³ m s⁻¹)
14. Q17. Reactor neutrons have energy 5 × 10⁻²¹ J. Find speed and wavelength.
Answer: 2.447 × 10³ m s⁻¹; 1.622 Å
15. Q18. Ratio λ_e/λ_p when the electron and proton have the same (a) speed, (b) energy, (c) momentum. Which is longer?
Answer: (a) 1836, electron; (b) 42.85, electron; (c) 1, equal
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A photocell for automatic street lights must work with visible light. Its cathode should be…
Answer: C. Lowest work function (2.3 eV).
2. With polychromatic light, the stopping potential is set by the…
Answer: B. The most energetic photons decide KE_max.
3. At equal kinetic energy, the longest de Broglie wavelength belongs to the…
Answer: D. λ = h/√(2mK); smallest mass.
4. Red and blue sources of equal power emit N_red and N_blue photons per second. Then…
Answer: C. Red photons carry less energy, so more are needed.
5. E = pc is valid…
Answer: D. Only massless particles obey E = pc.
6. Doubling the intensity of light (same frequency) on a photocell…
Answer: A. More photons, same energy each.
7. The work function of a metal with λ₀ = 620 nm is about…
Answer: A. 1240/620.
8. The slope of the stopping potential versus frequency graph is…
Answer: B. From eV₀ = hν − φ₀.
9. Energy of a photon of frequency 5 × 10¹⁴ Hz is about…
Answer: C. hν = 3.32 × 10⁻¹⁹ J.
10. An electron accelerated through 54 V has a de Broglie wavelength of about…
Answer: A. 1.227/√54.
11. The Davisson–Germer experiment demonstrated…
Answer: B. Electron diffraction.
12. If the frequency of light is below threshold, increasing intensity…
Answer: C. Each photon has too little energy.
13. Electron and proton have the same de Broglie wavelength. Their momenta are…
Answer: D. p = h/λ.
14. Which property of light needs the wave model?
Answer: A. Superposition of waves.
15. The photoelectric effect shows that light energy is…
Answer: B. Einstein’s photon picture.
