Textbook: Physics – Class 12 (Balbharati, official free PDF) · pages 186–213
Electrostatics is the physics of charges at rest. This chapter uses Gauss' law to find fields of a charged sphere, a long charged wire and a charged sheet; defines electric potential and potential energy for point charges, dipoles and systems of charges; explains equipotential surfaces, conductors, electrostatic shielding, dielectrics and polarisation; and then treats capacitors — combinations, the parallel plate capacitor with and without dielectric slabs, displacement current, the energy stored — ending with the Van de Graaff generator. Every exercise question is solved at the end.
Gauss' law, Φ = ∮E·dA = q/ε₀, gives quick results for symmetric charges: a charged spherical shell acts outside like a point charge at its centre (E = q/(4πε₀r²)) and has zero field inside; an infinite line charge gives E = λ/(2πε₀r); an infinite plane sheet gives E = σ/(2ε₀), the same at every distance.
Electric potential at a point is the work done per unit positive charge in bringing it from infinity: V = q/(4πε₀r) for a point charge, a scalar measured in volt (J C⁻¹). E = −dV/dr, so the field points towards decreasing potential. A dipole gives V = p cos θ/(4πε₀r²) — zero everywhere on its equatorial plane. Equipotential surfaces are always perpendicular to field lines and no work is done in moving a charge along one.
The potential energy of a system of point charges is the sum over all pairs of q_iq_j/(4πε₀r_ij). A dipole in a uniform field has U = −pE cos θ and feels torque τ = pE sin θ. Inside a conductor in electrostatics E = 0 and all excess charge sits on the outer surface; a hollow conductor shields its interior (electrostatic shielding).
A dielectric placed in a field becomes polarised; its induced surface charges set up an opposing field, so the net field drops by the dielectric constant k = ε/ε₀ = 1 + χ_e. A capacitor stores charge: C = Q/V (farad). Parallel plate: C = ε₀A/d, or kε₀A/d when filled with a dielectric, or ε₀A/(d − t + t/k) with a slab of thickness t. Series: 1/C = Σ1/C_i; parallel: C = ΣC_i. Spherical: C = 4πε₀ab/(b − a).
Energy stored U = ½CV² = Q²/2C = ½QV resides in the field, with energy density ½ε₀E². While charging through a battery, the same amount ½QV is lost as heat. A changing electric field between capacitor plates acts like a current — Maxwell's displacement current i_d = ε₀ dΦ_E/dt. The Van de Graaff generator uses corona discharge and the fact that charge on a hollow conductor goes to its outer surface to build up potentials of millions of volts.
Get a ✓ Verified tutor for “Electrostatics” — live online or at home. We aim to suggest up to 3 tutors within 24 hours.
A long straight wire carries 3.0 μC per metre. Find the electric field 15 cm from it.
Answer: 3.6 × 10⁵ N/C.
Charges +4 nC and −2 nC are 0.6 m apart. Find the potential at the midpoint and the point on the line (between them) where V = 0.
Answer: 60 V at the midpoint; V = 0 at 0.4 m from the +4 nC charge.
A dipole of moment 4 × 10⁻⁹ C m is at 30° to a uniform field of 2 × 10⁴ N/C. Find the torque and the work needed to turn it to 90°.
Answer: τ = 4 × 10⁻⁵ N m; W ≈ 6.9 × 10⁻⁵ J.
A parallel plate capacitor has field 6 × 10⁵ V/m in air. A dielectric with χ_e = 2 fills it with the charge held fixed. Find k and the new field.
Answer: k = 3; E = 2 × 10⁵ V/m.
Capacitors of 2 μF, 3 μF and 6 μF are joined in series across 12 V. Find the equivalent capacitance, the charge and the voltage on the 2 μF capacitor.
Answer: 1 μF; 12 μC; 6 V.
A 10 μF capacitor charged to 200 V is connected to an uncharged 10 μF capacitor. Find the energy before and after, and the loss.
Answer: 0.2 J → 0.1 J; 0.1 J lost (half).
| Quantity | Formula | Note |
|---|---|---|
| Gauss' law | ∮E·dA = q/ε₀ | closed surface |
| Charged shell | E = q/(4πε₀r²) outside; 0 inside | σ/ε₀ at surface |
| Line charge | E = λ/(2πε₀r) | infinitely long wire |
| Plane sheet | E = σ/(2ε₀) | independent of distance |
| Point-charge potential | V = q/(4πε₀r) | volt |
| Dipole potential | V = p cos θ/(4πε₀r²) | 0 on equatorial plane |
| Field and potential | E = −dV/dr | V m⁻¹ |
| Dipole in field | τ = pE sin θ; U = −pE cos θ | uniform field |
| Parallel plate capacitor | C = kε₀A/d | farad |
| Dielectric slab | C = ε₀A/(d − t + t/k) | metal: ε₀A/(d − t) |
| Combinations | 1/C_s = Σ1/C_i; C_p = ΣC_i | series / parallel |
| Energy stored | U = ½CV² = Q²/2C; u = ½ε₀E² | joule |
Solve each one in your notebook first. Then open the solution and compare every step.
1. Q1 Choose the correct option: (i) isolated capacitor, gap increased — Q, V, C; (ii) slab of thickness 3d/4; (iii) energy stored : dissipated on charging; (iv) work moving +Q from C (midpoint of +q at A and −q at B, AB = 2L) along the semicircle to D (L beyond B); (v) circular plates radius 8 cm, gap 1 mm, 100 V — charge.
Answer: (i) D; (ii) D; (iii) A 1 : 1; (iv) A −qQ/(6πε₀L); (v) A 1.78 × 10⁻⁸ C.
2. Q2 Answer in brief: (i) Work in moving q from A above a dipole to B below it, both on the equatorial line? (ii) Effect of increasing the radius difference of a spherical capacitor? (iii) Effect of introducing a metal plate between the plates? (iv) Why is a car the safest place in lightning? (v) Work done by electric forces when a charged shell (charge Q) expands from radius b to a?
Answer: (i) 0; (ii) decreases; (iii) increases; (v) (Q²/8πε₀)(1/b − 1/a).
3. Q3 A dipole (−q at (0, −b, 0), +q at (0, b, 0)) is in a uniform field E whose equipotentials are planes parallel to the YZ plane. (a) Direction of E? (b) Torque on the dipole?
Answer: (a) Along the X axis; (b) τ = 2bqE.
4. Q4 Charges −q, +Q, −q at equal spacing r on a line; the system's PE is zero. Find Q : q.
Answer: Q : q = 1 : 4.
5. Q5 A capacitor with a dielectric is charged, the battery disconnected, then the dielectric removed. How do C, U, E, Q and V change?
Answer: C decreases; U, E and V increase; Q constant.
6. Q6 C₁ : C₂ = 1 : 2. Ratio of voltages across the parallel and series combinations for equal stored energy.
Answer: V_p : V_s = √2 : 3.
7. Q7 Charges −4Q at (2a, 0) and +2Q at (5a, 0). Electric flux through a sphere of radius 4a centred at the origin?
Answer: Φ = −4Q/ε₀.
8. Q8 A 6 μF capacitor charged to 300 V is connected to an uncharged 3 μF capacitor. Energy lost?
Answer: 9 × 10⁻² J.
9. Q9 125 drops (each 0.5 μC, diameter 0.1 m) merge. Potential at the surface of the big drop?
Answer: 2.25 × 10⁶ V.
10. Q10 10²¹ water molecules (p = 6.3 × 10⁻³⁰ C m) aligned in E = 2.5 × 10⁵ N/C. Work to turn them all to 90°?
Answer: 1.575 × 10⁻³ J.
11. Q11 6 μC at the origin and −5 μC at A(0, 6) m. (a) Potential at P(8, 0) m. (b) Work to bring a proton from infinity to P; meaning of the sign.
Answer: (a) 2.25 × 10³ V; (b) 3.6 × 10⁻¹⁶ J, done by the external agent.
12. Q12 Air capacitor: A = 6 × 10⁻³ m², d = 2 mm. (a) C (b) charge at 100 V (c) charge after inserting a 2 mm mica sheet (k = 6) with the supply connected.
Answer: (a) 2.655 × 10⁻¹¹ F; (b) 2.655 × 10⁻⁹ C; (c) 15.93 × 10⁻⁹ C (charge rises six-fold).
13. Q13 Equivalent capacitance between P and Q: (a) three layers k = 1, 3, 6, each d/3 thick, full area A; (b) left half (A/2) filled with k = 4 over the full gap d, right half (A/2) with k = 3 and k = 6 layers each d/2.
Answer: (a) 2Aε₀/d; (b) 4Aε₀/d.
Read the question, answer it in your head, then tap the card to check. 20 cards.
15 questions. Tap an option — you will see at once if it is right and why.
1. A charged capacitor is isolated and its plate gap increased. Q, V and C respectively
Answer: B. C = ε₀A/d falls; V = Q/C rises.
2. A slab of thickness 3d/4 and constant k fills the plate area. New capacitance is
Answer: C. d − t + t/k = d(k + 3)/(4k).
3. Energy stored and energy dissipated while charging a capacitor are in the ratio
Answer: A. Each is ½QV.
4. Circular plates radius 8 cm, gap 1 mm, 100 V. The charge is about
Answer: D. C = ε₀πr²/d ≈ 1.78 × 10⁻¹⁰ F.
5. Work done moving a charge between two points on a dipole's equatorial plane is
Answer: B. V = 0 on the equatorial plane.
6. The field outside a charged spherical shell at distance r from its centre varies as
Answer: B. Like a point charge.
7. Electric field of an infinite plane sheet of charge
Answer: D. E = σ/(2ε₀).
8. Flux through a closed surface depends on
Answer: A. Gauss' law.
9. Equipotential surfaces of a point charge are
Answer: A. V depends only on r.
10. A dipole is in stable equilibrium when the angle between p and E is
Answer: A. U = −pE is minimum.
11. Inside a hollow charged conductor the electric field is
Answer: D. Electrostatic shielding.
12. Capacitors 3 μF and 6 μF in series give
Answer: B. 18/9 = 2 μF.
13. A battery stays connected while a dielectric k is inserted. The charge
Answer: A. V fixed, C rises by k.
14. Energy density of an electric field E in vacuum is
Answer: B. u = ½ε₀E².
15. Increasing the gap between the spheres of a spherical capacitor makes its capacitance
Answer: C. C = 4πε₀ab/(b − a).
