Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 131–157
When two waves meet, their displacements simply add. That one idea — the principle of superposition — explains echoes from a fixed or free end, the standing waves on a guitar string and inside a flute, the harmonics that give each instrument its sound, the throbbing 'beats' between two nearly equal notes, and how a sonometer tests the laws of vibrating strings. This chapter builds the progressive-wave equation, reflection, stationary waves, vibrations of air columns and strings, end correction, beats and the characteristics of musical sound, and solves every exercise.
A progressive wave carries energy from place to place without carrying the medium along; each particle performs S.H.M. about its mean position. A wave moving along +x is y = A sin(ωt − kx) = A sin 2π(t/T − x/λ), with k = 2π/λ, ω = 2πn and v = nλ. Reflection from a denser medium (a rigid end) reverses the phase by π; reflection from a rarer medium (a free end) does not.
Superposition: the resultant displacement at any point is the algebraic (vector) sum of the separate displacements. Two waves of the same frequency with phase difference φ give a resultant amplitude R = √(A₁² + A₂² + 2A₁A₂ cos φ) — largest (A₁ + A₂) for φ = 0, 2π…, smallest |A₁ − A₂| for φ = π, 3π…
Two identical waves travelling in opposite directions form a stationary wave y = 2a cos(2πx/λ) sin(2πnt). Nodes (zero amplitude) and antinodes (maximum amplitude 2a) alternate; neighbouring nodes are λ/2 apart, a node and the next antinode λ/4. No energy is carried along a stationary wave.
Air columns: a pipe closed at one end has a node at the closed end and an antinode near the open end, so only odd harmonics occur, n_p = (2p − 1)v/4L. A pipe open at both ends has antinodes at both ends and gives all harmonics, n_p = pv/2L. The antinode forms slightly outside the open end; the end correction is e ≈ 0.3d. A string fixed at both ends gives all harmonics, n_p = (p/2L)√(T/m).
Laws of a vibrating string (n ∝ 1/L, n ∝ √T, n ∝ 1/√m) are verified with a sonometer. Two sounds of nearly equal frequencies produce beats — waxing and waning of loudness — at a rate n₁ − n₂, used to find an unknown frequency and to tune instruments. Musical sound is described by pitch (frequency), loudness (intensity) and quality or timbre (the mix of overtones).
Get a ✓ Verified tutor for “Superposition of Waves” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A wave is given by y = 0.05 sin(40πt − 0.5πx) in SI units. Find the amplitude, frequency, wavelength and speed.
Answer: A = 5 cm, n = 20 Hz, λ = 4 m, v = 80 m/s.
Two waves of amplitudes 4 mm and 3 mm with the same frequency meet with a phase difference of 60°. Find the resultant amplitude.
Answer: About 6.1 mm.
In a standing wave on a string, adjacent nodes are 12 cm apart and the frequency is 250 Hz. Find the wavelength and wave speed.
Answer: λ = 0.24 m; v = 60 m/s.
A pipe 34 cm long, closed at one end, has inner diameter 4 cm. Find its fundamental frequency with end correction (v = 340 m/s).
Answer: About 241 Hz.
A sonometer wire 60 cm long under tension 90 N has linear density 4 × 10⁻⁴ kg/m. Find its fundamental frequency and second harmonic.
Answer: ≈ 395 Hz and 790 Hz.
A fork of unknown frequency gives 5 beats/s with a 256 Hz fork. When the unknown fork is loaded with wax, the beats become 3 per second. Find its original frequency.
Answer: 261 Hz.
| Quantity | Formula | Note |
|---|---|---|
| Progressive wave | y = A sin(ωt − kx) = A sin 2π(t/T − x/λ) | +x direction |
| Wave speed | v = nλ = ω/k | m s⁻¹ |
| Phase difference | Δφ = 2πΔx/λ = 2πΔt/T | rad |
| Resultant amplitude | R² = A₁² + A₂² + 2A₁A₂ cos φ | superposition |
| Stationary wave | y = 2a cos(2πx/λ) sin(2πnt) | nodes λ/2 apart |
| Closed pipe | n = (2p − 1)v/4L | odd harmonics only |
| Open pipe | n = pv/2L | all harmonics |
| End correction | e = 0.3d | closed l + e, open l + 2e |
| Resonance tube | e = (l₂ − 3l₁)/2; v = 2n(l₂ − l₁) | two resonating lengths |
| String speed | v = √(T/m) | m = mass per unit length |
| Vibrating string | n = (p/2L)√(T/m) | both ends fixed |
| Beats | beat frequency = n₁ − n₂ | < ~10 s⁻¹ audible |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Choose the correct option: (i) closed pipe with three nodes; (ii) open pipes 50 cm and 51 cm, 7 beats/s — speed of sound; (iii) tension up 25% — new frequency ratio; (iv) wave travelling along the y-axis; (v) string fixed at one end, free at the other — length condition.
Answer: (i) D 5; (ii) D 357 m/s; (iii) B 1.12; (iv) A; (v) A.
2. Q2 Answer in brief: (i) Direction of y = A sin(Bx + Ct)? (ii) Fundamental mode of a string fixed at both ends — any other point that can be touched? For the first and second overtones? (iii) What are harmonics and overtones? (iv) Ratio of fundamental to second harmonic for a string fixed at both ends? (v) For y = 0.2 sin 4π(t/0.08 − x/0.8), find λ, n and amplitude.
Answer: (i) −x; (ii) none / L/2 / L/3 and 2L/3; (iv) 1 : 2; (v) 0.4 m, 25 Hz, 0.2 m.
3. Q3 & Q4 State the characteristics of (a) progressive waves (b) stationary waves.
Answer: See steps.
4. Q5 & Q6 Derive the equation of a stationary wave on a stretched string, and find the resultant amplitude of y₁ = A₁ sin ωt and y₂ = A₂ sin(ωt + φ).
Answer: y = 2a cos(2πx/λ) sin(2πnt); R = √(A₁² + A₂² + 2A₁A₂ cos φ).
5. Q7–Q9 State the laws of vibrating strings and their sonometer verification; show only odd harmonics occur in a closed pipe and all harmonics in an open pipe.
Answer: See steps.
6. Q10 A 500 Hz wave travels at 350 m/s. (a) Phase difference at a point between times 1.0 ms apart? (b) Smallest distance between points 45° out of phase?
Answer: π rad; 8.75 cm.
7. Q11 Successive nodes of a standing sound wave are 3.75 cm apart; v = 1500 m/s. Find the frequency.
Answer: 20 kHz.
8. Q12 Two sources 4 m apart, 330 Hz, equal amplitude, 180° out of phase (v = 330 m/s). Where between them is the intensity maximum?
Answer: ±0.25, ±0.75, ±1.25 and ±1.75 m from the centre.
9. Q13 Two in-phase 540 Hz sources, v = 330 m/s. Phase difference at a point 3.5 m from one and 3 m from the other?
Answer: 1.636π rad.
10. Q14 Same wires on a sonometer loaded with 1.5 kg and 6 kg; first wire 60 cm long. Same fundamental — length of the second?
Answer: 1.2 m.
11. Q15 A closed pipe gives overtones at 640, 896 and 1152 Hz. Find its fundamental.
Answer: 128 Hz.
12. Q16 Open tube, fundamental 300 Hz, v = 340 m/s. Find its length.
Answer: ≈ 0.5667 m.
13. Q17 Open pipe 25 cm long, v = 330 m/s: fundamental, first and second overtones.
Answer: 660 Hz, 1320 Hz, 1980 Hz.
14. Q18 An open pipe has fundamental 600 Hz; the first overtone of a closed pipe equals the first overtone of the open pipe (v = 330 m/s). Find both lengths.
Answer: 27.5 cm and 20.625 cm.
15. Q19 A 1 m string fixed at one end, driven at 15 Hz at the free end, shows four complete loops. Find the wave speed.
Answer: ≈ 6.67 m/s.
16. Q20 Violin string fundamental 440 Hz: first and second overtones?
Answer: 880 Hz and 1320 Hz.
17. Q21 Eight forks in rising order, each giving 4 beats/s with the next; the last is twice the first. Find the first and last frequencies.
Answer: 28 Hz and 56 Hz.
18. Q22 A sonometer wire at 40 N is in unison with a 384 Hz fork. Beats in 2 s if the tension falls by 1.24 N?
Answer: 12 beats.
19. Q23 Sonometer wire 0.5 m, load 5 kg, fundamental 100 Hz. Find the linear density (g = 9.8 m/s²).
Answer: 4.9 × 10⁻³ kg/m.
20. Q24 A guitar string 80 cm long has fundamental 112 Hz. Where should it be pressed to get 160 Hz?
Answer: So that the vibrating length is 56 cm (press 24 cm from the other end).
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A closed pipe vibrates with three nodes. Its frequency is … times the fundamental.
Answer: A. Three nodes → L = 5λ/4, the 5th harmonic.
2. Open pipes 50 cm and 51 cm give 7 beats/s. The speed of sound is
Answer: B. v/1.00 − v/1.02 = 7 → v = 357 m/s.
3. Tension in a piano wire is raised by 25%. The frequency becomes … times.
Answer: C. √1.25 ≈ 1.118.
4. Which represents a wave travelling along the y-axis?
Answer: C. The phase contains y and t together; C and D are stationary.
5. A string fixed at one end and free at the other has a length that is
Answer: C. Node at one end, antinode at the other.
6. y = A sin(Bx + Ct) with positive constants travels
Answer: D. Plus sign between kx and ωt.
7. Distance between a node and the adjacent antinode is
Answer: B. Half the node-to-node distance.
8. The fundamental of an open pipe compared with a closed pipe of the same length is
Answer: A. v/2L vs v/4L.
9. A closed pipe gives overtones 640, 896 and 1152 Hz. Its fundamental is
Answer: D. Odd harmonics differ by 2n = 256 Hz.
10. Wave speed on a string depends on
Answer: A. v = √(T/m).
11. If the length of a sonometer wire is halved, its frequency
Answer: A. n ∝ 1/L.
12. End correction of a pipe with inner diameter 5 cm is about
Answer: A. e = 0.3 × 5.
13. Two forks of 300 Hz and 305 Hz sounded together give
Answer: D. Beat frequency = difference.
14. Filing the prongs of a tuning fork
Answer: B. It reduces the mass of the prongs.
15. Two instruments play the same note but sound different because of
Answer: C. Timbre depends on overtone content.
